DC/DC Converter suits xDSL applications.
Open-frame, isolated 7W Model ASDH-WS12 is fully approved for EN60950 and UL1950 SELV safety standards. It offers input range of 36-130 Vdc and provides single output of 12 Vdc at 0.5 A, nominal. Integral, finned heatsink permits operation over temperature range of -40 to +85Ã-
Read More »
Converter provides low voltage inputs for ASICs and DSPs.
Model WPA60 DC-DC converter meets EN60950, UL60950, and CSA safety requirements. Two independently regulated outputs deliver 1.8 and 3.3 V, respectively, and provide full regulation down to zero load. Power can be traded between outputs up to 60 W. Input voltage range is 36 to 75 V and includes input and output filtering. Using fixed switching frequency of 350 kHz, WPA60 operates at 90%...
Read More »
DC/DC Converters feature high-voltage isolation.
With efficiencies up to 82%, V3 Series 2 W converters are supplied in subminiature SIP and DIP packages with isolation voltages or 1,000 or 3,000 Vdc. Input voltages include 5, 12, 24, and 48 Vdc, while single-output voltages range from 3.3-24 Vdc. All isolated outputs are regulated, and no heat sinks are required. Operating temperature range is -40 to +85 Ã-
Read More »
Point-of-Load Converter provides all-in-one power solution.
Dual-output, non-isolated, point-of-load (POL) converter for DDR (double data rate) memory, DDR12, enables 2.5 V VDDQ supply for DDR logic and 1.25 V DDR termination voltage (VTT) to be derived from single module. Unit employs synchronous rectification techniques and has 85% conversion efficiency when operated at half-load or greater. The 2.5 V VDDQ output delivers up to 25 A, and 1.25 V VTT...
Read More »
Setting Yourself Up for Sales Success
This ebook provides tips on creating and implementing best practice front-end sales processes.
Read More »
DC-DC Converters feature miniature DIP package.
Fully encapsulated Series SB05 provides output power of 5 W. Converters accept single-range and 2:1 wide range inputs from 9-75 Vdc, and provide single and dual outputs from 3.3-24 Vdc. All contain short circuit protection, internal input filter, and 1600 V input-to-output isolation. They operate over temperature range of -25 to +71Ã-
Read More »
Isolated DC-DC Converters suit rack-mounted applications.
Series NTH 2 W, dual output, surface mount converters are 5.5 mm high with mounting footprint of 0.49 inÃ-². Input voltages of either 5 or 12 V and dual isolated options of 5, 9, 12, or 15 V are available. Isolation between input and output is 1 kVdc. Converters operate with efficiencies up to 84% and have total power density of 25.67 W/inÃ-³. Operating temperature is -40 to +85Ã-
Read More »
DC-DC Converter provides 88% efficiency.
Dual-output, quarter-brick Series ALQ15 offers output voltages of 3.3/2.5, 3.3/1.8, and 2.5/1.5 V. Rated to deliver up to 15 A from either output, series provides a full 60 W of clean, regulated, low-noise DC power. Unit can start up into high-capacitance loads of up to 10,000 microFarads per output. Features include over-temperature, over-current, and over-voltage protection. Input voltage range...
Read More »
Converters provide 95% efficiency.
Non-isolated, point-of-load (POL), 10 A DC/DC Series SIL10, for use with 3.3 and 5.0 V on-board bus levels, employs synchronous-buck topology, using fixed-frequency switching and low on-resistance MOSFETs. Power density is 107 W/in3. Fixed-output converter provides 8 voltages from 0.8 to 3.3 V, and accommodates input voltage of 3.0 to 5.5 V. Wide-output trim model requires 4.5 to 5.5 V input....
Read More »
Converter offers low profile with standard pin out.
PowerQorÃ-® Mega series eighth-brick sized isolated dc/dc converter delivers up to 15 A total output current at 3.3 V and below and 50 W at 5 V and above, without heatsink. The EML series has 48 V nominal input (35-75 V range) and meets input voltage transient requirements up to 100 V for 100 msec. Unit measures 0.9 x 2.3 x 0.37 in., occupies 60% of board space of standard quarter-brick, and...
Read More »
DC-DC Converter extends battery life in portable applications.
Inductorless, 100 mA FAN5660 converter achieves over 90% efficiency at full load with typical operating current of 120 Ã-µA. It inverts +l.5 V to +5.5 V input to corresponding -l.5 V to -5.5 V output. Unit can also split or double full load, +5.0V input voltage, of power supply or battery, providing +2.25 V in splitter mode and +9.5 V in doubler mode. Equipped with onboard oscillator circuit,...
Read More »
