Manometers

Test & Measuring Instruments

Compact Handheld Meters meet environmental field monitoring needs.

February 25, 2016

Digital HHC201 and HHC210 are, respectively, a dual thermocouple thermometer and IR thermometer with laser sighting. While HHC230 measures light intensity, HHC250 performs non-contact optical RPM measurement. Hygro-anemometer HHC261, used to measure air flow and humidity, offers ambient measurement, wind chill indicator, and integrated wet bulb flow vane. Differential (HHC280) and absolute pressure (HHC281) manometers are also available, and all meters have portable, rugged design. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Capacitance Manometer measures from 0.1-1,000 Torr.

February 18, 2014

Internally heated to 45, 80, or 100°C, a-Baratron® Capacitance Manometer provides accurate vacuum and pressure measurements. Unit features pushbutton zero, all-digital architecture, and sensor made from Inconel and Incoloy nickel alloys for corrosion resistance. Unit can be equipped with standard sensor or patented Etch Baffle sensor technology that minimizes process contamination. Fully CE and RoHS-compliant, manometer operates on ±15 Vdc input and provides 0–10 Vdc analog output signal. Read More

Test & Measuring Instruments

Hydronic Manometers offer expanded capacities.

August 12, 2013

Offering inputs for 2 temperature probes to maximize efficiency, Models HM675 and HM685 are used to balance commercial hydronic heating and cooling systems, check pump performance, and set balancing valves. Model HM685 performs onboard universal flow and btu/hr calculations and allows for 4X more storage capacity. Both splashproof models can simultaneously measure and display differential, high side, and low side pressure without changing hose connections or instrument valve settings. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Portable Combustion Analyzer Kit combines 5 tools in 1.

August 7, 2012

Intended for all 90%+ efficiency systems, BTU1100-HE High Efficiency Kit comprises combustion analyzer, CO leak detector, manometer, draft meter, and 2-channel thermometer. Unit is equipped with incoming air smart probe, field-replaceable sensors, built-in non-thermal printer, and unbreakable metal connections. Operating from rechargeable battery, analyzer meets needs of mechanical contractors, plumbers, and boiler technicians monitoring and installing condensing and high efficiency systems. Read More

Controls & Controllers, Test & Measuring Instruments

Brooks Instrument Launches New Mass Flow and Capacitance Manometer Technology at Intersolar North America 2012

July 10, 2012

HATFIELD, Pa. - Brooks Instrument will unveil its new XacTorr CMX0 capacitance manometer, as well as the new EtherCAT capabilities of its GF40/80 mass flow controller at Intersolar North America, July 10-12 in San Francisco. Brooks will showcase these and other mass flow, pressure and vacuum products for the solar and semiconductor industries at Booth 5648.<4444>The Brooks XacTorr CMX family of... Read More

Software, Test & Measuring Instruments

Brooks Instrument Wins Golden Gas Awards for Flow Control, Vacuum Technology and Software

March 9, 2012

HATFIELD, Pa. - Brooks Instrument, a world-leading provider of advanced flow, pressure, vacuum and level solutions, has won an unprecedented three Golden Gas Awards from Gases and Instrumentation International magazine. Brooks won in the categories of Vacuum Technology, Gas Flow Measurement and Control and Software. <4444>Brooks' XacTorr(TM) vacuum capacitance manometer received top honors in... Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Combustion Analyzer Kit suits all 90%+ efficiency systems.

October 18, 2011

Equipped with built-in manometer, thermometer, and CO leak detector, BTU1100-HE High Efficiency Kit measures O<sub>2</sub>, CO, and CO<sub>2</sub>, as well as efficiency, excess air, and all necessary temperatures. Unit includes incoming air smart probe, field-replaceable sensors, and built-in printer. Supplied in vinyl carrying case with calibration certificate, kit meets needs of mechanical contractors, plumbers, and boiler technicians monitoring and installing condensing and high efficiency systems. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Digital Manometer features 0.5 sec response time.

September 16, 2010

Traceable® Manometer displays gauge and differential pressure/vacuum in 11 different units via 5/8 in. high digits that are visible from 6 ft. Hose fittings permit use of hose/tubing with ID from 1/16-3/16 in. Count-up timer displays up to 99 hr, 59 min, 59 sec, DATA HOLD key freezes display to capture readings, and memory feature recalls highest and lowest reading over any time period. Powered by 9 V battery, device's accuracy is ±0.3% of FS between 0-50°C. Read More

Test & Measuring Instruments

Smart Manometers offer NIST traceable accuracy to ±0.025% FS.

September 8, 2010

Operating in temperatures from -4 to +122ºF, M200 Smart Manometers are available with 0-10.000 in. H<sub>2</sub>O range, 4 gauge pressure ranges up to 3,000 psig, and 2 absolute pressure ranges up to 1,000 psia. Products are also available in 8 compound pressure ranges to measure ±15 through -15 to +3,000 psig. They include backlight, alkaline battery power, and NIST traceable certificate of calibration with data, timed leak test, record mode, damping, and minimum/maximum value capture. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Differential Manometer offers dual pressure inputs.

March 26, 2010

Featuring dual display and dual pressure inputs Model HHP886 is CE-compliant differential manometer that displays pressure in selectable units of psi, mbar, in. H<sub>2</sub>O, and mm H<sub>2</sub>O. Device includes protective rubber boot and also has USB connection or wireless interface for real-time data logging to computer. Data logging software is included for display of data graphically, and allows export of data to Excel or text files. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Battery-Powered Manometer measures pressure and air velocity.

March 25, 2010

Suited for HVAC professionals, Model MP120 features pressure range up to 4 in. H2O and air velocity range up to 8,000 fpm with 0.1 resolution and accuracy of ±1% reading +0.2 mbar. Unit can display pressure in kPa, in. Wg, mbra, mm Hg, psi, m/sec, fpm, and km/hr and air velocity in fpm, m/sec, and km/hr. Measuring 5 x 2.5 x 1.25 in. handheld meter includes Max, Min, and Hold selection and blue 128 x 128 pixel display that can be read in light or dark environments. Read More

Test & Measuring Instruments

Handheld Digital Manometer suits field, plant, and lab use.

June 8, 2009

Available in gage and absolute and differential pressure models with ranges as low as 28 InH<sub>2</sub>O, HHP241 features 8 user selectable engineering units, min/max, hold, and display average modes with user activated back light. CE compliant device shuts off automatically after 20 min of keypad inactivity. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Differential Manometer offers 0.1 resolution.

March 3, 2009

With accuracy of ±1% rdg. + 0.2 mbar and 128 x 128 pixel backlit LCD display, MP100 manometer suits application in HVAC industry. It includes leak test procedures and air velocity with density compensation. Measuring 5 x 2.5 x 1.25 in., product also comes with pressure tubes, battery, and 11 pressure units including Pa, psi, mbar, bar, mm H<sub>2</sub>O, and in. H<sub>2</sub>O. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Digital Manometer precisely measures and logs pressure data.

October 15, 2008

Series HM35 can measure absolute pressure, differential pressure, or gauge pressure within 0.05% FS accuracy for critical applications. Data logging function can store up to 10,742 readings, taken manually or automatically at adjustable intervals from 1 sec to 24 hr. Handheld solution incorporates backlit LCD with 128 x 64 points that can graphically display trends in data as well as peaks and valleys. Data can also be transmitted to PC via IR serial port. Read More

Test & Measuring Instruments

Extech Instruments Offers Its New HD Series of Instruments for HVACR Applications

November 21, 2007

Four Separate Devices Provide Wide Range of Measurements, Capabilities <4444>Extech Instruments, a major supplier of test and measurement equipment for the industrial marketplace, announces the availability of its Heavy Duty Series of instruments, a new line of products specially designed to meet the needs of the HVACR industry. This durable series is comprised of four separate devices: the... Read More

Test & Measuring Instruments

Handheld Manometer is suited for field applications.

December 1, 2006

Designed to facilitate pressure calibration and monitoring processes, M2 Smart Manometer offers 11 selectable user units as well as 1- or 5-point field recalibration for zero, span, and linearity. Ranges handle gauge, differential, absolute, or vacuum pressure, and Min/Max feature captures varying signal extremes. With accuracy to serve as pressure reference standard, unit also provides leak test and flow functions. Compact polycarbonate enclosure measures 6.5 x 3.6 x 2.25 in. Read More

Test & Measuring Instruments

Handheld Digital Manometer is unaffected by humidity.

July 18, 2006

Operable with one hand, HHP-2000 Series features NEMA 4 (IP65)-rated, water-resistant case that withstands continual use in humid industrial or laboratory environments. Differential pressure models are offered with ranges from 0-10 to 0-2,815 in H2O and can be used to measure gauge or vacuum. Absolute pressure model, with 0-2,815 range in H2O, is also available. All models are autoranging, and data logging models can store readings comprised of up to 250 points. Read More

Test & Measuring Instruments

Manometer measures up to ±29 psi with 2% FS accuracy.

April 10, 2006

Available with single or differential inputs, model HHP91 is compatible with air or non-corrosive and non-ionized gases and liquids. It offers 8 selectable pressure ranges for compatibility with all measuring systems and displays readings in 15 mm high digits. In addition to built-in sensor with dual inputs for gage or differential measurements, unit features auto off function; reading hold/min/max, with push-button recall; and built-in tilt stand. Read More

Test & Measuring Instruments

Desktop Manometer comes in pressure and barometer versions.

December 2, 2005

Able to simulate and display instrument grade manometer, DM 2005 consists of 4 components: pressure sensor, housing, RS232 and USB interface cables, and software. It is offered in 3 versions for digital, amplified, and amplified mini pressure sensor series and can operate in interactive, one shot, free running, or over-sample modes. Pressure sensor ranges are available from ¼ in. water to 150 psi FS, and data sampling intervals range from 20 msec to 500 sec. Read More

Test & Measuring Instruments

Manometers measure primary and secondary pressure.

April 15, 2005

Offering primary pressure measurement, U-tube Manometers are available for vacuum, gauge, DP, or absolute pressure. Well type models are secondary pressure measurement standards operating over extended periods with minimal maintenance. Gang-mounted well type manometers can couple up to 6 units side-by-side to make multiple pressure measurements viewable from one location. Inclined tube manometers and laboratory quality micromanometers are suited for low-pressure measurements. Read More
