Signaling Controller targets Diameter based networks.
Feb 27, 2014
Leveraging dynamic multi-layer routing mechanisms, DiSC Diameter Intelligent Signaling Controller enables operators rolling out LTE and Evolved Packet Switched core networks to dynamically control and manage data traffic. Preemptive overload protection helps to maintain efficiency of Diameter traffic management during unexpected traffic peaks. Security features include connectivity access control, topology hiding, traffic measurements, and conditional protocol validations.
Wireless Test Set validates LTE-Advanced category 6 devices.
Agilent Technologies, Inc.
Santa Clara, CA 95051
Jan 28, 2014
Created for functional and RF design validation in 4G era and beyond, E7515A UXM Wireless Test Set enables realistic verification of bidirectional category-6 performance with stable throughput at 300 Mbps downlink. Unit offers wide range of network emulator capabilities, including complex handover scenarios and VoLTE support. With combination of 2 independent 100 MHz RF transceivers, UXM enables multiple cells, carrier aggregation, MIMO up to 4 x 2, and integrated fading.
Potentiometer Signal Conditioner offers <0.1% transmission error.
Germantown, WI 53022
Jan 27, 2014
Used for programming and monitoring, JUMPFLEX® 857-809 can convert potentiometer signal to various standard analog signal types. Unit accommodates input signals from 10–100 kΩ with configuration available via DIP-switches, teach-in switches, configuration software, or JUMPFLEX® To-Go app for Android mobile devices. Featuring precise signal values and CAGE CLAMP®S connection technology, 6 mm wide signal conditioner provides safe electrical operation with 2.5 kV 3-way isolation.
Signal Conditioner features loop-powered operation.
Germantown, WI 53022
Jan 20, 2014
Offering conversion, isolation, and transmission of variety of signal types, JUMPFLEX® 857-450 uses power supplied by output signal loop so no separate 24 Vdc power supply is required. Device ensures safe electrical isolation of circuits at 2.5 kV with less than 0.1% transmission error, enabling precise signal values. With extended temperature range of -25 to +70°C, JUMPFLEX® 857-450 can be used for electrical isolation of active I/O modules from fieldbus level.
Power Measurement Products serve industrial/building applications.
Germantown, WI 53022
Jan 10, 2014
Components for industrial and building applications include 750 Series 3-phase power measurement modules, 855 Series Rogowski coils and CTs, and 857/798 Series signal conditioners. Power measurement modules can integrate into WAGO-I/O-SYSTEM node with other standard digital/analog input and output signals. This system can also be networked to existing control platform. Signal conditioners can convert 1 or 5 A current transformer or Rogowski coil signals into standard PLC analog signal type.
Microcontroller Development Board includes GPS/GNSS receiver.
SkyTraq Technology, Inc.
Hsinchu City 300 Taiwan
Dec 30, 2013
Based on 100 MHz, 32-bit RISC with 16 KB I-Cache and 2 KB D-Cache, NavSpark includes IEEE-754 compliant floating point unit, 1 MB flash memory, and 212 KB SRAM. NavSpark-BD model has GPS/Beidou receiver onboard for smartphone manufacturers, while NavSpark-GL includes GPS/GLONASS receiver. Housed in 7 x 7 mm QFN56 package, Venus822 quad-mode GPS/GNSS processor with extended I/O pins can simultaneously process 34 GPS/GLONASS/Beidou/Galile /QZSS/SBAS signals in parallel.
DAQ Synchronization Module aligns multiple data streams.
Bellevue, WA 98004-3039
Dec 27, 2013
Time Base Synchronization module provides DSP-based approach to obtaining time-aligned sampled data sets from multiple measurement stations that monitor common time base signal. Timing reference signal and measured signals are observed in common multichannel data stream. Using hardware and processing to achieve high-quality measurements with optimal flexibility this solution is available with DAPtools Standard software package, with xDAP DAQ system, or as software upgrade.
FPGA-Based Modules come in XMC and 3U VPX form factors.
Extreme Engineering Solutions (X-ES)
Middleton, WI 53562
Dec 20, 2013
Utilizing Virtex®-7 family of FPGAs, XPedite2470 3U VPX and XPedite2400 XMC Modules merge configurable I/O, DSP-level processing, and thermal efficiency to meet demanding RF signal acquisition, SDR, and DSP requirements. XPedite2470 provides 11 high-speed GTX lanes to backplane and 8 high-speed GTX lanes to on-card FMC site. Supporting 32 LVDS signals through P14 connector, XPedite2400 includes 14-bit DAC, 2 GB of DDR3 SDRAM, Gen3 PCI Express interface, and up to 10 GTX lanes.
Phase Shifters offer 360° phase control in 1° increments.
Vaunix Technology Corporation
Haverhill, MA 01835
Dec 04, 2013
USB powered and controlled, Lab Brick LPS-402 and LPS-123 offer frequency range of 2–4 GHz and 8–12 GHz, respectively. Phase can be set from GUI, configured from uploaded phase profile, or programmed using provided API DLL. Units store settings in internal memory, allowing them to power up in specific phase state. Typical applications include beam forming, signal cancellation, phase modulators, MIMO test platforms for LTE and WiFi, and phased array antenna systems.
2-, 4-Wire Transmitters offer range of measurement options.
Wixom, MI 48393 7037
Nov 21, 2013
Supporting high-density DIN rail mounting, TT230 and TT330 series are configurable via USB connection to PC and feature front-facing, removable wiring terminals to facilitate connections and maintenance. Models TT234 and TT334 interface 100–100k Ω via potentiometer/slidewire or 100–1M Ω from thermistor/rheostat, while models TT235 and TT335 accept 100, 200, 500, or 1,000 Ω platinum RTD; 120 Ω nickle RTD; 10 Ω copper RTD; or 0–450 Ω linear resistance.
GNSS Controller regulates effective radiated power levels.
GPS Source Inc
Pueblo West, CO 81007
Nov 18, 2013
Capable of handling any GPS L1/L2 or GLONASS L1/L2 signal application, GLI-METRO-G offers ability to select GPS plus GLONASS, GPS only, or GLONASS only signal output power control. Unit includes built-in antenna monitoring and oscillation detection. When used in conjunction with active GPS/GLONASS receive antenna, controller will pass GPS+GLONASS signals inside building, hangar, or any structure where signal is not accessible.
Gesture Sensor Board streamlines touchless remote control.
Malvern, PA 19355
Nov 15, 2013
Used to add touchless swipe right, swipe left, tap, and push in and out control to any device, gesture control sensor board consists of VCNL4020 integrated digital proximity and ambient light sensor and 2 VSMF2890RGX01 IR diodes mounted on either side of sensor. Radiant intensity of 80 mW/sr typ at 200 mA allows for detection of hand gestures up to 25 cm above sensor board, and proximity signal is read out between each pulse via I²C bus interface.
DC-Powered Signal Conditioner features bridge balance pot.
Calex Mfg. Co., Inc.
Concord, CA 94520
Nov 07, 2013
Designed for load cells and transducers using full bridge strain gauges, Model 437 contains instrumentation amplifier with isolated, filtered output and regulated, adjustable output bridge excitation source. Amplifier accepts full scale live load signals as low as 5 mV and provides 16 mA output span. Encapsulated in 3.25 x 2.00 x 2.87 in. housing, signal conditioner delivers isolated 4–20 mA or 0–20 mA output capable of driving 1,000 Ω loop. Unit has bridge balance with 80% tare offset capability.
LVDT Digital Signal Conditioner employs TEDS-Tag technology.
Electro Standards Laboratories
Cranston, RI 02921 3403
Oct 15, 2013
Model 4338 LVDT AC excitation single-channel intelligent digital signal conditioner is available with CellView Lite GUI Software or CellView Multi-Display GUI Software. Unit connects directly to AC LVDT transducer and simultaneously generates serial output for connection to PC and ±10 V analog output. Integrated 6-point calibration capability compensates for transducer nonlinearities, while USB port and command set allow connection of multiple units in serial network configuration.
DSP Board targets ATCA and MicroTCA systems.
Leicestershire LE11 3EH Uruguay
Oct 11, 2013
With 16 DSP cores and shared memory, Model AMC-2C6678L is suitable as DSP accelerator or front end processor in AdvancedTCA systems used for image sensor processing, voice/video, telecom, and stepper control. Module includes two TMS320C6678 fixed- and floating-point octal core DSPs, which run at 1.25 GHz, for combined performance of 320 GFLOPS and 640 GMACS. Additional features include 4 GB DDR3-1600 SDRAM and 128 MB flash memory, as well as Serial RapidIO, PCIe, and Gigabit Ethernet interfaces.
Signal Conditioners include potentiometer and bipolar models.
Cumming, GA 30040-9905
Oct 10, 2013
Converting resistive signals from 10 KΩ potentiometer to 4–20 mA signal, Model FC-P3 is field-configurable for 3-wire potentiometer/slidewire inputs and can be scaled down to minimum 10% of potentiometer being used. Switch selectable analog output options range from 0–20 mA to 0–10 V. Additional FC versions include bipolar input-to-unipolar output and unipolar input-to-bipolar output models. All include 35 mm DIN rail-mounting adapter, LED indication, and removable screw terminal blocks.
DC Current Signal Splitters serve multiple industries.
Omega Engineering, Inc.
Stamford, CT 06907
Oct 09, 2013
Featuring one 4–20 mA input to two 4–20 mA outputs with full isolations, DRSP-I series offers zero and span adjustments for each input as well as output test button for each channel. Other features include built-in loop power supplies for sink/source I/O, split, convert, boost, and rescale process signals as well as ability to interface process signal with multiple panel meters, PLCs, recorders, data acquisition, DCS, and SCADA systems.
Bandpass Filters incorporate ceramic coaxial resonators.
Brooklyn, NY 11235
Jul 30, 2013
Designed with .678 x .474 in. footprint, CBP Series features shielded casings to withstand harsh thermal, mechanical, and environmental conditions, including stress during solder reflow cycles. Options are available off the shelf in passbands of 1170–1390 MHz, 1215–1400 MHz, 1320–1480 MHz, and 1780–1980 MHz for 50 Ω systems. Fabricated using SMT technology, filters are suitable for critical functions, including aviation, mobile radio, broadband and fixed wireless applications.
AMC Module provides 32 DSP cores.
Leicestershire LE11 3EH Uruguay
Jul 25, 2013
Equipped with four TMS320C6678 fixed- and floating-point octal core DSPs from TI, running at 1.25 GHz, Model AMC-4C6678 provides total performance of 640 GFLOPS and 1280 GMACS. PCI Express and Gigabit Ethernet interfaces use on-board switches for flexibility and access to all DSPs on card. SRIO link is directly connected to one DSP, shared using Hyperlink, and then extends to second DSP pair. In addition to 256 MB of flash memory, card includes 8 GB of DDR3 SRAM, with 2 GB allocated to each DSP.
OpenVPX Boards incorporate Xilinx Virtex FPGAs.
Upper Saddle River, NJ 07458
Jul 19, 2013
Incorporating Xilinx Virtex-6 and Virtex-7 FPGAs for onboard signal processing, 52xxx Series includes ruggedized and commercial grade boards for military and avionics applications. Compact 3U OpenVPX software radio modules support VPX REDI and PCIe x4 over VPX P1 connector. Available in air-cooled and conduction-cooled options, boards feature synchronous clocking locked to external system reference and LVPECL synch bus for synchronizing multiple modules to increase channel count.
