RF& Microwave Transmitters
Featuring programmable frequency bands and channels, STD-601 comes in SMD, 20 x 32 x 5 mm package and offers communication range of 600 m (LOS) at 10 mW. Frequency bands – 429, 434, 447, and 458 MHz – conform to various ISM bands to allow frequencies to be set within wide range, and transparent user data input allows use of proprietary protocol. Module also offers selectable RF power levels – 1, 5, 10, 20, 25, 50 mW – and data rates: 1,200, 2,400, 4,800, 9,600, and 19,200 bps. Read More
Employing quad-core ARM®Cortex®-A9 (Freescale i.MX6) processor running Linux, 4.4 x 1.6 x 1.1 in. Matchstiq™ S10 supports connectivity via GigE (PoE capable), USB 2.0 OTG, and HDMI and features integrated GPS with 1PPS. Platform is based on Sidekiq MiniPCIe SDR card, with RF transceiver providing independently tunable RF transmitter and receiver covering 70 MHz to 6 GHz as well as RF channel bandwidths up to 50 MHz and Xilinx® Spartan®6 LX45T FPGA. RTC with battery backup is also standard.
Available with user/factory programmable custom frequencies from 425–470 MHz, Model NTX2B can be dynamically re-programmed via microcontroller UART. Standard version consists of 10 mW, 25 kHz unit available on 434.075 MHz, 434.650 MHz European SRD frequencies and 25 mW on 458.700 MHz for UK. Internal LDO voltage regulator enables transmitter to be operated down to 2.9 V and up to 15 V voltage supply at nominal current consumption of 18 mA and less than 3 µA in power-down mode. Read More
Used to automatically identify and track location of objects or people, Real-Time Locating Systems comprise NSAR-820 Activators, 125 KHz/2.45 GHz NSAT-709 Tags, and NSAR-800/850 gain adjustable active RFID reader/writers. NSAR-820 transmitter provides 125 KHz signal which activates tags. Tags then transmit unique ID along with activator's address ID to 2.45 GHz reader/writers to provide tag's exact location. As long as tags are not being activated, they work in sleep mode to extend battery life. Read More
Implemented during design validation and manufacturing phases, X-Series provides RF conformance testing of LTE-Advanced FDD and TDD transmitters and components to 3GPP Release 11 specification. Application, available for benchtop and modular products, provides one-button measurements for Agilent X-Series and modular signal analyzers. Accelerated measurement, SCPI programmability, pass/fail testing, and simplified operation aid design verification/manufacturing. Read More
Measuring 31 x 50 x 5 mm, Sidekiq supports operation as 2-channel phase coherent RF receiver or as single-channel RF transceiver providing independently tunable RF transmitter and receiver. Tuning range for RF transmitter and receiver covers 70 MHz to 6 GHz frequency range, supporting RF channel bandwidths up to 50 MHz. On-board Xilinx Spartan® 6 LX45T FPGA provides reconfigurable logic for signal processing tasks, as well as high-speed PCIe interface for performing low latency data transfer. Read More
With 4 trace frequencies of 1, 8, 33, or 65 KHz, 5 Watt Gen-Eye Hot Spot™ Transmitter enables users to select frequency and power that best suits application. Graphic LCD with auto backlight indicates line resistance and current flow as well as battery level, output level, USB connection, connectivity, type of transmission, and active frequencies. Battery life keeps unit operating up to 100 hr, while selectable automatic shutdown feature helps save power. Read More
Suitable for use in hygienic applications and harsh environments, Sitrans LG series features modular design with numerous configuration options that allows for level measurement in oil and gas, chemical, pharmaceutical, and food and beverage industries. Microwave pulses are transmitted down rod or cable, offering reliable measurement with up to 0.08 in. accuracy. Compliant with SIL2 safety standard, series includes 4 basic versions and offers various configuration options.
Featuring standardized WR15 Waveguide Interface with +8 dBm P1dB output power, 60 GHz PRS2122 Transmitter and PRS2123 Receiver support rapid growth of multi-gigabit wireless Ethernet applications such as small cell backhaul, enterprise wireless infrastructure, and point-to-point links. Key attributes of 802.11ad modules include extremely low transition loss of less than 1 dB, flat passband response across all WiGig channels 57–66 GHz, and receiver noise figure of 5 dB. Read More
Offering redundant hardware and software architecture, SCU32 Transmitter Control Unit provides radio link for industrial applications and wireless solutions. Unit transmits up to 32 + 4 digital commands and up to 8 analog signals. It can be combined with various remote control receivers such as CT24, which features stop circuits that monitor output contacts, and shut down systems in event of failure. Read More
Delivering more than 8x capacity in 1/3 footprint of traditional systems, ETSI-optimized 9500 Microwave Packet Radio long-haul system addresses demand for high-bandwidth, long-haul connectivity for both traditional and IP-based services, including IP video and 4G LTE in Europe and other parts of world. System offers smooth transition from TDM and hybrid microwave networks to satisfy increased demand for data by providing path to 10G capacity between microwave towers. Read More
Incorporating radio transmitter and receiver functions, Mitros+ TTL Transceiver Flash enables photographers to control and fire remote compatible flashes in TTL or Manual modes, with no external triggers required. Users can control TTL EV adjustment of ±3 in 1/3 stops and manual power from full power to 1/128 in 1/3 stops. Unit also offers rotating and elevating flash head, 24–105 mm flash zoom, high-speed sync, second curtain sync, external battery port, and 3.5 mm sync port. Read More
Featuring dual digital inputs and 250 mW output power, EchoStream® EN1252 provides secure communications network that can serve as alternative to fiber or cable installation. Unit is designed for use with any standard contact or sensor that provides contact closure. Primary alarm input is selectable as normally open or closed, while secondary alarm input is set to normally closed only. Transmitter is suitable for perimeter security encasing remotely located buildings. Read More
Offering 12.1 in. touchscreen interface, MultiView function and MSRA function, R&S FSW50 signal and spectrum analyzer is suited for use in development, testing, verification, and production of transmitters and components such as those used in radar applications and satellite and military communications systems. Use of harmonic mixers enables extension of frequency range to 110 GHz. Analysis bandwidth of 320 MHz allows demodulation of wideband signals, such as radar chirps, up to 50 GHz. Read More
Completely transparent to existing equipment, WRT Series Wireless Data Transmitter/Receiver provides self-managed mesh network that works with any RS485 network protocol. System allows for wired and wireless equipment mixes to avoid radio signal obstacles, and offers wireless data transmission up to 100 m between receivers. Data transmission at up to 800 m is possible with multiple hops. Offering automatic route detection, WRT Series supports 100 nodes/network through 15 channels. Read More
Featuring IP67/IPx9K protection rating, 4 x 5 mm MDS D117 may be used from -25 to +100°C and suits tool identification applications as well as use with small workpiece carriers. ISO 15693-compliant transponder, fitted with 112 byte EEPROM, is configured for 13.56 MHz (RF) frequency range and can be used at read/write distance of 5 mm from reader. Plastic housing can be glued flush with metal, ensuring protection from mechanical influences in hostile industrial environments.
Optiva Satcom Band Microwave Fiber Optic Transmitters and Receivers offer band-specific C, X, Ku, or Ka transmitter and receiver modules compatible with EMCORE modular or flange-mount Optiva Platform configurations. Addition of Optiva Satcom Band RF Fiber Optic Transport System expands existing Optiva Platform that supports 50 MHz to 18, 22, or 40 GHz broadband microwave transport, reference oscillators, IRIG, IF, L-/S-band, plus audio, video, data, and Ethernet. Read More
Intended for test and measurement, wireless communications, and optical networking equipment, AFE7071 radio transmitter integrates dual 14-bit, 65 MSPS DAC; tunable baseband filters; RF IQ modulator with output range of 100–2,700 MHz; and digital quadrature modulation correction circuit. Also available, AFE7070 adds DDS with 32-bit NCO and LVDS output buffer. Products offer output power up to 0.3 dBm and adjacent channel power ratio of 66 dB (5 MHz WCDMA) and 61 dB (20 MHz LTE) at 2.1 GHz. Read More
Designed for power classes up to 10 W, RS MLx helps optimize coverage of DVB-T/DVB-T2 networks and affords flexibility when selecting installation site. Modular solution measures 250 mm deep, integrates up to 6 transmit channels in one system, and offers flexible configuration options for various applications and receiving conditions. Transport stream can be fed via coaxial cable or satellite; UMTS is also supported for monitoring broadcast operations. Read More
Integrated on machining centers and CNC milling machines, Model RMI-Q offers automated on-machine tool setting, tool breakage detection, part set-up/verification without cables. System is used to activate spindle-mounted touch probe or table-mounted tool setting probe, and gives visual indication of activated device. Utilizing 2.4 GHz FHSS radio transmission, system enables uninterrupted operation in busy radio environments. Transmission range up to 15 m makes RMI-Q suitable for large machines. Read More
