Next Generation Power Engineering, Inc.
Jacksonville, FL 32246
Apr 21, 2008 Measuring 30 x 16 x 20 in., 15CFM Diesel Air Compressor weighs 175 lb and fits into compartments with limited space. Unit supplies 15 cfm @ 150 psi, and powder-coated Schulz air compressor with all CNC-machined parts operates at 1,000 rpm. Along with electric start, product features single-cylinder, water-cooled Kubota 7 hp diesel engine that supplies constant power. Fuel tank (1 gal) provides 6-8 hr of use, and included air tank can be remotely or unit-mounted.

Atlas Copco Compressors, Inc.
Westfield, MA 01085
Apr 07, 2008 Able to operate in ambient temperatures to 131°F, GA Series Oil-Injected Compressors feature compression elements based on asymmetric rotor profiles. Optimization of oil injection, flow, and temperature keeps compression process at coolest possible temperature to minimize thermodynamic loss. Additional energy-saving elements include use of radial fans with Variable Speed Drive regulation, efficiency-optimized motors, and no-loss drains. Air quality is provided by oil removal system and dryers.

Next Generation Power Engineering, Inc.
Jacksonville, FL 32246
Mar 25, 2008 Measuring 38 x 24, x 45 in., KS3030 Diesel Air Compressor combines 12 hp, 2-cylinder, water-cooled Kubota Z482 engine and powder-coated Schulz compressor mounted on top of 30 gal, ASME-code air receiver. It does not require separate fuel supply from diesel-powered service vehicles; it runs on same fuel system and produces air flow volume of 30 cfm @ 175 psi (35 cfm @ 100 psi). With no electronic components, product is suited for use in outdoor conditions.

Thomas Industries, Inc.
Sheboygan, WI 53082-0029
Mar 11, 2008 Measuring 4.25 x 4.63 x 3.02 in. and weighing 2.5 lb, 260 Series brushless DC WOB-L® air compressor and vacuum pump is designed for medical and other applications requiring lightweight pump with variable output. It utilizes efficient brushless DC motor, enclosed crankcase, and WOB-L® piston technology. With maximum flow of 1.5 cfm at high speed, pump also offers maximum pressure of 30 psig and maximum vacuum of 22 in. Hg.9

Thomas Products Division
Sheboygan, WI 53081
Mar 04, 2008 Measuring 4.25 x 4.54 x 3.02 in. and weighing 1.9 lb, Series 250 WOB-L® air compressor and vacuum pump delivers variable output from 1,000-3,000 rpm utilizing brushless DC motor, enclosed crankcase, and WOB-L® piston technology. Unit features max flow of 1.0 cfm, max pressure of 30 psig, and max vacuum of 22 in. Hg.

VMAC Div., Mangonel Corp.
Nanaimo, BC V9X1R3
Jan 23, 2008 Delivering up to 40 cfm and 150 psi at dry weight of 150 lb, Model PREDATAIR40 above-deck hydraulic air compressor comes in 17 x 18 x 24 in. package. Rotary-screw compressor incorporates cold and soft start features, unload circuit, standby mode, service reminders, and system status display. Unit can operate at 100% duty cycle, and includes cooling system and remote LCD digital control box, system diagnostics, compressor/hydraulic temperature readings, and total system hours.

Atlas Copco Compressors, Inc.
Westfield, MA 01085
Oct 30, 2007 KT Series of 5-20 hp, 2-stage reciprocating piston compressors are suited for intermittent use in workshops and in light industrial applications. They are available in variety of configurations including horizontal or vertical tank mounted, duplex horizontal tank mounted, and gas driven tank mounted. For OEM applications, block unit is available by itself and can be combined with choice of driver.

Gardner Denver
Quincy, IL 62301
Oct 16, 2007 Able to be configured as air-cooled or water-cooled, Models VST 110, VST 150, and VST 180 are rated at 150, 200, and 250 hp, respectively. Two-stage rotary screw compressors include variable-speed cooling fans, AirSmart controller, and operating sound levels that allow units to be placed anywhere. Units have no gears and can supply any pressure from 85-175 psig.

Gardner Denver
Quincy, IL 62301
Oct 16, 2007 Combining Tempest integrated air end/sump and AirSmart control system, Model VS 11 operates from 70-175 psig and provides unlimited start and stop capability. Design allows for operation from 100% down to 20%, with precise pressure control to ±1 psig. Available with base or tank mounting and optional integrated refrigerated dryer, rotary screw compressor provides noise level of 64 dBA.

Gardner Denver
Quincy, IL 62301
Oct 16, 2007 Configured as air- or water-cooled, VS 135 and 170 rotary screw compressors combine Enduro + airend and AirSmart control system. Smart Mixing Valve Technology keeps air/oil mixture above pressure dew point and prevent water from condensing in compressor. While VS 135 provides 125-862 acfm, VS 170 provides 139-1,056 acfm. Both operate from 70-175 psig, exhibit respective noise levels of 76 and 77 dBA, and provides unlimited start and stop capability.

Hitachi America Ltd., Industrial Systems Division
Tarrytown, NY 10591
Apr 24, 2007 Designed to conserve natural resources and eliminate environmental emissions, SRL air compressors feature Scroll Wrap with Alumite(TM) surface treatment and labyrinth seal. Multi-stage cooling stabilizes discharge air temperature, while microprocessor-based cycle control logic automatically elongates Load/Unload cycle. Along with quiet enclosure, products incorporate Hitachi motors and air-ends as well as air receiver(s) that promote proper air system design.

Kaeser Compressors, Inc.
Marietta, GA 30067
Mar 07, 2007 Sigma Air Manager Basic (SAM Basic) master controller provides pressure band control, balances service hours, tracks preventive maintenance requirements, and prevents simultaneous motor starts. It can be adapted to almost any system and manage up to 4 compressors or vacuum pumps. Controller also connects to dryers, filters, and drains to monitor operating or maintenance status.

McFee Technologies
Battle Creek, MI 49015
Nov 15, 2006 SmartAir II(TM) works with reciprocating or rotary screw air compressors and displays information on web page. Users can set pressure set points, mode of operation, alerts, and start/stop times from desk or from anywhere worldwide. Controller includes up to 4 onboard pressure or vacuum transducers, 8 RTD inputs, and 8 user supplied inputs. When inputs are exceeded, email is generated and, if specified, compressor is shut down until problem is fixed.

Gardner Denver
Quincy, IL 62301
Nov 09, 2006 Featuring enclosed designs in both motor and compressor sections, TASKAIR(TM) E Series articulating piston units operate at 1,800 rpm, providing up to 150 psi of pressure and max flow of 3.35 cfm. Compressor section features oil-less design utilizing dual cast iron cylinders, stainless steel valves, and PTFE piston rings and skirts. Permanent magnet, TEFC motor is available in 12 and 24 Vdc versions. Applications include air suspension systems, air brakes, and tire inflation systems.

Sullair Corporation
Michigan City, IN 46360
Oct 19, 2006 Series 1100e, 1500e, and 1800e are 15, 20, and 25 hp encapsulated compressors, available with variable speed drive that can adjust to changes in air demand. To minimize noise levels, air-end and motor are mounted on rubber isolators. Units also include insulated intake and exhaust louvers as well as fully insulated enclosure.

Mi-T-M Corporation
Peosta, IA 52068
Oct 18, 2006 Powered by 4.0-4.5 hp Honda or Subaru gasoline engine, air compressors meet requirements of industrial users and professional contractors. They can be carried by hand and feature single-stage compressor with aluminum oil lubricated crankcase and aluminum head with cast iron cylinder. Along with drain and pressure relief valves, design features include 5.0 gal twin tank, quick connect fittings, roll cage, and pneumatic throttle control.

DeWalt Industrial Tool Co.
Hampstead, MD 21074
Oct 11, 2006 Suited for finish carpenters and woodworkers, Model D55140 produces .75 scfm at 90 psi, 135 psi max and operates at 69 dBA. It is equipped with 1 gal tank, 2.6 A motor, and oil-free pump. Weighing 24 lb and measuring 9 in. wide, portable compressor includes one-hand universal quick connect and ball drain valve for thorough tank draining. Roll cage design shields unit from wear and tear, while wrap-around control panel covers frame and provides further protection to key components.

Air Squared, Inc.
Broomfield, CO 80020
Jul 17, 2006 With completely sealed pumping section, semi-hermetic scroll Vacuum Pump/Compressor allows cooling of both scrolls. As compressor, unit develops up to 60 psig with 2 cfm displacement, while vacuum model develops up to 200 mtorr with displacement of 2 cfm. Seals are PTFE composite, and wetted surfaces are constructed of stainless steel, nickel, and hard anodized aluminum. Unit is suited for fuel cells, natural gas boosters, and pumping corrosive, radioactive, or hazardous gases.

Hitachi Power Tools
Norcross, GA 30093
Mar 29, 2006 Oil-free EC79 features contractor-grade induction motor, integrated control panel, and ball valve tank drain. Based on Inspire Design, maintenance-free, portable unit has 90 psi pressure rating that enables it to accomplish short burst applications with tools such as finish nailers and staplers. This 2 peak hp/1 Run hp compressor operates on standard household current, drawing 13 A, and features 6 gal tank and factory-installed ¼ in. coupler.

Sullair Corporation
Michigan City, IN 46360
Mar 23, 2006 Able to fit through standard 36 in. door, Series 3700 operates at 68 dba with fluid carryover less than 1 ppm. All standard maintenance can be performed from one side of machine, and compressor's fluid level can be checked without opening doors. Fully sealed environmental protection pan captures spills that may occur during servicing. Offering remote monitoring from Windows PC, WS microprocessor provides built-in full load solenoid valve for sequencing up to 16 machines.
