Rugged 10G-Base-T to XAUI Connector features 4 channels.

February 1, 2016

Built to survive military, aerospace, and industrial environments, 4-channel 10G-Base-T to XAUI connector facilitates bidirectional protocol conversion of IEEE 802.3 XAUI to IEEE 802.3 10G-Base-T. Split Pair Quadrax contacts support up to 6.5 Gbps signaling. Containing power supply, 2 dual-channel 10G-Base-T to XAUI PHYs, Ethernet transformers, clocking, and MDIO interface, connector supports 10G-Base-T cable distances of 100 m on CAT6A cable and 30 m on same cable in low power mode. Read More

Electronic Components & Devices, Electrical Equipment & Systems

DC-DC Step-down Converter features integrated inductor.

February 1, 2016

Delivering continuous 6 A at 85°C ambient temperature with no de-rating, EN6362QI PowerSoC is suitable for powering Altera Cyclone® and MAX® families of FPGAs and can optimize power usage in variety of systems requiring tiny, high-efficiency power source. With total size of 170 mm², device features power density of 56 W/cm², low EMI, programmable soft-start, full suite of protections, and 1.5% output voltage accuracy over line, load, and temperature. Read More

Display & Presentation Equipment, Electrical Equipment & Systems

High-Brightness LED Module simplifies designs, manufacturing.

February 1, 2016

In addition to employing 12 LM80-certified, high-brightness LEDs with luminous flux of 4,000 lm each at 1 A, VLSL12A03-3Q3T-50A integrates thermal sensor and fourfold plug-in connector (87438-0443) that eliminate need for additional soldering. LEDs are serially connected on aluminum metal-core, single-side PCB (161 x 50 x 2 mm), and layout, compatible with LEDiL 2x2 STRADA and High Bay quadruple lenses, allows various emission patterns. Color temperatures range from 4700K to 5500K. Read More

Electrical Equipment & Systems

Ultraminiature SMT Tact Switch measures 4.5 x 4.5 mm.

February 1, 2016

Rated 50 mA at 12 Vdc, TL3305 Series features surface mount termination and choice of 160 or 250 gf operating forces with operating lifecycles up to 500,000 and 200,000, respectively. Contact resistance is 100 mΩ max and insulation resistance is 100 MΩ min at 100 Vdc. Available with multiple actuator lengths from 3.8–7.0 mm, switch has SPST, normally open contact arrangement. Applications include wearable technology, telecommunications, consumer electronics, and medical devices. Read More

Controls & Controllers, Electrical Equipment & Systems

Digital Lighting Controls leverage Bluetooth® technology.

January 29, 2016

Available in dimmer and switch models, Decora Digital Controls with Bluetooth® technology provide ability to dim and time lighting without hub, gateway, or Internet connection. Users pair device with Leviton Decora Digital Dimmer and Timer App and use on-screen menu options to control lights via Apple or Android smartphone/tablet within 30 ft range. Along with flexibility to program timed events at set or random times, features include astronomical clock and countdown sleep timer. Read More

Electrical Equipment & Systems

PoE+ Gigabit Managed Switches suit outdoor applications.

January 29, 2016

Featuring 48~55 Vdc power input, LMP-1204G-SFP Series is designed with eight 10/100/1,000Tx gigabit ports that are IEEE 802.3at/af compliant with PoE power output up to 30 W per port, and four dual rate 100/1,000Tx SFP slots for fiber connectivity. Four fiber ports allow for implementation of fiber optic ring as well as separate fiber home run. With 24 Gigabit backplane speed, switches support Jumbo Frames and wide bandwidth for large Ethernet data packet transmissions. Read More

Electrical Equipment & Systems, Green & Clean

NFPA-Compliant Inverter has intelligent grid-connective design.

January 29, 2016

Offering CHP electrical efficiency of 34% while requiring 4 in. wc gas pressure, InVerde® e+ model INV-100e+ uses engine control technology that promotes stability and load turndown to permit load on equipment to be turned down to 10% (generating 10 kW of electrical output). DC input option facilitates battery or solar array integration, and 10 sec rapid start after blackout meets requirement for Type 10 Emergency Power Supply Systems (EPSS) per NFPA 110. Read More

Electrical Equipment & Systems, Green & Clean

Fiber Optic Illuminator brings sustainability to microscopes.

January 29, 2016

Featuring 6 x 4.75 x 9 in. footprint, LuxPro LED Fiber Optic Light System is suitable for mounting and stacking in constrained areas. Illuminator is equipped with standard 0.625 in. light guide fitting and provides consistent cool white color temperature of 4,500 K. Operating from 96–264 Vac, LuxPro features linear light intensity control with continuous dimming, and advanced heat pipe technology that uses metal core PCBs. Unit accepts virtually any light guide with quick change adapters. Read More

Electrical Equipment & Systems, Material Handling & Storage, Health, Medical and Dental Supplies & Equipment, Green & Clean

Power Entry Module can be used in Protection Class II equipment.

January 28, 2016

Designed according to IEC 60320-1 (style C18), Class II KMF supplied without ground pin and suitable for medical equipment used in residences. Double insulation between energized components and exposed parts is tested with 4,000 Vdc. Available with 2-pole line switch and 1- or 2-pole fuse holder, module supports current ratings from 1–10 A at 250 Vac and features 4.8 x 0.8 mm quick-connect terminals. EMC filter is available in medical and low-leakage, M5 versions. Read More

Electrical Equipment & Systems

Shorthaul Communications Unit supports wireless IoT.

January 28, 2016

Part of Sensor-2-Server™ communications solution, WavePro™ WP201™ combines Wi-Fi hotspot platform with shorthaul operation from 1–5 miles. Device delivers secure collection, control, and transport of all Voice, Video, Data, and Sensor information. By incorporating dual-band, concurrently operational radios (2.4 GHz and 5 GHz) into IP67 enclosure, WP201 brings industrial-grade communications to harsh outdoor environments without fail. Read More

Electrical Equipment & Systems, Green & Clean

Energy Storage System uses advanced vanadium technology.

January 28, 2016

Rated at 100 kW AC with up to 5 hour duration, ReFlex™ provides energy savings and power stability for commercial and industrial, microgrid, and utility customers. All components, including AC conversion, supporting systems, and controls are fully enclosed in standard 20 ft container. No external inverter, cooling, or control is required. With footprint of 160 ft², stackable system utilizes advanced vanadium technology which has no thermal runaway risk and flammability rating of 0. Read More

Electrical Equipment & Systems, Sensors, Monitors & Transducers

TMR Switch Sensors feature ultra-low power design.

January 28, 2016

Supplied in 2 x 1.5 mm LGA package, TMR1340/TMR1341/TMR1343/TMR1345 Tunneling Magnetoresistive Sensors feature switching point from 14–17 Gauss, ultra-low power at 1.5 µA in high-speed operation, and open-drain output. Omnipolar units are suited for industrial proximity switches, pneumatic cylinder switches, and liquid level switches that require precise measurement of position and displacement, temperature stability, and ability to adapt to different types of magnets and stroke lengths. Read More

Electrical Equipment & Systems

Uninterruptable Power Supply (24 V DC) measures 110 x 90 x 84 mm.

January 28, 2016

Suitable for use with compact controllers, PLCs, HMIs, and other low-power devices, UNO-UPS provides standby power upon AC mains power loss. Integrated 0.8 Ah absorbed glass mat lead-acid battery, mounted on front and released with screw, operates from -15 to +50°C and has 5-year max life expectancy. Battery runtime can be adjusted by rotary dial or remote shutdown input, and external 24 Vdc power supply is required to supply input power. Read More

Transportation Industry Products, Display & Presentation Equipment, Electrical Equipment & Systems

LED Bollards provide energy-efficient outdoor illumination.

January 27, 2016

Available in single-head (RZRB1) and twin-head (RZRB2) models, Razar LED Generation Bollard come in 3000K, 4000K, and 5000K color temperatures and feature 5 asymmetric PLED optical panels that can be replaced in field and rotated in 90° increments. Each bollard stands 42 in. high and is constructed of heavy-duty cast aluminum for environmental durability. With 175 and 350 mA drive currents, RZRB1 (12–22 W) delivers perimeter illumination while RZRB2 (22–44 W) is suited for open areas. Read More

Electrical Equipment & Systems

Communications Module adds Wi-Fi capability to alarm panels.

January 27, 2016

Targeting users who rely on Virtual Keypad™ App or MyVirtualKeypad.com to communicate with XT Series Burglary/Fire/Door Access Panel, 763 Wi-Fi Module enables reliance upon Wi-Fi® for primary communication link and cellular as backup. Add-on module supports WPS (Wi-Fi Protected Setup) to simplify configuration for residential customers and small businesses and offers functionality that accelerates installations, alarm signaling, and XT panel access via mobile devices. Read More

Electrical Equipment & Systems, Electronic Components & Devices

Class 2 Transformers offer power ratings from 5-40 VA.

January 27, 2016

Featuring Class F 155°C insulation system and UL 94V0 flammability rating, Class 2 Transformers are available with multiple primary and secondary windings, inherently or non-inherently limited for PCB mount, solder/quick connect terminals, and lead wires. Units are 100% hipot tested at 2,500 V and offer high safety isolation so no shielding is required. Supplied in variety of input and output ratings, transformers are suited for pumps, heating equipment, water treatment, and motor controls. Read More

Transportation Industry Products, Electrical Equipment & Systems, Optics & Photonics, Communication Systems & Equipment

Wireless HD Video Link enhances drone transmission reliability.

January 27, 2016

CONNEX mini, available for smaller, lighter aerial drones, delivers full 1080p HD video at 60 fps with zero latency over ranges up to 1,600 ft. While 65 x 45 x 15 mm, 40 g transmitter unit mounts on drone, 100 x 71 x 18 mm, 140 g receiver unit may be mounted on drone remote control. Further features include AES 128 encryption for secure transmission, multicast reception for up to 4 receivers, as well as telemetry and control solutions for S-bus, CANBUS, and PPM drone controllers. Read More

Electrical Equipment & Systems

DAS Antennas support in-building wireless applications.

January 26, 2016

Consisting of 2 x 2 MIMO antenna, HyperLink® HG72706DPCUPR-NF features linear radiators and 2 separate antenna leads that allow antenna to receive equal vertical and horizontal signals. HyperLink® HG75805CUPR-NF, providing Wi-Fi coverage from 2,400–6,000 MHz, is compatible with IEEE 802.11a/b/g/n networks as well as cellular bands. Both feature low-PIM rating of <-150 dBc or better, and mount through single hole in solid or suspended ceiling up to 1 in. thick. Read More

Electrical Equipment & Systems

Power Supply Modules operate in hazardous environments.

January 26, 2016

Featuring DIN rail design for control cabinet applications, wipos PS1 Series features input voltage of 85–264 Vac/90–350 Vdc and is rated for 24 Vdc/1.25–20 A output power, while PS3 Series accepts input voltages from 320–576 Vac/450–810 Vdc and is rated for 24 Vdc/5–40 A output power. Both are approved for Class 1/Division 2 locations, offer capability for 120% power boost for 10 seconds, and operate from -40 to +70°C with 100% power at 60°C. Read More

Electrical Equipment & Systems

Half Brick DC/DC Converters offer efficiencies up to 95.6%.

January 26, 2016

Utilizing synchronous rectification technology, MXW Series is available with 4:1 input ranges of 9–36 Vdc and 18–75 Vdc. Units deliver output voltages of 12, 24, 28, and 48 Vdc and operate down to no-load condition. Housed in 2.4 x 2.5 x 0.52 in. case, converters feature switching frequency of 200 kHz, output voltage setpoint accuracy of ±1.5%, and isolation voltage of 2,250 Vdc. Line and load regulations are 0.05% and 0.08%. With battery power source conservation in mind, OFF current is 2mA. Read More
