Soft-Seal Rotating Unions feature multi-passage design.
Waukegan, IL 60085-6747
Aug 07, 2014
Used when more than one media must be conveyed simultaneously using different passages, multi-passage soft-seal rotating unions come in standard, semi-custom, and custom options. Standard products feature 2–8 passages, while custom passages, for largest applications, can be 22 or more. Port types include NPT, BSP, or SAE, and Plastomeric seal technology consists of plastic and elastomer combination with chemistry and geometry that differs by application.
Non-Metallic Electrical Plugs feature NEMA 4X watertight seal.
Rosemont, IL 60018
Jul 31, 2014
Designed for washdown areas, corrosive environments, or outdoor spaces, Powertite® 30 and 60 A, corrosive-resistant plugs can be used with UL 1686-C1 receptacles. These products, built to deliver safe and reliable performance, provide non-metallic option for connecting equipment in industrial and heavy commercial environments. Along with impact-modified PBT polyester housing, features include dual-molded locking ring, shock absorbing rubber, and extra large wiring chamber.
Single-Use Gauge Tee allows secure pressure monitoring.
Meissner Filtration Products, Inc.
Camarillo, CA 93012 8760
Jul 30, 2014
Providing pressure monitoring for pre-sterilized single-use systems, SGT employs thermoplastic elastomer diaphragm, which allows standard sanitary pressure gauges and transducers to be attached while maintaining sterility of system and eliminating cross contamination. Gauges and transducers can be aseptically removed from system for offline calibration during processing. Hose barbs to support tubing from 3/8–1 in. diameter as well as ¾ in. sanitary flange connections are offered.
Liquidtight Fittings suit hazardous electrical applications.
Rosemont, IL 60018
Jul 28, 2014
Available in 3/8–4 in. trade sizes in straight, 45°, and 90° body designs, 4QS Steel Liquidtight Fittings suit jobs requiring protection of electrical wiring from liquids, vapors, or solids. Straight connectors have zinc-plated steel body and nut, while 45° and 90° bodies feature malleable iron/zinc plated design. Captive gland stays in connector, facilitating installation, while hex-shaped gland nut and extended length hub enables use of bushings to protect conductors from abrasion.
High Temperature Hose complies with DOT standards.
Rockledge, FL 32955
Jul 25, 2014
Used on commercial vehicles, Model 100R5 consists of blue, high-temperature hose with textile cover. Hose carries identifying marks of SAE J 1402 showing compliance with DOT standards and is made in USA. Typical applications include transmissions, power steering systems, and air brakes on vehicles ranging from dump trucks to school buses.
Round and Flat Profile Heat Pipes help cool hot components.
Advanced Thermal Solutions, Inc.
Norwood, MA 02062
Jul 24, 2014
Used for transporting power dissipation away from hot electronic components, ATS copper heat pipes are available in 33 round and flat profile versions. Products transfer component heat to heat sinks with minimal temperature difference while also distributing heat efficiently across length of heat spreaders. Shaped by hand or machine to meet application needs, all heat pipes can be friction fit, clamped, soldered, or adhesively attached and are effective in temperatures from 30–120°C.
RF Rotary Joints accommodate linear and rotational motion.
Fairview Microwave Inc.
Allen, TX 75013
Jul 18, 2014
Used where RF signals are transmitted between stationary and moving parts, single-channel/single-axis and single-channel/multi-axis RF Rotary Joints include models that collectively cover 0–18 GHz operating frequency range. Single-channel/single-axis rotary joints include 2 SMA female units, one PCB to SMA female unit, and one 3-hole flange to SMA female unit, while single-channel/multi-axis rotary joints include SMA male to female, SMA male to male, and SMA female to female configurations.
Swage Nipples and Bull Plugs target oil and gas market.
Brewster, NY 10509
Jul 15, 2014
Offered in Schedule 80 and Schedule 40 sizes: ½–4 in. and 2–4 in., respectively, Swage Concentric Nipples are reducers for high pressure piping systems that contain bore matching that of pipe they are fitted to. Bull Plugs, also available in Schedule 80 and Schedule 40 sizes: ½–4 in. and 2–4 in., respectively, provide flow control by plugging branches and outlets of piping system. Both conform to MSS SP-95, ASME B1.20.1, and ASME B36.10M (for wall thickness) standards.
Radiopaque Compounds target thin wall catheters.
Foster West Corporation
Putnam, CT 06260
Jun 13, 2014
Reinforced with nanoparticles for optimized pushability of catheters, LoPro Plus™ Compounds allow for extrusion of single layer tubes with radiopacity and strength properties equivalent to conventional 2 layer tubes, in which each layer provides distinct properties. Compounds use particles that are less than 1 nm thick and up to 1,500 x thickness in length. When added to radiopaque filled compounds in small quantities, nanoparticles optimize rigidity without increasing brittleness.
Insulated Process Tubing Bundles are steam- and electric-traced.
La Vergne, TN 37086
Jun 13, 2014
Used to protect viscous materials from freezing, avoid gas condensation, and improve employee safety, jacketed process tubing bundles are available with copper, stainless, high alloy, or fluoropolymer process tubing as well as various insulation and jacket materials. Traced bundles incorporate steam tubing or electric heat trace with choice of self-regulating or constant wattage heating elements. Bundles may include single or multiple process tubes suited for use in heat trace systems.
Armoured Cable Fittings provide watertight seal.
Gilmer, TX 75644
Jun 12, 2014
Designed for use with jacketed TECK cable with aluminum or steel armour, Plasti-Bond TECK Series features 40 mil gray PVC exterior coating that prevents corrosion in harsh environments. Aluminum fittings provide protective connection for passing cable into enclosure or panel board; form mechanical watertight and dust tight termination; and provide ground continuity between cable armour and metal enclosures. Units have standard neoprene seal suitable for operating temperatures of -25 to +60°C.
PP-R Piping System offers PP-R to copper sweated connections.
Lindon, UT 84042
Jun 06, 2014
Used in PHVAC applications, polypropylene-random (PP-R) piping systems feature straight, threadless transition from PP-R pipe to copper sweated connections. This facilitates fitting out installations entirely in PP-R. While PP-R portion of stub-out is mold-injected PP-R and connected via heat fusion, copper portion is connected using copper solder joints or compression fittings. Straight Aquatherm-to-copper stub-outs come in ½, ¾, and 1 in. dia and respective lengths of 11, 11, and 18 in.
Piping Systems feature PEX compression adapter.
Lindon, UT 84042
Jun 04, 2014
Used in variety of PHVAC applications, Polypropylene-Random Piping Systems feature PEX compression adapter made of PP-R and lead-free brass. Adapter allows installers to transition between Aquatherm and PEX in potable water and radiant systems. Manufactured to ASTM F1960 standard and available in ½, ¾, and 1 in. diameters, adapter has male-end design that enables installers to fuse directly into fusion outlets. Street connection can be welded directly into Aquatherm fitting.
High-Pressure Hose Couplings feature non-skive design.
Lyman, NE 69352
May 27, 2014
Combined with high-pressure braided hose, 6W Couplings eliminate leaks and in-field failures caused by shock and vibration, making them suited for hydraulic systems in oil, construction, mining, and off-road equipment industries. One-piece, bite-the-wire crimp couplings are available in 1 ¼, 1 ½, and 2 in. sizes and are designed to work with SAE R13 and 4SH hydraulic hose. Units withstand pressures up to 6,000 psi and operate in temperatures ranging from -40 to 250°F.
Miniature Burst Disc Plugs provide over-pressure protection.
Lee Products Ltd
Buckinghamshire SL9 9QE United Kingdom
May 23, 2014
Designed for critical liquid and gas flow control systems, Burst Disc Plugs provides pressure relief in 135 x 173 mm, leak-tight, corrosive-resistant package; sizes down to 64 x 94 mm are available upon request. Pressure ratings range from 3,000–15,000 psid, and construction is of NACE-compliant Incoloy 825 and Inconel 625. Operating up to 450°F, plugs exhibit tolerance of ±10% rated burst pressure and operate up to 80% of rated burst pressure.
Concealed Cable Railing Hardware offers unobstructed view.
Suncor Stainless, Inc.
Plymouth, MA 02360
May 22, 2014
Available for RailEasy™ and HandiSwage™ cable railing systems, flush fittings are completely concealed inside post and suit applications where through-post look is desired. Measuring under 1½ in. long, fittings lend to clean appearance, and cable passing through fitting accelerates installation. RailEasy™ Flush Fitting accepts 5/32 in. cable, while HandiSwage™ utilizes 1/8 in. cable. Both fittings are made from 316L stainless steel and feature mechanical swage fitting.
Pipe Handling System aids horizontal/directional drilling.
Tulsa, OK 74128
May 16, 2014
Utilizing wireless remote controller operation and vacuum-lifting technology, HDD Pipe Handling System tilts and places drill stem at angles from 0° and 30° without using ropes or slings. Weight lets one worker lift drill stem and transfer pipe into drilling rig, while 360° hydraulic rotator gives operators complete control over drill stem and allows for precise placement of pipe joints. System handles single joints of steel pipe from 3–18 in. dia with lift capacities from 1,700–5,400 lb.
Stainless Steel Fittings suit UHPLC and HPLC applications.
JM Science, Inc.
Grand Island, NY 14072-0250
May 13, 2014
Designed for applications that require no leaks at pressures at or above 20,000 psi, Tri-Fitt Kit includes black carbon-PEEK ferrule, stainless steel triangular ferrule, and stainless steel nut. Carbon PEEK ferrule deforms when stainless steel nut is tightened and stainless steel triangular ferrule clamps onto tubing at same time to increase sealing pressure. Both stainless steel parts are reusable, while carbon PEEK ferrule must be replaced when fitting is removed or loosened.
PVC Suction Hose resists crushing, kinking, and collapse.
NewAge Industries Inc.
Southampton, PA 18966
May 09, 2014
Suited for fluid or air transfer, Vardex® is made of clear, chemical-resistant PVC and reinforced with spiral steel wire. Construction permits bend radius of ~4X hose ID and handles pressure as well as full vacuum (29.9 in./Hg). Resistant to corrosion and abrasion, non-toxic hose offers flexibility, conforms to FDA standards, and comes in 9 sizes from ¼–2 in. ID. Hose assemblies with permanently crimped-on fittings are available, along with other fittings and clamps in plastic and metal.
High Temperature Exhaust Hose combines flexibility, durability.
Warsaw, IN 46580
May 08, 2014
Kevlar®-coated Flex-Lok® 570 is constructed with single-ply Para-Aramid fabric locked around coated steel wire by metal strip and mechanically crimped in continuous process. Suited for fume venting over -40 to 570°F range, flexible hose is flame retardant as well as puncture and abrasion resistant. Product comes in IDs from 4–18 in. and 25 ft standard lengths. Weighing ~0.71 lb/ft, 4 in. hose has 3 in. bend radius, and 6:1 compression ratio.
