Union Process, Inc.    Akron, OH 44313
May 11, 2012 Using disc/rod design for optimal grinding efficiency, DMQX(TM) can produce materials in single micron and even nanometer range using circulation grinding. Benefits include ability to continuously monitor slurry, add ingredients to premix tank at any time during grinding cycle, and precisely control temperature. Operating in circulation or continuous mode, mill features cartridge-type double mechanical seal, adjustable product discharge openings, and heavy-duty media separator.

Meese Orbitron Dunne Co.    Ashtabula, OH 44004
May 01, 2012 Rotationally molded from HDPE with internal rib design, Poly-Trux® P-405 Heavy Duty Tilt Trucks have powder coated steel support frame and base that safely accommodate up to 1,300 lb of material. Units roll and steer on two 10 in. rear wheels and 2 swiveling front, non-marking casters. Available with optional tow hitches, hinged lids and nylon dust covers, tilt trucks are suited for collection and transfer of bagged refuse, office waste, recyclables, and scrap.

Aqueous Technologies Corp.    Chino, CA 91708
Apr 13, 2012 Used with batch-format or inline defluxing systems, EcoCycler provides capture, filtration, re-deionization, and reuse of rinse water. Low and high level float switches allow for automatic water replenishment and protection against dry-run operation. Constructed of corrosion-resistant welded polypropylene, EcoCycler has built-in stainless steel recirculation/filtration pump that directs waste rinse water through dual particulate filters, and carbon and resin media tanks.

Alstom Power Inc., Air Preheater Co., Raymond Operations    Lisle, IL 60532
Mar 14, 2012 Used for production of powders used in fillers, coatings, and pigments, Raymond® Ultra Fine Mill offers flexibility to deliver powders as fine as 50% passing 2 microns or as coarse as 50% passing 10 microns. Shaft rotates convex rolls inside concave grinding rings to reduce materials in multi-stage process, and air flowing within mill carries ground material through classification process to achieve desired fineness. Grinding elements can be adapted to meet product size specifications.

Maguire Products, Inc.    Aston, PA 19014
Jan 09, 2012 Featuring 2-stage operation, Purging Recovery System(TM) first slices or planes rock-like purgings into small pieces, then reduces pieces to uniform regrind. System is applicable to flexible vinyl, which stretches when worked by cutting blades and can jam conventional granulators. In addition, system can process shear-sensitive polymers like polystyrene, which can melt as frictional heat builds up in standard equipment.

Munson Machinery Co., Inc.    Utica, NY 13503
Dec 26, 2011 With infinitely variable rotor speed from several hundred rpm to 5,400 rpm, 34 in. sanitary stainless steel model CIM-34-SS performs coarse to fine grinding (down to 400 mesh) of friable powders, flakes, and granules into controlled particle sizes. Desired particle size distribution is obtained by controlling rotor speed, and vertically orientated mill housing minimizes footprint while fostering access to all product contact surfaces for cleaning/inspection.

REVEND RECYCLING LIMITED    Kenley.Surrey   United Kingdom
Dec 15, 2011 Complying with EU and USA environmental and recycling standards, reVend® Reverse Vending Recycling Machine provides automated collection and recycling of domestic light bulbs, including incandescent, CFL, and LED bulbs. Automated soft drop system lowers light bulbs into special collection container, while internal mercury fume extractor and filter absorbs/removes any escaped mercury fumes. With optional add-on unit, system can also collect and recycle domestic batteries.

Munson Machinery Co., Inc.    Utica, NY 13503
May 17, 2011 Model SCC-15-B has rotor design consisting of cutter heads attached to helical array of staggered holders that shear oversize materials against twin, stationary bed knives. Cutter tips, available in stainless steel, tool steel, and tungsten carbide, slide onto blade holders and are secured with one retaining socket-head screw. Perforations of bed screen range from 1/32 to 1½ in. in dia and up to 3 in. square, enabling reduction of materials into uniform particle sizes down to 20-30 mesh.

DELUMPER ® Div., Franklin Miller Inc.    Livingston, NJ 07039
Mar 08, 2011 Available in carbon steel or 304 stainless steel construction with one-piece body, DELUMPER® 1065N features 6 5/8 x 11 in. inlet opening and hardened alloy one-piece cutting drum fitted with over 200 tapered teeth. Outboard bearings are protected by shaft seals to keep powders within cutting chamber. Supplied with direct gear drive or belt drive as required, crusher handles compressed products, silver and other agglomerates, minerals, and plastics.

Phoenix Technologies    Bowling Green, OH 43402
Mar 03, 2011 With footprint of 1,000 ft², Recycled Polyethylene Terephthalate System uses virtually no water and only 2.3 million kWh of electricity annually. Small capacity system can produce up to 4 million pounds of rPET annually. LNO(TM) process, relying on extremely small particle size technology, enables efficient decontamination and produces rPET with optimal color and yield, suitable for variety of food and beverage applications and various package types.

GaiaRecycle    Palo Alto, CA 94301
Feb 09, 2011 During 8-11 hr processing cycle, Model G-300CD reduces animal carcass weight and volume by up to 75%, removes odors through 6-step deodorizer process, and produces sterilized compostable output material. System employs patented shredder and blade technology, accelerating organic decomposition process based on drying, sterilizing, and grinding waste. Capacities range from 66 lb to 2 tons/day for small and mid-size users and up to 100+ tons/day for large recycling plants.

Munson Machinery Co., Inc.    Utica, NY 13503
Nov 08, 2010 Model RDC1515-SS reduces agglomerates and friable materials discharged from process equipment, storage vessels, and shipping containers. Machine features 15 in. square inlet for material entry, and dual rotors with 3-point breaking heads, while on-size material exits through apertures in 1/32-2½ in. dia twin bedscreens. Measuring 11 in. high, unit is powered by 3 hp motor with gear reducer and serpentine timing drive. Product's synchronized shafts rotate at 100 rpm to avoid heating.

Munson Machinery Co., Inc.    Utica, NY 13503
Nov 02, 2010 Model RDC1515-SS Sanitary Lump Breaker reduces agglomerates and friable materials discharged from process equipment, storage vessels, and shipping containers. Unit has 15 in. square inlet for material entry, and dual rotors with 3-point, stainless steel breaking heads inside curved, perforated bedscreen. Material exits through apertures in 1/32-2½ in. dia twin bedscreens. Measuring 11 in. high, system is powered by 3 hp motor and is constructed of #304 stainless steel.

Appleton Mfg. Div., Productive Solutions, Inc.    Neenah, WI 54957
Oct 13, 2010 Customized per application requirements, Safe-Slab Core Recycler comes in light-, medium-, and heavy-duty variations that safely and automatically remove leftover roll material so cores can be reused. Blade-free slabbing and core recycling units handle rolls up to 32 in. dia, up to 96 in. long, and up to 1,000 lb. With variable unwinding speeds, unit plugs into any grounded 110 V electrical outlet, and compact design enables use in space-constricted areas.

Modern Process Equipment, Inc.    Chicago, IL 60623
Sep 02, 2010 Achieving 80-95% yields on wide range of target sizes, including 20 x 50, 30 x 80, and 80 x 325, Activated Carbon Gran-U-Lizer(TM) produces narrow particle size distribution with minimal fines. Unit adjusts configurations in seconds with touch of button. Offering capacities from 500-5,000 lb/hr, system is suited for coconut, coal, and wood-based carbon products.

Modern Process Equipment, Inc.    Chicago, IL 60623
Aug 31, 2010 Delivering uniform grind in 20 x 100 US Mesh size with minimal dust or by-product, Model 1052 SAP Gran-U-Lizer(TM) includes BAVA Balance and Vibration Analysis, which senses when product moisture levels elevate beyond tolerable range. When this occurs, product becomes elastic and does not grind efficiently. BAVA senses material elasticity change and notifies plant personnel. BAVA can also predict bearing failures before they occur, further optimizing operating efficiencies.

Schutte Buffalo Hammermill    Buffalo, NY 14240
Aug 19, 2010 Constructed from heavy-duty carbon steel with infeed widths from 6-60 in., Munitions Crusher processes brass and aluminum shell casings, weaponry ignition components, and ejection projectiles in accordance with U.S. military standards. Material fed into grinding chamber is pulverized by continuous high speed hammer blows until it is reduced to particle size that will pass through discharge screen. Processed munitions are thoroughly deformed and unable to be reconstituted.

UNTHA shredding technology    Kuchl A-5431  Austria
Jul 27, 2010 Specifically designed for wood, plastics, and paper recycling industries, VR Series features fail-safe cutting system, constant material feed, and maintenance-free pusher system. Touch screen panel simplifies operation, while gear unit, integrated into rotor, eliminates problems of shaft stubs. Drive design allows for high throughput with low drive power.

Cumberland Engineering Corp.    South Attleboro, MA 02703
Jul 20, 2010 Offered in 20 x 28, 20 x 36, and 20 x 48 in. sizes, CT500 Series is suitable for recycling of large containers and blow molded objects. Series includes 3- and 5-knife rotor models with 20 in. cutting circle for optimized part ingestion. Rotational end discs provide clean, dust-free granulation without angel hair or smearing. Safety interlocked, rear access hopper facilitates cleanout and inspection, while front hopper access door completely opens up for maintenance.

Precision Airconvey Corp.    Newark, DE 19702
Jun 14, 2010 TrimPAC(TM) series is available with steel platform, which features industrial strength, non-marking casters with brakes, that supports entire self-contained trim system. Mobile package permits installation of flexible, automated trim handling system that may be rolled from one press, slitter, or die cutter to another to accommodate changes in production demands. This frees operators to run materials that generate difficult waste streams on any suitable line.
