Quarter-Turn Electric Actuators suit rugged applications.

Press Release Summary:




Intended for ball and butterfly valves or dampers requiring torque outputs from 800-40,500 lb-in., industrial-grade non-spring return P2-13 Series has self-locking hardened steel drive train, mechanical end of travel stops, and clutch-free manual override. Additional features include position indicator, 2 auxiliary switches, internal low-power anti-condensation heater, and cast aluminum polymer coated housing with two ¾ in. conduit connections rated NEMA 4X.



Original Press Release:



Reliable P2-13 Series Quarter-Turn Electric Actuators for Rugged Industrial Applications



ProMation Engineering P2-13 Series Quarter-Turn Electric, Non-Spring Return Actuators feature a rugged, industrial grade design for use with all ball and butterfly valves or dampers requiring higher torque outputs from 800 in. lbs. to 40,500 in. lbs. The series features a self-locking hardened steel drive train for smooth operation, mechanical end of travel stops, and patented clutch-free manual override for single-handed positioning of the actuator in any situation.

The P2-13 actuators include an integrated position indicator, two auxiliary switches, an internal low-power anti-condensation heater, and cast aluminum polymer coated housing with two 3/4" conduit connections that are rated NEMA 4X for safe exposure to high pressure hosing and corrosion resistance. Proportional control units accept a wide range of control signals while generating multiple feedback signals and are easily installed, calibrated, and adjusted in the field. The actuators are available for 24 VAC/VDC, 120/230 VAC or single phase and complete 3-Phase offerings. They are ISO 5211 compliant, conform to AWWA C540 standards, are certified to CSA 22.2 standards including ANSI/UL 50 and ANSI/UL 429, and are ARRA compliant.

Available options include torque switches, motor control centers, phase monitors, potentiometers, cold weather kits (for operation to -40 degrees F/C), timers, speed controls, single wire control interfaces, a wide array of feedback control interfaces, local control units, and fail safe solutions. All options are factory installed, calibrated, and tested.

For more information, call 352-544-8436, Fax: 352-544-8439, E-mail: jeff.jones@promationei.com, visit www.promationei.com, or write Promation Engineering, 16138 Flight Path Drive, Brooksville, FL 34604.
