Skuttle Mfg. Co.
Marietta, OH 45750 8718
Dec 09, 2005 Humidifier Automatic Flushing Timer, Model S-HAFT, is used to flush accumulated mineral deposits from central-system steam- and reservoir-type humidifiers. Unit may be programmed to perform 10-, 20-, or 30-sec flushes at 2-hr intervals, using total of 1.5, 3.0, or 4.5 gal of water per day, respectively. Painted steel body measures 2 13/16 x 2 13/16 x 2 13/16 in., and installation package includes 15 ft of 3/8 in. ID tubing as well as mounting hardware.

Hoyt Electrical Instrument Works, Inc.
Penacook, NH 03303 8798
Sep 19, 2005 Multifunctional EZM-4450 (1/16 DIN), EZM-7750 (1/8 DIN), EZM-4950 (1/8 DIN), and EZM-9950 (¼ DIN) can count up on 1 or 2 channels or subtract one from the other. Equipped with two 6-digit displays and on-board sensor power supply, products accept NPN, PNP, encoder, or dry contact input signals; have 2 set points, and communicate via RS-232 serial communication (MODBUS) or optional RS-485. Time range is programmable from 0.01 sec to 999.99 hr.

Control Company
Friendswood, TX 77546
Aug 08, 2005 Traceable® Lab Timer allows programming of 3 different activities from 9 hr, 59 min, 59 sec to 1 sec with 0.001% accuracy. Each channel has distinct electronic alarm and display indicator, and alarm is turned off manually or silenced automatically after 1 min. Measuring 3 x 3 x 1 3/8 in., 4 oz timer has chemical-resistant ABS case and 4 digit LCD display. Applications include QA/QC times tests, pharmaceutical/food testing, and water analysis timing.

Amperite Co., Inc.
Union City, NJ 07087
Jun 08, 2005 Housed in hockey puck style package, Series ST1D utilizes CMOS digital circuitry and 1 form A adjustable switching device by means of 10-position DIP switch encoded in binary format. Continuous load current of 3 A is standard. Timing ranges include .2–102.3 sec in increments of 0.1 sec and 1–1,023 sec in 1 sec increments, both with timing accuracy of ±5% plus ½ increment. Series ST1D is available in 12, 24, 48, 110, and 120 V ac or dc voltages.

Control Company
Friendswood, TX 77546
Oct 13, 2004 Used to help catch all test results, Traceable® Big-Foot Timer signals drying and incubating times. It allows simultaneous programming of 3 activities from 99 hr, 59 min, and 59 sec to 1 sec on portable countdown alarm timer. Resolution is 1 sec, and accuracy is 0.01%. Each of 3 channels has distinct electronic alarm and display indicator when zero is reached. Measuring 4 x 4.5 x .75 in., product has 1 in. high LCD digits that may be read from 30 ft.

Wisconsin Oven Corp.
East Troy, WI 53120
Oct 13, 2004 Adjustable from 1 min to 99 hr and 59 min, Watch Dog Oven Management System displays time-in and time-out, along with time remaining and present date and time. It keeps track of elapsed time from date of shipment and accumulates time when oven is in operation. LCD indicates service intervals at 500 hr increments, prompting maintenance personnel to perform recommended service. Unit will dial up to 3 stored telephone or pager numbers to notify of malfunction.

Fargo Controls, Inc.
Eatontown, NJ 07724
Oct 01, 2004 Panel-mounted series CH and TH Counters and Timers include 7-digit LCD display with push-button reset. CH counters accept non-voltage contact closure/NPN open collector, PNP 6-24 Vdc or 90-240 V ac/dc inputs, and offer one count per pulse function. TH timers accept non-voltage contact closure/NPN open collector or 90-240 V ac/dc inputs, and are available with timing function of minutes or hours.

Control Company
Friendswood, TX 77546
Aug 18, 2004 Traceable® Double Display Timer allows simultaneous programming of 2 different activities from 20 hr to 1 sec with 1 sec resolution and 0.01% accuracy. Each channel has electronic alarm and display indicator when zero is reached. Alarm may be turned off or is silenced automatically after 1 min. Second display mode shows time of day and stopwatch for count-up timing. Featuring impact-resistant ABS case, timer may be used flat or in flip-open stand position.

Verif-i Limited
Reading RG4 9SJ  United Kingdom
Jul 09, 2004 GPS Synchroniser units connect to equipment that provides logic output in order to give time stamp to events using GPS timing as reference. Units can be used individually to derive absolute independent event time or in groups to compare timing of different remote events. Products feature backlit display and store results in 512 last in/first out non-volatile buffer that can then be read out using RS-232 serial cable. Time resolution is 1 microsecond, and accuracy is ±2 microseconds.

Crouzet North America
Vista, CA 92081-8430
Jun 02, 2004 Based on microprocessor with built-in flash memory, Series TMR 48 provides total of 18 functions, timing up to 300 hours, and 1 or 2 output relays in 8- or 11-pin versions. Large button sets operating time, which is read directly without need for conversion or calculation. All units are multi-voltage; 12-240 Vdc and 24-240 Vac.

IDEC Corporation
Sunnyvale, CA 94089-2209
May 26, 2004 With time ranges from 0.1 sec to 600 hours, RTE timer meets wide range of timing requirements. It has 10 A contacts and is rated for 100–240 Vac/dc, 24 Vac/dc, or 12 Vdc. Unit is UL listed and CE marked.

Dwyer Instruments, Inc.
Michigan City, IN 46361 0373
Feb 18, 2004 Intended for dust collection and pneumatic conveying control systems, Series DCT1000DC eliminates need for external devices such as pressure switches, relays, and timers. Indicating light on control board notifies operators when solenoid valve fails to operate. Controller accepts 10–30 Vdc and comes in 6, 10, and 22 channel models. Modular design allows for use as continuous cleaning control or on-demand cleaning control using optional DCP plug-in pressure module.

Carlo GAVAZZI Automation Components
Buffalo Grove, IL 60089
Dec 22, 2003 Packaged in 17.5 mm wide DIN rail mount housing, DMB51 Series is powered by 12–240 V AC/DC, offers one SPDT 8 A relay output, and provides timing ranges to 100 hr. Time delay functions include: delay on operate, interval, interval on trigger open, double interval, delay on release, and symmetrical recycler (with relay on or off first).

Autonics USA, Inc.
Vernon Hills, IL 60061
Dec 05, 2003 CT series counter/timer combines functionality of both counter and timer. As counter, it features high-speed input of up to 10K cps, input scaling, and single or dual presets. As timer, it is classified as multi-mode and multi-range. Unit is available in 48 x 48 and 74 x 72 mm packages with 4- and 6-digit dual displays.

Extech Instruments Corp.
Waltham, MA 02451 1020
Oct 29, 2003 In addition to measuring temperature and relative humidity, Model HW30 calculates and displays heat index and allows user to set heat index alarm. Unit provides stopwatch timing to 1/100th of a second. It includes Fastest/Slowest/Average lap recall, 99-lap counter with 30 lap/split memory, 10 hr countdown timer with audible beeper warning for last 5 sec, and programmable alarm. Clock displays in 12 or 24 hr format and calendar mode displays day, month, and date.

Geotest - Marvin Test Systems, Inc.
Irvine, CA 92614-5846
Oct 01, 2003 Model GTX2220 delivers frequency, period, totalize, and time interval functions in PXI form factor. Reciprocal counting provides fixed number of digits of resolution for all frequencies, rather than fixed resolution in Hz for same gate time. Counter provides 2,300 measurements/sec and features 10 digits/sec of resolution for frequencies from 1 Hz to 1.3 GHz. It can determine any frequency to 7 digits in 1 ms, and can resolve each time measurement to 100 ps.

Trumeter Co., Inc.
Deerfield Beach, FL 33442
Jul 16, 2003 Model 877X indicates process time of continuous processes. Sensor or encoder provides pulses for unit to monitor. Time between pulses is measured, and internal calculations are made to apply appropriate scaling factor, enabling unit to indicate actual time taken for items to travel through process. Unit has bright LED display and is available in ac- and dc-powered versions. Dual relay output, analog output, and RS-485 communications are optional.

Control Co.
Houston, TX 77258 8307
Jul 01, 2003 Traceable® Double Display Timer allows simultaneous programming of 2 activities from 20 hr to 1 sec, with 1 sec resolution and 0.01% accuracy. Each channel has distinct electronic alarm and display indicator when zero is reached; timer automatically counts up from zero to indicate time since alarming. Second display mode shows time of day and stopwatch. With ½ inch high digits that can be read from 10 ft away, product may be used flat or in flip-open stand position.

Control Company
Friendswood, TX 77546
May 20, 2003 Traceable® Credit Card Timer counts down from 99 min, 59 sec with 1 sec resolution. Accuracy is 0.01%. Alarm sounds for 1 min when zero is reached, and memory automatically recalls last set time. Unit includes timeouts and count-up stop watch. Individually serial-numbered Traceable® Certificate indicates traceability to standards provided by NIST. Timer is supplied with silver-oxide battery, magnet and Velcroâ„¢. Size is 3 3/8 x 2 1/8 x 3/16 in.

Love Controls
Michigan City, IN 46361
Oct 22, 2002 Model LCT116 is offered with 8- or 11-pin sockets. Setpoint and timing functions are adjusted with individual set buttons. LCD on front indicates current time status and has bar graph for relative time remaining. Time ranges include 0.01-9.99 sec to 10-9990 hr. Timing functions include Signal On-Delay, Flicker on-Start, Signal ON/Off-Delay, Signal OFF-Delay, Interval Mode, One Shot and Flicker, Integration Time, Interval Delay, Flicker-One Shot, and Power On Start.
