Daubert Cromwell
Alsip, IL 60803
Oct 28, 2005 Measuring 1½ x 3 in., Daubrite® 1 packets contain volatile corrosion inhibitor that protects exposed metals inside enclosed spaces such as boxes, crates, and containers. Protective vapors form invisible layer on surface of metal, preventing moisture, dirt, oxygen, and other contaminants from depositing on metal and causing corrosion. Product is safe, clean, non-discernible, and has no strong chemical odor or residue. Tyvek® pouch is breathable and tear-resistant.

Bacou-Dalloz
North Smithfield, RI 02917
Oct 21, 2005 Constructed of plastic, LS-400 Leight® Source is designed for wall mounting or tabletop use. Workers access earplugs by twisting dial, and earplugs dispense into catch basin. Fitting instructions for roll-down and no-roll foam earplugs are displayed on dispenser. Base stand includes snap-in rubber feet for stability, and dispenser is compatible with Matrix(TM), Max®, Max Lite®, Laser Lite® and MultiMax® earplugs.

Remtec, Inc.
Norwood, MA 02062
Oct 21, 2005 Plated Copper on Thick Film technology permits manufacture of leadless ceramic chip carriers and packages larger than .75 in. Wrap-around interconnections eliminate use of leads and additional interface boards, and ensure connections can operate at frequencies above 32 GHz. Plugged via holes with resistance less than 1 mΩ provide for RF losses below .1 dB at 4 GHz. Depending on die size and package thickness, thermal resistance of 1-2°C/W and lower can be achieved.

Automated Packaging Systems Inc.
Streetsboro, OH 44241
Oct 18, 2005 Autobag® Maximizer(TM) continuous motion conveyor system allows operators to control speed up to 70 batches/min and allows single operator to package mixed parts. Using sensor technology, unit is capable of detecting and counting product from ¼-5.5 in. long and up to 3 in. wide. Unit can be used in combination with Autobag AB 180 bagging system and can also be integrated with robotics and inline printer for high productivity Print-n-Pack(TM) system.

Econocorp. Inc.
Randolph, MA 02368
Oct 11, 2005 Featuring base frame footprint of 115 x 30 in., ECONOSEAL PEGASUS continuous motion cartoner erects, loads (optional), and closes end load style cartons at speeds to 120 cpm. Modular, build-on concept allows users to start in manual product loading mode and add further automation as required. Unit accepts cartons from 2 x 1 x 5 in. to 8 x 3 x 12 in. and handles up to 7,200 cartons/hr depending on size, style, and other factors.

Rollprint Packaging Products, Inc.
Addison, IL 60101
Oct 11, 2005 ClearForm(TM) copolymer blend exhibits clarity for thermoform/fill/seal applications in medical and frozen food markets. Offered as alternative to bottom webs such as EVA/Surlyn/EVA, nylon coextruded films, and other PE-based polymeric blends, product is suitable for EtO and gamma sterilization. When coupled with Allegro® peelable top webs, total package offers machine-friendly forming and sealing characteristics and smooth, peelable, tamper-evident seal.

MonoSol, LLC
Portage, IN 46368
Oct 11, 2005 Offered in thicknesses from 1.5-3 mil, M-8900 copolymer-based, polyvinyl alcohol film is developed for compatibility with low pH products and offers stability with boron-containing compounds. Packaging chemicals in film allows manufacturers to minimize environmental impact of packaging and facilitate safe handling of products by providing pre-packaged, pre-measured, unit-dose product. Film eliminates contact between chemical and user and dissolves completely.

Storopack Inc.
Cincinnati, OH 45246 1106
Oct 07, 2005 Optimizing production without operator input, AIRplus® Cactus uses dispensing hopper with level sensor to monitor reserve of air pillows, then triggers production when low-level threshold is reached. Cactus Transport provides floor-mounted blower stand with up to 2 transport ducts, allowing 2 different sized pillows to be used. Standard sized hoppers include single outlet, or 10, 14, or 16 outlets. Ducting is available in 10 in. diameter and lengths of 5 or 10 ft.

Sealed Air Corp., Engineered Products Div.
Danbury, CT 06810
Oct 04, 2005 Available in 5 sizes, Instapak Quick® Room Temperature foam packaging bags provide custom-fit protective cushion suited for small- to medium-volume packaging applications. Products, without use of warmer, enable users to produce protective foam cushions at any location and support multiple packaging areas. Each bag contains 2 liquid components that, when mixed, provide cushioning, blocking, bracing, and void-fill protection.

O. BERK Company
Union, NJ 07083
Oct 03, 2005 Designed for 4 oz 70/400 and 8 oz 89/400 low profile PET jars, Flip-Top Jar Covers are bi-injected, polypropylene single-piece units available in variety of custom colors. They are suited for creams, lotions, and solid products in cosmetic/personal care, healthcare, and food markets. PVC jar discs may be used to seal product during shipping and then removed by consumer.

ARPAC
Schiller Park, IL 60176
Sep 23, 2005 Combining weighing and wrapping into one operation, semi-automatic Sidewinder 4LP WRAP-N-WEIGH integrates precision scale and digital controls with turntable. It features anti-static pre-stretch rollers, steel-it paint to prevent corrosion, and electronically controlled film tension adjustment. Machine also includes Allen Bradley Micrologix PLC, 3-wrap pattern selections, self-diagnostics, and operator controls with dual LED wrap counters.

ARPAC
Schiller Park, IL 60176
Sep 23, 2005 At speeds up to 40 packages/min, Hanagata Z-Series intermittent motion automatic L-sealer features text-driven control panel, pinch roller, and guillotine-style seal head. It produces fully enclosed shrink-wrapped packages and features quick changeovers via hand crank adjustments. Vision Series shrink tunnel utilizes convection-style heating system for uniform shrink. Along with double insulation, it features viewing window and illuminated shrink chamber.

Cortec Corp.
St. Paul, MN 55110
Sep 22, 2005 Branded Packaging For OEM Components identifies metal components and provides additional informational or warning text. Using VpCI(TM) Technology, bags protect multi-metal components against corrosion during shipment and storage for up to 2 years. Packaged parts are ready for immediate use without any cleaning or degreasing. Available as recyclable polyethylene and degradable film, packaging will protect ferrous and non-ferrous metals. It is also available in sheets and bags.

ARPAC
Schiller Park, IL 60176
Sep 16, 2005 Operating at speeds to 75 bundles/min, ARPAC 75GI shrink wraps random size bundles, short stacks, and lightweight products on-demand without interrupting production within printing and publishing industry. It features servo-driven sealing with precision electronic control and is designed to interact with 18,000-20,000 books/hr binding lines. Suited for use with counter stackers, seal height can be electronically programmed to vary with product height.

SWF Companies
Reedley, CA 93654
Sep 14, 2005 Featuring quick-change compression plates, Model CE 451 is capable of handling multiple case sizes. Frame incorporates sheet metal design, minimizing horizontal surfaces. Machine includes jack screws on main chain drive to facilitate chain tensioning, guarding package for operator safety, and MicroLogix 1200 PLC with display screen for operator control.

IWKA Pac Systems, Inc.
Fairfield, NJ 07004
Sep 14, 2005 Featuring servo-driven technology, CFR 21-compliant S Series incorporates carton-opening system that opens cartons before they reach transport lug, eliminating possibility of unopened cartons entering machine. Custom-engineered infeed system enables multiple components of varying sizes and shapes to be loaded into same carton.

Douglas Machine
Alexandria, MN 56308 3399
Sep 13, 2005 Featuring technologies for tray, pad, u-board, and film-only applications, Douglas Contour(TM) SPS-30 utilizes servo-driven wrapping wand that maximizes film control for placement accuracy. Variety of infeeds includes Smartrak Steady Stream Infeed, which ensures continuous product flow. Along with simplified pin metering and servo drives, unit features speeds to 30 cycles/min and accessible film cutter that consistently feeds film.

SUBNIL Packaging Machineries (P) Ltd.
Mumbai   India
Sep 12, 2005 Capable of producing 10,000 tubes/hr, twin-head LIMBUS 170 features servo-driven actions for tube loading from cassette into tube holder, tube orientation, and rotary turret movement. Pump has vertical dosing system, and servo-aided fill lift ensures clean and accurate filling. Lift timing for various tube lengths and fillings can be programmed and recalled through color touch-screen HMI, PLC, and VFD. Unit is capable of filling single material as well as 2- or 3-color striping.

Storopack Inc.
Cincinnati, OH 45246 1106
Sep 09, 2005 AIRPlus® Mini utilizes ambient air to produce air pillows 4""8 in. long by up to 8 in. wide at rates to 20 fpm. Amount of air in each pillow can be adjusted to packaging requirements. Suited for use at single packing stations, compact unit occupies less than 2 ft² of desktop space and weighs 20 lb. Available in 1.4 or 2.0 mil thicknesses, film can be pre-printed with company logo; anti-static LDPE film is also available.

AliMed, Inc.
Dedham, MA 02026
Sep 09, 2005 Comprised of 24 in. L gel pad that folds at 90° angle, AliEdge Gel attaches to tables, counters, or other straight, protruding surfaces with potentially hazardous edges. When applied to surface, product forms soft, sealed barrier between employees and sharp edges with added cushioning. Sealed in puncture-resistant thermoformed skin, ½ in. thick inner Blue Diamond Gel will not ooze, leak, or evaporate. AliEdge Gel wipes clean and is both anti-microbial and anti-bacterial.
