Hydraulic System Testers

Test & Measuring Instruments

Hydraulic Test Center supports powertrain testing.

April 8, 2016

Designed for those involved with testing heavy-duty, mobile equipment, such as dozers, trucks, and mining equipment, Hydraulic Test Center supports testing of transmissions, hydraulic motors and cylinders, valve blocks, torque converters, and open and closed loop pumps. System provides DynPro2 data acquisition and control system technology, remote monitoring, and effortless contamination control to ISO 16/13/11. All ratings are continuous duty, not intermittent. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Wireless Hydraulic Pressure Tester leverages RFIFD technology.

March 9, 2015

Using RFID technology, PT-RF transfers energy required for measurement to pressure transmitter via antenna, placed ~½ in. from pressure transmitter tip, of reading device. Pressing button activates pressure transmitter, and pressure is read in <½ sec. Supplied in IP65, hermetically sealed, stainless steel housing, handheld reader displays and stores data for 15,000+ measurement sets, which can be used for further evaluation or download to PC via USB interface. Read More

Test & Measuring Instruments, Transportation Industry Products

Taylor Dynamometer to Showcase Products and Solutions at the 2014 Brazil Automotive Testing Show and Expo

July 9, 2014

São Paulo, Brazil – Taylor Dynamometer will showcase its comprehensive product offering including engine, chassis and towing dynamometers along with engine testing equipment at the 3rd annual Automotive Testing Show and Expo (August 6-7, Sheraton WTC Hotel, São Paulo, Brazil, Stand A151). "We are excited to participate in the Brazil Automotive Testing Show and Expo," said Jeff Brown, Vice... Read More

HVAC, Plant Furnishings & Accessories, Test & Measuring Instruments

Hydraulic Test Centers offer oil mist collector option.

April 22, 2014

Designed for testing heavy-duty, off-highway hydraulic components, Hydraulic Test Centers offer 3-stage Oil Mist Collector option for components with unconcealed rotating equipment that develop oil mist while under test. First impinger stage provides surface for mist to collect and then drip back to tank. Second and third stages ionize remaining mist, forcing contamination onto surface where it then drips back to tank. All collection is done with reusable/washable filters. Read More

Test & Measuring Instruments

ASAP Offers Leak Hyd. Detection Systems

March 27, 2014

Looking for an easy way to determine if and where your hydraulic system is leaking? ASAP Hydraulics is pleased to offer the Spectroline Leak Detection System. It is a fast and simple way to detect fluid leaks within your hydraulic system. Simply add dye and allow it circulate and then using a light, shine the outside of the piece of equipment. If it leaks, it will fluorece. ASAP offers the... Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments, Green & Clean

Portable Hand-held Meter diagnoses hydraulics and pneumatics.

December 12, 2013

With scan rate of 1 ms and ability to measure pressure, flow, temperature, and rpm, SensoControl® Diagnostic Serviceman Plus™ provides maintenance and diagnostic data for hydraulics and pneumatics. Plug and Play automatic sensor recognition immediately scales measurement range, eliminating confusing setup routines. All measurements can be stored on nano USB drive or transferred to PC for analysis and documentation. Measuring 4 x 7 x 2 in., meter operates on rechargeable 3.7 V Li-Ion battery. Read More

Test & Measuring Instruments

Deadweight Testers calibrate multiple pressure devices.

October 18, 2013

Suitable for calibrating pressure transducers, transmitters, and gauges, P3100 Hydraulic Deadweight Testers include Models P3125XT-BAR, P3125XT-KGCM2, and P3125XT-MPA, which measure from 1–1,200 bar, 1–1,200 kgf/cm², and 1–120 MPa, respectively. Supplied with detachable lid for portability, all models include accredited calibration report; weight mass details; M14 x 1.5, M20 x 1.5, 1/8 in., ¼ in., 3/8 in., and ½ in. NPT and BSP female adaptors; operating fluid; and spare seals. Read More

Controls & Controllers, Laboratory and Research Supplies & Equipment, Services, Test & Measuring Instruments

Shanghai Jiaotong University and MTS Systems Corporation Announce the Establishment of an Aerospace Structural Strength Testing Demo Site

August 2, 2013

EDEN PRAIRIE, Minn. – MTS Systems Corporation (NASDAQ: MTSC), a leading global supplier of high-performance test systems and position sensors, today announced that it has finalized an agreement with Shanghai Jiaotong University (SJTU) to establish an Aerospace Structural Strength Testing Demo Site at SJTU in Shanghai. Under this collaboration, SJTU's School of Aeronautics and Astronautics... Read More

Test & Measuring Instruments

Handheld Hydraulic Tester withstands harsh conditions.

July 17, 2013

Available with either 2 analog sensor inputs or CAN interface for connecting up to 3 digital sensors, PPC-04-plus measures pressure, temperature, flow rate, frequency, and speed in mobile and industrial hydraulic systems. IP67-rated unit features oil-resistant rubber coating to withstand impacts, vibration, dust, and moisture. Using USB port and included software, measurement values can be read and transferred to PC, where they can be displayed, analyzed, and further processed. Read More

Laboratory and Research Supplies & Equipment, Test & Measuring Instruments, Green & Clean

Hydraulic Universal Testers use energy efficient pumps.

July 30, 2012

Operated via 10.4 in. color touchscreen and designed for high-precision stress and strain control, UH-X/FX Series automatically tune control parameters in real-time based on values during testing. Users can measure test force and strain without specifying amplifier range as well as perform tests without computer via USB memory stick with test parameters. Hybrid hydraulic unit powering both series combines AC servo motor with hydraulic pump, which only operates when necessary. Read More

Test & Measuring Instruments

Hydraulic Tester helps maintain large construction machinery.

December 8, 2011

Designed for testing mobile machinery with max theoretical power of over 1,500 hp, DHCR1500R Test Kit enables operator to measure flow, pressure, and temperature while simultaneously loading system using pressure loading valve. HV1500 valve, featuring built-in burst disc safety mechanism, allows operator to simulate machine circuit under normal conditions by restricting flow. With code 62 2-in. fittings, kit is rated to max of 400 gpm and 6,000 psi. Read More

Test & Measuring Instruments

Portable Hydraulic Tester features internal burst disc.

February 17, 2011

Flo-tech(TM) PFM Tester Series incorporates field-replaceable safety pressure relief disc (burst disc). IN case of over pressurization, design ensures fluid is safely allowed to bypass load valve and remain within hydraulic system. No fluids will escape outside of the tester, reducing maintenance and potential harm to environment. Used to measure flow, pressure, temperature, and horsepower on mobile hydraulic equipment, tester delivers readings with 1% FS accuracy and 0.2% repeatability. Read More

Test & Measuring Instruments

Digital Hydraulic Tester delivers laboratory accuracy.

January 24, 2011

Designed for diagnostic troubleshooting of all types of mobile or stationary hydraulic systems and components, CE-compliant HFP-110/120 lets users acquire flow pressure and temperature measurements simultaneously from one point. Self-contained and portable instrument, suited for hydraulics, automotive, and manufacturing industries, incorporates pressure relief disc protection and low battery/over-range indicators. LCD with 3½ digits facilitates reading of measurements. Read More

Test & Measuring Instruments

Hydraulic Test System provides data logging and reporting.

May 4, 2010

Designed to help hydraulic pump re-builders with testing and traceability, C2000 offers customized instrumentation, display, logging, storage, and reporting capabilities. Operator with minimal IT training can record data on key-press and produce test certificate, while ensuring full ISO9000 traceability. Fully scalable up to 64 inputs, system can be set-up to measure all hydraulic parameters such as flow, pressure, temperature, speed, contamination, and torque. Read More

Chemical Processing & Waste Management, Fluid & Gas Flow Equipment, Test & Measuring Instruments

Filtration Unit withstands system pressure up to 6,000 psi.

February 11, 2009

Featuring sensor and EasyTest(TM) fittings, ET-100 can be used to troubleshoot in instances of poor systems performance or excessive machine downtime, to check performance on production line, and to check systems before and after rebuild. It can be used with large meters that are clearly marked with scales. Pressure bearing parts are thick-section aluminum extrusions, and load control knob and scale selector switches are designed to provide grasp under any conditions. Read More

Test & Measuring Instruments

Universal HydraulicTest System features 1,000 kN capacity.

June 30, 2008

With design that allows limited number of jaw faces to cover large range of specimen sizes, 1000HDX Universal Testing Machine features dual test space for tension, compression, bend, shear, and flexure testing on high strength materials. Control electronics provide recognition and calibration of transducers, ensuring proper instrument is being used and that data is reliable. The 1000HDX conforms to EN10002-1, ISO 6892, ASTM E8, C39 and F606, SAE J429, standards and is CE compliant. Read More

Test & Measuring Instruments

Hydraulic Testing System delivers up to 1,000 kN.

February 21, 2008

Able to work with high-strength materials used in metal, fastener, and construction markets, Model 1000HDX provides dual test space for tension, compression, bend, shear, and flexure testing. It is available with 2 crosshead configurations: hydraulically actuated open front design or manually operated closed pocket design. Digital control electronics provide automatic recognition and calibration of transducers, and Windows®-based testing software facilitates operation. Read More

Test & Measuring Instruments

Hydraulic System Analyzer indicates flow and pressure.

October 3, 2005

Style K Hydraulic System Test Analyzer offers choice of aluminum constructed meters for pressures up to 3,000 psi or stainless steel meters for pressures up to 5,000 psi. Available for 3/8-1½ in. NPT or SAE port sizes, product is capable of handling operating temperatures up to 240ºF and flow rates to 150 gpm with ±2.5% of range accuracy. Read More

Test & Measuring Instruments

Hydraulic Tester offers reverse flow capability to 50 gpm.

July 27, 2004

With working pressure to 6,000 psi, Series RFIK provides safe in-line testing of mobile or industrial hydraulic circuits. Reverse flow feature allows machine to be fully cycled during troubleshooting and prevents cylinder lock-up and pressure intensification. Flow rate is displayed on 2.5 in. dial, which imparts rate of change indication and accuracy better than 4% FSD. Housed in steel case, kit requires no batteries to measure flow, pressure, and temperature. Read More

Test & Measuring Instruments

Universal Hydraulic Test Systems save floor space.

June 15, 2004

Series SATEC(TM) testing systems are available 2 model types ranging in capacity from 33,750-135,000 lbf. Testers combine frame, hydraulic power supply, electronics, and control panel into single machine. DX line features hydraulically powered load frames that include 2 test spaces, allowing tension and compression tests to be performed in separate areas. LX models have rigid 2-column load frame to provide test space to accommodate range of specimen sizes at comfortable working height. Read More
