Schunk    Morrisville, NC 27560
May 25, 2012 TENDOzero features 4 lateral set-screws, integrated into precision mounting, that directly affect tool shank, correct angular position of tool, and adjust run-out. Compensation for spindle run-out errors is done at machine, and vibration damping leads to even cut and minimizes micro blow-outs at cutting edge. In addition to conventional cooling from outside, TENDOzero also has internal coolant supply; slightly modified version offers minimum quantity lubrication (MQL).

Genevieve Swiss Industries, Inc.    Westfield, MA 01085
May 14, 2012 Multidec® Modular BACK TOOL tool holder is center height adjustable to +.20 in and features range of shanks, spacers, and insert modules. It allows for use of CUT 3000 series insert to perform grooving, threading or OD turning on back side of Swiss machine. Holder can be equipped with adaptor to provide coolant delivery system for insert lubrication and cooling, more efficient cutting tool life, and improved Swiss type machining.

BIG Kaiser Precision Tooling, Inc.    Hoffman Estates, IL 60192
Mar 30, 2012 Suited for the aerospace industry, HSK-A125 can handle large-scale titanium and other workpieces on massive tables of machines such as Makino's T2 and T4 models. Product lineup features myriad tool holder types, including HMC and Mega Double Power milling chucks up to 2 in. dia, Mega ER/Mega N/Mega E collet chucks, shrink fit holders, face mill adapters, Kaiser KAB adapters, and Mega Synchro Tapping Holders. All holders feature coolant through capability as standard.

Schunk    Morrisville, NC 27560
Jan 17, 2012 TENDO E compact eliminates need to use different holder technologies for milling, drilling, and reaming. Hydraulic expansion toolholders can safely transfer torques of up to 384 lb-ft at 20 mm clamping diameter and are suited for high-volume cutting. With vibration damping and precise run out accuracy of less than 0.0001 in. at 2.5 x D, product protects machine spindle and cutting tool from damage. Tools can be changed with Allen key, and several spindle connections are available.

Schunk    Morrisville, NC 27560
Dec 16, 2011 Directly clamping small tool shanks consistently along entire axis, TRIBOS-Mini eliminates collets, collet nuts, and inconsistent tool clamping for medical, dental, and micro level parts machining. Run-out accuracy is less than 3 microns, and balance grade is G2.5 at 25,000 rpm. Offering direct clamping via material elasticity, product utilizes polygon form in clamping bore to generate clamping. Holder is inserted into TRIBOS press, and cutting tool is released in less than 30 sec.

Schunk    Morrisville, NC 27560
Nov 18, 2011 Featuring adjustable run-out accuracy of 0.00 mm, TENDOzero is equipped with 4 lateral set-screws, which directly affect tool shank. Set-screws are directly integrated into precision mounting. With Torx-plus key, angular position of clamped precision tool is corrected and run-out is adjusted. Vibration damping leads to even cut and minimizes micro blow-outs at cutting edge. Besides conventional cooling from outside, TENDOzero also has internal coolant supply.

Wilson Tool International Inc.    White Bear Lake, MN 55110
Nov 15, 2011 Offering standard holders with truly universal punches, EXP(TM) punch technology is designed to fit in all styles of A and B station thick turret assemblies. It is available for every major brand of thick turret tooling, and design enables use of same holder with multiple punches. Available in round or special shapes, products are manufactured with Ultima(TM) premium tool steel for utmost wear resistance and are fully compatible with all current guide assemblies.

Schunk    Morrisville, NC 27560
Oct 17, 2011 Made of hardened stainless steel with dual clamping stroke and integrated turbo function, VERO-S Module clamps workpieces, pallets, existing fixtures, and tombstones with one or more clamping pins. Radial aligned clamping slides pull in clamping pin and lock it. Radial location is done via diamond pin, assuring repeat accuracy of less than 0.0002 in. Maintenance-free module is completely sealed and protected against penetration of chips, dust, and coolant.

Schunk    Morrisville, NC 27560
May 26, 2011 Designed for automated tool and cutter grinding, PRISMO Toolholder is based on precise clamping sleeve with prism guidance. Each of 5 chuck jaws is guided by double prism, while third prism on clamping face directly contacts tool shank. Holder always adjusts itself to individual tool diameter. At overhang length of 2.5 x D with tool diameter of 20 mm, PRISMO provides repeat accuracy of less than 0.005 mm. To avoid contamination, toolholder is rinsed with clean oil during grinding operation.

Genevieve Swiss Industries, Inc.    Westfield, MA 01085
Apr 25, 2011 EZR Swiss clamp system is available with EZR Swiss clamp nuts, EZR wrench adaptor, EZR torque nut adaptor, and spanner wrench. System eliminates wrench slippage and losing clamping nuts in machine sump/chip bin. Standard box wrenches or 3/8 in. drive ratchet wrench with either EZR wrench adaptor or EZR torque adaptor help in tightening clamp nuts.

Schunk    Morrisville, NC 27560
Feb 18, 2011 Suited for high-volume cutting, TENDO E compact can safely transfer torques up to 384 lb-ft at 20 mm clamping diameter. Hydraulic expansion toolholder, with vibration damping and precise runout accuracy of less than 0.0001 in. at 2.5 x D, protects machine spindle and cutting tool from damage. All common spindle connections are available for ¾ in. interfaces HSK-A63, SK40, BT40, and CAT40.

BIG Kaiser Precision Tooling, Inc.    Hoffman Estates, IL 60192
Nov 24, 2010 Offering runout accuracy of .00012 in. at 5 x D, Mega ER Grip features precision notch-free nut and AA-grade ERC collet, which is in accordance with DIN6499 and ISO15488 standards and features clamping range of .075-.787 in. diameter. Contact length of internal taper of chuck body minimizes undesired overhang of collet, while tapped holes around body periphery promote precision balancing. With Mega ER Perfect Seal, coolant can be delivered through tool or to cutter periphery.

HEIMATEC INC    Prospect Heights, IL 60070
Oct 27, 2010 Intended for lathe and mill/turn users, Unitec system allows standard ER output live tool to accept various adapters for different applications. Polygonal drive system promotes optimal power transmission stability, while collet nuts have internal threading for rigid mounting. Live tool base remains in position; only adapter and collet get swapped. Design also enables actual cutting tool to be brought into closer proximity to bearing, improving performance.

Lyndex-Nikken Inc.    Mundelein, IL 60060
Sep 28, 2010 Equipped with 3-phase 220 V power connector, Shrink Fit Machine can insert cutting tool into shrink fit holder in 2 sec. Induction coil allows unit to handle cutter bodies made from HSS, heavy metals and carbide, and automatic cutter size detection function eliminates need for inputting size of cutter shank, reducing set up time. Device is compatible with all holders with varying geometries, shrinking 2-40 mm with same inductor.

Slater Tools, Inc.    Clinton Township, MI 48038 1554
Aug 05, 2010 Available in several shank sizes, adjustment-free 3700 Series features bearing capacity capable of producing large forms. While most common forms made with rotary broaching tools are hexagon and square holes, 3700 series tool holder also accepts special Slater broaches that can be used to create double hex, double square, serration, spline, and other custom forms. Toolholder eliminates secondary operations, which conserves time and expense.

Parlec, Inc.    Fairport, NY 14450 0059
Aug 04, 2010 Clamping with up to 900 lb of force, Power clamping spindles for Series 1500 and 1800 TMM presetters positively clamp taper styles including ISO/SK/CAT/BT tapers as well as HSK and CAPTO style tooling. Units are suitable for when micron-precision repeatability is required and also minimize effects of tooling variability on measuring process.

Parlec, Inc.    Fairport, NY 14450 0059
Aug 04, 2010 Available in Cat, BT, and HSK shanks, DIN-style Heat Shrink Toolholders are pre-balanced to achieve optimal rpm and designed to be compatible with any heat shrink machine outfitted with DIN cooling systems. Inch and metric IDs are available, and AD/B coolant delivery is standard. Also, standardized lengths and nose shapes eliminate compatibility issues with machine types and program changes.

Schunk    Morrisville, NC 27560
May 20, 2010 Transforming precision toolholders into versatile units for narrow spaces independent from spindle interface, TENDO-SVL Hydraulic Expansion Extension is available in 4 sizes with shank diameter of 32 or 20 mm, clamping diameter of 20 or 12 mm, and length of 150 mm. Maximum torque of hydraulically clamped extension ensures that tools are held securely for all drilling, reaming, and finish milling operations.

Mate Precision Tooling    Anoka, MN 55303
May 04, 2010 ULTRAFORM® FX(TM) and XT(TM) holders increase flexibility and efficiency of thick turret punch press forming operations. Available in B through E stations, ULTRAFORM FX allows use of unlimited number of forming tool inserts with one holder and features lubrication grooves and multiple angle settings. ULTRAFORM XT, also available in B through E stations, facilitates and accelerates length adjustment. Features include grooved guides for lubrication and multiple angle settings.

REGO-FIX Tool Corp.    Indianapolis, IN 46268
Apr 26, 2010 Suited for aerospace and energy industries, Xtended Length (XL) toolholders feature Micro-Friction-Dampening (MFD) system, which reduces holder and tool vibrations. Available in ER and powRgrip® product lines, toolholders are offered with CAT, BT, HSK, and REGO-FIX CAPTO tapers in 2 in. increments up to max length of 14 in.
