Computer Module suits embedded systems with no graphics.

November 20, 2014

Based on 1.33 GHz Intel® Atom™ E3805 processor, Qseven Headless Module comes with 2 GB of DDR3L memory and up to 16 GB eMMC 4.5 for mass storage. Total of 6 USB 2.0 ports are provided, one of which supports USB 3.0 SuperSpeed. Three PCI Express 2.0 lanes and 2 SATA interfaces operating at up to 6 Gbps enable flexible system extension. With max TDP of 3 W, computer-on-module is suited for fanless designs in connected device applications for Internet of Things. Read More

Computer Hardware & Peripherals

Gigabyte PCIe Network Card supports medical applications.

November 20, 2014

Suitable for any computer with PCIe slot, IEC60601-1 compliant NIC-51010 features isolated Ethernet 1000Base-T interface and RJ45 in/out network isolator for galvanic isolation with dielectric strength up to 4,000 V. Card offers one Gbps Ethernet IEEE 802.3, 802.3u, and 802.3ab PHY specifications compliance; IEEE 802.3az energy efficient Ethernet; IEEE 1588 precision clock synchronization; 9 KB Jumbo frame support; 2 transmit/2 receive queues; and TCP/UDP/IP stateless offload. Read More

Computer Hardware & Peripherals

Fanless Hygienic IP65 Medical Panel PC has 77 mm deep design.

November 20, 2014

Powered by fourth generation Intel® Core™ i5 and i7 CPUs with quadcore technology, MLC 4-21 offers up to 16 GB memory, various I/O options, and support for Wi-Fi®, Bluetooth®, and RFID readers. Toughened glass of 21.5 in. display, which delivers full HD resolution with 1920 x 1080 pixels, can be disinfected with cleaning agents common to medical area/epidemic control. Optional 4K display (3840 x 2160) is available, and optional multi-touch screen supports operation with surgical gloves. Read More

Electronic Components & Devices, Computer Hardware & Peripherals

USB 3.0 Interface ICs come in low-pin count packages.

November 20, 2014

Respectively, FT600Q and FT601Q come in 56- and 76-pin QFN packages and feature 16- and 32-bit wide FIFO bus interface. Both chips, which function as SuperSpeed USB 3.0 to FIFO bridges, support up to 8 endpoints (other than management endpoints) linked to configurable buffers of 16 KB length for in and 16 KB for out. Providing data bursting rates up to 3.2 Gbps, USB 3.0 products support 2 interfacing modes: 245 FIFO mode and multi-channel FIFO mode. Read More

Computer Hardware & Peripherals

Mini-ITX Motherboard suits digital signage and control.

November 19, 2014

Based on Intel® Atom™ E3800 series, conga-IA3 measures 25 mm in height with I/O shield, allowing installation in display and panel PCs. Two SODIMM sockets support up to 8 GB DDR3L memory, while Intel® Gen7 graphics support DirectX 11, OpenGL 3.2, OpenCL 1.2 plus flexible hardware decoding. In addition to 3 USB 3.0 SuperSpeed ports and 4 USB 2.0 ports, board includes 2 Intel I211 Gigabit Ethernet controllers that each provide Gigabit Ethernet LAN access via 2 RJ45 sockets. Read More

Computer Hardware & Peripherals, Machinery & Machining Tools, Communication Systems & Equipment

Wi-Fi Range Extender offers facilitated setup via touchscreen.

November 19, 2014

Boosting Wi-Fi® signals to cover up to 10,000 ft² by repeating and amplifying original signal of any Wi-Fi router, 5 in. wide x 5 in. tall TAP-EX can be setup within minutes and does not require other devices for such. Touchscreen UI lets user search for and select desired Wi-Fi network as well as control Parental Control features and other settings. Along with optional digital clock display, features include 2 additional wired ports for network devices and USB port for local file sharing. Read More

Computer Hardware & Peripherals

Mini ITX Motherboard features Intel® quad-core SoC.

November 19, 2014

Based on quad-core Intel® Celeron® J1900 processor with Intel® HD Graphics engine, MANO840 utilizes high bandwidth DDR3L-1333 SO-DIMM with memory up to 8 GB. Embedded board provides 6 USB ports, 6 COM ports, 2 Gigabit Ethernet ports, and digital I/O. Various display interfaces support dual-view via VGA, HDMI, and 18/24-bit dual-channel LVDS. With 12 V single voltage DC power jack, MANO840 can be applied to medical/healthcare, in-vehicle infotainment, kiosk, digital signage, and POS uses. Read More

Electronic Components & Devices, Computer Hardware & Peripherals, Controls & Controllers

Embedded SoC fosters graphical HMI implementation on FPGAs.

November 19, 2014

Integrating memory and display control, graphics accelerator, alpha blending and transparency, as well as various HMI graphics objects, Lattice Semiconductor embedded HMI-On-Chip (HOC) accelerates creation and implementation of embedded graphical HMIs on Lattice FPGAs. Complete functionality required for display driving, graphics rendering, and embedded visualization – scalable from small size QVGA to large full HD displays as well as other system interfaces – is provided. No OS is required. Read More
