ESD Protection Devices use multi-layer ceramic technology.

June 19, 2015

Supplied in 1005 and 0603 packages, respectively, Models LXES15AAA1-153 and LXES03AAA1-154 combine low voltage ESD protection with dielectric strength to withstand continued high voltage discharge. Units offer ESD protection according to internationally recognized IEC61000-4-2 Level 1 standard at low voltage and low peak voltage levels. Operating from -40 to +85°C, devices are suited for automotive electronics, antenna terminals, and external interfaces of touch panels, monitors, and switches. Read More

Chemical Processing & Waste Management, Materials & Material Processing

Wet Electrostatic Precipitator controls fine particulate.

June 16, 2015

Incorporating discharge electrode technology that can be sized to specific applications, HEI Wet Electrostatic Precipitator concentrates high-intensity ionizing corona in strategic areas within collecting tubes instead of distributing it along entire length of tubes' treatment area. Resultant particle charging fields are stronger than conventional precipitators and deliver higher particulate charges and migration velocities, as well as smaller size for gas capacities from 1,000–300,000 acfm. Read More

Chemical Processing & Waste Management, Fluid & Gas Flow Equipment, Materials & Material Processing

Air-Purge Jacket keeps temperature sensor lenses clean.

January 20, 2015

Designed to work with IRt/c and Micro IRt/c.4 sensors measuring 3/8 in. dia x 3 in. long, Micro Clean Micro Air-Purge Jacket prevents oil, dust, condensation, and other debris from obscuring lens and degrading sensor readings. Miniature-sized lens and efficient jacket design make it possible to clean surface with as little as 0.06 cfm of air, and to use instrument air, eliminating need for additional hardware. In addition to keeping lens clean, jacket cools sensor, allowing operation up to 347°F. Read More

HVAC, Materials & Material Processing

Long Static Eliminator neutralizes and cleans wide surfaces.

January 16, 2015

Available in one-piece construction with lengths from 60–108 in., Long Super Ion Air Knives neutralize static electricity while blowing away dust and particulates from wide webs and other surfaces. Laminar airstream, full of static eliminating ions, ifs effective up to 20 ft away, and materials off construction include aluminum as well as 303 and 316 stainless steel. Operating effectively down to 5 psig, solid state product has adjustable and shockless design. Read More

Fluid & Gas Flow Equipment, Materials & Material Processing

Static Eliminators neutralize and clean wide surfaces.

January 15, 2015

Available in lengths from 60–108 in., Long Super Ion Air Knives feature one-piece construction, ensuring seamless airflow and eliminating coupling of multiple short-length air knives together. Units neutralize static electricity while blowing away dust and particulates from wide webs and printed surfaces, paper, plastics, wood, acrylic, and 3-dimensional shapes. Made of aluminum, 303 SS, or 316 SS, air knives operate down to 5 psig and provide optimal cleaning up to 20 ft away. Read More

Electronic Components & Devices, Materials & Material Processing

ESD Protection Diode protects high-speed interfaces.

December 4, 2014

Built to protect equipment attached to communication lines, Model DF5G7M2N shields high-speed interfaces such as USB3.1, HDMI®, DisplayPort™, and Thunderbolt™ from static electricity. Device can also protect small portable devices such as smartphones and tablets from ESD events. Housed in 1.3 x 0.8 mm DFN5 package, diode realizes low capacitance of 0.2 pF by optimizing process, suppressing signal quality deterioration, and providing ESD resistance. Read More

Electrical Equipment & Systems, Electronic Components & Devices, Materials & Material Processing

Circuit Protection Diode protects 2 CAN bus lines.

November 18, 2014

Providing >25 kV ESD protection, PESD2CAN is suited for assembly line automation, access control systems, and machinery. Component is compatible with IEC standards 61000-4-2 (ESD): air 15 kV, contact 8 kV; with 61000-4-4 (EFT): 40 A, 5/50 ns; and with 61000-4-5 (surge): 4 A, 8/20 µs. Provided in molded JEDEC SOT-23 package, RoHS-compliant diode operates from -55 to 150°C and features 200 W of peak pulse power per line. Read More

Mechanical Power Transmission, Materials & Material Processing

Power Transmission Belt features antistatic design.

November 7, 2014

Capable of maintaining static conductivity to ISO 9563 levels, Poly Chain® Carbon™ Volt™ Belt is engineered to minimize safety risks in explosive environments. Static-conductive fibers safely transfer static to carbon tensile cords and away from driven side of power transmission for safety in unstable settings. Polyurethane belt is suitable for use in volatile environments such as oil and gas refineries, chemical processing plants, and grain silos. Read More

Electronic Components & Devices, Green & Clean, Materials & Material Processing

PPTC/Zener Diode Devices protect consumer electronics.

November 5, 2014

Combining Zener diode and resettable PolySwitch PPTC device in 4.0 x 5.0 x 1.2 mm package, PolyZen ZEN056V230A16YC and ZEN056V260A16YC simultaneously protect against damage from overload, overcurrent, reverse-bias, ESD, and overtemperature events. Hybrid units offer up to 2.6 A hold-current at room temperature, ±30 kV ESD protection, and 8/20 µs pulse = 150 A overvoltage protection to help meet IEC standards. Applications include tablets, set-top boxes, hard disk drives, and DC power ports. Read More

Safety & Security Equipment, Materials & Material Processing, Non-Industrial Products

ESD Control Smocks identify visiting personnel.

November 4, 2014

Made of polyester with 9% carbon conductive nylon fibers, Trustat White ESD Control Smocks have VISITOR dye sublimated on back to identify visiting personnel. Panel-to-panel resistance is 1 x 105 to < 1 x 109 Ω tested per ESD TR53. Available in XSmall, Small, Medium, and Large, USA-made smocks have snapping cuffs for adjustment. Read More

Electrical Equipment & Systems, Sensors, Monitors & Transducers, Materials & Material Processing

Static Grounding Relay helps control ignition risk.

October 13, 2014

Featuring HAZLOC-approved, Intrinsically Safe-certified circuit, Earth-Rite® OMEGA II monitors resistance of circuits designed to ground equipment subject to electrostatic charging. Adjustable resistance monitoring settings of 2, 4, 10, and 600 Ω accommodate requirements of diverse applications. While 2-pole FM-approved static grounding clamps and Cen-Stat™ grounding cable connect relay to hazardous area equipment, internal 2 dry changeover contacts allow interlocking with process equipment. Read More

Materials & Material Processing

ESD Training Paddles demonstrate electrostatic principles.

September 25, 2014

Portable 06850 ESD Training Paddles can be used for demonstrating several electrostatic principles: static electric fields, polarity, field suppression, neutralization, field induction, and field induced discharges. Able to generate static electric field charge of several kilovolts, paddle kit consists of one insulative plate and one conductive plate. Both are isolated with insulative handles and feature 3 x 4 in. surface (aluminum and acrylic). Read More

Plant Furnishings & Accessories, Materials & Material Processing

Workstation Covers protect products from ESD.

September 23, 2014

Made of polyester fabric with minimum 9% carbon conductive nylon fibers, ESD Workstation Covers protect products from ESD, dust, and other contaminants. Surface resistance is 1 x 105 < 1 x 107 Ω RTT to attenuate electrostatic fields and electrostatic discharges. Available in 18 x 24, 36 x 48, and 48 x 48 in. sizes, covers feature built-in continuous and consistent charge dissipation. Attached 3/8 in. snap allows covers to be grounded to workstation's ground point. Read More

Electronic Components & Devices, Materials & Material Processing

Automotive Varistors protect electronics against ESD.

August 29, 2014

Featuring multilayered varistor technology, ChipGuard® Automotive MLA Series protects automotive electronics from threat of ESD up to IEC 61000-4-2 Level 4. Bidirectional devices with insulating overcoat provide overvoltage protection and stable low leakage performance over operating temperature of -55 to +125°C. With response time of less than 0.5 ns, varistor clamp protectors meet ESD protection needs of HDMI, CANbus, Ethernet, sensor, and touchscreen interfaces as well as GPS and camera links. Read More

Materials & Material Processing

Mini Ionizer covers 6 x 24 in. area.

July 10, 2014

Designed to neutralize electrostatic charges on insulators and ungrounded conductors, Mini Zero Volt Ionizer 2 provides air flow from 33–51 cfm and decay times as low as 1.6 sec at 12 in. Steady-state DC operation offers ±5 V offset voltage balance, while solid tungsten emitters maintain sharp points for optimum performance. Measuring 5.3 x 3.5 x 1.7 in., ionizer is housed in stainless steel with shielded bearings, and is suited for small spaces such as environmental chambers. Read More

Materials & Material Processing, Non-Industrial Products

Pocket Protectors fit ESD smock pockets.

July 2, 2014

Available in sizes to fit both breast and hip pockets of smocks, ESD Pocket Protectors hold pens and other implements as well as cards and notes while protecting pockets from ink and other damage. Products are made of clear static dissipative PVC with Rtt of 1 x 106 to <1 x 1,011 Ω per ANSI/ESD STM11.11. ESD Protective Symbol is imprinted on front. Read More

Chemical Processing & Waste Management, Green & Clean, Materials & Material Processing

Wet Electrostatic Precipitator controls fine particulate.

May 28, 2014

Incorporating unique discharge electrode technology that can be sized to specific applications, HEI Wet Electrostatic Precipitator System concentrates high intensity ionizing corona in strategic areas within collecting tubes instead of distributing it along entire length of tubes' treatment area. Ultimix™ Conditioning System provides gas saturation and collection tube cleaning, while patented RotaBed™ Pre-Scrubber facilitates acid removal and particulate loading reduction. Read More

Electronic Components & Devices, Materials & Material Processing

ESD Protection Diode is designed for automotive CAN bus lines.

May 20, 2014

Supplied in molded JEDEC SOT-23 package, PESD1CAN provides ESD circuit protection of >25 kV for CAN_HI and CAN_LO bus lines as well as other automotive applications and offers overvoltage circuit protection against electrical fast transients (EFTs). Rated stand-off voltage is 24 V, min breakdown voltage is 25.4 V, and max clamping voltage is 70 V. Compatible with various IEC standards, RoHS- and REACH-compliant diode features 200 W peak pulse power per line for typ 8/20 µsec waveshape. Read More

Materials & Material Processing

Silicon ESD Devices offer 20 kV air discharge rating.

March 28, 2014

Exhibiting ±20 kV and ±22 kV air discharge ratings, SESD Series helps designers solve pervasive protection challenge caused by charged board events. Products come in uni-directional and bi-directional configurations with input capacitance of 0.30 and 0.15 pF, respectively. Clamping voltage of less than 15 V helps facilitate fast turn-on time and minimize energy let-through to sensitive down-stream chipsets. Surge capability is 2.2 A for 4-channel array and 2.5 A for 1- and 2-channel devices. Read More

Materials & Material Processing

Ionizing Bars eliminate static across large production lines.

January 21, 2014

Featuring compact profile that fits in confined spaces of machinery where static charge is generated, electrically powered Long Ionizing Bars eliminate static on paper, film, and plastics that are up to 96 in. wide. High concentration of positive and negative ions produce fast static decay, neutralizing any surface within 2 in. of bar. Life expectancy has been extended by insertion molding stainless steel ion emitters into durable plastic.   Read More
