SWM24 Stepper Motors feature torque ripple smoothing.

November 23, 2016

Featuring Modbus/RTU for easy communication with PLC or HMI, IP65 rated SWM24 Stepper Motors offers RS-232, Ethernet and EtherNet/IP Communication options. With built-in incremental encode, motor offers command control modes for Step direction, velocity and streaming. Fusing high torque NEMA 24 frames step motor with sophisticated, 6.0 A/phase (peak-of-sine) step motor drive into single dustproof device, unit requires 24 and 48 volt DC power supplies.

Read More

Mechanical Power Transmission

DC022C DC Series Motor features neodymium stator.

November 18, 2016

Available in 22-mm diameter in three lengths, DC022C DC Series Motor delivers 0.0056 to 0.141 Nm output torque. Designed with 2-pole stator with neodymium magnets, 5-slot skewed rotor and sintered bronze bearings, unit is suitable for lab automation, medical devices, communications equipment. Constituting ball bearings, copper graphite brushes and RFI suppression, motor features speeds up to 10,000 RPM and DC bus voltages up to 36 Vdc.

Read More

Mechanical Power Transmission

Can Stack Linear Actuators offer max holding force of 50 N.

October 19, 2016

Featuring 7.5° step angle that provides fine incremental movement, 20 mm Series 20DBM is suitable for electronic pipettes, medical and non-medical analyzers, XY stages, and valve actuators. Customizable linear stepper motors are powered by high-energy neodymium magnets, optimized electromagnetic circuit, and bearing preload design. RoHS compliant products are available in Captive and Non-Captive versions with various leadscrew pitch options. Read More

Mechanical Power Transmission

Brushless Motors range in torque from 0.04 to 8.5 Nm.

October 18, 2016

With torque from 6–600 oz-in. and speeds from 40–4,500 rpm, 44 mm Series EC044A is available in range of lengths and windings to accommodate application requirements. Series EC042B, measuring 42 mm in diameter, delivers 9–1,200 oz-in. of torque and speeds from 40–4,500 rpm. Both are equipped with E30 encoder and PLG42S planetary gear. Stock gear ratios range from 4–100:1, with optional ratios to 512:1 yielding 14 Nm of output. Read More

Mechanical Power Transmission

Miniature Linear Voice Coil Motor has high force to size ratio.

October 17, 2016

Along with 14.5 oz continuous force and 45.7 oz peak force, 0.875 in. dia x 0.50 in. long LVCM-022-013-01 offers zero cogging, 0.25 in. stroke length, and precision drilled and tapped 4-40 UNC-2B mounting holes. This clean, quiet, low-inertia, high-acceleration, high-speed motor delivers repeatability to <0.00004 in. when operated in closed loop as DC servo motor. Uses include pick-and-place, testing, laser steering, mirror positioning, scanning, oscillation, and switching applications. Read More

Mechanical Power Transmission

High-Speed Brushless Motor suits medical devices/equipment.

October 6, 2016

Designed primarily for medical ventilator and respirator use, ResMax 28 achieves speeds up to 90,000 rpm with dynamic responsiveness of 0–50,000 rpm in 20 ms (unloaded). Operating life is 30,000+ hr at 40,000 rpm (average speed), and maximum efficiency is 90%. Along with rated power of 46 W, these 28 mm, 24 V motors feature integrated Hall-effect sensors that provide commutation information and NTC thermal sensor that monitors motor temperature. Balancing minimizes audible noise/vibration. Read More

Mechanical Power Transmission

Torque Motors target direct drive applications.

September 19, 2016

With 200 mm active length for each diameter, TMB+ series includes 62 standard model sizes with four different windings each. These motors, compatible with most CNC controllers, achieve peak torque of up to 42,900 Nm and utilize flux weakening to increase speed capabilities. Optional IMTHP thermal module provides users with precise and reliable temperature monitoring, while no backlash and zero maintenance requirements promote stable performance with smooth, precise, and efficient motions.

Read More

Mechanical Power Transmission

CM-ET Lodestar Classic Electric Chain Motor Now IP66 Rated

September 1, 2016

Legendary motor is ideal for use in outdoor environments and is designed for long service life GETZVILLE, N.Y. – As part of our dedication to providing customers with the best products and services in the industry, Columbus McKinnon Corporation (NASDAQ: CMCO), a leading designer, manufacturer and marketer of material handling products, systems and services, has made significant improvements...Read More

Controls & Controllers, Laboratory and Research Supplies & Equipment, Mechanical Power Transmission

HEIDENHAIN to Offer Daily Motion Control Presentations at IMTS Booth -See Schedule Online Here - http://www.heidenhain.us/wp-content/uploads/TakeTen.pdf

August 30, 2016

SCHAUMBURG, IL – Bringing its international expertise in the area of motion control to the International Manufacturing Technology Show (IMTS) in Chicago’s McCormick Place (Sept. 12 – 17), HEIDENHAIN CORPORATION will offer five different concise presentations covering the latest in manufacturing technology at their booth (#E-5226) each day of the show. Each presentation will last a maximum...Read More

Mechanical Power Transmission

High-Torque 17 mm Brush DC Motor has energy efficient design.

August 22, 2016

Featuring coreless design with optimized self-supporting coil and magnetic circuit, Athlonix™ 17DCT offers torque carrying capabilities up to 6.14 mNm and efficiency up to 85%. Torque per ampere performance promotes battery life, and constant force spring design for carbon brush provides consistent performance. This 17 mm dia motor is available in variations that include precious metal commutation and graphite commutation with neodymium magnet inside. Read More

Mechanical Power Transmission, Transportation Industry Products

Solar Impulse 2 Finishes Flight with ETEL's Proud Assistance

August 11, 2016

SCHAUMBURG, IL – Recently the Solar Impulse 2 airplane finished its flight around the globe, with airtime lasting over 500 hours and is the first plane to do so relying entirely on Solar Energy. With an ETEL motor inside, the Solar Impulse 2 successfully started in Abu Dhabi and flew across Asia, the Pacific Ocean, the United States, Atlantic Ocean, and Europe before heading right back where...Read More

Mechanical Power Transmission, Transportation Industry Products

Environmentally-friendly, Economical, Reliable and Simple: Parallel Hybrid Propulsion Offers Nothing But Advantages.

July 29, 2016

  • Environmentally-friendly, economical, reliable and simple: parallel hybrid propulsion offers nothing but advantages.
Electric propulsion generates no emissions and is extremely user-friendly: the vessels that use it are silent, experience much lower levels of vibration and are easier to handle. Last but not least in terms of its advantages: parallel hybrid represents an...Read More

Mechanical Power Transmission

Outboard Engines combine output power and regulation compliance.

June 29, 2016

Covering 150–200 hp range, Evinrude E-TEC G2 models 150, 150 HO, 175, and 200 are optimized for delivery of torque and fuel efficiency as well as regulated emissions reduction. Motors, available with integrated Dynamic Power Steering and i-Trim (intelligent trim system), promote handling confidence and performance at any speed or in any sea conditions, and steering mechanisms in mid-section simplifies rigging for clean transom. Pushbutton automatic winterization is also standard. Read More

Mechanical Power Transmission

Miniature Brush DC Motor features coreless design.

June 14, 2016

Measuring 16 mm in diameter, Athlonix™ 16DCP features energy-efficient coreless design with optimized self-supporting coil and magnetic circuit. Unit is available in precious metal and graphite commutation variations, both featuring Alnico magnet inside. Constant force spring design for carbon brush ensures consistent performance. With max continuous torque up to 2.63 mNm, motor is suited for medical and industrial pumps, gas analyzers, power tools, mesotherapy guns, and tattoo machines. Read More

Mechanical Power Transmission

Hybrid Motor exceeds NEMA Premium efficiency levels.

June 10, 2016

Utilizing hybrid motor design, RPM XE achieves efficiency performance 2–4 efficiency bands above NEMA Premium® efficient levels (IE3). Design specifically exceeds premium efficiency performance on sine wave power while meeting IE3 as combined motor and drive package. Along with technology that combines starting attributes of induction cage with permanent magnets, features include laminated finned frame construction. Available configurations include power dense and standard NEMA frame. Read More

Mechanical Power Transmission

Motor (600 rpm) serves low-speed direct drive applications.

June 6, 2016

Available from 0.75–3 hp, 600 rpm versions of PremiumPlus+® Electronically Commutated Permanent Magnet (ECPM) motors are suited for directly driving larger-diameter fans at low speeds. Geometry allows use of ferrite (versus rare earth) magnets, and overall design contributes to energy conservation by eliminating maintenance and efficiency losses associated with belts and pulleys. Read More

Mechanical Power Transmission

Miniature BLDC Motor balances high speed and high torque.

May 2, 2016

Available in 45 and 60 mm lengths with Hall sensors and 3 different coils to match speed and voltage requirements, Ultra EC™ model 22ECP utilizes Ultra coil technology for optimized torque and power density from low to high speed. This brushless slotless 2-pole mini motor, suitable for medical and industrial markets, supports customization via gearbox, encoder, coil, and mechanical interface options. Read More

Mechanical Power Transmission

Heavy-Duty Hydraulic Motors have interchangeable design.

April 26, 2016

Adapting Geroler gear set design with high-speed distribution of flow and high pressure, bidirectional 500-Series suits for low-speed, high-pressure applications with smooth rotation throughout speed transitions. Available shafts, mounts, and displacements – 125, 160, 200, 230, 250, 300, 350, 375, 475, 540, and 750 – allow motors to be configured to application requirements. These high-torque motors are interchangeable with such brands as Charlynn, White, Ross, Parker, and Danfoss. Read More

Mechanical Power Transmission

WEG and Alpha Electrics to supply Grange Resources Mill Motor

April 18, 2016

WEG Australia, through its local business partner Alpha Electrics (Tasmania), has successfully won the tender for Grange Resources, supplying two synchronous mill motors (frame size 1400). Facilitated by the ongoing business relationship between Alpha Electrics and Grange Resources and bolstered by the long standing supply and service history that Alpha Electrics has with WEG Australia, WEG...Read More

Mechanical Power Transmission

Brush DC Motor carries up to 14.96 mNm torque.

April 8, 2016

Featuring coreless design with self-supporting coil and magnetic circuit in 24 mm diameter size, Athlonix™ 24DCT provides efficiency reaching up to 90%. Miniature DC motor is available in 2 variations: precious metal commutation and graphite commutation with Neo magnet inside. Product is suited for battery-driven applications such as medical and industrial pumps, drug delivery systems, robotic systems, miniature industrial power tools, tattoo machines, and dental tools. Read More
