Strain Gages
(Showing headlines 1 - 11)
|
 Pre-Wired Strain Gages require no soldering at measuring point.Omega Engineering, Inc.
Stamford, CT 06907
Apr 24, 2013
Fully encapsulated for protection from environment, KFH Series features 50 mm PTFE cable before transitioning to AWG 28 leads to prevent leads from adhering during installation. Linear gages are available with 0.3–20 mm grids, while XY gages and 0°/45°/90° planar rosettes have 0.6–6 mm grids. Featuring rugged polyimide carrier, series is suited for R/D and automotive industries where stress analysis of suspension components is necessary.
|
 Strain Gauge features rugged, all-welded design.NIAGARA METERS
Spartanburg, SC 29306
Jun 13, 2011
ForceMeter strain gauge is designed to sense force of fluid in flow stream. It has 2-line display for showing flow rate and total measurements, and also features no-friction moving parts and all-welded construction. Suitable for water, compressed air, and super-heat saturated steam applications, unit is HART-compliant and FM approved for use in hazardous locations.
|
 Optical Strain Gage comes in rosette form.HBM, Inc.
Marlborough, MA 01752 3014
Oct 14, 2010
Based on fiber Bragg gratings, Model K-OR uses light to measure strain instead of electrical signals. Unit comes in rosette form comprising 3 measuring grids at angles of 0, 60, and 120° to sense strain as it occurs, allowing absolute value and direction of mechanical stresses to be defined. Measuring 43 x 47 mm, K-OR enables tests of up to 10 million load cycles with strain of ±5.000 µm/m. Unit is suited for potentially explosive atmospheres and areas where there is high voltage or EMI.
|
 Optical Strain Gage survive extreme environments.HBM, Inc.
Marlborough, MA 01752 3014
Feb 19, 2010
Based on fiber Bragg gratings, K-OP type optical strain gage (SG) suit material tests of new fiber composites. Tests with up to 10 million load cycles with alternating strain of ±5.000 µm/m are possible. As no electric signal is required, utilization in environments with explosive atmospheres, EMI, or high voltage is possible without difficulties. Several optical SGs can be attached to fiber, enabling implementation of parallel measurements.
|
 Optical Strain Gage comes with plastic encapsulation.HBM, Inc.
Marlborough, MA 01752 3014
Jun 09, 2009
With ability to make sensors highly resistant to mechanical damage, optical K-OP strain gages reach 10 mil stress cycles in continuous vibration behavior with alternating strain of ±3.000 µm/m. Unit is available with data sheet containing necessary data, such as gage factor for strain measurements. It is suited for measurements in hazardous areas and in high current and voltage engineering components.
|
 Strain Gauges optimize PCB production quality.HBM, Inc.
Marlborough, MA 01752 3014
Mar 11, 2009
At 1.2 x 2 mm, Y series micro-strain gauges detect mechanical stresses that occur during production of complex PCBs. They attach directly to board to monitor levels, which are 850 µm/m for unpopulated PCBs and around 450 µm/m for populated boards. Measurements can be obtained during production processes including depanelization, plug assembly, in-circuit testing, and installation as well as in solder bath. Units are available in linear and rosette form.
|
 Strain Gages are rated up to 1,800°F.Vishay Intertechnology, Inc.
Malvern, PA 19355 0988
Feb 18, 2004 High-Temperature, Weldable Strain Gages are free-filament wire units pre-bonded to shim stock with flame-sprayed alumina. Bonded wire design resists fatigue, making gages suited for dynamic, impact, or vibratory strain measurements. Devices come with choice of Nichrome V or Pt8W sensor alloys and either of 2 types of pre-attached, high-temperature, insulated cable. All feature nominal resistance of 120 ohms and sensor gage length of 0.25 in. |
 Strain Gages offer ±5,000 microinch/in. strain range.Vishay Intertechnology, Inc.
Malvern, PA 19355 0988
Feb 17, 2004 Sealed Weldable Strain Gages are pre-bonded with adhesive to thin, 0.005 in. stainless steel carrier. Each is fully encapsulated with protective coat for moisture resistance. Three leadwire configurations are available to provide best fit for application, environment, or installation. All units feature nominal resistance of 350 ohms, nominal gage factor of 2.0, gage length of 0.125 in., and shielded vinyl leadwire. Operating temperature range is 32–180°F. |
 Strain Gage Interface Card handles 4- and 6-wire circuits.HBM, Inc.
Marlborough, MA 01752 3014
Aug 07, 2002 AP815, for single strain gages, allows connection of quarter bridges in 4-wire circuit, and half and full bridges in 6-wire circuit. With half bridges, card allows active and compensation strain gages to be arranged separately, and corrects voltage loss at connecting line. Five excitation voltages are available, providing measuring range of 8 to 80 mV/V and 0 V listening mode to assess line noise. Internal shunt resistor per channel is switchable upon user demand.
|
 Target Flow Meter withstands 100% over range.Aaliant Fluid Measurement Solutions
Spartanburg, SC 29306
Jun 24, 2002
Strain Gage Target Flow Meter accurately measures flow of liquid, gases, and superheated and saturated steam from -320 to +500°F and up to 15,000 psi. It has no frictional moving parts and has been tested to over 100 million full-scale flow cycles with no measurable effect on performance. Mounting options including inline, insertion and sanitary models.
|
Interface Card inputs strain gauges.HBM, Inc.
Marlborough, MA 01752 3014
Nov 19, 2001 AP810 card allows 8 strain gauge half or full bridges to be connected in regulated 6-wire circuit. Excitation points are equipped with sense lines so cable effects are fully compensated. All 8 channels operate simultaneously, so there is no scanning and no multiplexing. Card has digital filtering for synchronous channel operation. Bessel and Butterworth filters are available, and measurement frequency is variable between 0.05-500 Hz. |
(Showing headlines 1 - 11)
|
