Servomex Company, Inc.    Sugar Land, TX 77478
Mar 15, 2011 Available for SERVOTOUGH 2700A1, 2700A2, 2700B1, and 2700C1 Fluegas Combustion Gas Analyzers, sulfur-resistant Combustibles Sensor Upgrade Kit enables Tfx sensor to operate at elevated temperature, optimizing performance in high-sulfur applications, where excess levels of SO2 can inhibit traditional catalytic sensor function. Sensor upgrade will also maximize longevity and minimize service downtime where SO2 levels generally exceed 1,000 ppm.

Mark-10 Corp.    Copiague, NY 11726
Mar 15, 2011 With capacities from 0.12-500 lb, sampling rate of 2,000 Hz, and accuracy of better than ±0.3% FS, Series 3 is designed for tension and compression force testing in QC, manufacturing, and R/D areas. Product integrates backlit graphic display and accommodates data output to PC via USB. Overload protected to 150% of capacity, handheld or test stand/fixture-mounted devices measure 2.5 x 3.9 x 1.5 in. and come with MESUR(TM) Lite basic data collection software for data tabulation/exporting.

MadgeTech    Warner, NH 03278
Mar 15, 2011 Featuring flexible piercing probe, RFOT wireless temperature data logger can be used in harsh environments in temperatures from -4 to +212°F. Splash-proof device withstands wash down cycles and can record and transmit internal product temperature readings back to central computer in real-time. Included software features programmable control points, which are automatically annotated on graph and tabular data views, while data can be exported to Excel® for further calculations.

Micro-Epsilon UK Ltd    Cheshire   United Kingdom
Mar 15, 2011 Offering 5-600 mm measurement ranges, optoNCDT 1402SC series comes in housing of corrosion-resistant V4A steel that provides class IP69K protection. Electronics operate with measuring frequency of 1.5 kHz, reaching linearity of 0.18% and resolution of 0.01%. Consumption level of 50 mA enables applications that involve wireless energy transmission to sensor. Design is resistant to high-pressure jet cleaning as well as aggressive detergents and disinfectants.

Micro-Epsilon UK Ltd    Cheshire   United Kingdom
Mar 15, 2011 Operating on time-of-flight principle, optoNCDT ILR 1030 offers measuring range of 0.2-8 m on diffuse reflective surfaces and up to 50 m when using reflector plate. Measurement speed of 100 Hz also enables length measurements with different objects in measuring range as well as reliable measurements on different target materials. Sensor measures with visible, class II laser pulse, is insensitive to external light influences, and can measure under artificial lighting.

Micro-Epsilon UK Ltd    Cheshire   United Kingdom
Mar 15, 2011 When measuring on metals, particularly annealing metals and organic materials such as wood, skin, foodstuffs, and veneers, Triangulation Sensors with Blue Laser technology do not penetrate measuring object. Laser generates minimal laser point on surface and therefore offers stable, precise results on measuring objects that are normally considered critical. In addition, sensors are equipped with high-end lenses, intelligent laser controls, and evaluation algorithms.

Mini-Circuits    Brooklyn, NY 11235
Mar 15, 2011 Measuring 4.89 x 1.74 x 0.95 in., Model PWR-2.5GHS-75 turns Windows® or Linux® PC into power meter. Pocket-sized HID requires no driver installation and is shipped with quick-locking USB cable for connectivity. Measurement Application GUI software, displaying numerical data and graphs, enables user to perform measurements on RF components such as couplers, filters, amplifiers.

Yamaha Corp. Of America    Buena Park, CA 90620
Mar 15, 2011 Housed in 2.0 x 2.0 x 0.8 mm package with I2C host interface, Model YAS530 features wide dynamic range of ±800 µT with resolution of 0.15 µT for X and Y axes and 0.3 µT for Z axis. Unit consumes 4 mA during operation and offers measuring time of 1.5 msec. Operating from -40 to 95°C, IC will have variety of uses, including navigation apps that require GPS, augmented reality maps, and games that utilize gyro sensor.

austriamicrosystems AG    Premstatten   Austria
Mar 14, 2011 Featuring automatic power-down and wake-up modes, AS5050 operates from 3.3 V power supply and is used for contactless position sensing. Single-chip solution integrates 4 Hall sensor elements, one 10-bit angle encoder, one smart power management controller, and one 3- or 4-wire SPI communications interface in one 4 x 4 mm QFN-16 package. Depending on readout rate, current consumption is reduced to µA levels; typical current drain is 50 µA at 10 measurements/sec.

Honeywell Sensing and Control    Golden Valley, MN 55422
Mar 11, 2011 Equipped with on-board signal conditioning, ASDX/ASDX-DO Series are used with non-corrosive, non-ionic working fluids, such as air and dry gases. Units are fully calibrated and temperature compensated for sensor offset, sensitivity, temperature effects, and non-linearity using on-board ASIC. Featuring compensated analog output, ASDX Series provides ratiometric 12-bit analog output, while ASDX-DO Series with compensated 14-bit digital output provides I2C or SPI digital interface.

Maxim Integrated Products    Sunnyvale, CA 94086
Mar 11, 2011 Model 78M6613 enables capture and reporting of real-time energy data, which allows datacenter managers to manage and control energy usage. Accurate to ±0.5% over 2,000:1 dynamic range, it includes tools for self-calibration as well as AC load monitoring. Unit integrates range of AC power diagnostics, including power, power factor, voltage current, voltage sag, and dip. Single-phase, self-contained IC has 32-pin QFN package with on-chip Flash and MCU for storage of calibration coefficients.

MadgeTech    Warner, NH 03278
Mar 11, 2011 Offering 2-way communications, splash-proof RFOT is suited for smoke houses, ovens, and other cooking processes up to 212°F as well as refrigerators and freezers down to -4°F. It records and transmits internal product temperature readings back to central computer for real-time monitoring. Able to withstand washdown cycles, logger is equipped with flexible piercing probe, stores each reading to internal memory for backup, and offers user-programmable critical control points.

Novotechnik U.S., Inc.    Southborough, MA 01772
Mar 11, 2011 RSM 2800 Series supplies absolute position values and rotational counts up to 16 turns without mechanical gearing, batteries, or optics. Non-contact sensors permanently store shaft rotation as well as position when power is lost. When power is restored, units automatically provide accurate position and count. Measuring 30 mm in dia with 6 mm dia shaft, sensors offer independent linearity up to ±0.25%, electrical range up to 5,400°, and repeatability of ±1 LSB.

Atmel Corporation    San Jose, CA 95131
Mar 09, 2011 With integrated non-volatile registers and 2, 4, or 8 Kb of Serial EEPROM memory, AT30TS750 Series allows for user-configured settings to be retained across power cycles. Units feature ±0.5°C accuracy, user-selectable 9-12 bit resolution, and temperature range of -40 to +125°C. Sensors can directly control other circuits in system to offload requirements in MCU. Equipped with I2C/SMBus compatible serial interface, ICs are suited for consumer, industrial, computer, and medical applications.

ITW Muller    Arlington Heights, IL 60004
Mar 09, 2011 OctoMAX(TM) system includes hardware and software to monitor and measure stretch wrapping equipment and film effectiveness. It also ensures that optimal settings, pre-stretch gears, number of wraps, and amount of film are set at all times. System is connected through Internet and machine or film problems are relayed to user via email, and are also available on system's operator interface. Users can also visit personal online portal to view historical data and download reports.

BlueLevel Technologies, Inc.    Rock Falls, IL 61071
Mar 09, 2011 Able to detect presence/absence of material as lightweight as 0.624 lbs/ft³, VHS Vibrating Fork operates with dry and free-flowing powders as well as granular materials to provide level control. Piezoelectric technology creates harmonic vibration in absence of material, and vibration is dampened when material is present at single-element probe. Components include AC/DC power supply, SPDT relay, bi-color LED indicator, stainless steel wetted parts, and NEMA 4X enclosure.

CSI Controls    Ashland, OH 44805
Mar 08, 2011 Designed to mount on 4 in. electrical conduit, AlarmBot(TM) outdoor post alarm features factory-sealed weatherproof enclosure that helps prevent gases and moisture from entering system. As level in tank rises to activate high water alarm float, clear beacon illuminates 360° by 4 alternating red flashing LEDs and 95 dBA audible alarm sounds. Alarm can be silenced using on/test/silence switch. Operating on 12 V, pump and alarm power can be separated.

Columbia Research Labs., Inc.    Woodlyn, PA 19094
Mar 08, 2011 Suited for downhole well service applications, SA-220RHT and SA-225RHT Force Balance Accelerometers are completely self-contained and provide high level, low impedance output, eliminating need for high-temperature signal conditioning. Model SA-220RHT operates from +15 Vdc at temperatures up to 200°C, while Model SA-225RHT requires +5 Vdc and operates to 190°C. Weighing 3.34 oz, biaxial accelerometers are packaged in nickel-plated aluminum cases measuring 1.13 in.² x 2.285 in. H.

Enmet Corp.    Ann Arbor, MI 48106
Mar 08, 2011 With internal sample draw pump and gas sensors, microprocessor-based GSM-60 is designed for industrial process, aerospace, pharmaceutical, and semiconductor applications. It can be custom configured for monitoring combination of gas parameters, including VOCs, dew point, oxygen, and CO, or other target gases, such as O3, HF, HCl, Cl2, etc. Optionally, instrument may be connected to range of remote 4-20 mA toxic or combustible gas sensors/transmitters.

Applied Measurements Limited    Aldermaston, Berkshire RG7 8PN  United Kingdom
Mar 07, 2011 Based on battery-powered, 2.4 GHz wireless telemetry data acquisition and transmission system, Model DTDR-F is intended for rotating applications up to 6,500 rpm where direct, in-line torque measurement is desired. System has pair of balanced Delrin housings, one containing telemetry module and another containing 3.6 V Li-Ion battery that is recharged in-situ. With 120 m range, T24-SA telemetry module achieves 650 hr/27 day battery life based on continuous use at transmission rate of 1/sec.
