HDMI Extender supports Ultra HD/4K resolution.

May 18, 2015

Able to extend 4K, 3D, 1080, 720, and 480 signals up to 75 ft, Phantom Series™ KD-HD1x1ProK and KD-HDFIX22 HDMI Extenders feature EDID booster and buffer with built-in audio de-embedding of digital coaxial and analog L/R. Forced Hot Plug Detection ensures source always outputs signal. Additionally, KD-HDFIX22 is HDCP 2.2 compliant, uses auto-eq to deliver optimal picture quality, and resolves such common HDMI integration obstacles as HDCP, EDID, HPD, and audio breakout. Read More

Test & Measuring Instruments

Ethernet-Over-Copper Extenders support PoE+ and pass through.

May 8, 2015

CopperLine® Ethernet over COAX/UTP products include CLFEEOC and CLFEPOE series capable of supplying 30 W of PoE+. While CLFEEOC series offers extended distance transmission with pass-through PoE meeting IEEE802.3af standard, CLFEPOE series can act as PoE power source (PSE), injecting IEEE 802.3at PoE+ to powered devices as well as support for pass-through POE+. There are 1-, 4-, 8-, and 16-channel models available that utilize coaxial cable or twisted pair. Read More

Test & Measuring Instruments, Communication Systems & Equipment

Optical Extenders target professional AV systems.

December 16, 2014

Using single fiber optic cable, Models DVI-7313 and DVI-7314 extend HDMI v1.4 signals with resolutions up to 4K/30p over cable distances of 1,640 ft and 1.2 miles, respectively. DVI-7313 supports Multi-Mode optical fiber, while DVI-7314 supports both Multi-Mode and Single-Mode fiber optic cable. By employing high-speed SerDes that combines DVI/HDMI signal channels into single uncompressed 10.3 Gbps bit stream, extenders enable transmission of signal over single wavelength. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Communication Systems & Equipment, Electronic Components & Devices

HDMI Splitter/Extender drives up to 8 displays.

February 12, 2014

Consisting of VOPEX-C6HD-8LC HDMI broadcast unit and ST-C6HD-R-130LC remote unit for each remote display, Splitter/Extender simultaneously distributes video and audio signals from HDMI source to up to 8 HDMI displays located up to 130 ft using CAT6 cable. Unit supports HDTV resolutions to 1080p and computer resolutions to 1920 x 1200. HDMI features include: 8- and 12-bit Deep Color; bandwidth up to 225 MHz (6.75 Gbps); LPCM 7.1 Channel, Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Coax Extender Kit facilitates CCTV system expansion.

September 26, 2013

POE over Coax Extender Kit helps firms consolidate cable installation expense by leveraging existing coax cable to build CCTV systems. Designed specifically to provide optimal image quality to HD cameras involved in monitoring surveillance applications, solution extends transmission of signal by distance of up to 900 ft within industrial setting. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Electrical Equipment & Systems

HDMI USB KVM Over IP Extender includes audio, RS232, and IR.

August 22, 2013

Supporting HDTV resolutions to 1080p and computer resolutions to 1920 x 1200, XTENDEX® ST-IPUSBH-1G provides remote KVM access to USB computer or HDMI source up to 330 ft over Gigabit network using single CAT5e/6 cable. Users can connect mouse, keyboard, flash drive, and/or HDD to 4 USB 2.0 ports on receiver. Providing full IR control of HDMI source from remote HDTV using existing source remote control, unit supports 2-way RS232 commands at baud rate of 115200. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

KVM Extenders and Network Switch form 10 Gbps solution.

April 3, 2013

Compatible with APO IntellaPatch® Series 3000 XE network switches, Matrox Avio F120 and F125 KVM Extenders use full bandwidth available in 10 Gbps SFP+ transceivers to transmit 2 uncompressed HD video signals, USB keyboard and mouse, USB 2.0 devices, and stereo analog audio over single fiber-optic duplex LC-LC cable. Once each workstation is connected to port on IntellaPatch XE switch, administrators can use APO software interface to route workstation or server to remote location. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Materials & Material Processing

Ethernet Extenders transmit data up to 10,000 ft. .

February 21, 2013

Designed for environments where network services are needed beyond Ethernet limit of 328 ft, Ethernet Copper Extenders expand Ethernet data transmission up to 10,000 ft over copper wiring. Over 40 models of 10/100 and 10/100/1000 extenders are available, operating in temperature range of -40 to 167°F. All have on-board microcontroller to deal with link error detection and recovery. Read More

Test & Measuring Instruments

DisplayPort Extender extends flat panel displays up to 1,000 ft.

October 13, 2011

Measuring 2.91 x 1.3 x 0.45 in., FO-DP-300-EMI DisplayPort Extender over Single SC Fiber Optic transmits up to 4 videos and 1 low-speed lane, while simultaneously receiving 1 low-speed signal, all on 1 multi-mode fiber. Device supports DPCP and HDCP by AUX channel as well as resolutions up to 2,560 x 1,600. Applications include video wall systems, large LED sign boards, medical imaging equipment, TV broadcast stations, and conference rooms. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

USB Over Cat5 Extender comes in wall plate version.

April 18, 2011

With wall-plate form factor that provides streamlined, finished look to wiring installations, USB Wall Plate (model B202-150-WP) uses Cat5/Cat6 cable and lets users place host computer up to 150 ft away from any USB peripheral device. Rear-mounted RJ45 jacks facilitate connections between wall plates, without 110-type punchdown connections. Compliant with USB 1.1 specifications, bus-powered solution does not require any additional AC adapters and provides 1.5-12 Mbps transfer rates. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Communication Systems & Equipment

KVM Extender drives mission-critical applications.

November 12, 2010

Utilizing bus extension technology to ensure full HD resolution support and uncompromised workstation performance at operator station, Extio F2408 separates up to 4 Hi-Res displays plus USB keyboard, mouse, and other HIDs from host system by up to 3,280 ft of fiber-optic cable. Additional outputs can be added, via optional Extio F2408 Expander, to connect up to 8 displays at resolutions up to 2,560 x 1,600 per monitor Independent and stretched mode supports 4x1 and 2x2 configurations. Read More

Test & Measuring Instruments

Cat 5 Audio/Video Extender provides dual audio/video output.

July 15, 2010

Model VE200 Audio/Video Extender has dual output that supports 1 local and 2 remote displays and offers video up to 1,920 x 1,200 at 60 Hz at 30 m, 1,600 x 1,200 at 60 Hz at 150 m, and 1,280 x 1,024 at 60 Hz up to 200 m. Product uses Cat 5e cable to connect local transmitting unit and remote receiving unit. Video quality adjustment is enabled by IR receiver, and IR remote control allows for screen on/off and video adjustment at remote site. Two RS-232 channels are also included. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Ethernet Extenders send 10/100 Ethernet up to 984 ft.

June 8, 2010

Enclosed in ruggedized aluminum cases that are wall, DIN-rail, or panel mountable, iCON-32300 Series extends 10/100 Ethernet circuits to 984 ft at up to 50 Mbps using existing copper telephone wire and up to 6233 ft at 1 Mbps. Units meet NEMA TS1/TS2 standard for traffic control equipment and IEC61000-6-2 EMC generic standard immunity for industrial environment. Operating from -40 to 75°C, extenders are suitable for building automation, surveillance, and digital signage. Read More

Test & Measuring Instruments, Communication Systems & Equipment

HDMI Extenders transmit stereo audio and RS-232 data signals.

August 21, 2009

Twisted pair transmitter and receiver modules AT-HDS100SR and AT-HDS250SR extend HD signals over CAT5/6/7 cables for up to 330 and 825 ft, respectively, maintaining video resolutions up to 1,920 x 1,200 with no signal degradation. Devices feature embedded equalizer, gain, and CTI adjustments, and built-in EDID for storing necessary data. HDCP compliant units come with wall mountable brackets. Read More

Test & Measuring Instruments, Communication Systems & Equipment

DVI Video Extenders are HDTV compatible.

August 18, 2009

Designed for computer video graphics, AT-DVI100SR and AT-DVI250SR are capable of extending video signal up to 330 and 825 ft, respectively, while maintaining video resolutions up to 1,920 x 1,200. Units are twisted pair transmitter and receiver modules that transmit stereo audio as well as RS-232 data signals over CAT5/6/7 cables. HDCP compliant extenders feature embedded equalizer, gain, and CTI adjustments, as well as built in EDED for storing necessary data. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

HDMI Video Fiber Optic Extenders are HDCP/DDC compliant.

July 27, 2009

Capable of sending HDMI v1.3 digital audio/video signal through multimode optical fibers, AT-HDF20SR and AT-HDF30SR allow any HD display to extend signals up to 1,320 ft at WUXGA or HDTV resolutions. They offer self adjustment with no compression, bit reduction, or signal degradation and can run multiple signals in single conduit without crosstalk. CEC compliant units support 12-bit color depth and have 8 dB input equalizer, which compensates losses over 16 ft. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Video Extenders transfer HD video over multimode fiber.

July 24, 2009

AT-DVIF20SR and AT-DVIF30SR are capable of sending DVI video signal and HDCP/DDC information through single multimode optical fiber, allowing any high definition source to extend signal up to 1,320 ft at WUXGA (1,920 x 1,200 at 60 Hz) or HDTV resolutions 1080p/1080i/720p. CEC compliant units support 12-bit color depth and have 8 dB input equalizer, which compensates signal losses over 16 ft. Both models are fully Mac and PC compatible, and include ESD protection on all I/O interfaces. Read More

Test & Measuring Instruments, Communication Systems & Equipment

Video Extenders transfer HD video up to 1,000 ft.

July 24, 2009

UL/CE approved, model AT-3GSDI20SR transfers high definition video over multi-mode, optical type, fiber optic cables without any signal loss. It can send 3G SDI signals, and allows users to transfer 1080P HDSDI signal at 3Gb/s, supporting single channel SMPTE-424M 3G HD-SDI, SMPTE-292M HD, or SMPTE-259M serial digital video signal. Supporting wide range of video formats including SDI, DVB-ASI, HD-SDI, and 3G-SDI, extenders are ideal for medical imaging applications. Read More

Test & Measuring Instruments, Display & Presentation Equipment

Extender Kit is designed for videoconferencing application

March 16, 2009

Featuring high speed differential signaling, WallVIEW PRO EagleEye 1080 HD provides HD video quality over longer Cat. 5 cabling distances and ability to adjust signal depending on length of cabling used. Kit includes EZCamera Interface Module, Quick-Connect PRO interface, Vaddio Thin Profile EagleEye 1080 HD wall mount and EZIM HD breakout cable. Other features included are four-position distance adjustment for Cat. 5 cabling, and Y-Gain adjustment for cable length compensation. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Communication Systems & Equipment

Video Extender distributes HD signal over CAT5/5e/6 cable.

November 17, 2008

AT-HD19SS, combined with AT-HDRS, form expandable solution for routing HD video and audio to multiple remote displays. AT-HD19SS units take HD video at resolutions up to 1080p over a HDMI 1.2a connection, and extend signal over single CAT5/5e/6 cable up to 200 ft. At each display end, cable is connected to AT-HDRS receiver units that feature adjustable equalizer, which ensures signal quality with no degradation. System can be cascaded, allowing for infinite number of display locations. Read More
