Inclination and Tilt Sensors prevent heavy equipment from tipping.

January 29, 2016

As IP67-rated inclinometers with integrated RS-232 interface and flying lead cable, MTLT series operates from single 9–32 V supply and utilize MEMS sensors, over temperature calibration, and SmartSensing™ technology. Programmable tilt alarms, also included, can be used to lock out controls or trigger alarm or warning light. Respectively, models MTLT105S and MTLT110S are designed for applications needing <0.5° and <1.0° accuracy over full operating temperature range. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Absolute Feedback Systems integrate into drives.

July 31, 2015

Supplied in IP67-rated housing, Absolute Position and Angle Measurement Systems are suited for installation or direct integration into drive and positioning systems, and can be used in rotary applications as well. Magnetically encoded systems, featuring Permagnet® nonius technology, enable formats, strokes, and end positions of axes to be adjusted automatically. Position data is generated in real-time and made available in absolute form using SSI or bidirectional BiSS C interfaces. Read More

Test & Measuring Instruments

Inclinometer helps maximize operator safety.

May 12, 2015

Constructed with Pyrex borosilicate glass tube assembly and black indicator ball, Lev-o-gage 9 measures angular tilt from -11 to +11° and percent slope from -20 to +20%. At almost 6 in. wide, inclinometer can be read from distance and in low light conditions. Numerals and hashmarks are engraved and hand-filled with acrylic Titanium white paint for optimal visibility. Read More

Test & Measuring Instruments

Inclinometer targets sailboats, cruisers, and sport boats.

May 5, 2015

Designed to measure angular tilt from -30 to +30°, Lev-o-gage 8 provides resolution from -15 to +15°. Unit is designed with shatterproof polymer tube assembly and brass indicator ball. At almost 5 in. wide, inclinometer can be read from distance, even in low light conditions. Numerals and hashmarks are engraved and hand-filled with acrylic Titanium white paint for optimal visibility. Read More

Test & Measuring Instruments

High-Visibility Inclinometer improves operator safety.

April 29, 2015

Able to be read even from distance and in low light conditions, Lev-o-gage 7 measures angular tilt from -11° to +11°. Numerals and hashmarks are engraved and hand-filled with acrylic Titanium white paint for visibility and durability. Glass tube assembly is constructed of Pyrex borosilicate, and Saturn yellow color contrasts black indicator ball. Featuring damping fluid that works over -40 to +125°F range, 5.85 x 2.12 x .50 in. instrument offers ±1.0° angular tolerance and 1° resolution.
Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Industrial Inclinometers utilize MEMS technology.

May 16, 2014

Providing measurement of slope or tilt angles of object with respect to gravity, T-Series offers dual axis measurement range up to ±60° or single axis measurement of 360°, with 0.01° resolution and 0.1° accuracy. Sensors incorporate built-in linearity and temperature compensation. Available with glass fiber reinforced plastic or AW6082-T6 aluminum alloy housing, encapsulated units are sealed to IP68 for harsh outdoor applications. Output options include 4–20 mA, 0.5–4.5 V, or CANopen. Read More

Test & Measuring Instruments, Labels, Tags, Signage & Equipment, Portable Tools

Center Punch measures angles and marks pipes.

March 14, 2014

Featuring digital inclinometer gauge set on angled base, Sumner Center Punch is designed for measuring angles on pipe. Gauge displays angles to nearest hundredth, is removable from magnetic base, and includes zero button. Once desired angle is reached, pushbutton spring-loaded striking hammer clearly marks pipe at desired locale. Read More

Test & Measuring Instruments

Dual Axis Inclinometers include RS 232/RS 485 communications.

February 15, 2013

Equipped with microprocessor-based electronics, Model 0729-1755-99 provides 0–5 V outputs for each axis and for temperature, while Models 0729-1759-99 and 0729-1760-99 are available with RS 232 and RS 485 communications, respectively. All offer angle range of ±60° in X and Y axes, 0.2 arc min resolution, and ±0.1° repeatability. RoHS-compliant units are suited for aerial lift platform leveling, crane boom angle measurement, robotic controls, and alarm system activation. Read More

Test & Measuring Instruments, Optics & Photonics

Compact Electronic Autocollimator is optimized for sensitivity.

October 26, 2012

Portable CONEX-LDS offers 0.01 µrad angular measurement sensitivity and 2 kHz data refresh rate, enabling analysis of resonance modes of structures. Controller is integrated into optical head of autocollimator, occupying only 4 x 1.5 x 1.5 in., and other features include ±0.85° FOV eyepiece, PSD sensor, and RS-422 communications. Autocollimator is used for traditional metrology applications in production environments such as pitch, yaw, straightness, bearing eccentricity, and wobble.
Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Electronic Tilt Sensors suit surface mapping applications.

July 24, 2012

Based on force balance accelerometer technology, Model SI-701B is available in ranges from ±15° to ±90° and features 5 terminal pin electrical interface. Model SI-701BC offers same electrical features but has 4-pin connector electrical interface. Using patented HP suspension system for added accuracy, high performance Models SI-701BHP and SI-701BHPC operate from ±5° to ±90°. All feature damping and desensitization circuitry that allows tilt measurements in strong vibration and shock environments. Read More

Test & Measuring Instruments

Rotary Single Axis Inclinometer offers 360° monitoring range.

July 5, 2012

Based on MEMS devices that incorporate micro-electromechanical capacitive elements into sensor, Rotary Single Axis CANopen Inclinometer measures angular tilt in reference to gravity. Unit is suitable for monitoring mechanical arms, such as tensioners or moving components, as well as monitoring and reporting position of outriggers, booms, or other vertically rotating parts. Featuring IP68-rated housing, device operates in temperatures from -40 to +70°C. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Geometric Measurement System utilizes iOS devices.

June 8, 2012

Supported with dedicated App, ALiSENSOR(TM) LEVEL data collector contains MEMS gyros, accelerometers, and microprocessor. Data of angular and translational movements are delivered via Bluetooth® to iOS unit, which provides environment for operator to analyze data. ALiSENSOR(TM) LEVEL offers ability to select from wide range of measurement units, self-calibration for measurement with new or special fixtures, and instant reports with all data from measurements that can be shared via email or MMS. Read More

Test & Measuring Instruments

Inclinometer is offered in 2 ruggedized variants.

October 28, 2011

Available in single-axis (360°) or 2-axis (±80°) models, ACCELENS (ACS) temperature compensated inclinometers offer ±0.01° max resolution and multiple interfaces. Fiber-reinforced PBT plastic housing and fully encapsulated electronic components suit industrial environments, while die-cast aluminum housing with reinforced connection points is designed for off-road or harsh environment conditions. Both housing versions are rated to IP69K protection. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Single-/Dual-Axis Inclinometer survives harsh environments.

February 23, 2011

Operating with MEMS technology, POSITILT® PTAM5 comes in single- and dual-axis versions with respective measurement ranges of ±180° and ±60°. Both are available for smaller measurement ranges in ±15° increments and offer resolution of 0.05° with linearity of ±0.5°. Stainless steel housing, rated to IP67/69K as standard or IP68 optionally, withstands outdoor use in harsh environments. Tilt sensor is available with 4-20 mA and 10 V analog outputs as well as CANOpen and CAN SAE J1939. Read More

Test & Measuring Instruments

Inclinometers are offered with DeviceNet(TM) interface.

February 15, 2011

ACCELENS inclinometers are available with DeviceNet(TM) electronic interface, facilitating connection of devices to embedded control units (ECUs) and programmable logic controllers (PLCs). Other available interfaces include analog (voltage or current), serial (SSI), and CANopen. Offered in single-axis (360°) and 2-axis (±80°) models, devices have molded polyurethane enclosures rated to IP68 and internal components that can withstand shock loads up to 100 g and vibrations to 20 g. Read More

Test & Measuring Instruments

Servo Inclinometers offer max linearity error of less than ±0.02% FS.

November 29, 2010

Sensorex SX41100 inclinometers enable high-precision angular measurements within extreme testing environments. They provide output signal proportional to angle being measured over range of ±1° to ±70° and operate from 9-30 V unipolar power supply. Featuring IP65 environmental sealing, units include inertial mechanism immersed in oil for high shock and vibration resistance. Analog versions and digital models that allow direct communication with PC are available. Read More

Test & Measuring Instruments

Dual Axis Inclinometer offers microprocessor-based electronics.

November 15, 2010

Designed to interface with all types of instrumentation and equipment, Dual Axis Inclinometer provides 0-5 V analog outputs for PWM and temperature. Unit offers angle range of +60° over X and Y axis, 0.2 arc min resolution, and +0.1° repeatability. Housed in high-impact plastic enclosure, microprocessor-based electronics feature operating temperature of -40 to +85°C. Typical applications include solar tracking, aerial lift platforms, and alarm system activation. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Inductive Angle Encoder withstands harsh environments.

September 27, 2010

Available with ODs from 75-250 mm, IncOder uses absolute inductive measuring technique and offers measurement performance unaffected by humidity, moisture, condensation, or dust. Components of this non-contact, absolute angle encoder include powered stator and passive rotor, each shaped like flat ring. Through-bore size accommodates larger through-shafts, slip rings, cables, etc., while flat, low-profile design accommodates applications with limited space. Read More

Test & Measuring Instruments

Compact, MEMS-Based Inclinometers feature linear output.

August 16, 2010

Contained in 10 mm high, IP64-rated flat housing, PTAM27L series inclinometers are available in single axis versions with measurement ranges from ±15° to ±180°, while dual axis versions have ranges from ±15° to ±60°. Both are offered in measurement range increments of 15°, are shock-resistant, and operate in temperatures from 0-60°C full scale. Units have 0.1° resolution, ±1° linearity, and ±100 x 10-6/°C temperature stability, with several analog outputs available. Read More

Test & Measuring Instruments

Programmable Inclinometer provides 2 discrete outputs.

July 20, 2010

Designed to measure angular tilt in reference to gravity, single-axis Inclinometer offers adjustable measuring range of 360° and is programmable for settings such as on or off points, span, and hysteresis. IP68-rated unit is based on MEMS device, which incorporates micro-electromechanical capacitive element with 2 parallel plate electrodes, 1 stationary and 1 attached to spring-mass system. Signals are conditioned to provide single analog voltage output of 0.1-4.9 Vdc or current output of 4-20 mA. Read More
