Level Indicators

Sensors, Monitors & Transducers, Test & Measuring Instruments, Controls & Controllers

Fluid Detector monitors fluid in tanks and piping.

March 13, 2015

Mounting directly into existing pipelines between 2 standard 150 lb flat-faced flanges, Clear Line™ Fluid Detector uses RF admittance to monitor presence or absence of fluid, providing complete assurance that tank is empty. Proprietary Cote-Shield™ circuitry ensures dependable detection regardless of conductive coatings or product build up on sensor. Featuring sanitary, crevice-free design, Clear Line works without recalibration on processes where fluids can vary from organics to caustics. Read More

Test & Measuring Instruments, Controls & Controllers, Sensors, Monitors & Transducers

Non-Contact Level Meter targets solids applications.

July 22, 2014

With frequency modulated continuous wave radar technology, DR6300 Series provides distance, level, volume, and mass measurement of powders, granulates, and other solids. Non-contact, 2-wire, k-band meter offers choice of touchscreens, including tank illustration, bar graph, oscilloscope, signal, and reflectivity screen. Available with drop antenna or horn antenna, device has measuring range of 260 ft and will operate up to flange temperature of 290°F and pressures of 580 psig. Read More

Test & Measuring Instruments, Controls & Controllers, Sensors, Monitors & Transducers

Single Float Level Transmitters suit shallow tank monitoring.

July 16, 2014

As drop-in replacements using existing tank fittings, XM/XT Series provide continuous fluid level monitoring of tanks with depths <20 in. XM/XT-300 Series, constructed from all-wetted polysulfone plastic parts, is direct compatibility with various chemicals, while XM/XT 700 Series comes in stainless steel or brass. Both fluid level transmitters feature 0.14 in. resolution, indicating length to 14 in., and stem length to 20 in. Custom mountings and float materials are available. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Transmitter/Receiver Pair enables wireless level measurement.

July 11, 2014

Able to maintain line of site communications over distances up to 125 ft, Wireless Level Measurement Transmitter and Receiver platform is intended for liquid level (0.0–34.6 ft) measurement. Transmitter sends updated level data and battery condition data once every second, while receiver reads that information and provides analog 4–20 mA output and SCADA register data. RS-232 serial port (Ethernet optional) allows connection to SCADA system for remote monitoring. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Liquid Level Gages offer adjustable centerlines.

February 13, 2014

Compensating for variances that can occur during production of plastic tanks, nylon liquid level gages accommodate centerline distances up to ¼ in. longer or shorter than specified measurement for total adjustability of ½ in. Adjustment can be made by hand, facilitating installation, and features include round Trogamid nylon sight that is clear and durable. Gages are available with centerline measurements from 6–36 in., and red line on back of sight enhances liquid level visibility. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Capacitance Point Level Indicator offers plug/choke detection.

November 15, 2013

IP65-rated for hazardous dust environments, Binswitch Elite detects level or plug situations for bulk granular solids or liquids in tanks, bins, or silos. Unit features user selectable relay output that can be magnetically calibrated to be normally energized or de-energized. During calibration, sensor automatically compensates for potential dust build up. Sensor is fully encapsulated in 30 mm diameter polycarbonate body that is corrosion- and abrasion-resistant, dust-tight, and waterproof. Read More

Test & Measuring Instruments, HVAC, Controls & Controllers, Electrical Equipment & Systems, Sensors, Monitors & Transducers

Capacitive Level Sensor suits rugged coolant applications.

July 26, 2013

Designed to resolve emergency generator failure issues stemming from coolant level sensor, CAP-300 uses capacitive technology, which is tolerant of coolant coating, and has sealed (IP67, IP6K9K Approved) design for consistent operational reliability. Sensor remains reliable in standby mode with nearly zero maintenance and is compatible with temperatures from -40 to +257°F. Other water-based coolant applications range from remote power supplies to trucks, trains, and off-highway vehicles. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Wireless System targets operators of oil and gas terminals.

June 12, 2013

Combining wireless-enabled products, services, and productivity tools tailored for terminal operators, OneWireless™ Terminal Solution includes ISA100-compatible Honeywell Enraf SmartRadar FlexLine wireless radar gauge, which utilizes integrated radio to send tank level measurements securely and wirelessly to central control room. FlexLine is also used as data concentrator, collecting data from local tank instruments and sending it wirelessly through same ISA100 network. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Portable Tools, Sensors, Monitors & Transducers

Smart Level Sensor targets solid/water interface applications.

May 20, 2013

When equipped with optional stainless steel interface style plumb bob, SiloPatrol® can provide level measurement for settled solids in blanket of water. Plumb bob penetrates through water, makes contact with surface of solid material, and retracts to provide measurement. Housed in split-compartment enclosure, maintenance-free system combines weight and cable techniques, Hall Effect sensor technology, sealed bi-directional optical sensing, and isolated outputs. Read More

Test & Measuring Instruments

Tank Level Meter displays level in feet and inches.

April 2, 2013

Featuring explosion proof design for safe or hazardous environments, PD6801 ProtEX™ F&I Level Meter has 0.6 in. high upper display that shows level in feet and inches and 0.4 in. lower display that shows volume, percent, or custom tag programmable for any 7 alphanumeric digits. Backlit meter can be read under various lighting conditions, and from viewing angles up to ±40°. Housed in NEMA 4X enclosure, meter has Safe-Touch through-glass buttons that allow operation without removing cover. Read More

Test & Measuring Instruments

Rotary Single Axis Inclinometer offers 360° monitoring range.

July 5, 2012

Based on MEMS devices that incorporate micro-electromechanical capacitive elements into sensor, Rotary Single Axis CANopen Inclinometer measures angular tilt in reference to gravity. Unit is suitable for monitoring mechanical arms, such as tensioners or moving components, as well as monitoring and reporting position of outriggers, booms, or other vertically rotating parts. Featuring IP68-rated housing, device operates in temperatures from -40 to +70°C. Read More

Test & Measuring Instruments, Controls & Controllers

Tuning Fork offers liquid/solid interface option.

May 15, 2012

Providing electronic vibratory level control, LP1000/LP2000 Pulse Point Tuning Fork is effective in lightweight powders and granular solids. Measuring device features vibration-resistant surface mount components and universal power supply that includes 24 Vdc. With FM and ATEX agency approvals, unit is dust ignition proof and explosionproof. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Continuous Level Measuring System provides 100 ft range.

February 29, 2012

Designed for continuous measurement of powder and bulk materials in silos, tanks, or hoppers, Series DBOB utilizes internal motor that drives weight suspended by firm stainless steel tape down to bulk material level. Upon reaching material, unit reverses and weight is drawn back into upper stop position. Distance weight descends is electronically measured based on internal rotations of unwinding tape. User-programmable to output height or volumetric signal, device measures at rate of 0.6 fps. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Digital DP Level Sensor System replaces mechanical impulse piping.

June 28, 2011

Suited for applications such as tall vessels and distillation towers, Rosemount® 3051S Electronic Remote Sensor (ERS(TM)) System replaces mechanical impulse piping with two 3051S pressure sensors linked together electronically. Differential pressure (DP) is calculated in one of 2 sensors and transmitted via 2-wire, 4-20 mA HART signal. In addition to DP calculation, system provides real-time access to readings from each pressure sensor and scaled output for tank level or volume measurement. Read More

Test & Measuring Instruments

Rotary Paddle Bin Level Indicators suit hazardous locations.

June 15, 2011

Model RHX Rotary Paddle Bin Level Indicators are certified for use in Class I and II locations, Division 1 and 2, Groups C, D, E, F, and G. Featuring explosionproof and NEMA Type 4X enclosure, products also include DPDT relay output fail-safe on power failure, automatic motor shutoff, and 4 shaft bearings and, on Model RH units, LED status indicators. Devices are used for high, low, or intermediate level control and plugged chute detection in grain processing, milling, and chemical industries. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Continuous Level Sensor works in bins up to 60 ft tall.

January 25, 2011

Designed for operations with multiple, smaller storage and process bins containing powders or bulk solids, SmartBob-TS1 weighs less than 10 lb and works in environments where airborne dust and filling noise are present. Cable-based sensor gathers data that can be viewed from control console mounted at base of bins via eBob software loaded onto PC or Web-based BinView software. Communications options include 4-20 mA outputs, RS-485 wired network capabilities, or optional wireless modem. Read More

Test & Measuring Instruments

Rotary Bin Level Indicator has extension for thick bin walls.

November 29, 2010

Horizontal rotary extension for bin level indicator provides ability to install rotary through sides of bin walls, such as those in concrete silos, up to 12 in. thick. Extended drive shaft has protective guard that keeps shaft centered, and bearing at end of shaft extension forms seal between rotary shaft and shaft guard to prevent bin material from packing up into extension. Standard lengths of 6, 8, 10, or 12 in. are available for MAXIMA+ or BMRX rotaries. Read More

Test & Measuring Instruments

Bin Level Indicator handles temperatures to 750°F.

November 17, 2010

Suited for applications with continual exposure to elevated process temperatures, High Temperature Model RH/RHX rotary paddle bin level indicator features extension, air purge, mounting plate, and mounting seal of complete stainless steel construction. Additional design aspects include flexible folding paddles, SUPER BRIGHT locally visible LEDs, and DPDT relay output. Four bearings promote smooth shaft rotation, and automatic motor shutoff provides safety when material is present. Read More

Test & Measuring Instruments, Fluid & Gas Flow Equipment

Rotary Level Indicators offer stainless steel connections.

November 2, 2010

Available for BMRX and MAXIMA+ rotary level indicators, 304 Stainless Steel Fittings come in 1¼ and 1½ in. NPT sizes with stainless steel seal/bearing carrier. Process connections can be used in conjunction with 3-vane, 2-vane, insertable, or bayonet-style stainless steel paddles for use in food processing or in caustic materials. Designed to detect level of dry bulk material in bins, hoppers, tanks, and chutes, indicators handle bulk densities from 1-150 lb/ft³. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

PVC Tape Liquid Level Indicator does not need any electricity.

September 9, 2010

Without requiring any electricity, manual Series DTV provides uninterrupted liquid level indication for 30 or 55 gal storage tanks/vessels. Stem and mounting feature all-PVC construction, and only float and stem make contact with liquid to ensure indication tape remains clean and readable. Recommended for use in calm liquids and ambient temperature and pressure levels, product comes in lengths from 6 in. to 6 ft and is accurate to 1/16 in. Read More
