Special Optics, Inc.
Wharton, NJ 07885
Jun 17, 2008 With ability to accommodate large input beam dia of up to 17 mm and wavelengths of 266 or 355 nm, telecentric UV scanning lenses include 4 units with focal lengths of 34, 50, and two at 100 mm with scan fields of 9, 20, 45, and 55 mm, respectively. Diffraction limited units have deviation from telecentricity of less than 0.9° for single axis scanning and less than 3° for dual axis. F-Theta scan lenses are capable of achieving spot sizes of 1.4, 3.5, and 7.1 microns, respectively.

LMI Technologies USA, Inc.
Southfield, MI 48075
Jun 17, 2008 Facilitating development of scalable machine vision systems, FireSync(TM) consists of sensor controllers, camera and embedded sensors, machine vision software, industrial computers, and lighting. System supports 4 independent camera channels, pre-processing, DSP algorithms, and Gigabit networking. With image streaming, components are combined with proportional/functional control of sub-components and synchronization of image collection to within microsecond accuracy.

Toshiba Teli America, Inc.
Irvine, CA 92618
Jun 16, 2008 Suited for high-speed applications, CleverDragon CSC12M25BMP19 employs 1.9 in. CMOS monochrome progressive scan sensor with 4,096 x 3,072 pixel resolution and full-frame speed of 25 fps. Electronic global shutter helps capture clear images of parts, and Camera Link(TM) interface allows integration into new/existing systems. Window of Interest (WOI) function can be programmed to display 28 square windows within one image and lets user select only those that are to be read out.

Accu-Sort Systems, Inc.
Telford, PA 18969 1196
Jun 16, 2008 Cameras and scanners read low-aspect ratio barcodes, which range from 3/8-½ in. tall and have narrow elements (10 mil), in any orientation as tire passes scan point. Axiom-X(TM) barcode-reading, omni-directional laser scanner offers hot-swap component change-outs. Also available, AccuVision® HandsFree(TM) barcode reading CCD camera/decoder has 30 in. depth of field. High-end CCD camera, AV4000, reads 1D bar codes as well as 2D symbologies and can also capture images of no-reads.

Vicon Industries Inc.
Hauppauge, NY 11788
Jun 16, 2008 Featuring optical construction of 10 elements in 7 groups, Verifocal IR Lenses provide adjustable angle of view from wide to normal, eliminating need for trial-and-error lens fitting and stocking of multiple fixed-focal-length lenses to cover different viewing angles. They can be used with true day/night cameras to provide sharp, focused images in daylight and at night, particularly in presence of IR light. Equipped with CS-type mounts, units can also be used on ¼ in. format cameras.

W.A.C. Lighting Company
Garden City, NY 11530
Jun 13, 2008 Providing 350° horizontal adjustment and 90° vertical aiming with 10° indicator guide marks, W2 Wall Washers feature clean design with concealed wiring that is routed within track head to ensure that cords are not exposed. Seamless design prevents light leaks from the rear of fixture, while ballast housing offers locking feature for positive support of track head. Lamping options include 200 W Halogen T3, 20, 39, and 70 W metal halide T4, Metal Halide TD6, and Tri-Tube CFL.

Avago Technologies
San Jose, CA 95131
Jun 13, 2008 Available in 3.4 x 3.2 x 2.0 mm PLCC-4 package, Blackbody ASMT-QTC0 LED offers 115° viewing angle along with contrast and sharpness required for short distance viewing in variety of indoor full color displays. RoHS compliant, silicone-encapsulated device incorporates heat sinking capabilities to handle high drive currents, and moisture sensitivity level of 2a makes LED compatible with SMT production environments and reflow soldering processes.

Avago Technologies
San Jose, CA 95131
Jun 13, 2008 Available in amber and red colors, 1 W Moonstone(TM) LED emitter ASMT-Mx00 is capable of being driven to high current of 350 mA to deliver up to 42 lumens output. Energy efficient product features 120-deg viewing angle, exposed pad for heat transfer, low-profile design of 3.3 mm H, and greater than 8 kV ESD. Utilized in architectural, garden and decorative lighting applications, emitter is compatible with IR soldering processes, and is encapsulated in heat and UV resistant silicone compound.

Photron USA, Inc.
San Diego, CA 92126
Jun 12, 2008 Designed for production line and automation fault-finding, Fastcam MC2 features global electronic shuttering rate from 20 ms to 6 µsec for clear slow motion image capture. Light-sensitive, CMOS (Bayer system color), 10 micron pixel, single-sensor camera with 512 x 512 pixel resolution comes in 3 models. Unit has 1 Gb (4 sec recording time at 1,000 frame/sec) or 2 Gb (8 sec recording time at 1,000 frame/sec) memory options, C-mount lens adaptor, and automatic download feature.

Contex
Herndon, VA 20170
Jun 11, 2008 Nextimage corrects every scan for contrast, balance, and detail to cut out fine-tuning and re-scanning for imaging professionals. It features ICC color management or closed loop color calibration, B/W adaptive thresholding for monochrome cleanup, and built-in application printer drivers. Software provides plug'n'play connectivity with nearly all wide format printers, fast pre-scans with instant preview, and edge-preserving smooth filter that prevents hard lines and borders.

Prosilica Inc.
Burnaby V5J 5E9  Canada
Jun 10, 2008 Measuring 51 x 89 mm, GB Series includes 4 models with VGA to 5 megapixel resolution and full resolution frame rates to 120 fps. Units come in color or monochrome models with landscape or portrait orientation, and with in-line or vertical connection. GigE Vision compliant interface allows use of Cat5e Ethernet cable up to 300 ft. Equipped with progressive scan Sony CCD sensors, cameras offer snapshot/global shutter, pixel binning, area of interest readout, and external trigger.

Toa Electronics, Inc.
South San Francisco, CA 94080
Jun 09, 2008 Suited for indoor and outdoor use, CV-Series Vandal Resistant Day/Night Color Mini-Dome camera operates as color camera in daylight and monochrome camera in darkness. Body is made of die-cast aluminum alloy with polycarbonate dome cover making it resistant to vandalism and abuse. With dustproof and waterproof construction, C-CV854D-9 flicker-free camera features backlight compensation function, 3-axis mount, 3-9 mm lens, and dual voltage of 24 Vac or 12 Vdc.

Toa Electronics, Inc.
South San Francisco, CA 94080
Jun 09, 2008 With backlight compensation function that enables operation under various lighting conditions, CV-Series Outdoor Day/Night Color Cameras are water and dust resistant to withstand outdoor use. Flicker-free cameras feature 3-axis mount, focus adjustment switch to achieve optimal focus in daylight and low-light conditions, and selectable 24 Vac or 12 Vdc voltage. Models C-CV454D-3, C-CV454D-9, and C-CV454D-18 are supplied with 3-9 mm, 9-22 mm, and 18-50 mm lenses, respectively.

FARO Technologies, Inc.
Lake Mary, FL 32746 6204
Jun 09, 2008 Photon and LS Laser Scanners, using FARO Scene v4.5 software, support combining of scans into clusters and their relative alignment. Software also automatically accounts for common slab thicknesses and accelerates scanning alignment by letting users perform registration with common facility objects, including pipes and planes. Other features include support for alignment with checkerboard paper targets and 3D visualization with gap-filling and gradient background color capabilities.

TOFRA, Inc.
Palo Alto, CA 94303
Jun 06, 2008 RGB LED Light Source enables independent control of red (619 nm), green (515 nm), and blue (465 nm) LEDs to create any desired color, including white light, for visual observation. Color images can be produced from monochrome cameras, giving full non-interpolated color at every pixel. Light source head mounts instead of condenser on upright microscopes and does not create any vibration or noise. Light source controller connects to computer serial or USB port.

SICK, Inc.
Minneapolis, MN 55438
Jun 05, 2008 Providing pass/fail output, Inspector Vision Sensor verifies completeness and quality of product regardless of angle/orientation as it comes down line. Unit features 384 x 384 resolution, IP 67 metal housing, and integrated dome light that delivers high quality images even on glossy and reflective surfaces. Applications include verifying label position, date code presence and cap inspection in packaging, as well as bowl feeder inspection and verification of part assembly.

Ricoh Corp.
West Caldwell, NJ 07006
Jun 05, 2008 GlobalScan(TM) v3.1 with Workflow Suite helps document-intensive organizations develop workflow efficiencies by integrating scanning into their business processes. Scanning plug-ins connect MFPs directly to backend systems, document management systems, and fax servers to create customized and optimized workflows. Along with document compression, solution offers OCR capabilities for converting hardcopy documents into various electronic formats.

Dalsa Inc.
Waterloo, ON N2V2E9
Jun 04, 2008 Featuring 2/3 in. CCD sensor from SONY, Genie C1410 and Genie M1410 cameras are designed for industrial imaging applications in semiconductor, robotics and traffic control industries. They come in color (C1410) and monochrome (M1410) versions running at 22 FPS. Integrating both advanced camera and board image acquisition technologies, cameras feature global electronic shutter with exposure control, on-board flat-field correction, and on-board color conversion.

Flir Systems, Inc.
North Billerica, MA 01862
Jun 03, 2008 ThermaCAM® P660 can automatically record location of equipment as well as tag captured IR images for determining equipment failure patterns before failure occurs. Along with thermal sensitivity of less than 45 mK and accuracy to ±1% or ±1°C, thermal imaging camera features 3.2 Megapixel visible light camera, target illuminator, and 640 x 480 detector array. Wireless LAN-based remote control and display enable equipment monitoring at safe distances.

Flir Systems, Inc.
North Billerica, MA 01862
Jun 03, 2008 Designed to meet electrical survey and mechanical inspection needs, T-250 and T-200 offer 200 x 150 IR resolution (30,000 pixels), auto and manual focus, as well as thermal sensitivity optimized to pinpoint problems. Picture-in-picture FUSION feature lets users overlay IR image directly over corresponding visible image, facilitating identification and interpretation. for sketching diagrams and marking images, T-250 includes touch screen capability.
