Microcontrollers offer 2 independent closed loop channels.

March 2, 2015

Based on 8-bit platform, Series PIC16(L)F1769 comprises intelligent analog and digital peripherals, including tri-state op amps, 10-bit ADCs, 5- and 10-bit DACs, 10- and 16-bit PWMs, and high-speed comparators, along with two 100 mA I/Os. Programmable Ramp Generator provides real-time responses to system change, without CPU interaction for multiple independent channels. Hardware-based LED dimming control function is enabled by interconnections of Data Signal Modulator, op amp, and 16-bit PWM. Read More

Electronic Components & Devices, Computer Hardware & Peripherals

Automotive-Grade MCUs support HMI and LIN applications.

March 2, 2015

Based on ARM® Cortex®-M0+ processor, SAM DA1 Series features integrated peripheral touch controller for capacitive touch button, slider, wheel, or proximity sensing applications. Atmel |SMART MCU products operate at max frequency of 48 MHz and reach 2.14 Coremark/MHz. Housed in 5 x 5 mm QFN package with wettable flanks for automated optical inspection, AEC Q100 Grade 2-qualified devices come with 32–64 pins, up to 64 KB Flash, 8 KB SRAM, and 2 KB read-while-write Flash. Read More

Electronic Components & Devices

Compact ADC/DAC/GPIO Combination IC fosters design flexibility.

March 2, 2015

Integrating 400 Ksps ADC, 6 µsec settling time DAC, digital inputs/outputs, and reference on 2 x 2 mm WLCSP, AD5592R can be user-configured in any combination of up to 8 devices. This lets designers use one IC to complete multiple system monitoring and control functions in high-density and space-constrained applications. Safe power-up functionality prevents conflict with external circuitry if set up incorrectly. Read More

Electronic Components & Devices

Audio Modulated LED Driver supports 144 LEDs.

February 27, 2015

Supporting 2 arrays of 72 LEDs, Model IS31FL3732 features pre-programmed lighting and animation functions which are accessed via 1 MHz I2C compatible interface. LEDs can be individually dimmed in 256 steps with 1/9 cycle rate. Housed in 5 x 5 mm QFN-40 package, IS31FL3732 integrates 8 frames of memory, which can be displayed with programmable time delays to create LED matrix animations. For extra dimension, analog inputs such as audio signals can be used to modulate LED display intensity. Read More

Electronic Components & Devices

Clamshell BGA Socket features heat sink lid.

February 27, 2015

Designed for 25 x 25 mm package size, Model GT-BGA-2019 operates at bandwidths up to 75 GHz with less than 1 dB of insertion loss. Socket is designed to dissipate 7 W using compression screw with heat sink fins and can be customized up to 100 W with modified fin design on top of screw and adding axial flow fan. Constructed with low inductance elastomer contactor, socket features typical contact resistance of 30 mΩ per pin and is mounted on target PCB with no soldering. Read More

Electronic Components & Devices, Computer Hardware & Peripherals, Communication Systems & Equipment

Microwave Baseband/RF SoCs support growing wireless traffic.

February 27, 2015

Integrating cross-polarization interference cancellation (XPIC) and line-of-sight multiple-input and multiple-output (LoS-MIMO) functionalities, BCM85650 supports channel aggregation and delivers 4K-QAM (quadrature amplitude modulation). Employing digital RF correction mechanisms, BCM85820 integrates support for XPIC, MIMO, 4K-QAM modulation, 112 MHz channels, and channel aggregation. Both SoCs provide mobile access carriers with 5 Gbps capacity and 48 bps/Hz spectral efficiency. Read More

Robotics, Sensors, Monitors & Transducers, Electronic Components & Devices

Motion Module combines co-processor with motion sensors.

February 27, 2015

Measuring 17 x 17 mm, self-calibrating MM7150 Motion Module combines SSC7150 motion co-processor with 9-axis sensors, including accelerometer, magnetometer, and gyroscope. Co-processor is pre-programmed with sophisticated sensor fusion algorithms which intelligently filter, compensate, and combine raw sensor data to provide accurate position and orientation information. With I2C connection to most MCUs/MPUs, embedded/IoT applications can tap into module's motion and position data. Read More

Electronic Components & Devices

TRIAC-Dimmable LED Drivers deliver 15 W output.

February 26, 2015

Compatible with leading edge, trailing edge, and smart dimmer technologies, PDA015N Series provides flicker- and shimmer-free performance for residential LED fixtures, including indoor and outdoor downlights and area lights. Waterproof devices are available in 3 constant current outputs of 350, 700, and 1,000 mA. Measuring 3.15 x 3.07 x 0.99 in., drivers operate using 108–132 Vac and ≤0.3 A input power to deliver 80% efficiency at 120 Vac with power factor of >0.9 and THD of less than 20%. Read More

Electronic Components & Devices

Dual Inductor operates up to 155°C.

February 26, 2015

Offering 2 inductors in one 4032 package, Model IHLD-4032KB-5A is optimized for automotive and commercial class D amplifier circuits. AEC-Q200-qualified inductor offers max DCR from 32.6–107 mΩ, inductance from 10–33 µH, rated current to 5.6 A, and frequency range up to 1 MHz. Manufactured with 100% lead-free, shielded, composite package, IHLD-4032KB-5A is specified for operating temperature of 55–155°C, with resistance to thermal shock, moisture, mechanical shock, and vibration. Read More

Electronic Components & Devices

Embedded Platform powers IoT and other connected devices.

February 26, 2015

Housed in 107 x 115 mm package, Osprey Visual IoT Platform is based on Intel Quark X1000 SoC, which provides Ethernet, USB Host, USB Client, UART, SPI, I2C, and GPIOs. Device also includes SM750 embedded graphics controller and Ferri eMMC storage, which is compliant with eMMC/JEDEC 4.5. SM750 features dual analog CRT and dual 18-bit/single 24-bit digital outputs, dual full HD or single 1,920 x 1,200 max resolution support, 16 MB integrated video memory, and 128-bit 2D ROP3 graphic engine. Read More

Electronic Components & Devices

FPGAs, 3D ICs, and MPSoCs suit LTE Advanced applications.

February 26, 2015

Suited for 5G wireless, terabit wired communications, automotive ADAS, and IoT applications, UltraScale+ FPGA portfolio comprises Kintex® UltraScale+ FPGA and Virtex® UltraScale+ FPGA and 3D IC families, while Zynq® UltraScale+ family includes all programmable multi-processing SoCs. UltraRAM, scaling up to 432 Mbits, attacks bottlenecks by enabling SRAM integration. SmartConnect technology applies interconnect topology optimizations to match design-specific throughput and latency requirements. Read More

Electronic Components & Devices

AC Motor Run Capacitors accelerate install with locking terminals.

February 24, 2015

Supplied in rugged, flame-retardant case, QPC Series operates from -25 to +85°C and offers locking push-wire contacts that accelerate installation and eliminate soldering. Users push and lock wire in place, and removal is accomplished by sliding probe tip into release port. Removable slide-lock metal mounting bracket, which can be mounted first, also accelerates assembly. Multiple contacts eliminate need for terminal strips, and standard values include 0.4–10 µF, 250–450 Vac, 50/60Hz. Read More

Electronic Components & Devices, Electrical Equipment & Systems

Multi-Channel Automotive-Grade PMIC suits ADAS applications.

February 24, 2015

Supplied in 40-pin QFN package, S6BP401A multi-rail power management IC lowers system heat and complexity for advanced driver assistance systems (ADAS) implementation. Power output includes 4-channel DC/DC converter and 2-channel LDO. Output setting impedance and phase compensation circuits are integrated internally for all channels, and other features include windowed watchdog timer, separate pins to turn on/off each channel, and dedicated pins to monitor power integrity of each channel. Read More

Electronic Components & Devices, Computer Hardware & Peripherals

Microcontroller targets MFP devices.

February 24, 2015

Built around ARM® Cortex®-M0 processor, Model TMPM036FWFG is specifically designed for use in multifunction peripheral devices and printers. Microcontroller incorporates 8-channel communication interface, 14-channel 16-bit timer, 128 KB of Flash, and 16 KB of SRAM. Housed in 14 x 14 mm LQFP 100-pin package, device operates from 2.3–3.6 V with max frequency of 20 MHz. Read More

Communication Systems & Equipment, Electronic Components & Devices

Universal Quad Clock (800 MHz) suits complex timing solutions.

February 24, 2015

Utilizing flexible delta-sigma modulator and 2–3 GHz VCO, XR81411 quad-output LVCMOS/LVDS/LVPECL configurable clock synthesizer generates 10–800 MHz frequencies with 4 independent PLLs. Clock outputs have phase noise jitter down to <0.2 psec, and each independent output can be configured to select from 4 different frequency multiplier settings. Supplied in 5 x 5 mm LGA package, each clock synthesizer includes integer/fractional divider that allows output frequency resolution of <2 Hz intervals. Read More

Mounting & Attaching Products, Electronic Components & Devices, Electrical Equipment & Systems

External Power Adapter meets Level VI efficiency standards.

February 23, 2015

While meeting efficiency and no load input power requirements of US Department of Energy (DOE) Level VI standards, SWI12-SC (12 W) and SWI24-SC (24 W) series feature screw terminal connections that accommodate designs requiring flexibility beyond standard 5 ft DC cord. Output options include 12, 15, and 24 Vdc; no-load power consumption is <0.1 W; and universal input range is 90–264 Vac. These single-output US wall power adapters cover both UL 60950 and UL 1310 safety approvals. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Communication Systems & Equipment, Electronic Components & Devices

Analog Video Decoder/Encoder for ADAS improves automotive safety.

February 20, 2015

Able to replace up to 9 discrete components with one 10 x 10 mm WQFN chip, AEC-Q100 qualified TW9984 enables generation of 360° surround images for advanced driver assistance systems (ADAS). Integration of 4 NTSC/PAL analog video decoders with 10-bit ADCs supports 4 analog camera inputs simultaneously. For system designer, flexible digital output interface facilitates sending of images to processor for combination of 4 images into unified around-view image. Read More

Electronic Components & Devices, Computer Hardware & Peripherals

Crypto Element enables smart, connected, and secure systems.

February 20, 2015

Targeting IoT market, ATECC508A provides confidentiality, data integrity, and authentication in systems with MCU or MPUs running encryption/decryption algorithms in software. This CryptoAuthentication™ IC requires one GPIO and integrates ECDH (Elliptic Curve Diffie-Hellman) security protocol, ECDSA (Elliptic Curve Digital Signature Algorithm) sign-verify authentication, and Elliptic Curve Cryptography (ECC) capabilities. Features include 256-bit SHA/HMAC hardware engine and 72-bit unique ID. Read More

Electronic Components & Devices

SMD Terminal Blocks have integrated pushbuttons.

February 20, 2015

Offering 1-, 2-, and 3-pole variants with 4 or 8 mm pin spacing, 2060 Series features strength-optimized housing material and wall thickness as well as mechanical stability-optimized housing length. Solid conductors can be inserted directly, and pushbuttons facilitate connection/removal of all conductor types. Suited for automated and manual wiring of fine-stranded conductors, products feature insulating material with optimized electrical properties for rated voltages up to 630 V (IEC). Read More

Electronic Components & Devices

Current Sensing LED Resistors suit battery-powered applications.

February 20, 2015

Bulk Metal® Z-Foil current sensing resistors improve LED brightness and efficiency in portable applications. With respective power ratings of 1 and 8 W and resistance ranges of 0.3–10 Ω and 0.5–500 Ω, LED1625 and LED221 provide TCR of 0.05 ppm/°C nominal (0 to +60°C) and 0.2 ppm/°C nominal (-55 to +125°C, +25°C ref), load-life stability of ±0.005%, and tight tolerances to ±0.01%. Non-inductive (<0.08 µH), non-capacitive design has PCR (or ΔR due to self-heating) of 5 ppm at rated power.
