Diodes

Electrical Equipment & Systems, Electronic Components & Devices, Vision Systems, Display & Presentation Equipment

LED Task Lights help reduce energy expenditure.

April 24, 2015

Available in swivel head, high-intensity fixed focus head, and slim aluminum lamp head models, Sirrus Industrial Grade LED task light offers 25,000 hr-rated alternative to fluorescent lighting in diverse applications. Design allows adjustment to facilitate examination and inspection of close-up work, and 19.5 in. industrial grade flexible arm is coated for protection against permeation by dust and liquids. While metal mounting clamp is supplied as standard, magnetic base is optional. Read More

Electrical Equipment & Systems, Electronic Components & Devices, Vision Systems

Automotive LEDs combine efficacy and sulfur resistance.

April 17, 2015

Satisfying automotive application demands, golden Series specifically suits head lamp, DRL, fog lamp, side signal lamp, and rear tail lamp applications. Golden lead frame models A09KU, 67-21U, and 67-31U, deliver sulfur resistance that promotes performance stability. PC Amber LEDs feature 3 chip manufacturing process that results in brightness decay minimized to 15% at 85°C. All products comply with AEC-Q101. Read More

Electrical Equipment & Systems, Electronic Components & Devices, Vision Systems, Display & Presentation Equipment

LED Gooseneck Lamp illuminates instrumentation, cargo bay areas.

April 16, 2015

Constructed of aluminum and designed for harsh environments, NVIS Gooseneck Map Light features MIL-DTL-D38999/20 connector and firm, 10 in., flexible gooseneck for flexible lighting placement. Various lighting colors are available as options to standard MIL-STD-3009 NVIS/NVG-compatible white led lighting (45 lm), which is produced using 20 NVIS/NVG LEDs. While product offers full 0%–100% dimming control, light output remains constant during any voltage swing from 18–34 Vdc. Read More

Electronic Components & Devices, Vision Systems

IR Emitters reduce component count while increasing intensity.

April 15, 2015

Comprising one leaded 5 mm IR emitter with parabolic lens and 8 SMD devices in 0805, PLCC-2, top-looking and side-looking packages, high-speed 940 nm IR emitters employ SurfLight™ surface emitter chip technology. Emission of nearly all light and power from top of chip results in radiant intensity ratings up to 600 mW/sr (leaded) or 10–120 mW/sr (SMD). Respectively, angles of half intensity for leaded and SMD devices are ±3° and ±9° to ±60°. Rise and fall times are 10 nsec. Read More

Electrical Equipment & Systems, Electronic Components & Devices

Flexible Light Pipes feature anodized aluminum body.

April 9, 2015

With NEMA 4 rating, ESD protection, and resistance to shock and vibration, FLXR Series litepipes™ are suitable for harsh conditions and outdoor environments. Optical core ends are polished to 10 microns for optimal light transmittance. For brightest light output, narrow viewing angle non-diffused LEDs with output greater than 100 mcd can be used. Available in lengths from 4–12 in., series has 0.400 in. mounting hole and 3 LED connection options using SMD 22, THR 22, and THR 5 22 connectors. Read More

Vision Systems, Labels, Tags, Signage & Equipment, Electronic Components & Devices, Display & Presentation Equipment, Electrical Equipment & Systems, Green & Clean, Retail & Sales Equipment

Backlit Light Box uses LED strips for efficient illumination.

March 27, 2015

Used for marketing, advertising, or visual display, LED Indoor Backlit Light Box with LED Strips comes in 2,700 lm (standard output) and 7,300 l (high output) options. Indoor options for ADA-compliant frame design include hinged side access Standard Slim Line aluminum frame and snap open Front Access aluminum frame.  Depth is 2 7/8 in., and graphic sizes are available up to 48 x 96 in. For outdoor conditions, Backlit Light Box comes in weatherproof, locking, Hidden Hinge Frame design. Read More

Electrical Equipment & Systems, Electronic Components & Devices, Vision Systems, Display & Presentation Equipment

LED Closet Lighting Kit can be trimmed to needs on site.

March 27, 2015

Available for new or existing residential or commercial closets and storage locations, clear anodized aluminum LED Closet Rod Light Kit comes with closet rod, LED ribbon flex lighting strip, and 2 mounting brackets. Supplied lengths of 3, 4, and 5 ft can be trimmed as needed in 2 in. increments while on job site. Delivering cool white (6,500K) light with 120° beam spread and ~50,000 hr bulb life, kit also supports various options: power supply, IR door sensor, and manual on/off switch. Read More

Electronic Components & Devices, Electrical Equipment & Systems

BiSy Single-Line ESD Protection Diode conserves board space.

March 26, 2015

Supplied in 0.6 x 0.3 x 0.27 mm package, VBUS05B1-SD0 protects high-speed data lines and antennas in mobile devices against transient voltage signals. Leads length and package size minimizes inductance, allowing fast transients, such as an ESD strike, to be clamped with minimal overshoot/undershoot. Properties include 0.29 pF typ load capacitance (0.4 pF max), <0.1 µA max leakage current at 5.5 V working voltage, 8.8 V typ breakdown voltage at 1 mA, and 18 V max clamping voltage at 2.5 A. Read More

Electrical Equipment & Systems, Electronic Components & Devices, Vision Systems

Explosion Proof LED Light features pole top slip fit mount.

March 25, 2015

Providing 13,000 lm while drawing 150 W, Model EPL-PT-150LED-RT features adjustable swivel bracket constructed of 3/8 in. aluminum that allows 270° of adjustment and is attached to slip fit yoke for installation. Unit has copper-free aluminum alloy body that is powder coated for durability, and heat dissipating design that helps achieve 60,000 hour rated lifespan with 80% lumen retention. IP67-rated LED flood light is universal voltage capable and can be operated with 100–277 Vac. Read More

Electrical Equipment & Systems, Electronic Components & Devices, Vision Systems

LED String Light Set utilizes rechargeable battery bank.

March 25, 2015

Designed for portability within job site, 300 W Model WAL-RPS-WBC-2XSL10.5-LED includes 30 LED lamps producing combined 31,500 lm of light. Each 10 W bulb screws into molded E26 lamp socket and is enclosed in bird cage style plastic guard. String light system is powered by 140 Ah rechargeable battery bank mounted within wheelbarrow-style cart, which allows system to be used as source of emergency lighting during power outages or in remote locations without primary power sources. Read More

Electrical Equipment & Systems, Electronic Components & Devices, Vision Systems, Green & Clean, Display & Presentation Equipment

Non-Dimmable Retrofit LED Lamps come in 277 V versions.

March 24, 2015

Leveraging chip on board LED package to optimizes lumen output, LED PAR30 and PAR38 lamps are offered in 3000K and 4000K color temperatures and rated for 25,000 hr lifetime at L70 standards. Lamps are suited for retrofitting recessed, track, and other lighting fixtures operating on 277 V electrical systems; can also be used in damp locations; and operate from -4 to +104°F. While 17 W PAR38 delivers up to 1,800 lm with 40° beam angle, long neck 13 W PAR 30 produces up to 1,200 lm.
Read More

Optics & Photonics, Electronic Components & Devices

High-Power Pulsed Laser Diode Module is used for optical testing.

March 23, 2015

Designed for use in optical spectrum analyzers (OSAs) and optical time domain reflectometers (OTDRs) for optical testing applications, SCW 1632-350R operates at 1,625 nm and features optical power of 350 mW typ. Ridge waveguide (RWG) Fabry-Perot (FP) laser diode, housed in 14-pin butterfly package, is optically coupled to single-mode fiber (SMF) pigtail and includes thermoelectric cooler (TEC) and electrically isolated, temperature-sensing thermistor. Read More

Electrical Equipment & Systems, Electronic Components & Devices

LED Work Light features quadpod-mounted design.

March 23, 2015

Equipped with 400 W LED light, Model WAL-LQP-400LTL-LED provides 20,000 ft² of work area coverage with 52,000 lumens of light. IP67-rated waterproof light tower has removable light head assembly mounted on top of 4-legged quadpod equipped with solid wheels for portability. Adjustable quadpod can be extended to 9 ft and collapsed to 5 ½ ft. Supplied with 100 ft of SOOW cord, light features heavy-duty aluminum construction and stainless steel hardware. Read More

Electronic Components & Devices

Miniature Point Source LEDs deliver precise performance.

March 16, 2015

Designed for high-speed optical encoders, linear positioning, optical switch, and critical sensing applications, 650 and 850 nm Point Source LED series are available in PLCC-4 and miniature ceramic packages. LED die and optical-grade glass lenses produce narrow, near parallel radiation pattern. Arrangement eliminates dark spot typically associated with center of LEDs. Through-hole package options include hermetically sealed TO-18 and TO-46 metal cans with various lensing options. Read More

Electronic Components & Devices

High Temperature 80 V Quad Diode operates from -55 to +225°C.

March 13, 2015

In hermetically sealed TDFP16 ceramic package, CHT-ELARA includes 4 independent and dielectrically isolated diodes that can be connected in series, in parallel, or in rectifier bridge. Each individual diode can sustain 80 V reverse voltage and has max forward current of 900 mA at 225°C. Diodes have junction capacitance of 15 pF at 25 V reverse voltage, forward voltage of 0.33 V for forward current of 1 mA at 225°C, and leakage current limited to 2 µA at 80 V reverse voltage and 225°C. Read More

Electrical Equipment & Systems, Electronic Components & Devices

TVS Diode Arrays protect low-voltage CMOS devices.

March 12, 2015

Protecting Ethernet and WAN/LAN equipment, switching systems, and computers from effects of ESD and lightning-induced transients, SLVU2.8-8 Series comprises 2.8 V, 30 A TVS Diode Array (SPA® Diodes). Capacitance of 2.6 pF per line preserves signal integrity and minimizes data loss, while dynamic resistance of 0.3 Ω optimizes clamping voltage for sensitive chipsets. AEC-Q101-qualified products safely absorb repetitive ESD strikes at ±30 kV and dissipate up to 30 A with low clamping voltages. Read More

Transportation Industry Products, Electrical Equipment & Systems, Vision Systems, Electronic Components & Devices

LED Round Bollard Lights feature aluminum cones reflectors.

March 11, 2015

Featuring 15 W LED arrays with Samsung LED chips, LED Round Flat Top and Dome Top Bollards with Aluminum Cone produce 2,089 lumens with CRI of 83, suitable for illuminating walkways, streets, and driveways of residential and commercial areas. LEDs are mounted in head of bollard, facing down with wide beam spread to effectively light surrounding area. Treated with chromate conversion coating, extruded aluminum housing withstands elements and is CSA listed for wet locations. Read More

Electrical Equipment & Systems, Electronic Components & Devices, Vision Systems, Green & Clean, Display & Presentation Equipment

LED High Bays deliver 140 lumens per watt efficacy.

March 10, 2015

Available for 120–277 V and 347–480 V applications and other product variants, Vigilant® H2 Series comprises IP66-rated LED high bay lighting fixtures capable of delivering ~25,000 lm output with 140 lm/W efficiency. UL1598A-certified and CE-compliant design incorporates proprietary reflector technology, tempered glass lens, and power supply in durable and lightweight (18 lb) package. Ambient temperature operation range is -40 to +65°C.

Read More

Electrical Equipment & Systems, Electronic Components & Devices, Vision Systems, Green & Clean

Linear LED Luminaire suits open ceiling environments.

March 3, 2015

Available in 4, 8, and 12 ft modular sections, Corelite RZL LED Suspended Luminaire provides 5 light level options ranging from 3,000/30 W to 8,000 lm/84 W. Direct/indirect LED continuous row system provides efficacies surpassing 100 lm/W and offers choice of 5 shielding variations to fit different architectural styles and preferences. Equipped with 0–10 V continuous dimming driver, luminaire maintains greater than 70% of initial light output after 60,000 hr of operation. Read More

Electronic Components & Devices

ESD Protection TVS Diode Arrays target fast-charging peripherals.

February 11, 2015

Supplied in 1.8 x 2.0 x 0.55 mm µDFN-6 package, AEC-Q101 qualified SP1255P Series offers 0.3 Ω dynamic resistance and suits such applications as fast-charging peripherals or PoweredUSB. Integration of 3 channels of steering diodes with TVS diode maximizes ESD protection of USB data and ID pins per IEC 61000-4-2 standard. Allocated for Vbus protection, high surge current protection device with working voltage of 12 V protects against lightning level fast transients up to 100 A on USB Vbus line. Read More
