Wire-to-Board Connector connects multiple coax cables in one step.

March 24, 2015

Reducing vehicle roof antenna installation time, GT36 Series provides one-step connection of multiple coaxial cables to PCB. Internal solution specifically enables attachment of 4 coaxial lines to automotive antennas, including shark fin antennas, and features rugged positive lock structure that offers lock strength of 98 N. RoHS- and ELV-compliant product has rated voltage of 50 Vac, rated current of 1 A, contact resistance of 50 mΩ max, and insulation resistance of 100 MΩ min at 500 Vdc.
Read More

Electrical Equipment & Systems, Electronic Components & Devices

Pressurized Connectors conform to IP68 without internal O-rings.

June 23, 2014

Available in 2.92 mm, 3.5 mm, SMA, TNC, and Type N series connector types, pSeries has 3-piece design – body, center contact, and dielectric –that eliminates need for internal O-rings, gaskets, and silicone greases. Seal integrity exceeds 10-5 cm³/s when tested under 30 psi pressure of alcohol per STI 8.2.4-13. Coaxial connectors provide low-loss, high-stability performance through 30 GHz at ±65 psi and meet MIL-STD 202 Method 212, Condition D (+125°C fluorocarbon leak), test conditions.
Read More

Electronic Components & Devices

Low Loss Bias-Tee supports military tactical booster amplifiers.

March 10, 2014

Supplied in treated aluminum enclosure that meets IP67 standards, AR-RBT Remote Bias-T combines RF signals and DC power onto single coax cable. Product lets military warfighter use single KMW1031 (20 W), AR-50 (50 W), or AR-75 (75 W) power amplifier (PA) to be located remotely using single RF coax cable, eliminating need to transport multiple copper DC power lines to remote amplifier. Product withstands hostile environments and handles up to 1,000 V spikes during thunderstorms. Read More

Computer Hardware & Peripherals, Electrical Equipment & Systems, Electronic Components & Devices

Coaxial Cable Assemblies suit in-building DAS applications.

March 4, 2014

Intended for Distributed Antenna Systems, Coaxial Cable Assemblies efficiently transfer RF signal, minimize interference caused by intermodulation, fit into tight spaces, and are plenum-rated to meet building fire codes. Times Microwave SPP-250-LLPL™ consists of small diameter corrugated cable, while TFT-402-LF is extremely flexible with low minimum bend radius. Available in standard and custom lengths, cables offer 7-16 DIN male, 4.1-9.5 DIN male, N male, and SMA male terminations. Read More

Electronic Components & Devices

Medium and High Power RF Loads operate to 18 GHz.

February 25, 2014

Offered in 25, 50, and 100 W models, RF Loads are available with many connector configurations, including male and female versions of SMA, N, TNC, and 7/16 DIN. Models rated to 25 and 50 W operate to 18 GHz, with exception of 7/16 DIN version, which is rated to 8 GHz. All 100 W loads also operate to 8 GHz. Manufactured with black anodized aluminum cooling fins for convection cooling, coaxial terminations operate from -55 to +125°C and require no additional heat sink. Read More

Computer Hardware & Peripherals, Electrical Equipment & Systems, Electronic Components & Devices

Coaxial Products (7/16 DIN) serve high-power applications.

December 31, 2013

Designed for use in high power wireless communication systems, such as cellular network antenna systems, 50 Ω 7/16 DIN coaxial products include connectors for 400 and 600 series low loss cable, within series and interseries adapters, caps, 400- and 600-series cable assemblies, as well as 1/4 wave coaxial lightning protectors. Construction withstands harsh environments, and custom versions of cable assemblies are available. Read More

Electrical Equipment & Systems, Electronic Components & Devices

Multi-Pin Connectors suit applications up to 600 Vac/Vdc.

November 25, 2013

Designed to safely connect and disconnect power, control, and instrumentation equipment, M-Line™ Multi-Pin Connectors include MEP Series for hazardous ATEX/IECEx locations and MN Series for heavy-duty but non-hazardous environments. Both provide plug-and-play operation as well as IP68 environmental protection. Connectors are available in standard and custom configurations, combining wide range of conductor numbers and sizes, contact materials, and termination options. Read More

Electrical Equipment & Systems, Electronic Components & Devices

Hi-Rel Connectors come in horizontal and coax types.

August 15, 2013

In addition to 41 other configurations available as standard, off-the-shelf items, Datamate Mix-Tek mixed-technology series includes 2 mm pitch horizontal format and coax contact versions. Units feature power contacts rated up to 20 A, signal contacts rated up to 3 A, and 50 Ω coax contacts rated at 6 GHz. Moldings are polarized and carry UL94V-0 rating. Hexagonal slotted jackscrews are offered across range. Read More

Electrical Equipment & Systems, Electronic Components & Devices

N Male Connectors simplify installation on coax cables.

August 2, 2013

Simplifying installation of RF connectors onto high-performance coax cable, RFN-1006-49I with solderless captive pin and RFN-1006-4I with crimp pin eliminate need to trim braid during cable prep. Combination hex/knurl coupling nuts allow tightening by hand/wrench, while white bronze plating eliminates tarnishing, promotes electrical performance, and reduces PIM (Passive Intermodulation). VSWR of <1.10:1 up to 3 GHz and <1.20:1 up to 8 GHz is achieved through impedance matching design. Read More

Health, Medical and Dental Supplies & Equipment, Electrical Equipment & Systems, Electronic Components & Devices

Combo D-subminiature Connectors feature non-magnetic design.

February 18, 2013

Comprised of copper alloy shells, tin-plated brass hardware components, and die cast zinc brackets, Combination D-Subminiature Connectors are designed for medical imaging equipment. Units come in 21 standard pin configurations and can include signal, high power, or coaxial contacts, which are available in 50 or 75 Ω versions. Offered with 4-40 UNC or M3 threaded inserts, RoHS-compliant connectors feature power rating from 10–40 A and temperature range of -40 to +105°C. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Electronic Components & Devices

Interface System supports RF performance from DC to 40 GHz.

January 16, 2013

Intended for subminiature, RF coaxial cable-to-board and board-to-board applications, 50 Ω SMP Interface System features VSWR of 1.18 max at 40 GHz. Male PCB connectors are available in vertical surface mount, vertical surface mount through-hole, and edge mount configurations. Three levels of detent are available, each with different engage and disengage coupling forces. Cable ended SMP female connectors accommodate 0.047, 0.085, and 0.086 dia semi-rigid or conformable coaxial cable. Read More

Electronic Components & Devices

Precision Coaxial Termination covers frequency from DC-67 GHz.

August 31, 2012

Featuring passivated stainless steel body with center contact made of gold-plated and heat-treated beryllium-copper material, Model T5M offers max VSWR of 1.2 from DC-40 GHz and 1.43 from 40-67 GHz. Termination has 2.4 mm male connector and measures 0.84 x 0.36 in. in diameter. Unit is useful when terminating unused ports, on isolated ports of hybrids and combiners, and to protect devices from signal reflections. Read More

Electronic Components & Devices

BNC Coax Connector mounts vertically or horizontally to PCBs.

April 19, 2012

Developed for employment with PCMICA cards in wireless applications, 50 ohm BNC E-Snap(TM) conectors have small protrusions within slot to allow devices to snap firmly into solder-pasted holes as they are slid onto PCB. Construction promotes board retention and RF performance without use of adhesives. Suited for dense packaging arrangements, miniature connectors have gold-plated contacts, come in male or female versions, and offer repeatable performance to 18 GHz standard or 20 GHz optional. Read More

Electrical Equipment & Systems, Electronic Components & Devices

VGA Connector enables keystone integration.

March 29, 2012

Featuring field terminated screw terminal design, VividVGA Connector eliminates need for crimping and soldering and minimizes signal degradation and shorted terminations. Connector is backwards compatible and supports WUXGA video signal transmission over UTP/STP CATx and mini-coaxial cable up to 10 ft and 50 ft respectively. XGA transmission coverage extends to 20 ft and 160 ft, respectively. Read More

Electrical Equipment & Systems, Electronic Components & Devices

Edgeboard Connector features bottom shielding.

December 19, 2011

For optimal performance through 18 GHz, V-Bite(TM) RF Edgeboard Connector comes in bottom-shielded female Type N model designed to eliminate inductance by shielding open bottom. Connector snaps onto PCB prior to hand or reflow soldering, and is supported from below and above board to disperse rotational torque relief, minimizing rotational stress on solder area. Offered in impedance of 50 W, Type N V-Bite(TM) is suited for joining coaxial cables in high-power RF applications. Read More

Electronic Components & Devices

Coaxial Connectors feature maximum profile of 1.0 mm.

April 20, 2011

Suited for various mobile devices, JSC series connectors feature board-mounted, 2 x 1.8 x 0.5 mm receptacle that mates with 0.81 mm dia RF cable. Mated height of receptacle and cable plug is 1.0 mm maximum. Product withstands up to 30 mating cycles and emits audible click on connecting. Connector and cable structure supports RF performance up to 12 GHz and voltage standing wave ratio of 1.3 GHz up to 3 GHz, 1.4 GHz between 3-6 GHz, 1.5 GHz between 6-9 GHz, and 1.6 GHz between 9-12 GHz. Read More

Electrical Equipment & Systems, Electronic Components & Devices

Double Ended Connector is suited for data/signal transmission.

January 13, 2011

Designed to take voltages up to 7 kV, double ended HN Connector has glass ceramic insulator and current rating of 2.5 A. It suits high frequency signal transmission or fast rise time pulses for data transmission. Ceramaseal® products include industry-standard coaxial connectors, ranging from Microdot through SHV. Coaxial connectors, manufactured for high and ultra-high vacuum service, are available with or without air side plugs and come in grounded and floating shield versions. Read More

Electrical Equipment & Systems, Electronic Components & Devices

Sealed Interconnect Systems withstand harsh environments.

December 6, 2010

Made of highly resistant aluminum, Fischer UltiMate(TM) Original Series of connectors and cable assemblies withstand severe environmental, industrial, and chemical conditions. One-piece plug body contains epoxy potting and is IP68/69K sealed, even when unmated. Push-pull connector is available with multi-pole contacts from 2-42 poles. Able to withstand temperature fluctuations from -55 to +135°C, units include 360° EMC shielding and visual coding to prevent misconnection. Read More

Electrical Equipment & Systems, Electronic Components & Devices, Mounting & Attaching Products

Polarized Plugs and Connectors carry 10 A, 600 V rating.

July 21, 2010

Weatherproof when caped or mated, molded rubber 8-wire, 10 A, polarized plugs and connectors are available with 14 AWG cable and have max rating of 10 A, 600 V. Industrial-/commercial-grade quick disconnect connectors, suited for power/control applications, are molded to heavy-duty, 8 conductor, 600 V SOOW cable in solid Hypalon Rubber, UL/CSA-Rated to UL 94 V-0 in all colors. Specific products include 8MP-10 Male and 8FP-10 Female models. Read More

Electrical Equipment & Systems, Electronic Components & Devices

Plenum BNC Connectors are designed for CCTV systems.

June 29, 2010

Constructed of nickel-plated brass for corrosion resistance and field durability, 75 W RG-59 and RG-6 connectors cover dual-shield Plenum-rated coaxial cables with compression-style sleeve that adapts securely to wide range of outer jacket cable diameters. Gold plated center and outer contacts provide electrical performance with frequency range up to 3 GHz, while colored cable bands allow for easy coding of video signals. Tight fit stops moisture from entering into cable. Read More
