Electrical Equipment & Systems

Gas-Insulated Switchgear utilizes eco-efficient gas.
Switchgear

Gas-Insulated Switchgear utilizes eco-efficient gas.

Offering alternative to widely used greenhouse gas sulfur hexafluoride (SF6), AirPlus™ uses fluoroketone based gas mixture as insulation medium for medium- and high-voltage switchgear applications. Global warming potential of chemical compound is almost 10% lower than that of SF6, without any compromise on equipment quality and reliability.

Read More »
Ultra-Miniature Connector supports 10 Gbps data transfer.
Electrical Connectors

Ultra-Miniature Connector supports 10 Gbps data transfer.

Suitable for use in harsh environments, MiniMax 06 Connector can include up to 12 power and signal contacts in 10 mm footprint. Unit also offers configuration with 2 signal and 2 high-power 1.3 mm contacts for applications needing 10 A or more. Featuring IP68 sealing when mated and unmated, MiniMax 06 is available with 3 locking systems, including push-pull, screw, and quick-release. Connector...

Read More »
Bicycle Shelters

Slim, Lockable Shelter protects bikes from weather, theft.

Tailored to situational requirements, fully enclosed and locking Bike Garage™ stores up to 9 bikes by staggering them vertically on MaxRack hangers. Structure is anodized aluminum with translucent polycarbonate panels on 3 sides, steel garage door rolls up and down and tucks under roof, and steel hasp riveted to door accepts padlocks. At 4 ft 8 in.Â- deep and 13 ft 1 in. wide,...

Read More »
Testers

Stahlin J, CF, and F Series Non-Metallic Enclosures Pass UL 2043 Fire Test for Air Handling Spaces

On March 17, 2016, Stahlin Non-Metallic Enclosures provided the UL lab at the Northbrook testing facility with samples of the J, CF, and F Series. All three series were subjected to the same flame test described in UL Standard 2043, Fourth Edition. Each of the Stahlin Non-Metallic enclosures product specimens tested MET all three requirements, which are: a)Â- Ã‚  The peak rate of heat...

Read More »
Mechanical Wire, Cable and Rope

LEMO and Northwire Feature Fully Integrated Medical Cable and Connector Solution

New Medical Technologies Showcased at Medtec 2016 Present LEMO’s Redel SP Connector and Northwire’s BioCompatic Cable OSCEOLA, WI. – Custom cable assemblies for the life sciences engineered by cable manufacturer, Northwire, Inc., (NWI) and precision cable connector leader LEMOÂ- were featured among Medtec’s most recent innovations and technology within medical device design and...

Read More »
Electrical Boxes

Explosion Proof Junction Box features global approvals.

Constructed of 316 stainless steel, Explosion Proof Junction Box is available assembled with company's stainless steel product lines such as dual seal certified, explosion proof 12 Series pressure and temperature switches as well as hermetically sealed TX200 pressure transmitters. Option M432 has Â-½ in. NPT threads, while option M433 has M20 threads. Also available for separate purchase...

Read More »
Single Gang Floor Box installs flush in wood subfloors.
Electrical Connectors

Single Gang Floor Box installs flush in wood subfloors.

Offering drop-in installation with any floor covering, Steel City® Residential Floor Box is available as complete kit for new- and old-workÂ- installations, providing solution for power, voice, or data connections in open-space areas. Unit features metallic outlet box with ½ in. knockouts, pry-outs, and integral cable clamps for NM sheathed cable; stamped, one-piece brass cover...

Read More »
Dry-Type Condenser Bushings target power transformers.
Electrical Bushings

Dry-Type Condenser Bushings target power transformers.

Available in voltage classes ranging from 25–138 kV, O Plus Dry™ Bushings incorporate resin impregnated synthetic condenser body and high temperature vulcanized silicon weather shed. Design eliminates potential leaks of oil-filled bushings and porcelain shards from fragile porcelain insulators. Use of HTV weather sheds also minimizes need for cleaning in highly contaminated environments and...

Read More »
Underground Distribution Switchgear suits large urban areas.
Switchgear

Underground Distribution Switchgear suits large urban areas.

Incorporating 40 kA load-break switches, Vista® Underground Distribution Switchgear is available for 15 kV systems, offering utilities fully submersible switching solution for underground distribution networks. Instead of using oil, solution uses gas sealed in completely submersible stainless steel tank. Submersibility is essential given that in urban networks, switchgear is frequently...

Read More »
Micro-Power Buck Converters (65 V) feature low quiescent current.
Power Supplies

Micro-Power Buck Converters (65 V) feature low quiescent current.

Respectively intended for powering factory automation and automotive sensor applications, LM5165 and LM5165-Q1 are 65 V, 150 mA synchronous DC/DC buck converters thatÂ- feature 10.5 µA quiescent current and 10-pin, 3 x 3 mm VSON package. Input voltage range of 3–65 V and dual control modes optimize efficiency and PCB area. Other features include dual MOSFETs, PFM and COT control...

Read More »
