Low-Profile Mini-ITX System offers flexible functionality.

February 27, 2015

Suited for general automation and digital signage applications, 201.9 x 45.0 x 199.9 mm TKS-EMB-LP operates from 0 to +45°C and offers 3 low-profile Mini-ITX motherboard options – EMB-H81B, EMB-Q87A, and EMB-BT4 – to promote customization to application needs. Front offers 4 USB 2.0 and one COM port for external device/hardware connections as well as power switch and 2 LED indicators for power and HDD activity. Casing supports internal mounting of 2.5 in. HDD. Read More

Computer Hardware & Peripherals

PC/104-Plus SBC targets rugged, I/O-rich applications.

February 26, 2015

Designed in PC/104-Plus form factor with wings (4.5 x 4.0 in.), conduction-cooled Aries™ supports dual independent displays, offers optional integrated DAQ circuitry, and is based on 1.91 GHz quad core or 1.46 GHz dual core Intel E3800 Bay Trail CPU series CPUs with choice 2 or 4 GB soldered memory. I/O includes 3 USB 2.0, with one operable as USB 3.0; 4 fully programmable RS-232/422/485; 2 GbE; and SATA. Stackable I/O expansion options are also standard. Read More

Computer Hardware & Peripherals

SBC and Internet Appliance leverage 5th Gen Intel Core CPUs.

February 9, 2015

Requiring 15 W, which allows for fanless configuration, EPIC-BDU7 board offers graphics capabilities that support Ultra HD (4k resolution) videos and triple simultaneous display. Unit supports up to 8 GB of DDR3L 1600 MHz SODIMM x 1. Also available, FWS-7520 network appliance offers 3 swappable network interface module slots. Both board and network appliance are powered by workstation-grade processors (5th Generation Intel® Core™ CPUs) built on 14 nm process. Read More

Computer Hardware & Peripherals

COM Express Compact Size Type 6 Module uses Core i7/5/3 CPUs.

February 3, 2015

Powered by fifth generation Intel® Core™ i7-5650U, i5-5350U, and i3-5010U CPUs, cExpress-BL supports 16 GB max dual channel DDR3L memory, and suits fanless edge device solutions serving graphics-intensive and multitasking applications. Intel HD Graphics 5500 and 6000 provide 2 DDI channels (4K max resolution) and one LVDS channel supporting 3 independent displays. Embedded DisplayPort is optional, and standard I/O includes 4 PCIe x1 or single PCIe x 4, 4 SATA 6 Gbps, 2 USB 3.0, and 6 USB 2.0. Read More

Computer Hardware & Peripherals

Embedded SBC suits mission-critical applications.

January 29, 2015

Based on 22 nm 4th generation Intel® Core™ i7/i5/i3 processors with Intel® HM86 or Intel® QM87 chipset, Model CAPA881 comes with DDR3L SO-DIMM socket up to 8 GB. Integrated 3.5 in. embedded board includes VGA, LVDS, dual HDMI, and optional DisplayPort as well as 4 COM ports, 2 USB 3.0 ports, 4 USB 2.0 ports, 8-IN/OUT digital I/O, and dual Gigabit Ethernet ports. For storage, CAPA881 provides one SATA-600 socket, one CFast™ socket, and one PCI Express Mini Card interface with mSATA supported. Read More

Computer Hardware & Peripherals

Single Board Computer features 6U VME64X VMEbus form factor.

January 29, 2015

Based on 4th Generation Intel® Core™ i7 or i5 processor, Model XVME-6410 utilizes Intel 8-Series QM87 PCH chipset for extensive I/O support. Unit provides up to 16 GB of high-speed DDR3L removable memory with 1–64 GB flash memory optional. Two PMC/XMC sites can be used in any combination, and optional P0 connector allows 2 Gigabit Ethernet connections. Available in extended temperature models for -40 to +75°C operation, air-cooled processor board supports MS Windows® and Linux OS. Read More

Computer Hardware & Peripherals

SFF OpenVPX SBC delivers 2.4 GHz quad-core (8-thread) performance.

January 13, 2015

Leveraging 4th generation Intel® Core™ i7 chipset, VPX3-1258 accommodates compute-intensive applications in SWaP-constrained platforms. Fully ruggedized board, featuring up to 16 GB dual-channel ECC-protected DDR3 memory as well as built-in support for drop-in processor replacement, accelerates and facilitates integration of high-performance processing into such defense and aerospace deployed applications as mission computing, general processing, virtualization, and small multi-SBC ISR. Read More

Computer Hardware & Peripherals

Single Board Computer features 5th Gen Intel® Core(TM) processor.

January 12, 2015

Based on 5th generation Intel® Core™ processor with Intel® HD graphics 5,500, 5.25 in. Model EBM-BDW supports HDMI+LVDS dual display configurations and two 204-pin DDR3L SODIMM system memory with up to 8 GB capacity per SODIMM. I/O deployment includes 2 mPCIe ports, 1 HDMI, 1 CF, 2 USB 3.0 ports, 4 USB 2.0 ports, 1 COM port, and 16-bit GPIO. Equipped with built-in touch controller, SBC is suited for gaming, industrial, retail, digital signage, medical, and SMB storage applications. Read More

Computer Hardware & Peripherals

Compact COM Express Module leverages fifth gen Intel Core CPUs.

January 8, 2015

Type 6 COM Express Compact (95 x 95 mm) module, PCOM-B633VG runs multiple applications securely and reliably on virtualization-optimized platforms to deliver optimized value models and service levels. Along with 3 symmetric independent displays, module employs 5th generation Intel® Core™ CPU built on 14 nm process technology. Other features include up to 8 GB DDR3L 1600 MT/s SDRAM and optional 4 GB DDR3L memory, expansion via configurable PCIe interface, and support for 3 independent displays. Read More

Computer Hardware & Peripherals

SBC Module features single-chip, quad-core processor.

January 5, 2015

Based on Intel® Atom™ E3800 processor and PC/104-plus Carrier board, Em104P-i2313 ETXp SBC Module provides up to 8 GB fast DDR3L memory via 1 SO-DIMM socket. Integrated graphics support DirectX 11, Open GL 3, OpenCL 1.2, and ability to decode multiple full HD videos in parallel. Two SATA interfaces with up to 3 Gbps and one PATA channel with CF socket enable system extension. Operating from -40 to 85°C, SBC also includes 4 USB 2.0 ports, 1 GigE and one 10/100Base-T Ethernet, and 4 COM ports. Read More

Computer Hardware & Peripherals

Full-Size Board leverages Intel® 4th Generation processor.

January 5, 2015

Based on Intel® 4th Generation i7/i5/i3 processor, Model FSB-H81H comes equipped with Intel® H81 chipset, which integrates HD Graphics and supports VGA or DVI output. Realtek 8111E PCI-Express GbE is used for high-speed internet connections. In addition to 4x RS232 ports and 2 x RS232/422/485 ports, single board computer provides support for DDR3 memory as well as DDR3L 1333/1600 DIMM memory up to 16 GB. Support for SATA 6.0Gb/s and SATA 3.0Gb/s is also available. Read More

Computer Hardware & Peripherals, Display & Presentation Equipment

Embedded Motherboards serve digital signage applications.

January 5, 2015

Along with one HDMI, EMB-Q87B features 3 DisplayPort interfaces that are programmed to be used simultaneously or independently to accommodate those wishing to enlarge signage or show signage in sequence. Other features include USB ports, onboard Intel® Active Management Technology (AMT) with remote management capabilities, full size and half size MiniCard slots, and 12–24 V operating range. With exception of AMT, EMB-H81B can perform same functions as EMB-Q87B. Read More

Computer Hardware & Peripherals

ARM-Based 3U VPX SBC has SWaP-optimized design.

December 30, 2014

Built for SWaP-constrained defense and aerospace applications, VPX3-1701 employs features ARM architecture and employs 1.0 GHz Freescale™ QorIQ™ LayerScape LS1020A processor with integrated dual ARM Cortex-A7 processors. Rugged 3U VPX COTS processing module, rated at <15 W max power dissipation, delivers processing capabilities suited for managing data from high-speed I/O interface cards. Options are provided for supporting Sysgo PikeOS™ and Wind River® VxWorks® operating systems. Read More

Computer Hardware & Peripherals

Fanless ISA Bus SBC enhances CNC machine capabilities.

December 29, 2014

Targeting CNC machining and automation industry, AR-B8172 connects CPU, motion controller cards, and other I/O interfaces in order to offer accurate response to CNC machine. Design can overcome heat dissipation difficulties encountered in factories, and available chassis aids integration within machine. Along with onboard 800 MHz DM&P Vortex86DX CPU and 256 MB DDR2 SDRAM for data storage, features include PC/104, 2 COM, 4 USB 2.0, VGA, and 10/100 LAN interfaces. Read More

Computer Hardware & Peripherals, Electronic Components & Devices

Fanless Mini-ITX Boards balance performance, power consumption.

December 17, 2014

Powered by Intel® Atom™ E3800 series CPUs, EMB-BT2/-BT4 are built to negate such problems as vibration and mechanical breakdown from moving or changing of parts. Heat sinks ensure complete dissipation, and ATX power specifications require only 12 V. Suited for factory automation applications, boards both support dual LAN and mSATA, offer 2 LVDS sockets, and provide up to 6 COM ports and up to 8 USB ports. EMB-BT4 is slim enough to be used in panel PCs and slim PCs. Read More

Computer Hardware & Peripherals, Electrical Equipment & Systems

COM Express Type 10 Mini Module operates from -40 to +85°C.

December 15, 2014

Powered by quad-core Intel® Atom™ E3800 (Bay Trail) CPUs, 84 x 55 mm CEM840 supports 4.75–20 V input, 4 lanes of PCIe, and up to 4 GB onboard DDR3L memory. Flexible x86 feature set and 7th generation Intel® HD graphics engine are complemented by diverse connectivity: LPC, 2 SATA-300, GbE supporting Wake-on-LAN, 8 USB 2.0, USB 3.0, HD audio, 4 DIO, LVDS (18-/24-bit, single-channel), and DDI supporting HDMI/DVI/DisplayPort. Hardware monitoring and Watchdog Timer are supported. Read More

Computer Hardware & Peripherals

Scalable COMe Module is powered by AMD G-Series GX processors.

December 9, 2014

Suited for performance-intensive, multi-touch display systems as well as industrial tablet PCs, COMe-cSE6 supports quad-core processors up to dual-core and leverages AMD embedded technology to optimize graphics resolution on HD displays. This 95 x 95 mm COM Express® Computer-on-Module also supports up to 16 GB DDR3L dual channel RAM as well as Windows 8/7, WE8S, WES7, and Linux. Features include 3 independent display outputs, several standard I/O options, and PCIe x1-enabled extensions. Read More

Computer Hardware & Peripherals

Single Board Computer offers choice of multicore processors.

December 5, 2014

Available with Freescale™’s Power Architecture™ QorIQ™ AMP CPUs, SBC314 3U OpenVPX Single Board Computer is suitable for mission computing and ISR applications. Version featuring T1042 4-core e5500-based processor is designed for environments requiring minimal power consumption, while board using T2081 8-virtual core e6500 processor delivers maximum performance. Offered in 5 air- and conduction-cooled ruggedization levels, SBC314 supports Gigabit Ethernet, COM ports, USB 2.0, SATA, and GPIO. Read More

Computer Hardware & Peripherals

Rugged SBCs offer modular I/O for MIL-aerospace applications.

December 4, 2014

Powered by ARM Cortex-A9 dual-core CPU, North Atlantic Industries (NAI) 6U VME and 3U cPCI SBCs are built on Custom-On-Standard Architecture™ (COSA™) and support Mil-Aero applications requiring high-density, configurable I/O and communication functions. SBCs support 3–6 function module slots that let system integrators choose from 40+ I/O and communication functions. BSP and SSK support for Wind River® Linux, VxWorks®, and Xilinx® PetaLinux Tools is also included. Read More

Computer Hardware & Peripherals, Robotics

Digital Signage Player features 4K UHD video playback.

December 2, 2014

Powered by 2.4 GHz Intel® Core™ i7-4500EQ or 2.7 GHz Intel Core i5-4400E CPU, 175 x 116 x 32 mm SI-83 features 2x DDR3L-1600 SO-DIMM (dual channel) up to 16 GB, QM87 integrated graphics controller, and support for 1080P video playback on 3 independent displays via two 4K (3840 x 2160p @ 60 Hz)-capable DP 1.2 and one HDMI 1.4a (3840 x 2160p @ 30 Hz). On-board I/O (2 GbE, 2 USB 3.0, 2 USB 2.0, audio, 12 Vdc-in) is complemented by storage and expansion support via mSATA and Mini PCIe(x1) slot. Read More
