Shaft Grounding Products deliver reliable bearing protection.

October 14, 2015

Protecting against electrical discharge machining (EDM), Smart Shaft Grounding combines Current Diverter Ring® technology and other features. Providing voltages with low impedance path to ground away from bearings while monitoring grounding effectiveness increases motor reliability. Products – Smart™ CDR®, Smart™ MGS®, and Smart Ground Monitor™ –provide permanent protection from conduction-inhibiting shaft oxidation and offers continuous monitoring and feedback of shaft grounding performance. Read More

Safety & Security Equipment

Foot Grounder converts non-ESD footwear to ESD footwear.

March 5, 2015

Constructed of non-marring, tear- and chemical-resistant, TPE material, stat-A-Rest™ consists of static dissipation unit sole that securely affixes to bottom of wearer's footwear through elastomer perimeter attachment system. This product, as alternative to strap-type products and ESD shoes, provides full coverage with contact points on sole and heel area. Walking voltage generation is <50 V, and point-to-groundable point resistance is <1 x 109 ohms. Read More

Safety & Security Equipment, Computer Hardware & Peripherals, Electrical Equipment & Systems

Panel Mount USB Cables feature ground wires.

November 24, 2014

Offered in 0.3, 0.5, 0.75, 1, 2, and 3 m lengths and suited for use inside box or enclosure, USB 2.0 panel mount cables are available with ground wire for option of electrically grounding USB female connector to panel or enclosure. Molded, panel-mountable construction features 20 AWG power conductors and 28 AWG twisted pair data conductors all under double shield for maximum EMI resistance. Cable is light gray, and each assembly includes two 4-40 x 3/8 in. Phillips pan head mounting screws. Read More

Safety & Security Equipment, Test & Measuring Instruments, Sensors, Monitors & Transducers

Shaft Grounding/Monitoring Ring serves critical applications.

July 22, 2014

Featuring real-time functionality, AEGIS® iPRO-MR combines shaft voltage bearing protection with continuous monitoring of shaft voltage levels from remote location. Assembly features 8 rows of conductive microfiber: 6 provide bearing protection, while 2 isolated rows allow for voltage monitoring. Combined shaft grounding ring and shaft monitoring ring promotes uptime and reliability of motors and generators in critical applications. Read More

Safety & Security Equipment, Material Handling & Storage, Electrical Equipment & Systems

Custom Grounding Cables/Clips promote workplace safety.

May 13, 2014

Able to be built to customer specification or in accordance with regulatory compliance requirements, custom grounding cables and clips help prevent generation of electrical sparks caused by static electricity. Hand clamp and alligator clip cables come in multiple lengths, in both insulated and non-insulated versions, with copper or stainless steel wire construction. Terminal end options include solid copper or steel clips, steel ground clamps, and solid copper lugs in various sizes. Read More

Safety & Security Equipment, Test & Measuring Instruments, Transportation Industry Products, Vision Systems, Computer Hardware & Peripherals, Mechanical Components & Assemblies, Electrical Equipment & Systems, Sensors, Monitors & Transducers, Mechanical Power Transmission, Electronic Components & Devices, Green & Clean, Display & Presentation Equipment

Flashing Dome LED Beacon Lights suit AC or DC applications.

April 10, 2014

Offering IP23 protection and vibration resistance, Models XPE and XME provide brightly colored triple-flash sequence that illuminates at 110 flashes/min, making them suited for indoor mobile equipment. XPE model measures 162 mm dia x 203 mm tall and has high-impact, heat-resistant ABS resin body, while XME version, made of stainless steel with melamine baked finish, is 187 mm in dia x 239 mm tall. Typical current consumption ranges from 0.07 A for 230 Vac models to 0.42 A for 12 Vdc models. Read More

Safety & Security Equipment, Optics & Photonics

Combination IR Window/Ultrasound Port meet global demand.

December 30, 2013

Leveraging multi-technology approach, CAP-4-US permanent electrical safety device (PESD) enables electricians to find failure points in critical electrical assets, such as transformers and switchgear, before failure can occur. Solution is available with transparent or opaque polymer, both of which comply with all mandatory impact, load, and flammability requirements. This industrial-grade IR window meets OSHA NFPA 70E requirements for arc flash safety. Read More

Safety & Security Equipment, Electrical Equipment & Systems, Mounting & Attaching Products

Clip-On Grounding/Shielding Strips come in custom lengths.

December 4, 2013

Fingerstock product, Edge Guide Clip-on Strip, offers optimal grounding/shielding contact from PCB to card guide on rack or housing inside electronics. Snap-in feature of contact fingers prevents any potential snagging, allowing for bidirectional sliding contact along edges. Strip, made from BeCu, is available with various plating options, including tin or nickel. While compression forces facilitate card installation, customizable length options afford flexibility in design phase. Read More

Safety & Security Equipment, Electrical Equipment & Systems

VFD Cable features 3 insulated symmetrical grounds.

July 24, 2013

Designed to connect power from drives to motors, 1 kV DRIVEFLEX® A220 VFD Cable features 3 symmetrical ground design that minimizes stray currents in motor shaft and bearings. Cable includes flexible XLPE conductors, non-wicking fillers, dual layer shield for optimal EMC results, and specially formulated jacket for oil resistance. Compliant with NFPA 79 for wiring of industrial machinery, sunlight-resistant, direct burial cable is suitable for dry, damp, or wet conditions. Read More

Safety & Security Equipment, Fasteners & Hardware

Split Grounding Bushings eliminate rework.

December 5, 2012

Available in trade sizes from ¾–4 in., Mighty-Rite® SGB Series helps contractors safely install electrical systems. Units can be installed before pulling wire or after, eliminating rework. This feature also makes pulling larger conductor wire easier when contractors can install grounding bushings after pull. Equipped with 150°C rated liner, cULus Listed bushings feature captive screws and hinged design that adjusts and aligns, even in tight spots. Read More

Safety & Security Equipment, Electrical Equipment & Systems

XLPE VFD Cables feature 3 symmetrical grounds.

November 20, 2012

With 3 symmetrical grounds, DRIVEFLEX® A219 Series minimizes stray currents in motor shaft and bearings. In addition to thick wall insulation RHW-2 for added safety in wet and dry conditions, cables feature dual layer shield with foil and braid combination for EMC compliance. Flexible materials allow 7.5 OD bending radius for routing of conductors within cabinet. For code compliance and added protection against high-voltage spikes, cables have 2,000 V Flexible VFD and Servo Cable UL listing. Read More

Safety & Security Equipment, Materials & Material Processing

Hazardous Area Static Grounding System protects portable equipment.

September 8, 2011

Intrinsically safe Earth-Rite TELLUS® II offers static ground monitoring for drums, IBCs, and other mobile or portable equipment during hazardous area operations. Operating in real-time, system confirms that positive connection to ground remains intact for duration of operation. As long as resistance of connection to designated ground remains below 10 ohms, green pulsing LED display inside hazardous area assures operator that there is no buildup of dangerous static electricity. Read More

Safety & Security Equipment, Green & Clean, Mounting & Attaching Products

Solar Mounting Systems also serve as grounding devices.

July 14, 2011

Polar Bear® FR Gen II and Grizzly Bear® FR Gen II ballasted commercial flat roof solar mounting systems address varied roof conditions and project requirements via features such as 5° tilt option, inter-row spacing selections, and wavy-roof friendliness. These solar racking solutions, which are UL 2703 certified electric grounding and bonding devices, also deliver thermal compensation via a-thermalized deflector and integrated recycled rubber roof protection pad. Read More

Safety & Security Equipment, Material Handling & Storage

Self-Retracting Cable Reel suits static grounding applications.

June 30, 2011

Housed in powder-coated steel, Model VESM02 provides static ground protection for difficult field applications such as tanker trucks, rail cars, IBCs, and mobile tanks or drums. NEMA 4/IP56-rated unit is fitted with 50 ft of Cen-Stat(TM) Static-Dissipative Hytrel(TM) protected cable with adjustable ball stop, which is held under constant tension by spring/auto-locking device. Main cable is pre-terminated by additional 10 ft of 2-conductor cable to facilitate connection to Earth-Rite grounding system. Read More

Safety & Security Equipment

Grounding Station operates in flammable or explosive atmospheres.

March 16, 2011

Made of SS304L stainless steel, Cen-Stat(TM) Grounding Station provides extra margin of safety when operations in flammable or explosive atmospheres make static electricity significantly hazardous. Product provides identifiable location for effective grounding path while also reminding operators of safety issues. Integral signs - Danger Static Hazard and Attach Grounding Clamp - are included, and product is linked to reliable grounding path. Design accommodates 2 grounding clamps. Read More

Safety & Security Equipment, Mounting & Attaching Products

Grounding Ring protects motors against electrical damage.

February 2, 2011

AEGIS(TM) SGR Bearing Protection Ring prevents electrical fluting damage in bearing, bearing noise, and downtime by safely channeling VFD-induced bearing currents to ground. AEGIS(TM) Universal Mounting Kit (U-Kit) includes AEGIS grounding ring and mounting hardware for most motor designs. Ordered based on NEMA u shaft diameter, kit contains the correct size ring for motor and 4 styles of brackets with bolts and lock washers that can be used in various configurations. Read More

Safety & Security Equipment

Electronic Grounding System provides failsafe tanker truck loading.

September 15, 2010

Before allowing loading or unloading of flammable or combustible liquids, gases, and powders from tanker truck, Earth-Rite® RTR(TM) Static Grounding System provides confirmation of connection to static dissipative ground point and continuous electronic verification of less than 10 W connection to that point. It also provides specific tanker truck recognition. Operating from -13 to +131°F, system features NEMA 4X corrosion-resistant XP enclosure for harsh environments. Read More

Safety & Security Equipment, Electrical Equipment & Systems

Grounding System facilitates process of making earth connection.

July 20, 2010

Suited for grounding connections in areas with limited visibility or accessibility, ground|mate(TM) conserves time to make earth connection by plugging into threaded bolt without requiring any tooling. Radsok contacts, offering contact-covering up to 65%, provide minimal contact resistance, while click|fit locking system ensures connection stability during vibration and shock. Grounding system is designed for threaded bolt sizes M6 or M8 as well for pins with diameter 3.6, 6, or 8 mm. Read More

Safety & Security Equipment, Material Handling & Storage

Static Grounding Clamp serves mobile/portable equipment.

January 18, 2010

Bond-Rite(TM) intrinsically safe, hazardous area grounding clamp protects against static electricity build-up in mobile/portable equipment. It creates and continuously monitors low-resistance connection to ground, which is visually verified via flashing LED. Integrated electronic module enables up to 12 months of service between lithium battery changes, based on typical duty cycle of 3 hr/day, and inline Quick-Connect feature facilitates replacement of clamp and retractable cables. Read More

Safety & Security Equipment, Test & Measuring Instruments, Sensors, Monitors & Transducers

Multipurpose Grounding System protects sensitive electronics.

August 12, 2009

Performing in any type of soil condition, TerraDyne® Electrolytic Grounding System (EGS) provides long-term protection from lightning strikes, electrical transients, static discharges, electro-magnetic interference, and other electrical hazards threatening sensitive electronic equipment. Offered in vertical and horizontal models, UL- and cUL-listed system is corrosion-resistant and produces effective, stable, year-round ground reference. Read More
