Crystals

Electronic Components & Devices

Stock Crystal Oscillators accelerate product development.

April 8, 2015

Available for use in industrial, consumer, and computing applications, 3.3 V crystal oscillators (XOs) include versions operating from -40 to +85°C with stabilities as tight as ±25 ppm as well as those operating from -20 to +70°C with stabilities to ±50 ppm. Sizes 2.0 x 1.6 mm and 2.5 x 2.0 mm cover 12–50 MHz range, while 3.2 x 2.5 mm size covers cover 1–125 MHz range and 5.0 x 3.0 mm and 7.0 x 5.0 mm sizes cover 1–200 MHz range. Read More

Electronic Components & Devices, Materials & Material Processing

Crystal Units offer optimized frequency tolerance.

August 4, 2014

With frequency tolerance of ±20 ppm at +25°C, and frequency shift by temperature of ±20 ppm max from -30 to +85°C, XRCGB-F-P Series is suitable for use in 802.1 wireless connectivity designs using protocols such as Bluetooth Low Energy and ZigBee. Units are constructed in 2016 package, making them ideal candidates for second sourcing. Read More

Electronic Components & Devices

Laser Crystals Ideal for Integration into a Wide Range of Applications

March 21, 2014

Laser Crystals are the active gain medium in solid state laser systems Barrington, N.J. — Edmund Optics® (EO), the premier provider of optical components, introduces new Laser Crystals. Laser Crystals serve as the active gain medium in solid state laser systems. The optical properties for a given crystal are determined by the crystal's composition, which dictates the optimal application... Read More

Electronic Components & Devices, Optics & Photonics

Crystal Unit targets wearable electronics and computing.

October 8, 2013

With frequency precision of ±20 ppm, Model XRCGD supports stringent frequency tolerances required for wireless communications such as Wi-Fi, Bluetooth®, and Radio Frequency/Base Band. Device is available with nominal operating frequencies from 24–48 MHz and ESR from 60–22 Ω, depending on model. Measuring 2 x 1.6 x 0.45 mm, crystal unit operates from -30 to +85°C. Fusion sealing technique provides complete hermetic seal that uses alloy in metal cap structure. Read More

Electronic Components & Devices, Test & Measuring Instruments, Timers & Clocks

Hybrid Crystal Timing Device targets automotive applications.

October 7, 2013

Measuring 2.5 x 2.0 mm, XRC Series is available with nominal frequencies of 12–24 MHz, providing highly accurate clock for automotive electronic control units. Typically used for in-vehicle networks such as CAN and FlexRay, series incorporates crystal element within ceramic resonator package structure. Frequency tolerance is typically ±100 ppm at 25°C, and operating temperature range is -40 to +125°C. Read More

Electronic Components & Devices, Materials & Material Processing, Optics & Photonics

Quartz Crystal features nominal frequency of 32.768 kHz.

July 23, 2013

Housed in 3.2 x 1.5 x 0.75 mm package, Model SC-32S is available with load capacitance of 7, 9, or 12.5 pF. Ceramic quartz crystal uses tuning-fork resonator processed in photolithography technology, which assures low aging of 3 ppm/year and optimized shock and heat resistance. Ion gun trimming method allows tight frequency tolerance over temperature range of -40 to +85°C. Device is 100% Pb-free and suitable for automatic and high density surface mounting. Read More

Electronic Components & Devices

SMD Crystals and Oscillators measure 2.5 x 2.0 mm.

March 28, 2013

Supporting -10 to +70°C or -40 to +85°C ranges, ultra light crystals offer precision with frequencies from 15.000–48.000 MHz in fundamental mode. Ultra low phase noise oscillators, designed to minimize power consumption with availability of Tri-State Function, operate from -40 to +85°C and support frequencies from 0.750–110.000 MHz in fundamental or Third OT Mode. Current consumption is 30 mA max, and phase jitter from 12 KHz to 20.000 MHz is 1 pS max with P-P Jitter of 25 pS max. Read More

Electronic Components & Devices, Materials & Material Processing

Glass Crystal Enclosure suits precision SC cut resonators.

February 9, 2012

Inherently non-conducting and insulated from adjacent components, Model HC-26/U is sealed by heat, fusing glass envelope to glass base while under vacuum. Resulting hermetically sealed crystal features 4.90 mm lead pitch, frequency range of 4-220 MHz, and operating temperature of -40 to 200°C. Measuring 13.46 x 10.40 x 4.10 mm, impermeable enclosure is suited for RF systems and manufacture of oven controlled crystal oscillators. Read More

Electronic Components & Devices, Materials & Material Processing

Swept Quartz Crystals feature customization and packaging options.

August 24, 2010

Suited for design engineers specifying OCXOs or requiring ultra-low phase noise, SC Cut Series doubly rotated crystals are offered with customizable frequencies from 3.0-150 MHz, are available enclosed in glass, and offer dual mode functionality. Swept quartz crystals, with aging characteristics as low as ±1.25 ppm for 20 years, are available with customized platings on crystal blanks and integrate 4-point mount for ruggedized designs. Shock resistant products can also be RoHS-compliant. Read More

Electronic Components & Devices

Cut-to-Style Crystals offer customizable frequencies.

July 7, 2010

With frequency range of 1.0-150 MHz, AT Cut Crystal Series is designed to withstand shock and vibration found in aerospace, defense, and industrial electronic applications. Units offer custom specification of frequencies to 6 decimal places, 4-point mount, ±15 ppm available over temperature, and high-temperature reflow capability. RoHS-compliant when specified, crystals are suited for VCXO or TCXO crystal oscillator and crystal filter designs. Read More

Electronic Components & Devices

SMD Crystal Resonator provides 32.768 kHz nominal frequency.

February 23, 2010

Housed in 3.2 x 1.5 x 0.8 mm ceramic package, Model ST3215SB has frequency tolerance of ±20 ppm, max ESR of 70 k<font face='Symbol'>W</font>, and operating temperature of -40 to +85°C. Standard capacitance range is 9-12.5 pF, and low capacitance versions of 7 pF or less are available on request. Pb-free and RoHS-compliant, reflow compatible tuning fork crystal resonator is suited for consumer and mobile equipment applications. Read More

Electronic Components & Devices

Automotive-Grade Ceramic Crystals come in compact packages.

September 22, 2009

Respectively supplied in 3.2 x 2.5 mm and 2.5 x 2.0 mm packages, 12-52 MHz FXA3225B and 16-50 MHz FXA2520B series are used in various automotive devices and systems. Both RoHS-compliant, SMD crystals are engineered to withstand shock and vibration in temperatures from -40 to +125°C and exhibit frequency stabilities from ±50 to ±100 ppm. Additional characteristics include drive level of 100 µW, load capacitance of 7 pF, and ±5 ppm aging per year. Read More

Electronic Components & Devices

Ceramic Crystals have frequency stabilities of ±50-100 ppm.

July 7, 2009

Available with operating temperatures range between -40°C to +85°C and -40°C to +125°C, respectively, and 3 ppm aging/yr, FXA5032B and FXA7050B suit automotive timing applications, including GPS navigation and collision warning systems. Model FXA5032B series features 5 x 3 mm package with frequency range of 8-150 MHz, while 7 x 5 mm FXA7050B series offers 6-133 MHz frequency range. Units feature load capacitance of 10 pF, drive level of 100 µW and max soldering temperature of 260°C per 10 sec. Read More

Electronic Components & Devices, Materials & Material Processing

Ceramic Crystals target consumer electronics market.

February 28, 2008

Shock-resistant and designed for high-temperature reflow, B-Series SMD Crystals are available in wide range of package sizes. Ultra-mini units come in 2.5 x 2.0 mm package with frequency range of 16-60 MHz and 3.2 x 2.5 mm package with 13-54 MHz frequency range. Crystals are RoHS-compliant and suited for digital video, digital still camera, PDA, PC, office automation, wireless, and audio realms. Read More

Controls & Controllers, Electronic Components & Devices

Euroquartz to Launch Wide Range of New Frequency Control Products at Electronica 2006

January 30, 2007

Pittsford, NY: Saelig Co. Inc. announces a wide range of new products from its supplier Euroquartz, to be launched at Electronica 2006 (14 to 17 November, Munich, Germany).<4444>Euroquartz will show a new range of dielectric microwave products, a new 8-pin DIL oscillator for defense and aerospace industries, high performance ultraminiature crystals, low power clock oscillators, an impressively... Read More

Electronic Components & Devices

Euroquartz to Launch Wide Range of New Frequency Control Products at Electronica 2006

November 15, 2006

Pittsford, NY: Saelig Co. Inc. announces a wide range of new products from its supplier Euroquartz, to be launched at Electronica 2006 (14 to 17 November, Munich, Germany). <4444>Euroquartz will show a new range of dielectric microwave products, a new 8-pin DIL oscillator for defense and aerospace industries, high performance ultraminiature crystals, low power clock oscillators, an impressively... Read More

Electronic Components & Devices, Optics & Photonics

Miniature Watch Crystal suits space-critical applications.

March 28, 2006

Measuring 3.2 x 1.5 x 0.9 mm, FX135A has frequency of 32.768 kHz and is optimized for 12.5 pF load capacitance standard; optional load capacitance of 9 pF is available (FX135B). Properties of this RoHS-compliant, surface mount device include frequency tolerance of ±20 ppm @ 77°F and frequency stability of -0.045 ppm/(delta C°)² over operating temperature range of -40 to +185°F. Max equivalent series resistance is 50 kohms and insulation resistance is 500 Mohms at 100 Vdc. Read More

Electronic Components & Devices

Crystal Oscillator offers 1.2-5.5 V operating range.

March 22, 2006

Model EM1564 integrates 32.768 kHz tuning fork crystal and CMOS circuit assembled in specifically designed SMD ceramic package. It offers extended temperature range between -40 to +125°C and is output enabled. Unit replaces standard quartz as solution to limitations of miniaturization. Oscillator suits digital systems, metering, and automotive applications. Product acts as clock driver-timekeeping in data logger systems, and networked servers and computers. Read More

Electronic Components & Devices, Optics & Photonics

Watch Crystals come in variety of surface-mount packages.

March 2, 2006

RoHS-compatible watch crystals, suited for real time clock applications, come in 6 package sizes from 3.2 x 1.2 mm to 10.4 x 4 mm. With nominal frequency of 32.768 kHz, products offer ±20 ppm standard calibration tolerance and 1 µW max drive level. Low power consumption types are available for portable battery-powered applications, while products manufactured in epoxy resin are suited for mass-market devices. Load capacitance is rated at either 7 or 12.5 pF. Read More

Electronic Components & Devices, Materials & Material Processing

Quartz Crystal oscillates in 4 MHz frequency range.

October 19, 2005

Measuring 3.2 x 2.5 x 0.55 mm, low-frequency Model CX3225SB features load capacitance of 8 pF and operating temperature of -10 to +70°C. Miniature unit is suited for cellular handsets, portable DVD players, handheld games, tuners, and PDAs. It is RoHS-compliant and compatible with reflow profile of lead-free soldering. Read More
