Vibration Transmitter helps prevent unscheduled downtime.
Emerson Process Management
Knoxville, TN 37932
Aug 26, 2014
By capturing vibration or position data and translating it into 4-20 mA signal, Model CSI 9360 delivers real-time information about rotating equipment. Unit can be field-configured for 3 radial vibration ranges or position with invertible position signal, selectable sensor loop response times, and optional sensor fault lock out times. To verify radial vibration or axial thrust movement measurements, CSI 9360 can be used to perform 2oo3 sensor voting on shafts as small as 5/8 in. diameter.
LVDT Pencil Probe verifies part measurements.
Minneapolis, MN 55421
Aug 06, 2014
Offering spring extend and pneumatic extend actuation types, KURTSmart PROBE™ outputs linear value over entire stroke of probe. Unit requires 5 V power for measurement operation and can run stand-alone, measuring and sorting parts based on feature size. Onboard input and output port supports triggering of measurement and action to be taken based on measurement result. With 5 LEDs, probe can be programmed to visually show operator if part is good (green), trending bad (yellow), or bad (red).
AC/AC LVDT works under pressure and temperature extremes.
Ellington, CT 06029
Aug 04, 2014
Rated for pressures to 35,000 psi at continuous temperatures to 450°F, High-Temperature High-Pressure Linear Displacement Transducers (LVDTs) have .30 in. OD body with perforated housing that equalizes internal and external pressure. Fluids must be electrically non-conductive and chemically benign, since holes in housing expose internal coils. Non-linearity is ±0.25%, and temperature coefficient of sensitivity is ±0.01%/°F. Signal conditioners for DC/DC or 4–20 mA operation are available.
Linear Displacement Transducer has smart Ethernet technology.
Ametek Automation & Process Technologies
Clawson, MI 48017
Jul 21, 2014
Simplifying installation and wiring, GEMCO® ReadyLink™ is designed with EtherNet/IP™ network interface that requires single point network connection for configuration and control. Magnetostrictive technology is used to provide absolute non-contact feedback. Available in 953N Rod Style and 957N Brik™ Low-Profile Style packages, product supports Line, Star, or Device Level Ring topology, has measuring range of up to 300 in., and incorporates RapidRecall™ network configuration module.
Ultrasonic Thickness Gauge utilizes dual element transducer.
Waltham, MA 02453
Jun 16, 2014
Ergonomically designed for one-hand operation, Model 27MG makes accurate measurements from one side on internally corroded or eroded metal pipes and structures. Battery-operated unit features backlit LCD and intuitive color-coded keypad with direct access to many key features. Automatic Probe Recognition ensures optimal transducer performance, while Auto Zero compensation maximizes accuracy of measurements on hot surfaces, and Gain Adjust optimizes measurements on sound-attenuating materials.
Eddy Current Flaw Detectors feature 5.7 in. VGA display.
Waltham, MA 02453
Jun 16, 2014
Available in 4 models, NORTEC 600 Series provides Application Selection menu, all-in-one display, real-time readings, and signal calibration in Freeze mode. NORTEC 600 delivers basic single frequency eddy current inspection; NORTEC 600C adds digital conductivity and coating thickness measurements; NORTEC 600S adds rotating scanner use; and NORTEC 600D adds dual frequency capabilities. Featuring IP66 rating for harsh field conditions, battery-powered units provide 10 hours of standard operation.
Rotary Torque Transducer withstands extreme vibration.
Sterling Heights, MI 48314
Jun 10, 2014
Supplied with Bluetooth remote base station, BT4000 Series Wireless Coupled Flange Drive Rotary Torque Sensor can measure torque up to 8,000 Nm at speeds to 7,000 rpm with analog voltage, digital, or frequency signal outputs. Encapsulated electronics provide strain gauge bridge excitation, bridge output amplification, and amplified signal conversion into 16-bit digital word. Any device equipped to receive 2.4 GHz Bluetooth data can receive signals from BT4000 Series for subsequent processing.
Programmable MCU Resolver Kit replaces dedicated conversion ICs.
Texas Instruments, Inc. / Tiris Division
Dallas, TX 75243
Apr 22, 2014
Conserving system expense and space in diverse industrial applications, C2000™ MCU Resolver Kit shows designers how to implement digital conversion using software on programmable C2000 MCUs. Solution replaces dedicated resolver-to-digital chipsets with MCUs while extending functionality by letting MCU handle resolver-to-digital decoding as well as other software-programmable, real-time functions. Kit provides complete hardware and includes software and hardware development packages.
Thickness Gauge measures battery electrode coatings.
Germantown, WI 53022
Apr 10, 2014
Used to monitor thickness of coatings on lithium-ion battery electrodes directly on coating line, Model WEBFREX3ES consists of up to 5 frames, which accommodate Beta-ray type sensor, measurement manager station to generate coat weight profiles, operator stations, and profile stack server. System provides high-speed synchronization scanning, automatic identification of coated or non-coated parts, zone trend panel, profile data tracking, and material coefficient window.
Ultrasonic Thickness Gauge provides ±0.5% accuracy.
Dwyer Instruments, Inc.
Michigan City, IN 46361
Feb 26, 2014
Equipped with 4-digit, 0.394 in. LCD, Model UTG measures thickness from 0.047–7.874 in. with 0.001 in. resolution. Unit includes adjustable sound velocity option for measuring variety of materials. With gauge, users can find wall thickness of pipe when programming ultrasonic transmitter without cutting or removing section of pipe to measure it. Operating from 32–122°F, Model UTG is also suitable for monitoring corrosion in closed vessels such as boilers and chemical tanks.
Contacting Thickness Tester ensures accurate measurement.
Medford, MA 02155
Feb 14, 2014
i-Thickness 4400 Auto-Feed Thickness Tester can be used with Online Data Management System for packaging testing, which comes with Cloud and Intranet versions, to meet user requirements. Cloud version consist of 6 functional modules – Test/Target/Instrument/File Management, Settings, and Online Support – and cloud services for storage, calculation, and analysis of mass test data. Intranet version features storage space for data and correlation/trend/statistical analysis of test data.
Rugged LVDT measure position of valves for subsea oil fields.
Measurement Specialties, Inc.
Hampton, VA 23666
Feb 10, 2014
Able to function submersed in oil at pressures to 7,500 psi, Linear Variable Differential Transformer (LVDT) features digital calibration, digital linearity correction, and temperature compensation. LVDT zero and gain are digitally adjustable in field via serial port to correct for valve tolerances. This 4–20 mA loop transducer is compliant with ISO 13628-6, and 4–20 mA output, CANopen CiA443, or other outputs as well as different mechanical packages are available to meet specific needs.
Resolver Feedback Module facilitates AC drive upgrade.
Advanced Micro Controls, Inc.
Terryville, CT 06786
Jan 28, 2014
Designed to plug into Allen-Bradley PowerFlex® 750-Series AC Drives, Model RD750 eliminates need to replace resolver-equipped motors when upgrading from PowerFlex 700 drives. Module provides single channel resolver interface and variety of diagnostic data using two bi-color LEDs. Critical information such as card-to-drive communication, card-to-resolver connection, and parameter faults are all provided visually. With onboard DIP switches, resolver settings can be configured in field.
Laser Sensor measures thickness of coils in slitting lines.
Raleigh, NC 27617
Jan 21, 2014
Used to determine thickness profile of individual metal strips in slitting lines, thicknessCONTROL MTS 8201.LLT O-frame measurement system uses two laser triangulation profile sensors to perform alloy-independent measurements with accuracy to few micrometres. Laser line sensor addresses specific measurement tasks, including channelled sheets and thickness of sandwich plates made from non-homogeneous materials. Non-contact thickness measurements are performed continuously.
Thickness Measurement System offers multi-layer capabilities.
Saelig Company Inc
Fairport, NY 14450
Dec 17, 2013
Non-contact, non-destructive, self-calibrating OptiGauge MLS™ can measure each translucent coating in object up to 20 layers thick; thickness of individual layers and total overall thickness is calculated automatically. Selection of available optical probes can direct 1,310 nm IR light from LED through transparent, translucent, or colored materials, and automation eliminates opportunity for operator error. Measurements deliver sub-micron accuracy for objects 12 µm to 50 mm thick.
Ultrasonic Thickness Gauge delivers non-destructive testing.
Danvers, MA 01923
Nov 05, 2013
Used to measure metal structures subject to corrosion, EHC-03 entry-level thickness gauge features IP54-rated case; 128 x 64, graphic, monochrome, sunlight-readable LCD with multiple on-screen languages; and ability to display readings in inches, mm, or µsec. Thickness range is .040–20 in. in steel, and Q-Bar feature confirms measurement stability. Along with 2-point calibration, features include material velocity list for common engineering materials.
Web Gauging Systems target blown film industry.
NDC Infrared Engineering
Irwindale, CA 91706 2089
Oct 21, 2013
Designed for commodity single-layer film products, Model 8110-BF provides stationary film thickness measurement on either bubble or layflat. System features GBS sensor that is insensitive to environmental and product composition effects. For higher value-added blown film products, Model 8000 includes Double Layflat Separation Algorithm that computes single-layer film thickness from scanning double-layflat measurement and aligns film against die positions for accurate polar plot thickness profile.
Flaw Detector supports range of applications.
Waltham, MA 02453
Oct 03, 2013
To meet range of application requirements, OmniScan MX supports conventional eddy current testing (ECT), eddy current array (ECA), and bond testing (BT) C-scan technology via 2 module versions. Both modules are compatible with MXE (ECT/ECA) and MXB (BT C-scan) software, facilitating transition between technologies. In ECA mode, flaw detector can perform inspections through thin coatings on conductive material. C-scan BT technology is suited for honeycomb composite inspections.
Flaw Detector uses corrosion inspection software.
Waltham, MA 02453
Sep 05, 2013
Available with portable EPOCH 600 Ultrasonic Flaw Detector, Corrosion Module includes automatic ultrasonic setups based on transducer selection, Automatic Gain Control, thickness gage measurement algorithm, V-Path correction, and transducer wear compensation using automatic zero function. Module also features corrosion-style data logger file types, color-coded Grid View, and timed B-scan view for fast data collection and consolidated reporting of areas of interest.
Flaw Detector Software offers simplified interface.
Waltham, MA 02453
Jul 11, 2013
With single operation mode, every item of Omniscan v4.1 interface is always accessible. Title bar provides instant access to main display options, and most common functions are available through interactive menus of full-screen mode, offering tablet-like operation. For applications requiring multi-probe configuration, multi-group layouts are optimized so that scanner configuration is reflected in software interface. Position of different scans is determined by their distance to center of weld.
