CPU Heatsinks

Computer Hardware & Peripherals

Multi-Sectional Fansinks effectively cool CPUs and GPUs.

January 21, 2016

Based on Multiple Flow Entrance Technology™, QuadFLOW™ Fansinks use directed airflow in multiple fin fields, cooling electronic components more effectively than liquid cooling methods. Fin fields are not parallel to each other, but instead are designed to allow airflow to enter from multiple directions. Airflows reach central core, where they are extracted by blower through multiple fin fields. Depending on configuration deployed, cooling performance is near or equal to 0.1°C/W. Read More

Computer Hardware & Peripherals

Heatsink Kit supports 120 W LED flood lights.

August 25, 2015

Featuring heatsink with thermal resistance of 0.34°C/W, mounting bracket with 90° adjustability, and optional lens or LED cover, Igloo SS120 accommodates high-output CoB or MPCB LEDs up to 120 W. Kit can be ordered in single, double, or triple unit options. Up to 3 flood lights, each on its own adjustable bracket, can be connected together for high output lighting needs. With each module rated for 120 W, total of 360 W of LED flood lighting can be grouped as triple unit array. Read More

Computer Hardware & Peripherals, Materials & Material Processing

Low-Profile Heatsinks enhance space-constrained designs.

July 29, 2015

Optimized for deployment in streamlined, high-density electronic designs, LPH00xx series utilizes VersarienCu™ microporous copper technology and offers form factors that cover 10 x 10 x 2 mm through 40 x 40 x 5 mm. Microporous structure maximizes surface area and optimizes heat dissipation in space constrained designs. For applied load of 5 W, thermal resistance of 40 x 40 x 5 mm LPH0010 heatsink is 17.4°C/W, while 20 x 20 x 5 mm LPH0004 offers thermal resistance of 35.8°C/W for 2 W load. Read More

Materials & Material Processing, Computer Hardware & Peripherals, Thermal & Heating Equipment

Thin Cooling Device eliminates hot spots in compact electronics.

March 23, 2015

At <1 mm thick, thin loop heat pipe helps prevent overheating of localized parts due to heat generated from internal components in such small, thin electronic devices as smartphones and tablets. Heat-transfer device consists of evaporator and condenser connected by pipes into loop with encapsulated working fluid. Evaporator features six 0.1 mm thick copper sheets stacked together and contains porous structure with numerous holes driving fluid with capillary action. Read More

Computer Hardware & Peripherals

Zipper Fin Heat Sinks optimize cooling performance.

March 20, 2015

Designed to protect components from excess heat, Zipper Fin Heat Sinks have zipper fins machined from thin sheet metal, typically aluminum or copper, formed into custom shapes. Sheets are designed to interlock with very narrow space between layers. Fin assembly is wave soldered to metal base forming very rigid, lightweight heat sink. To contain and optimize cooling airflow, heat sinks can be designed with integral ducts. Read More

HVAC, Computer Hardware & Peripherals

CPU Cooler and Fan suit space-restricted systems.

March 20, 2015

With compact heatsink and 14 mm NF-A9x14 PWM fan, NH-L9x65 Cooler stands 65 mm tall, making it suitable for home theater PCs and Small Form Factor cases. Unit provides 4 heatpipes in 95 x 95 mm footprint, guaranteeing 100% RAM and PCIe compatibility on Intel-based ITX mainboards. Available in PWM version, 60 mm NF-A6x25 Fan has NE-FD1 IC for fully automatic speed control via 4-pin fan headers and comes with Low-Noise-Adapter to reduce max speed during PWM control from 3,000 to 2,300 rpm. Read More

Computer Hardware & Peripherals, Thermal & Heating Equipment

Stamped Heatsinks cool high-power LED lighting.

February 2, 2015

Available in 3 power ratings of 100, 150, and 200 Watts, Igloo SS Series features rectangular profile and provides up to 0.53°C/W thermal resistance using stamping process. Heat pipe models dissipate heat from high-power CoB LEDs using evaporative technology, while non-heat pipe models are suitable for lighting fixtures with multiple CoB LEDs or Metal Core PCB LEDs. Number of fins can be tailored to fit LED fixture housing, and base mounting pattern can be customized to design specification. Read More

Computer Hardware & Peripherals

Heat Sinks work with panel mount solid state relays.

December 16, 2014

Available in variety of sizes with different mounting methods, including DIN rail, panel, and through-wall mounting, Heat Sinks work with solid state relays for resistive and inductive switching/motor control. Units feature thermal resistance ranges from 4.0–0.12°C per Watt, and include options for single or multiple SSR assemblies. Read More

Computer Hardware & Peripherals, Thermal & Heating Equipment

Cold Forged Round Heatsinks enhance CoB/MPCB LED heat dissipation.

October 17, 2014

Heatsinks for CoB LED applications use 7 or 10 mm base to address heating needs. Base thickness spreads heat dissipation for effective operation. Heatsinks for Metal Core PCB (MPCB) LED applications use 5 mm base for efficient cooling. Inherently designed with concern for thermal management in mind, metallic board exhibits thermal resistance that promotes heat dissipation over horizontal surface area. Use of thin base accelerates raising of heat to fins to promote heating efficiency. Read More

HVAC, Computer Hardware & Peripherals, Thermal & Heating Equipment, Green & Clean

Dual Tower CPU Cooler provides quiet operation.

April 18, 2014

Featuring 150 mm wide fin-stack and widely spaced heatpipes, Model NH-D15 enables uniform heat distribution for optimal efficiency. Recessed lower fins enable NH-D15 to provide 64 mm clearance for tall memory heatsinks in single fan mode. Cooler also features pro-grade SecuFirm2™ multi-socket mounting system and NF-A15 fans that support PWM for automatic speed control through mainboard. Using supplied Low-Noise Adapter, max fan speed can be reduced to 1,200 rpm for quieter operation. Read More

Material Handling & Storage, HVAC, Computer Hardware & Peripherals

CPU Coolers feature pulse width modulation.

January 30, 2014

Compatible with Intel® LGA1366 type CPUs up to 85 W, Freezer 120 Series is available with pulse width modulation, with fan speed changing automatically, based on CPU loading activity. Fan speed operates within range of 800–4500 rpm with maximum airflow of 27.02 cfm and noise range of 0–39 dBA. Measuring 90 x 90 x 26.5 mm, coolers have 2 ball bearings and are rated for 12 V operation. Read More

Computer Hardware & Peripherals

Heat Sinks cool high-power LEDs.

December 2, 2013

Comprising 32 heat sinks for convection cooling of high heat flux LEDs, Star series is made from aluminum and has round profile. Cooling fins, arrayed in round, star-like cross section, optimize thermal performance in local air flow. Depending on model, cooling performance reaches more than 60 K (∆Ths-ambient) at 50.0 W of power dissipation. Flat base at one end allows secure, direct mounting of LEDs, while integral threads on base perimeter allow attachment of brackets and other hardware. Read More

HVAC, Computer Hardware & Peripherals

CPU Coolers offer pulse width modulation option.

August 8, 2013

Measuring 60 x 58 x 31 mm, Freezer 200 Series is compatible with Intel® Mobile type CPUs up to 65 W. Standard 2-ball bearing units feature fan speed of 5,300 rpm with airflow of 11.06 cfm and 33 dBA noise. With PWM, fan speed changes automatically based on CPU loading activity. PWM-enabled models support fan speeds from 500–5,300 rpm with max airflow of 11.06 cfm and noise range of 14–33 dBA. All fans used in coolers have rated voltage of 12 V. Read More

HVAC, Computer Hardware & Peripherals

CPU Coolers include fans with automatic speed control.

May 24, 2013

Model NH-U12DX i4 CPU coolers feature NF-F12 120 mm fan and 45 mm fin depth, allowing access to RAM slots. Integrating two NF-B9 92 mm fans, NH-U9DX i4 units measure 125 mm high, supporting use with standard 4U server cases. Products support LGA1356, LGA1366, and square and narrow ILM LGA2011-based Xeon platforms. They are fitted with SecuFirm2™ mounting system and include industrial-grade NT-H1 thermal compound and low-noise adaptors to minimize fan speed and noise. Read More

HVAC, Computer Hardware & Peripherals

Slim Single-Tower CPU Coolers deliver quiet operation.

April 17, 2013

While NH-U12S comes with NF-F12, 120 mm FocusedFlow™ fan, NH-U14S features 6 heatpipe design and NF-A15, 140 mm fan. Both fans support PWM for automatic speed control through mainboard, and max fan speed can be reduced from 1,500–1,200 rpm using supplied Low-Noise Adaptor for quieter operation. Design facilitates RAM access and promotes compatibility with tall memory modules. Other standard features include pro-grade SecuFirm2™ multi-socket mounting system and NT-H1 thermal compound. Read More

HVAC, Computer Hardware & Peripherals

CPU Coolers feature low-profile, socket-compliant design.

November 8, 2012

Providing full compatibility with tall RAM modules and VGA cards on mini-ITX mainboards, NH-L9i and NH-L9a are respectively intended for Intel LGA115x- and AMD FMx-based HTPCs and SFF systems. These 37 mm tall CPU coolers employ 23 mm heatsink that complies with Intel LGA115x and AMD FMx socket keep-out zones as well as 14 mm thick NF-A9x14 fan that supports PWM for fully automatic speed control. Low-Noise Adaptor, included, allows max fan speed reduction from 2,500 to 1,800 rpm. Read More

HVAC, Computer Hardware & Peripherals

CPU Coolers work with Intel® LGA 775/1155/1156 CPUs.

October 4, 2012

Optimizing cooling effect to components surrounding CPU to help extend working hours, Igloo i670CU Combo CPU coolers are constructed of aluminium alloy, feature high-fin density with Y shape, and come in constant fan speed and PWM versions. Latter increases fan speed with overloading of CPU and operates at 800 rpm ±300 rpm to 3,600 rpm ±10%. Constant speed versions are specified at 2,000, 2,600, and 3,200 rpm, all ±10%. Depending on model, 12 Vdc units operate at 20, 25, 32, or 15–38 dBA. Read More

Computer Hardware & Peripherals

Radial-Fin Heat Sink Extrusions target LED light engines.

June 12, 2012

Made of black anodized aluminum, 19000 Series features radial-fin geometry optimized for natural convection. Five models are available with power ratings of 42.8, 26.3, 9, 4.5, and 24 W and corresponding thermal resistances of 0.68, 1.15, 2.38, 3.27, and 1.15 C/W. Expected temperature rise above ambient ranges from 14.7°C max for 4.5 W model to 29.2°C for 42.8 W unit. Available in 2-10 in. lengths and 1.26-4.51 in. diameters, heat sinks include screw bosses for LED substrate attachment. Read More

Computer Hardware & Peripherals, Thermal & Heating Equipment

Adaptable Heatsinks accommodate TO-264 devices.

May 14, 2012

C-series heatsinks feature camming clips that eliminate need for mounting holes and screws and provide same amount of force after repeated use. They are now offered in 30, 58, and 85 mm for TO-264 packages. Series is also offered in 25, 50, and 75 mm lengths for TO-220 and TO-247 devices, and TO-126 heatsinks are offred in 25 mm for single clip and 40 mm for 2 clips. Custom lengths and clip quantities are available. Read More

HVAC, Computer Hardware & Peripherals

Compact CPU Cooler comes in PWM, constant speed versions.

April 16, 2012

Igloo 5761 series, comprising 96 x 128 x 90 mm tower style exposed heatpipe base CPU coolers, is designed for socket types from Intel LGA775/1155/1156 and AMD FM1/AM2/AM2+/AM3/AM3+ and also provides cooling effect to components around CPU. With 30 dBA noise rating, PWM version increases/deceases fan speed, from 800 (±300 rpm) to 2,000 rpm (±10%), to match CPU load and produces 43 cfm airflow. Constant fan speed version, operating at 1,200 rpm, produces 34 cfm and is rated at 20 dBA. Read More
