Matrix Switches

Electrical Equipment & Systems, Test & Measuring Instruments

PXI Switching Solutions concurrently carry full 16 A on each path.

March 13, 2015

While 16 Amp PXI power multiplexer (model 40-662) comes in 7 configurations, from 4-off 2:1 multiplexers to 1-off 16:1 multiplexer, 16 Amp PXI power matrix (model 40-552) comes in 4 configurations with 8x2 and 4x4 matrix sizes and ability to expand matrix size with Y-Axis loop-thru connections. Both models, capable of withstanding 400 Vdc for cold switching, feature hot switching up to 16 A at 28 Vdc, max DC hot switch rating of 300 Vdc, and hot switching AC signals up to 250 Vac at 16 A. Read More

Electrical Equipment & Systems, Communication Systems & Equipment

KVM Matrix Switches/Extenders have hybrid fiber/CATx architecture.

February 16, 2015

Comprising matrix switches and extenders, TLX Series provides flexible and efficient, uncompressed signal architecture supporting fiber-optic and CATx connectivity. Extension and switching is possible for full, uncompressed 4K video with full color depth (4096 x 2160 resolution, 4-4-4 color depth) at 60 Hz frame rate using 2 fibers or CATx cables. Single laser, single-data-stream, 10 Gbps architecture supports delivery of uncompressed video, audio, and peripheral data. Read More

Electrical Equipment & Systems

High-Density LXI Switching Matrix has dual bus arrangement.

January 29, 2015

As 1,024 x 4 dual bus 1-pole matrix supplied in 1U full rack width enclosure, 60-553 supports high relay closure counts to optimize use with digital multimeter (DMM) or source meter for checking for insulation problems between single contact and all other contacts in unit under test (UUT) requiring closure of up to 1,024 crosspoint relays. Dual bus arrangement allows matrix to be divided into 2 smaller independent matrices and features isolation relays. Read More

Computer Hardware & Peripherals, Machinery & Machining Tools, Electrical Equipment & Systems

Multiservice Transport Platform aids seamless service evolution.

September 25, 2014

Designed to transport diverse traffic in metro-edge networking applications, Coriant™ 6350 Switch Node offers switch matrix (400G, high order/80G low order) and service interface (2.5G/10G) capacities that let end-users replace multiple nodes. SDH and Ethernet switching, along with low-order grooming, enable transport of end-user business services, mobile backhaul, and IP offload traffic. Platform also offers seamless scalability and low latency when Ethernet is mapped into SDH and OTN. Read More

Electrical Equipment & Systems

Cross-Point Matrix Switch supports 4K Ultra HD digital media.

July 1, 2014

Suited for small-to-large enterprise connectivity applications, Genesis XD is designed as modular, non-blocking, full cross-point matrix switch that is scalable from 8 x 8 to 256 x 256 for connectivity to one or many displays. Unit accepts and converts both analog and digital signals, including HDMI 1.4b with HDCP, Display Port, DVI, VGA, Component, and 3G HD-SDI. Signals can be transmitted to remote locations via singlemode or multimode Fiber, CATx/HDBaseT, or IP/Ethernet. Read More

Electrical Equipment & Systems

PXI Express Matrix Switch delivers 320 crosspoints.

April 29, 2014

Rated at 300 V and 2 A, Model SMX-4410 is designed for ATE systems where max signal integrity and density is desired. Programmable switch contains four (4 x 10) 2-wire building blocks that can be bussed together under software control to create 2 (8 x 10), 1 (8 x 20), 2 (4 x 20), or 1 (4 x 40) 2-wire matrices. Module incorporates extensive signal shielding and exposes shield pins on front panel connector for tying to cable shield. For preventative maintenance, self-test utility is provided. Read More

Electrical Equipment & Systems

Matrix Module targets critical signal switch applications.

April 21, 2014

Made up of dual 2 x 32 (2-wire) matrix with access to integrated DMM within chassis, Safe-to-Connect EX1200-4265 provides parametric testing capability when connecting to critical products such as rockets, missiles, and aircraft. Switch module combined with software allows users to accomplish isolation measurements between any 2 points, continuity measurement, and parametric path measurement. Users can scale up from 64 channels to thousands of channels as required by application. Read More

Electrical Equipment & Systems

HDMI Matrix Switch features HDBaseT functionality.

February 20, 2014

Unlike standard HDMI Matrix Switches that rely on external extenders, Model HDMICAT-44-HDB has HDBaseT extension built into transmitter. It is also paired with 4 HDBaseT receivers that can be connected to remote displays using long runs of standard Category 6 cable. Each receiver includes independent zone remote control for selecting input source without having to go near Matrix Switcher itself. With IR emitter, each source device can be independently controlled from each remote location. Read More

Electrical Equipment & Systems, Communication Systems & Equipment

Wireless Matrix incorporates multicast capabilities.

January 10, 2014

Available for consumer, business, and custom installations, Long Range Wireless 5x2 HD Matrix Pro (GWHDMS52MB) can send same content to as many as 4 wireless receivers. Solution can send fully uncompressed HD 1080p content up to 200 ft through standard residential walls from up to 5 sources (digital and analog). With additional Wireless HD Matrix Receivers (GWHDRX01), same content can be sent to 5 locations. Matrix supports HD 1080p, 3D content, and 5.1 channel digital audio. Read More

Electrical Equipment & Systems, Communication Systems & Equipment

Switch Matrix enables vector network analysis with up to 48 ports.

November 18, 2013

Able to be controlled and operated directly from R&S ZNB network analyzer for testing multiport components, R&S ZN-Z84 external switch matrix comes in base model equipped with 6 test ports and covers 10 MHz to 8.5 GHz range. Number of test ports can be increased in groups of 6 to provide up to 24 ports when needed, enabling 4-port R&S ZNB with two 24-port matrices to support 48 test ports. Solution suits users in R&D and production who test components for communications sector. Read More

Electrical Equipment & Systems

HDMI Matrix supports demands of professional applications.

November 1, 2013

Featuring seamless switching that ensures immediate delivery of HD A/V content, 4 x 4 Seamless Matrix for HDMI provides full cross-point routing of 4 sources to 4 displays. Built-in scaler allows precise video refinements up to 1080p full HD with added ability to resize each image for exact alignment and performance. While matrix provides ability to configure up to 10 routing scenarios for professional installations, users can also upload configurations on-the-fly using IP connectivity. Read More

Electrical Equipment & Systems

Single-Pull 4-Throw Switch Matrix covers DC to 18 GHz band.

August 21, 2013

Supplied in rugged metal casing, USB-1SP4T-A18 has RF switch with longevity of 100 million cycles and typical switching time of 25 msec. Configuration includes 5 SMA(F) connectors (COM, 1, 2, 3, and 4); 2.1 mm DC socket; and USB type B control port. Offering 0.2 dB typ insertion loss and 85 dB typ on/off isolation, product suits test lab applications and includes GUI software with API DLL com object. Switch position is indicated on control screen and device itself. Read More

Electrical Equipment & Systems, Communication Systems & Equipment

Multi-Format Matrix Switcher extends life of legacy gear.

August 8, 2013

Allowing legacy gear to operate seamlessly alongside digital video equipment, DVS-MFSW-94XT provides 4 HDMI with stereo audio, 3 HDMI via CATx cable, and 2 multi-format analog inputs. On output side, switcher features 2 HDMI outputs and 2 HDMI over CATx outputs, each scaled to match resolution of display. Incorporating intelligent EDID and HDCP management, unit can be controlled from front panel, remotely via RS-232 or TCP/IP, or through built-in web server. Read More

Software, Electrical Equipment & Systems

Automated Switching Solution tests multilane digital buses.

May 21, 2013

Used for testing each lane of multilane digital bus interfaces (DisplayPort, HDMI, PCIe®, MIPI™ D-PHY/M-PHY), automated switching solution comprises switch matrix software options for Infiniium compliance applications and preconfigured switch matrix hardware models that work with applications. Supported switch matrix hardware models include Agilent U3020AS26 and BitifEye BIT-2100 Series. Solution works with Infiniium Series oscilloscopes and is available on compliance applications. Read More

Electrical Equipment & Systems

Multi-Slot, 2 A, PXI BRIC Matrix has high-density design.

May 2, 2013

Occupying 2/4/8 slots of PXI chassis, Model 40-568 provides range of 1-pole matrix solutions from 75x4 to 600x4. It uses electromechanical relays to achieve 2 A switch rating and 60 W power capability to voltages up to 100 Vdc, 70 Vac. BRIC structure allows creation of large matrices in PXI over multiple slots, while integrated programming interface represents matrix as single entity to facilitate user programming and reduce user error. User connections are made via 78-way D-type connectors. Read More

Electrical Equipment & Systems

High-Density PXI Matrices feature 2 A current rating.

May 2, 2013

Models 40-575, 40-576, 40-577, 40-578, and 40-579 are single-slot, 1-pole matrices with up to 60 W hot switch power and 150 Vdc/100 Vac rating. Featuring PXI matrix sizes of 84x4, 64x6, 50x8, 36x12, and 28x16 as well as Y sizes of 6 and 12 to compliment standard 4, 8, and 16 sizes, products use electro-mechanical relays and allow for switching matrix expansion. Depending on model, user connections are provided by 160-pin DIN41612, 78 way D, and 50 way D type connectors. Read More

Electrical Equipment & Systems

LXI Wideband Modular Matrix features fully scalable design.

November 29, 2012

Fully compliant with LXI Version 1.4 standard, Model 65-110 supports up to 16 of 104 X connections simultaneously to 16 measuring devices on Y axis with usable BW of 500 MHz. Users can add X connections in blocks of 8 from 8–104 connections by adding or removing plug-in boards to chassis. Matrix achieves crosstalk better than 60 dB at 30 MHz and typically better than 45 dB at 500 MHz, even on adjacent paths. All connections are carried on SMB coaxial connectors to preserve signal BW. Read More

Electrical Equipment & Systems, Communication Systems & Equipment

HDMI/DVI A/V Matrix Switch utilizes CAT5e/6/7 cable.

October 9, 2012

Designed to route audio and video inputs from 8 HDMI/DVI video sources to 8 displays and speakers via CAT5e/6/7 cable, VEEMUX® SM-8X8-C6HD supports HDTV resolutions to 1080p and computer resolutions to 1920 x 1200 with video quality adjustment done automatically at every connection change. Distance between HDMI and DVI receivers and transmitters can be extended up to 600 ft. Compliant with HDCP, switch can be controlled through Ethernet, serial port, front panel buttons, or IR remote control. Read More

Electrical Equipment & Systems, Communication Systems & Equipment

Multi-Matrix Color Corrector operates in real-time.

August 20, 2012

As live HD/SD-SDI signal passes through, DCC-7000 performs real-time adjustment, enhancement, and color correction of up to 12 separate colors and hues in video. Product offers 12-axis color correction, which includes RGB, saturation, and hue. Supporting HDTV and SDTV standards with 10-bit, 4:2:2 digital signal processing, standalone unit is available with front panel control or external control panel. Areas of use include live sports and post production applications. Read More

Electrical Equipment & Systems, Communication Systems & Equipment, Optics & Photonics

Optical Matrix Switch cross connects up to 192 x 192 fiber ports.

March 2, 2012

As fully non-blocking, all-optical, single-mode fiber cross-connect for up to 192 x 192 fiber ports, Series 6000 Optical Matrix Switch exhibits less than 1 dB typ optical loss. DirectLight® beam-stearing optical switch technology allows optical connections to be established with or without light on fiber; supports transparent, protocol-agnostic connections; and can switch bi-directional and transient signals. Modular design allows symmetric and asymmetric matrix configurations. Read More
