Pressure & Vacuum Gages

Test & Measuring Instruments, Sensors, Monitors & Transducers

Cold Cathode Gauge provides ±10% accuracy.

January 13, 2015

Offering wide measurement range from 10-10 to 10-2 Torr, Granville-Phillips® Series 500 includes electronics as well as digital and analog interfaces. Patent-pending method for determining pressure dosage over time provides for predictive maintenance. With USB interface and GP Connect software, users can set up gauge, graph pressure trend, and check usage statistics. Applications include R&D, coating, semiconductor, analytical, high energy physics, and general vacuum. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Pb-Free Pressure Gauges carry NSF International certification.

November 18, 2014

Compliant with U.S. Safe Drinking Water Act, lead (Pb)-free pressure gauges feature wetted parts with lead content ≤0.25% and are safe for applications where water is anticipated to be consumed by humans. Gauges also meet lead content requirements for Pb-free plumbing as defined by CA, VT, MD, and LA state laws. Products comply with NSF/ANSI Standard 61, 372, and 61 (Annex G) and feature NSF mark, along with test standard, on dial and socket stamped with universal No Lead symbol. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Digital Pressure Gauge includes data logging/charting software.

November 5, 2014

Suited for harsh industrial environments, DPG409S Sanitary/Clean-In-Place digital pressure gauges incorporate 316 SS enclosure, designed for washdown and marine applications, with precision 0.08% accuracy pressure transducer as well as 316L SS wetted parts and body. Gauge, Absolute, Compound Gauge, Vacuum, and Barometric models are available, all of which feature 1 in. backlit LCD, hi and lo alarms, MIN/MAX/AVG reading, and user-selectable analog output 0–5 Vdc, 0–10 Vdc, or 4–20 mA. Read More

Test & Measuring Instruments, Fluid & Gas Flow Equipment, Sensors, Monitors & Transducers

Single-Use Gauge Tee allows secure pressure monitoring.

July 30, 2014

Providing pressure monitoring for pre-sterilized single-use systems, SGT employs thermoplastic elastomer diaphragm, which allows standard sanitary pressure gauges and transducers to be attached while maintaining sterility of system and eliminating cross contamination. Gauges and transducers can be aseptically removed from system for offline calibration during processing. Hose barbs to support tubing from 3/8–1 in. diameter as well as ¾ in. sanitary flange connections are offered. Read More

Test & Measuring Instruments, Fluid & Gas Flow Equipment, Sensors, Monitors & Transducers

Pressure Gauges and Calibrators offer extended pressure range.

July 24, 2014

Offering full scale accuracies from 0.025–0.25%, ADT681 and ADT680 Digital Pressure Gauges, ADT672 Digital Pressure Calibrator, and ADT949 Hydraulic Pressure Pump offer extended pressure range of 40,000 psi. Each product comes with NIST-traceable certificate of calibration. Read More

Test & Measuring Instruments, Controls & Controllers, Sensors, Monitors & Transducers

Multi-Gauge Controller displays 10 pressure measurements.

July 9, 2014

Providing pressure measurements from 1,000 Torr to 2 x 10-11 Torr, Model MGC4000 can display measurements from up to 10 different vacuum gauges simultaneously. Instrument can be configured to display up to 6 gauges in single screen or any number of gauges can be assigned to various screens for auto scrolling of display. By specifying number of gauges, set points, and AI/AO they require, customers can configure MGC4000 to exact specifications. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Differential Pressure Gauges offer colored bezel options.

July 2, 2014

In addition to customer logo and other custom scale design options, Sensocon® Series S2000 is available with both standard and custom color options for front bezel. Standard colors include Blue, Red, White, and Black. With color options, users can match logo or equipment colors as well as code gauges for specific purposes. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Digital Vacuum Gauge features battery-operated design.

April 29, 2014

Compatible with DV-4, DV-5, and DV-6 vacuum gauge tube families, handheld Model HPM 4/5/6 features graphical display that allows user to select units of measure, including Torr, mbar, and Pa. Vacuum gauge tubes utilize rugged, but sensitive, noble metal thermocouples that are designed specifically for each range of vacuum. Read More

Test & Measuring Instruments, Electrical Equipment & Systems, Sensors, Monitors & Transducers

Tire Pressure Monitor features self-calibrating design.

March 26, 2014

As tire pressure drops by approximately 4 psi, LED Smart Cap Version 2 activates blinking red light to notify users. Low tire pressure alert light remains blinking for as long as 600 hours to provide ample warning. Powered by single Li-Ion battery, Smart Cap automatically compensates for ambient temperature changes to prevent false alarms, and comes complete with anti-theft device. Since monitoring system is self-calibrating, same cap can be used on tires ranging from 10–70 psi. Read More

Test & Measuring Instruments, Electrical Equipment & Systems, Sensors, Monitors & Transducers

Pressure Switches suit most industrial applications. .

March 4, 2014

Available in variety of sizes and configurations, Ashcroft® Pressure Switches can be provided with NEMA 4 watertight and NEMA 7 explosion proof housings. Each switch can be constructed with variety of diaphragm materials, sanitary connections, or with external media isolators for specialized installations. With pressure ranges extending from 0/10 in.H2O to 0/7500 psi and up to 600 psid, switches offer option of dual-seal rating and SIL capability. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Digital Pressure Gauge suits field and laboratory applications.

January 20, 2014

Powered by three AA alkaline batteries, Model PTG200 features backlit LCD screen with 5-digit resolution and choice of 9 pressure units. Standard models are housed in aluminum alloy case with atmospheric reference choices of gauge, sealed gauge, or absolute, compound, and differential. Gauge ranges measure over 2,500 bar, while compound ranges from -1 to 2.5 bar, and differential ranges from 0.0025–0.05 bar. Featuring 316L SS wetted parts, Model PTG200 offers accuracies of 0.1% or 0.2% FS. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Digital Test Pressure Gauge offers laboratory precision.

December 9, 2013

Suited for use in field pressure calibration, Palmer Precision Test Gauge (PTG) has 3.9 in. dia dial and displays up to 6 digits on backlit LCD. User can select from up to 9 engineering units, and models are available for measuring over 36,000 psi. Fully temperature compensated accuracy from 32 to 122°F, Palmer PTG100 comes in accuracies of 0.5%, 0.1%, 0.05%, and 0.025% FS. Standard models are available with atmospheric reference choices of gauge, sealed gauge, or absolute. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Digital Test Pressure Gauge suits field calibration.

November 27, 2013

Featuring 3.9 in. dia dial that displays up to 6 digits on backlit LCD screen, Palmer PTG100 allows users to select from up to 9 engineering units, including models measuring over 36,000 psi. Unit offers accuracies of 0.5, 0.1, 0.05, and 0.025% FS with temperature compensated accuracy from 32–122°F. Standard models are available with atmospheric reference choices of gauge, sealed gauge, or absolute; compound and differential models are also available. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Digital Pressure Gauge measures up to 25,000 psi.

November 26, 2013

Housed in IP67-rated enclosure with 5-digit LCD, Ashcroft® DG25 is available in accuracies of 0.5% and 0.25% FS. Unit offers selectable units of measure, 20-segment bar graph indicator, Min/Max/Tare, and list of agency certifications. Featuring minimum battery life of 2,000 hours, gauge is also available with backlight and rubber protective boot. Read More

Test & Measuring Instruments, Labels, Tags, Signage & Equipment, Sensors, Monitors & Transducers

Custom Dial Faces are available for temperature/pressure gauges.

November 6, 2013

Custom dial face design and manufacturing service is available for Palmer BiMetal and Direct Drive Dial thermometers and Palmer Pressure Gauges with screw-on bezels regardless of dial size. Options include dual scales with different units of measure, colored scales, high-visibility markings, color pie-wedge sectors, bands, or lines. Original ideas and artwork can be submitted, or in-house engineering services can work with customers to design model specific to application requirements. Read More

Test & Measuring Instruments, Mechanical Components & Assemblies, Sensors, Monitors & Transducers

Pressure Gauge withstands harsh operating conditions.

November 5, 2013

Measuring 4 ½ in. in diameter, Ashcroft® Type 1020S is specifically designed for monitoring pressures on Christmas tree control assemblies located on top of oil and gas wellheads. Unit features rotary movement and is constructed with stainless steel exterior and wetted parts to resist potentially damaging effects of petroleum pressure media. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Isolated Pressure Instruments operate with harsh media.

October 1, 2013

When used with harsh or corrosive liquids and gases, Pressure Instruments such as dial/digital gauges, switches, and transmitters can be configured with diaphragm seal or other isolation device for complete media protection. Seals are available in variety of sizes, wetted materials, and configurations, including capsule type, welded, or bonded and clamped designs with threaded, flanged, or flushing connections. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Panel Builder's Pressure Gauge delivers reliability via design.

September 5, 2013

Ashcroft® Type 2008S features 63 mm dia gauge dial that combines stainless steel wetted parts and case along with PowerFlex™ spring suspended movement to promote reliability and longevity. Also available, liquid fill and PLUS! Performance™ dampen potential pointer bounce caused by vibration and pulsation. This all-welded, front-flanged pressure gauge is suited for monitoring pressures in various installations, including oil and gas control panels.
Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Pressure Gauge features solar powered design.

August 14, 2013

Equipped with 5/8 in. high LCD screen, Solar Pressure Gauge is available in ranges from vacuum to 1,000 psi, as well as kPa, KG/CM2, or Bar with corresponding vacuum scales. Models are available with or without 4–20 mA transmitter capability for connection to remotely installed controller or recorder. Supplied with ¼ in. NPT or ½ in. NPT lower connection fittings, gauge features IP65 weatherproof rating making it suitable for exterior installations. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Digital Pressure Gauge has rugged, weatherproof design.

August 7, 2013

Featuring 304L stainless steel wetted material for compatibility with range of liquids and gases, Series WDG measures pressure with accuracy of ±0.5% FS for ranges up to 1,000 psig and ±1% FS to 5,000 psig. Housing is of fiberglass reinforced PP plastic, and 4-digit backlit display features 4 selectable units. Offering long term stability of ±0.05% FS/year, 2.5 in. OD gauge has IP65 enclosure rating, ¼ in. male NPT process connections, and 14 to 140°F temperature limit. Read More
