Particle Monitors

Sensors, Monitors & Transducers

Digital Dust Monitor supports use in diverse applications.

May 6, 2015

Able to measure particles in PM 10 concentrations, 2.9 lb Kanomax Dust Monitor has 0.1–10 µm particle size range and 0.001–10 mg/m³ measuring range. Instrument logs data for up to 100,000 measurements and allows data transfer via USB, while operation is facilitated via usability-optimized interface and 24+ hr run time with Li-ion battery. Capable of analog and digital output, unit comes with tripod mount for stationery locations or rubber protector and shoulder strap for portable use. Read More

Test & Measuring Instruments, HVAC, Sensors, Monitors & Transducers

Sensor Monitoring Unit displays key contamination data.

September 23, 2014

In addition to allowing live display of TCM ISO code, TWS water concentration, and fluid temperature, SMU Sensor Monitoring Unit will store data for later retrieval. TestMate® Particle Counter, TPM, can be ordered without internal pump, which can be installed in systems with operating pressures up to 5,000 psi. Pump-less version can also be ordered with Viton® seals allowing unit to be used with Phosphate Ester Fluids. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Remote Particle Counters feature integrated pump.

June 11, 2014

Designed to eliminate need for external vacuum source, AeroTrak® 6310, 6510, and 6510-VHP feature hot-swap combined particle sensor and blower assembly condensed into 316L stainless steel enclosure. Systems come standard with four 4–20 mA analog inputs that integrate local environmental parameters such as room pressure, temperature, and relative humidity. Environmental data, as well as particle counts, are transmitted back to facility monitoring software via Ethernet or RS 485. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Particle Monitor distinguishes particles sizes from 4-70 µm.

October 11, 2013

Using LEDs, 8-channel LPM II Particle Monitor provides precise image of degree of contamination in hydraulic system. Unit shows measured data on display as contamination class according to ISO 4406:1999, NAS 1638, AS 4059E, and ISO 11218 or as particle count per size. Permanently installed for continuous monitoring, device enables users to quickly respond to increasing contamination. Monitor comes with or without display and keypad, and is also available with integrated moisture sensor. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Leak, Emissions, Flow Monitors serve power/utility industry.

April 11, 2013

Comprising bag leak detectors, emission monitors, and solids flow monitors, TRIBO.dsp U3000 series measures particulate/dust emissions and dry solids flow. Core technology, TRIBO.dsp, unifies DC impaction (triboelectric) and AC induction electrostatic signals for optimal accuracy, reliability, and repeatability. Signals can be used to activate operational functions, such as alarms and relays, or generate continuous 4–20 mA or digital signals for trending/recording. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Reflectance Measurement System monitors particles in real-time.

November 16, 2012

With FBRM® G600L Focused Beam Reflectance Measurement System, users can track rate and degree of change to particles, particle structures, and droplets at full process concentration. Pneumatic probe, for use in classified laboratory hoods, enables monitoring in vessels from 500 mL to 10 L or insertion into continuous pipeline. In each application, FBRM® G600L enables chemists and engineers to link experiment variables to changes in particle dimension, shape, and count. Read More

Material Handling & Storage, Sensors, Monitors & Transducers

Airborne Particle Sensor targets wafer processing applications.

January 26, 2011

Moving through semiconductor process equipment, Airborne Particle Sensor monitors airborne particles, reporting back information in real-time to allow engineers to validate and analyze wafer contamination. Vacuum-compatible unit can detect 0.1 µm particles in multiple Bin schemes and does not require engineers to open chambers or expose ultra-clean process areas. Using companion software, particle data can be recorded to compare past to present operations as well as one tool to another. Read More

Vision Systems, Sensors, Monitors & Transducers

Particle Imaging System monitors oceans, lakes, and streams.

March 11, 2010

Using Submersible FlowCAM®, scientists and water quality professionals can automatically acquire biological and particle images and data in real-time from remote sensing platforms for continuous, unattended, in-situ monitoring. System takes high-resolution digital images of individual, waterborne particles and microscopic organisms, measures each one based on multiple parameters, and saves images and data for identification, analysis, and collaborative review. Read More

Sensors, Monitors & Transducers

Particulate Monitoring System offers baghouse leak detection.

February 18, 2010

Designed for general process and environmental monitoring, Model BM-30 LGX detects many types of particulate including dusts, powders, granulars, and pellets. Intrinsically safe system consists of control unit, particulate sensor probe that is mounted on airflow stream, and sensor coaxial cable. As particulate flows near and over sensing element, concentration of particulate is measured, and when predetermined threshold is detected, alarm is activated. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Handheld Particulate Monitor offers wide sensitivity range.

February 4, 2009

Microdust(TM) Pro airborne particulate monitor features 1 µgm -3 to 2,500 mgm -3 range for assessing suspended matter concentration. Monitoring various microscopic particles using near-forward light scattering technology and 12-20° scatter range, it presents data with scrolling graph on LCD screen. Internal logger stores up to 15,700 data points over 32 separate runs and data is downloaded to PC/printer via RS-232 interface cable. Device is battery powered. Read More

Sensors, Monitors & Transducers

Hydraulic System Monitoring Unit incorporates optical sensor.

December 2, 2008

Testmate Monitoring Unit measures solid particle contamination in hydraulic systems, and measurement accuracy is ±½ ISO code. It features automatic measurement and display of cleanliness ratings as ISO 4406:1999, SAE AS 4059, and NAS 1638. Unit has viscosity range of 46-1,622 SUS, and measures particles whose sizes are greater than 4, 6, 14, and 21 microns. Integrated pump and hoses with test point connections allow operation on reservoirs, control circuits, and high pressure circuits. Read More

Sensors, Monitors & Transducers

Particle Monitor continuously measures solids in fluids.

April 23, 2008

Offered as stationary sensor that delivers instantaneous readings, TestMate Contamination Monitor (TCM) is designed for connection to hydraulic and lubrication lines with pressures up to 1,450 psi and viscosities up to 4635 SUS. It is enclosed in 4 in. dia case, utilizes optical sensor, and is able to self-diagnose continuously with error vindication via status LED. Measurement results can be output as contamination code according to ISO 4406: 1999 or SAE AS 4059 (D). Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Ambient Particulate Monitor has touchscreen user interface.

December 10, 2007

TEOM Series 1405 comes in 4 models providing ome to three PM measurements, PM-10, PM-2.5 (Fine), and PM-Coarse (PM-10-2.5), and FDMS option is available to account for volatile and semi-volatile fraction. Each model is delivered with network-ready configuration with user interface that allows access to system and TEOM data, settings, and instrument conditions. System's default data output consists of a running 1 hr and 24 hr average mass concentration updated every 6 minutes. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Particulate Transmitter utilizes induction sensing.

December 5, 2007

Usable as dust collector emissions monitor and leak detector, standard Series PMT is designed for general maintenance planning and process protection applications. Adjustable linear or logarithmic output scaling enables trending of baseline and high peak emissions that are caused by filter cleaning cycles and developing leaks. Protective layers on probe work with induction-sensing to ensure reliable operation with all types of particulate. Read More

Sensors, Monitors & Transducers

Particulate Sensor requires minimal maintenance.

August 6, 2007

Employing combination of passive-induction and protected-probe technologies, PMS Particulate Sensor detects all types of particulate including moist powders and conductive dusts. As particles flow near and around probe, minute currents are dynamically induced into probe by flowing particulate. DSP processes signal into absolute output that is reasonably linear to mass. For durability, sensors are passive and free of electronics. Read More

Sensors, Monitors & Transducers

Particulate Monitor gauges leaks in real time.

July 20, 2007

Combined with PMS Particulate Sensor, Series DPM provides basic baghouse and cartridge filter leak detector for general maintenance planning and process protection. Alarm point is set by moving indicator up and down gauge with lockable keypad. Housed in cast aluminum enclosure, monitor features LCD that displays particulate levels in bargraph and digital forms. Absolute units ensure correct interpretation of readings and provide accurate historical comparisons. Read More

Sensors, Monitors & Transducers

Monitor detects ferrous debris in oil.

June 28, 2006

ANALEX® FDM detects and measures ferrous wear debris in lubricating oils, hydraulic oils, and greases with resolution of 1 ppm in range of 0-2,000 ppm. Test data can be time stamped and stored in internal memory, then transferred to database on host PC using RS232 interface. Data entry via touch pad screen can include equipment identification, sample number, and lubricant hours. Self-contained, rugged, bench or portable unit is supplied protective portable carrying case. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Contamination Monitors perform fluid cleanliness analysis.

December 7, 2004

Portable Cleanliness Monitor, PCM400, and Particle Counter, PFC400W, obtain fluid cleanliness data in order to detect abnormal contamination. Former uses multiple mesh blockage technology to monitor fluids that are dark, cloudy or contaminated by water or air. Particle counter measures size and quantity of particulate in industrial fluid systems. It combines laser blockage technology with water sensor, which measures amount of dissolved moisture in oil. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Particulate Analyzers are suited for in-use measurements.

November 24, 2003

SEMTECH QCM (quartz crystal microbalance) and MPS (micro-proportional sampler) provide transient, mass measurement of particulate matter (PM) in engine exhausts. Former calculates mass of PM with resolution approaching 1 nanogram. SEMTECH MPS delivers response times of 0.1 sec and operational speeds of greater than 5 Hz. Based on Labview® platform, both are configurable for short, high-mass deposits or long-term sampling. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Materials & Material Processing

Liquid Standards Generator handles highly reactive VOCs.

July 10, 2003

Model LSG-2-GF continuously blends flowing stream of calibration standards mixture. It uses permeation technology to add analyte to precisely known flow of clean water to form primary mixture, an aliquot of which is then diluted to form liquid standard. Dilution water flows are controlled by precision metering pumps. Concentrations ranging from sub ppb (w/w) to several ppm are possible, and output flow range is 10-200 cc/min. Read More
