Shell Mill Adapter secures wheel brushes to CNC machines.

May 5, 2015

Facilitating brush attachment for automated deburring, Shell Mill Adapter works by placing adapter plates on both sides of wheel brush and securing device with bolt that runs through centrally located opening into shell mill holder. Set screws prevent brush from rotating. Made of lightweight aluminum, adapter is compatible with range of Tanis Wheel Brushes from 2–14 in. in diameter. Read More

Mounting & Attaching Products

Directional Valve Panel Mount Plate conserves space in cabinets.

April 29, 2015

By letting OEMs and end-users directly connect 501 Series valve manifold to panel in wall or floor of cabinet, Numatics 501 Series adapter plate eliminates need for complex tubing routing and bulkhead fittings, reduces custom machining and drilling, and simplifies panel layout. Design suits pneumatic panel applications in process industries where directional control valves are installed in cabinet due to environmental or packaging constraints. Product also helps minimize leaks and air loss. Read More

Electrical Equipment & Systems, Mounting & Attaching Products, Electronic Components & Devices

Solderless Coaxial Connector supports up to 50 GHz.

April 28, 2015

Featuring stub-less design with screw-mounting to PCB, H2.4 Series meets MIL-STD348B standard, and supports up to 50 GHz with transmission speed of 25 Gbps. Compression-mounted 2.4 mm connector, rated for 500 mating cycles, has contact resistance of 4 mΩ max in center and 2 mΩ max in outer section. Plug is manufactured with 0.085 in. semi-flexible cable and terminated plugs on each end, while receptacle features gold-plated ground ring for stabilizing grounding on PCB. Read More

Mounting & Attaching Products, Materials & Material Processing, Adhesives & Sealants

High-Temperature Sealant suits applications to 950°F.

April 24, 2015

Formulated by combining high-temperature resin with ceramic fibers and powders, Pyro-Putty™ 950 can be used as gasketing compound for boilers, compressors, heat exchangers, furnaces, ovens, and exhaust manifolds. Product repairs rough, scored, or irregular surfaces and is resistant to chemical and steam attack, high pressure/vacuum atmospheres, mechanical vibration, and joint movement. Offered in 11 oz caulk gun cartridge, sealant can cure in service or by heating joint without pressure. Read More

Fluid & Gas Flow Equipment, Health, Medical and Dental Supplies & Equipment, Mounting & Attaching Products

Single-Use Sterile Manifold Adapters create closed systems.

April 22, 2015

Offered in gamma and high-temperature versions, AseptiQuik® Tee and Cross Manifold Adapters provide flexibility for biopharmaceutical manufacturers by enabling onsite connection of standard sub-assemblies to create wide array of customized single-use systems. Units mate with genderless AseptiQuik G series connectors without need for clamps or fixtures. Adapters are suited for transferring valuable media in single-use bag and tubing assemblies, cell banking systems, bioreactors, and mixers. Read More

Computer Hardware & Peripherals, Mounting & Attaching Products

Low Power Programmable Sensor Hub enhances wearables, smartphones.

April 21, 2015

ArcticLink® 3 S2 LP, featuring active power consumption of 75 µW (68 µA @ 1.1V), extends battery life for smartphone and wearable devices. Simultaneously, support for SenseMe™ sensor algorithm library as well as OEM-developed and third-party algorithms enables designers to add features/capabilities and extend battery life of those same devices.
Read More

Mounting & Attaching Products, Chemical Processing & Waste Management, Materials & Material Processing

TPE Overmolding Material provides vibration damping.

April 14, 2015

Offering optimal bonding capability to rigid polymers, Versaflex™ VDT reduces vibration that can cause discomfort and potentially lead to muscle and joint damage. Material can also reduce noise by minimizing vibrations transmitted from motors and pumps. Applications range from sports and leisure equipment, lawn and garden tools, and consumer electronics cases to kitchen appliances and power tools. Read More

Mounting & Attaching Products, Electronic Components & Devices

BGA Socket Adapter supports 500-pin 0.65 mm pitch package.

April 13, 2015

Giga-snaP™ BGA Socket Adapter pairs SFS-BGA500C-52 female BGA sockets with BeCu pins assembled into substrate that matches male pin adapter. SFS-BGA500C-52 allows 0.65 mm pitch, 14 x 17 mm body, 20 x 25 array 500 ball BGA package to be placed in socket and operated without compromising performance in high-speed applications. Both socket and adapter are constructed with high-temperature polyimide and FR-4 body, assuring match with target PCBs and preventing failures due to CTE mismatch. Read More

Mounting & Attaching Products

Ceiling Mount Adapter handles up to 80 in. flat panel displays.

April 9, 2015

Featuring black powder coat finish, weighing 23.6 lb, and offering adjustable 0° to 15° tilt, PDS-LCM2B allows VMP PDS-LCB large flat panel tilt ceiling mount to accommodate two 37–80 in. flat panel displays, back-to-back, with combined weight of up to 360 lb. This dual large flat panel ceiling mount adapter, measuring 12.1 x 34.8 x 22 in. (variable width), accommodates hole patterns from 200 x 200 mm to 860 x 500 mm. Areas of use include restaurants, bars, health clubs, and arenas. Read More

Mounting & Attaching Products

Wall Bracket maintains optimal wireless access point orientation.

April 8, 2015

Right-angle wall bracket enables secure, horizontally oriented mounting of wireless access points to walls in residence halls, hotels, and other hard lid venues. Conduit, raceways, and cable can be terminated in bracket to provide for clean appearance, and access points can be locked in place using access point manufacturer's locking features. Available options for Models 1008 through 1013 include design for open beam placement and options for covering top, sides, and back of access point. Read More

Mounting & Attaching Products

Adjustable Hinges allow for precise positioning.

April 6, 2015

Suitable for inch and metric applications, EN 236 Plastic Adjustable Alignment Hinges allow for technically and visually perfect positioning and alignment of door in frame. Serrations at wings of hinge and at adjusting bushings create form lock that prevents hinge from moving after installation. Depending on installation position of bushings, hinges are adjustable in both vertical and horizontal directions. Units are made of glass fiber reinforced plastic with stainless steel pin. Read More

Mounting & Attaching Products, Electronic Components & Devices

Low-Profile Power Connector facilitates layout and connection.

April 3, 2015

Allowing mating/unmating of power and signal cables from plug-in side, PS3F Series front access hybrid connector eliminates need for on-site cable wiring. Power contacts support up to 100 A with rated voltage to 1,000 AC/DC, and signal contacts support up to 1 A per contact and interface with 2 Hirose GT8E connectors utilizing one 8- and 10-position connector. Blade contact structure features multiple contact points, and signal lines can be configured in daisy chain. Read More

Mounting & Attaching Products, Material Handling & Storage

Anti-Shock Components double as emergency food source.

April 2, 2015

Designed to reduce vibration and optimize equipment stability, Gell-Low Anti-Vibration Shock Mounts are created from recycled bovine by-products and produced in variety of sizes. Compression-mounted vibration isolators are also suitable for mounting under mobile cameras on drones and for isolating vibration in UAV applications. Available in red (strawberry), green (lime), and black (liquorice), products can also function as emergency food source for disaster conditions. Read More

Mounting & Attaching Products, Fasteners & Hardware

Torque Insert features position-control technology.

March 31, 2015

Featuring 5 mm wide housing and overall single-fin profile, Model TI-C5M is suited for consumer electronics applications. Unit offers symmetric torque ranges from 1.3–2.66 lb-in. and is engineered for press-fit mounting into metal or plastic materials. Delivering full 360° range of rotation with minimal freeplay, insert can perform for fully qualified service life of 30,000 cycles. Unit is designed with zinc housing, zinc finish, and hardened steel shaft and torque element. Read More

Fasteners & Hardware, Mounting & Attaching Products

Strain Relief is designed for Amphenol AT-SR01 Series Connectors.

March 31, 2015

Providing bend relief, Multi-Flex strain relief for Amphenol AT-SR01 Series connectors features injection-molded, low-durometer material over existing shrink tube lip. This provides aesthetic compliment to cables and harnesses while promoting cable assembly life by limiting bend radius. Construction characteristics promote longevity for field, off-road, and under-hood applications. Read More

Mounting & Attaching Products, Test & Measuring Instruments

Precision Adjustable Shim simplifies leveling adjustments.

March 27, 2015

Eliminating trial and error of lifting machinery to slip in shims and wedges, Microshim lets user adjust stainless steel lifting bolt to raise/lower machine in height adjustments of 0.001 in. Each unit lifts and supports 10,000 lb, and applying adhesive to 2 sliding surfaces allows for adjustment before product is permanently locked to specific height. While shim is milled from solid block of aluminum and protected by hard anodized coating, lifting hardware is fabricated in stainless steel. Read More

Mounting & Attaching Products, Electronic Components & Devices, Electrical Equipment & Systems

Low-Profile, High Density Interposers provide design flexibility.

March 27, 2015

Used as interposers or integrated into connector housings, Z-Ray™ 0.80 mm pitch, one-piece compression contact arrays offer 28+ Gbps performance. ZA8 Series, available with choice of dual compression contacts or single compression with solder balls, has up to 400 total BeCu micro-formed contacts and features 25 g normal force with .008 in. contact deflection. Available in customizable shapes and patterns, products are optimized for density, X/Y/Z axis flexibility, and cycle life.
Read More

Mounting & Attaching Products, Electronic Components & Devices, Electrical Equipment & Systems

Wire-to-Board Connector connects multiple coax cables in one step.

March 24, 2015

Reducing vehicle roof antenna installation time, GT36 Series provides one-step connection of multiple coaxial cables to PCB. Internal solution specifically enables attachment of 4 coaxial lines to automotive antennas, including shark fin antennas, and features rugged positive lock structure that offers lock strength of 98 N. RoHS- and ELV-compliant product has rated voltage of 50 Vac, rated current of 1 A, contact resistance of 50 mΩ max, and insulation resistance of 100 MΩ min at 500 Vdc.
Read More

Mounting & Attaching Products, Construction Equipment & Supplies

Camera Track System minimizes space requirements.

March 23, 2015

Featuring streamlined triple track system with continual auto track-trolley alignment, TeleGlide TG4M delivers stable operation with almost no maintenance. Unit is Virtual Reality and Augmented Reality ready with no updates or retrofits required. Constructed of strong but lightweight aluminum components, frame offers smooth transitions between track sections and has trolley load capacity of 200 lb. System is fully servo controlled, providing accurate preset positioning and repeatable motion. Read More

Mounting & Attaching Products, Safety & Security Equipment, Optics & Photonics

Roof Mounts feature non-penetrating design.

March 20, 2015

Using 8 x 8 x 16 in. cinderblocks as ballast to avoid damaging roof surface, FRM Series is suited for wireless security surveillance systems, as well as DBS, off-air antenna, satellite internet systems, and point-to-point CCTV signal transmission. FRM-125 features 60 in. mast with 1.25 in. OD, while FRM-166 has 30 in. mast with 1.66 in. OD. In addition, FRM-200 provides 30 in. mast with 2 in. OD. FRM-MAT Protective Rubber Mat is available as accessory for all FRM mounts. Read More
