Scintera Networks Inc.    San Jose, CA 95129
Apr 13, 2012 Supplied in 64-pin, 9 x 9 mm QFN package, SC1889-00B11 RF Power Amplifier Linearizer (RFPAL) with integrated dual-RMS power measurement unit (PMU) lets designers reduce size, power, and design cycles in 3G and 4G RF cellular infrastructure systems. PMU provides data as digital codes for export, and simultaneous dual-RMS power detector provides typical absolute accuracy of ±0.1 dB over first 20 dB of input range and ±0.5 dB over last 10 dB of input range for PA lineup input and output.

Basler Electric Co.    Highland, IL 62249
Feb 16, 2012 Combining microprocessor-based platform, fiber optic rectifier bridge firing control, and online maintenance-capable rectifier bridges, Model DECS-2100 provides excitation currents up to 10,000 Adc on systems ranging from 1-1,300 MW. BESTCOMS(TM)Pro GUI software is used for configuring, monitoring, and maintaining control system. Through USB port or optional Ethernet port, local communication between controller and PC operating with BESTCOMSPro software is possible.

Texas Instruments, Inc. (TI)    Dallas, TX 75243-4136
Nov 04, 2011 Supplied in 3 x 3 mm VQFN package, bq25504 manages microwatts to milliwatts of power generated from solar, thermoelectric, electromagnetic, and vibration sources and stores extracted energy in elements such as Li-ion batteries and super capacitors. Included circuitry helps protect energy storage element from over and under voltage conditions as well as kick-start system when battery is deeply discharged. While typ quiescent current is 330 nA, conversion efficiency is greater than 80%.

Texas Instruments, Inc. (TI)    Dallas, TX 75243-4136
Oct 28, 2011 Supplied in 12 x 12 mm, automotive-qualified, 169-ball nFBGA package, TPS658629-Q1 provides all power supply functions and reduces board space for infotainment, navigation, and LCD/TFT cluster applications. Components include 3 DC/DC buck converters, 11 LDOs, 4 programmable PWM outputs, 2 RGB LED drivers, and one WLED driver. I²C interface enables control of subsystem parameters, and internal registers have complete set of status information.

austriamicrosystems AG    Premstatten   Austria
Oct 18, 2011 With start-up configuration programming capability, AS3710/11 can be adapted to various processors as well as for last minute changes or fine tuning without design re-spin. Both models include 3 DC/DC, 4 MHz, step-down converters; 2 DC/DC, step-up converters; 8 LDOs; 4 GPIOs; 1.5 A charger; I²C interface; 3 current sinks; ADC; watchdog timer; and RTC. While AS3710 adds third booster, AS3711 adds 3 A step-down converter. Configuration options include selecting linear or switching charging.

Server Technology, Inc.    Reno, NV 89511
Oct 07, 2011 Sentry Power Manager (SPM) v5.0 and v6.1 firmware for intelligent cabinet (CDU) power distribution units (PDUs) optimize data center power management. SPM serves as primary interface to any number of PDUs in data center. As Web 2.0-compliant UI and middleware solution, it provides actionable, real-time data and integration with all major components in systems management and data center infrastructure management (DCIM) spaces.

Texas Instruments, Inc., Semiconductors    Dallas, TX 75243
Jul 22, 2011 Offered as standalone device, bq77910 offers protection and cell-balancing for 4- to 10-cell Li-Ion and lithium iron phosphate battery packs. IC monitors individual cell voltages and drives 2 N-channel power MOSFETs to interrupt current flow during fault conditions. Criteria for fault detection and recovery is fully programmable in non-volatile memory. Product simplifies battery pack designs for e-bikes, e-scooters, portable gardening tools, power tools, and UPS.

The Modal Shop, Inc.    Cincinnati, OH 45241
Jul 01, 2011 By integrating solid-state power amplifier, SmartShaker(TM) K2007E01 can be driven directly from any sound source. Unit provides force rating of 7 lbf with ½ in. usable stroke and 92% efficiency, contributing to precise modal testing or vibration studies. Model K2007E01 includes flexure suspension arms built from carbon fiber composite and EasyTurn handles for shaker positioning. Multiple gain settings and system mute are selectable via integrated digital control.

National Semiconductor Corp.    Santa Clara, CA 95051-0695
Jun 30, 2011 Featuring on-chip PMBus support, Models LM5066 and LM5064 operate over input voltage ranges of 10-80 V and -9 to -80 V, respectively. Integrated system protection and management blocks precisely measure, control, and manage electrical operating conditions in systems such as routers, switches, and base stations. Both models have selectable 25 mV/50 mV current limit thresholds for addressing wide range of intermediate bus voltages and load currents.

Mitsubishi Heavy Industries America    Leetonia, OH 44431
Jun 22, 2011 Capable of storing up to 408 kWh of power, Energy Storage System consists of 40 ft long container unit, which houses more than 2,000 units of Li-Ion rechargeable batteries, and 20 ft long container unit with 2 power conditioners for DC/AC conversion and I/O control. System offers 90% efficiency and can be moved by container trailers. Applications include large-scale outdoor events, construction sites, and mobile power charge stations for electric vehicles.

Maxim Integrated Products    Sunnyvale, CA 94086
Jun 21, 2011 Compatible with energy harvesting sources with output levels from 1 µW to 100 mW, MAX17710 integrates all power management functions for ambient energy harvesting as well as charging and protecting micro-energy cells (MECs). IC incorporates programmable input boost regulator and does not require any external components to charge MEC with energy sources as low as 0.8 V. Also, adjustable LDO with selectable voltages of 3.3, 2.3, or 1.8 V allows IC to adapt to various loads.

austriamicrosystems AG    Schloss Premstaetten A 8141  Austria
May 11, 2011 Supplied in 40-pin, 5 x 5 mm QFN package, AS3605 integrates 7 LDOs, one DC/DC converter, complete battery charger, LED backlight driver, and audio power amplifier. PMIC is specified for operation from battery supply range of 3.0-5.5 V over ambient range of -40 to +85°C and software-programmable startup sequences provide operational flexibility. Controlled via serial interface, product also integrates all necessary system specific functions, such as Reset, Watchdog, and Power-On Detection.

GE Co.    Southfield, MI 48034
Mar 08, 2011 Ruggedized and conduction-cooled, SPR870A integrates Xilinx® Virtex(TM)-6 FPGA technology that enables deployment in wideband signal acquisition and conversion applications such as radar ECM (electronic counter measures), pulse intercept and analysis, and RF test. This 3U VPX digital receiver/exciter can digitize analog input signals from below 50 MHz to over 1.5 GHz using dual-channel, 10-bit ADC and two 12-bit DACs and create analog output waveforms over similar frequency range.

Fujitsu Semiconductor Europe GmbH    Langen D-63225  Germany
Feb 09, 2011 Operating at 6 MHz, Model MB39C326 switches automatically between buck operation when battery is fully charged and boost operation as battery is discharged, maximizing battery's overall operating voltage and providing stable power supply to power amplifier. Power management IC provides up to 800 mA of output current over input voltage range of 3.1-4.6 V. Housed in 20-pin 2.15 x 1.94 mm WL-CSP, device features built-in FET, over-temperature protection, and input-under-voltage lockout.

Summit Microelectronics, Inc.    Sunnyvale, CA 94085
Feb 07, 2011 Used for powering multi-rail digital chipsets, SMB109 offers multiple DC/DC outputs with digital power management/monitoring and non-volatile system configuration. IC integrates 8 outputs, 3 current-mode buck controllers, one LDO controller, and 4 load switch controllers with digital I²C interface in 7 x 7 mm QFN-56 package. Able to be configured during development and re-programmed in-system by host software, product supports pulse skipping mode and 300-1,200 kHz switching frequency.

Texas Instruments, Inc. (TI)    Dallas, TX 75243-4136
Dec 20, 2010 Supplied in 3 x 3 x 1 mm monolithic QFN package, SWIFT(TM) TPS54618 synchronous switcher integrates two 12 mW FETs and achieves 95% power efficiency over full load. Current mode control enables external compensation and flexible component selection, while synchronized switching frequency from master clock eliminates beat noise in sensitive DAQ circuitry. With 200 kHz to 2 MHz switching frequency range, PMIC features 2.95-6 V power stage input range.

Power Integrations, Inc.    San Jose, CA 95138
Dec 13, 2010 Targeting up to 3.2 W portable device chargers and adapters, LinkZero(TM)-LP integrated offline switcher IC automatically enters zero-input-power mode when load is disconnected. EcoSmart technology, in combination with said proprietary power-down mode, brings no-load power consumption to 0.00 W and eliminates no-load waste without requiring mechanical switch. Conversely, device automatically restarts when load is detected. Operating frequency (100 kHz) minimizes charger size.

Wolfson Microelectronics plc    Edinburgh EH11 2QB  United Kingdom
Oct 04, 2010 Supplied in 8 x 8 x 0.85 mm QFN package that enables 4-layer PCB manufacturing, WM8325 serves as power management subsystem for portable multimedia applications. It has 4 programmable DC/DC converters, including one that delivers up to 2.5 A, and 11 LDO regulators. On-chip regulator provides power for always-on PMIC functions and also offers autonomous backup battery switchover. Other features include 12-bit auxiliary ADC, OTP non-volatile memory, XO, and internal RC oscillator.

Linear Technology Corp.    Milpitas, CA 95035
Sep 02, 2010 Housed in 4 x 7 x 0.75 mm QFN package, Model LTC3675 features 7 independent rails, with I2C control and fault monitoring. Device contains 4 synchronous step-down regulators, buck-boost regulator, synchronous boost regulator, dual-string 40 V LED driver, and always-on LDO. Pushbutton ON/OFF/RESET control, precision enable inputs, and power-on reset output provide flexible power-up sequencing. With all DC/DCs off, quiescent current is only 16 µA to maximize battery run time.

Quicklogic Corporation    Sunnyvale, CA 94089
Aug 17, 2010 Designed for inclusion in Customer Specific Standard Products, Frame Recycler Proven System Block allows handheld mobile system developers to conserve significant battery life. System removes display refresh responsibilities from CPU when no change in display content is present, allowing CPU to operate in power-down state until next change of display content is requested. Applications include e-readers, tablet computers, smartphones, and notebook computers.
