Physik Instrumente (PI)    Auburn, MA 01501
Apr 13, 2007 Equipped with ultra low noise E-536 driver/controller, P-363 PicoCube® employs non-contact, direct-measuring, parallel-metrology capacitive sensors for position feedback. Piezeo drives allow for resonant frequency of 10 kHz, important for high-speed scanning applications. Housed in titanium case, scanner is vacuum compatible and suitable for AFM, SPM, nanomanipulation, bio-technology, nanotechnology, nano-imprint, semiconductor, and data storage test equipment.

McBain Instruments, Inc.    Chatsworth, CA 91311
Apr 03, 2007 Compatible with Class 1 cleanrooms, semi-automatic WL150 and WL200 Series handle 3-6 in. and 5-8 in. wafer sizes, respectively. Systems feature smart stepper motors for drive axis, stall and fault detection, linear stages for smooth action, and vacuum touch end effectors with sensing capabilities. Offering user-defined inspection positions, devices include intuitive HMI control box and numeric keypad, and VESA interface for integration with microscopes, optics and inspection devices.

Waytek Inc.    Chanhassen, MN 55317
Mar 27, 2007 Power Relay Module contains 2 female fuse positions and one sealed 70 A relay. While one fuse protects relay, other is single-circuit inline fuse. Module is available with or without output connector and works with JCASE cartridge style fuses. Also available, Power Fuse Module holds 2 fuses, each as separate circuits. Silicone seal and removable cover offer weather-tight enclosure for fuse positions.

Aries Electronics, Inc.    Bristol, PA 19007-6810
Mar 27, 2007 Designed for 24-, 28-, and 32-pin SOIC and SOJ devices, Correct-A-Chip Adapters are available on 0.400 in. and 0.600 in. centers with operating temperature up to 221°F. Each is constructed of 0.062 in. FR406 or IS410 per IPC4101A/26, with 1 oz of copper traces on both sides. Pins are 360-1/2 hard brass alloy with 10 µin. minimum gold plating over 100 µin. nickel plating. Suggested PCB hole diameter is 0.028 in. and all tolerances are 0.005 in.

Prescolite    Spartanburg, SC 29303
Mar 26, 2007 Compatible with all common construction materials, Pro-Nail(TM) incorporates real nail to facilitate fastening of bar hanger to joist. Flutes on nail shank lend to holding power, and nail position promotes installation. Multiple features also allow removal of nail for housing repositioning. In addition to curtain rod shaft design, other components include integral joist alignment, grid lock, and friction tabs. Product lets housings in adjacent ceiling tiles be aligned without offset.

Bridgeport Fittings, Inc.    Stratford, CT 06497
Mar 20, 2007 Models BXE-100/200/300 feature continuous, smooth, nonmetallic side walls that completely enclose devices, creating insulating barrier between them and their respective metal boxes. Extender does not interfere with wiring, so no trimming is required. Mounted completely flush with wall, products fit most metallic or nonmetallic electrical boxes and accommodate GFCIs. While BXE-100 and BXE-200 correct up to 1 in. setbacks, BXE-300 corrects up to 5/8 in. setbacks.

Greenheck    Schofield, WI 54476 0410
Mar 19, 2007 Hinged base assembly includes factory-assembled hinge, hold-open restraint cables, and curb seals mounted to base that slides directly over standard curb. It is available on Model CUE and CUBE spun aluminum fans sizes 200 and smaller.

TE Connectivity Ltd.    Berwyn, PA 19312
Mar 19, 2007 Rated up to 35 kV, UTILUX copper compression terminals and splices install with industry-standard tooling and are color-coded. They are made from seamless ETP copper and precision heat-treat tempered. Available in 1- and 2-hole versions, terminals are compatible with cable from 6 AWG to 1,000 MCM and accommodate termination with compact, compressed, or stranded copper conductors. Splices have same range and accommodate concentric, compact, or stranded copper conductors.

ACE Controls, Inc.    Farmington, MI 48335
Mar 13, 2007 Featuring fully threaded steel body, MC 5M Industrial Shock Absorber offers 3 effective weight ranges from .22-11.1 lb with energy per cycle rating of 6 lb-in. Unit can be mounted in confined spaces and is suited for office and medical equipment, instrumentation, circuit board production, small slides, packaging equipment, and small robotics.

Micro Plastics, Inc.    Flippin, AR 72634
Mar 07, 2007 Molded in black or natural nylon 6/6, Combo Cradle Mount offers chemical resistance and optimal wear properties. Large base assures stable mounting surface and can be secured with screw or rivet. Part can be used with standard or hook-and-loop wire ties to route bundles of wires, cables, or tubing.

Lobster Tools/S-B Industries, Inc.    Fenton, MO 63026-2914
Mar 06, 2007 Made of abrasion-resistant natural and reclaimed rubber compounds, Dock Bumpers are available in variety of 2-Hole Truck Trailer and Specialty size options. They withstand temperatures from -60 to 180°F and are suited for trucks, trailers, and forklifts as well as to help protect curbs, rollers, walls, corners, and any place metal to surface contact is harsh and continuous.

EMX Inc.    Melbourne, FL 32934
Mar 02, 2007 IP66 rated EPT-40 Pan/Tilt Positioner features pan speed of up to 60°/sec, continuous 360° pan range, tilt range of +45/-30°, and side-mounted payload of up to 50 lb. Control electronics are configurable to accept Marine Radar TTM message data for slew-to-cue operations with radar, and incremental encoder with 2,048 resolution provides position feedback while also providing on-screen display of pan/tilt position in azimuth and elevation.

Heyco Products    Toms River, NJ 08753
Mar 02, 2007 Suited for applications where limited clearance exists inside electrical cabinets/housings, Snap-In Cord Grips can be configured for electrical power, HVAC, and systems-management installations. They allow cords and cables from .079 to more than 1 in. dia to insert through grips, without binding or scraping of insulation which facilitates safe, secure passage. Grips are constructed from polyamide 6/6 nylon, and feature smooth, rounded interior edges.

Plastic Design, Inc.    North Chelmsford, MA 01863
Feb 27, 2007 Able to be set up in any conditioned environment, custom-fabricated isolators are secure solutions that may be used for animal quarantine, housing and production of immunodeficient animals, and maintenance of foundation colonies of genetically-modified animals. Semi-rigid models include 3 ft (right- and left-handed) cube and 8 ft isolators, and 6 ft flexible film isolator is also available. All models are designed to be stacked 2 units high.

C & M Corporation    Wauregan, CT 06387 0348
Feb 22, 2007 Made of medical-grade silicone rubber, Wave Strain Relief combines smooth, cleanable surface of straight strain relief with flexibility of chambered-style strain relief. RoHS-compliant unit is applicable wherever cable is used that requires ease of cleaning. Configuration may also be produced in PVC, polyurethane, and thermoplastic elastomer formulations.

K&B Duct    Greensboro, NC 27409
Feb 14, 2007 Designed to hasten installation and facilitate system modification, Clamp-Together Duct is available in 24-10 gauge thick galvanized or stainless steel in 1 in. dia increments from 3-24 in. It is assembled with lifetime-guaranteed Forever Clamp and suited for any negative-pressure ventilation system up to 40 in. wg with entrained dust, sand, fumes, mist, smoke, chips, or trim scrap. Adjustable sleeves and components enable field fitting to any length.

Chomerics, Div. Of Parker Hannifin Corp.    Woburn, MA 01888-4014
Feb 14, 2007 Form-in-place CHOFORM® 5550 offers one-component, thermal cure, electrically conductive material that provides EMI shielding effectiveness above 80 dB from 1-10 GHz and demonstrates galvanic corrosion resistance when dispensed on bare metal electronics housings. Suited for severe environments, material contains nickel-plated graphite particles dispersed in silicone elastomer and is designed to meet UL 94V-0 flammability requirements.

Worldlabel.com Incorporated    Garrison, NY 10524
Feb 13, 2007 Infinity V1 RFID Tag and Inlay Embedding System converts RFID tags/inlays so that they may be embedded accurately into paper or film label, even when each production batch has varying size labels or requires different type of RFID tag to be embedded in different area of label. Along with online bad tag detection and removal system, machine features touch pad for operator entry of required length to ensure accurate insertion.

Carr Lane Manufacturing Co.    Saint Louis, MO, MO 63119
Feb 13, 2007 Chuck Jaw Master Plates are made in 3 sections that mount on chuck, and accept variety of machinable jaw segments. They are available for chucks with 10-60 in. dia, in standard height and extra-high versions. Made of aluminum alloy, mounting pattern is machined according to chuck specifications based on make and size.

SKF Linear Motion & Precision Technologies    Lansdale, PA 19446
Feb 13, 2007 Controlled with desk, hand, or foot switches, SKF® TELESMART TMA/TMD series promote safe height adjustment for desks, tables, chairs, and industrial workstations. Type TMA pillars have 640 mm retracted length and 500 mm stroke, delivering push forces to 1,000 N at speeds to 55 mm/sec. With 550 mm retracted length and 700 mm stroke, Type TMD pillars achieve push forces to 800 N at speeds to 60 mm/sec. Dimensions of both types contribute to optimized workplace ergonomics.
