Power Indicators

Test & Measuring Instruments, Communication Systems & Equipment

Power and Energy Meter measures lasers up to 120 kW.

February 18, 2015

With response time of <1 minute, 120K-W Laser Power Meter can measure very high power, fiber, IR, and Nd:YAG lasers. Portable unit consists of beam dump with overall dimensions of 50 x 50 cm, and water flow power measurement unit with 11 x 15 x 34 cm dimensions. Connecting to PC via RS-232 interface, meter includes software that displays and graphs power and water flow rate. It is suited for heavy-duty applications, such as deep penetration welding, drilling, and cutting large products in field. Read More

Test & Measuring Instruments, Communication Systems & Equipment

Digital Panel Meter measures voltage to 300 V and current to 5 A.

January 26, 2015

Able to measure voltage, current, and apparent power, ProVu® PD6400 is NEMA4X/IP65 rated for use in panel or field under harsh environmental conditions. Independent, field-selectable current and voltage inputs accept up to 300 V and 5 A (AC or DC), and 1/8 DIN size unit also accepts current transformer inputs for higher measurements. Dual-line display features LED digits and warning lights with adjustable brightness, and Modbus® capability (Slave) enables network integration. Read More

Test & Measuring Instruments, Communication Systems & Equipment, Green & Clean

Power and Energy Meter supports BACnet MS/TP communication.

January 12, 2015

Featuring native BACnet MS/TP serial communication, Shark® 50B supplies power and energy data to building automation systems. Unit comes pre-programmed with 34 BACnet objects for seamless integration into existing BACnet networks. Meter also supports Modbus over TCP/IP so that it can communicate to stand-alone energy management system or energy dashboard. In addition to building automation, meter supports LEED projects and other green building initiatives. Read More

Test & Measuring Instruments, Communication Systems & Equipment, Optics & Photonics

Light and Color Meter suits on-line production applications.

October 22, 2014

Designed for industrial manufacturing of LEDs, Model BTS2048-VL provides complete photometric, scotopic, colorimetric, and radiometric spectral data. Meter is equipped with BiTec light sensor, which combines properties of silicon photodiode with those of back-thinned CCD diode array. Controlled via USB2.0, Ethernet, RS232, or RS485 interface, BTS2048-VL uses 3 processors and electronic shutter plus input and output triggers for synchronized LED binning. Read More

Test & Measuring Instruments, Communication Systems & Equipment

Solar Power Meter serves residential plant applications.

October 21, 2014

Solar-Log® 350 & GE Meter, comprised of General Electric I-210+ residential meter and Solar-Log technology, puts itself in service automatically after being plugged into any standard socket meter base. Solar-Log technology monitors and logs incoming data from solar array with revenue-grade precision required to collect state/utility incentives. Solution communicates with servers and online applications via 3G cellular modem and comes with 5 years of cellular data and Solar-Log WEB services. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Circuit-Level Monitor delivers actionable network analytics.

October 17, 2014

As 8,000 A circuit-level monitoring system for DC power distribution, UL-Listed and NEBS-Certified nrgSMART™ BDFB generates real-time data for remote site management, power provisioning, and threshold management. Functionality helps operators reduce OPEX as well as CAPEX.
Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Software, Communication Systems & Equipment, Optics & Photonics

Handheld Combination Analyzers debug satellite ground stations.

September 16, 2014

Enabling DDR4 DIMM protocol validation and debugging at over 2.5 Gbps, FieldFox analyzers provide solution for satellite ground station installation and maintenance. Products cover frequencies up to 26.5 GHz and provide all-in-one functionality: spectrum analyzer, full 2-port vector network analyzer, and power meter. Measurement Option 208 verifies frequency converters, and Option 212 expands cable testing beyond single-ended coax cable to provide insight into differential device performance. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Electronic Components & Devices

Digital Power Monitors support wide common mode input voltage.

July 25, 2014

Specified for temperature range of -40 to 125°C, Series ISL2802x comprises 3 devices offering bi-directional, high-side, and low-side digital current sense and voltage monitoring with serial interface. Devices deliver high-accuracy measurements through integrated 16-bit sigma-delta ADC with gain error of ±0.05% in wide input common mode voltage range of 0–60 V. Providing real-time alerts with response time of 500 ns, monitors are suited for telecom, industrial, and consumer applications. Read More

Test & Measuring Instruments, Communication Systems & Equipment

High Density Energy Metering System comes in NEMA 1 enclosure.

July 22, 2014

Without requiring complex redesign, Shark® MP200™ in Enclosure enables switchgear capability expansion and/or facilitates metering of circuits. This multipoint energy metering system in NEMA 1 type enclosure assembly suits high-density applications. Offering 0.5% Class Energy accuracy on all circuits, solution provides up to 24 energy metering points in one CPU. Unit can be ordered as eight 3-phase circuits or 24 single-phase circuits and offers multiple connectivity choices. Read More

Test & Measuring Instruments, Communication Systems & Equipment, Green & Clean

Power Meter is available with photovoltaic monitoring chip.

July 9, 2014

Able to be used for PV power plant monitoring, General Electric GE I-210+ with built-in Solar-Log® chip allows remote configuration of data logging and meter functions. Solar-Log chip monitors and logs incoming data from solar array with revenue-grade precision, including PBIs and SRECs. While chip can transmit data via 3G cellular modem or Ethernet, Solar-Log and GE Meter bus allows up to 16 more meters to be connected to monitoring system. Read More

Test & Measuring Instruments, Communication Systems & Equipment

Handheld Solar Power Meter measures up to 1,999 W/m².

June 20, 2014

Using end mount light sensor, Model SLR-01 measures solar energy to determine appropriate position or location for solar panels. Autoranging meter can read and display in units of W/m² and BTU/(ft2*h). Large numbers and high contrast of 3½ digit LCD enable users to read measurements in bright areas. Operating on 9 V carbon zinc battery, handheld meter is suited for solar farms, telemetry systems, and office buildings that utilize energy harvesting sensors. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Green & Clean

Power Monitor tracks usage for one machine or entire facility.

June 10, 2014

Factory-configured with 0–500 A or 0–2,000 A flexible coils to measure load current, DIN mounted APN-R Series can measure power usage of one piece of equipment, machine system, plant area, or entire facility. Line voltage (up to 600 Vac) connects directly to transducer, and installation over multiple conductors or bus assemblies produces accurate data while also allowing intervention. Digital format provides information on system voltage, current, and power factor in addition to wattage. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Green & Clean

Data Center Power Monitor helps manage energy consumption.

May 12, 2014

Helping maximize energy management and efficiency, STARLINE Critical Power Monitor (CPM) keeps track of power usage and distribution in data center environment. Revenue-grade device drills down to provide critical energy usage statistics which may be analyzed and acted upon. Accommodating up to 6 current inputs, CPM accelerates provisioning and implementation via Web interface and offers wired Ethernet and Modbus connectivity options as standard; 802.11n Wi-Fi is optional. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Communication Systems & Equipment

Power Quality Meter supports low-voltage power supply option.

May 5, 2014

Nexus® 1500 power quality monitor can be used with low-voltage power supply option that is UL rated at 18–60 Vdc to support 24–48 Vdc systems. This option lets meter be used in applications where it needs to remain on in order to record power quality events when AC mains voltage becomes unstable. In addition to 10 MHz resolution transient capture for waveform recording, standard features include one GB storage memory, color touchscreen UI, and multiple communication ports. Read More

Test & Measuring Instruments, Controls & Controllers, Communication Systems & Equipment, Green & Clean

Industrial Control Panel monitors solar systems.

March 4, 2014

Providing data acquisition for commercial and utility-scale solar PV installations, LGate 360 combines revenue-grade power meter and Modbus-enabled datalogger pre-wired in outdoor-rated metal enclosure. Unit includes integrated RS-485 surge suppression and power supply that accommodates all 3-phase configurations. Together with web-based SolarOS™ monitoring platform, LGate 360 enables plants to gather data for troubleshooting, asset optimization, and performance guarantee/billing functions. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Communication Systems & Equipment

USB Power Sensors offer frequency range to 67 GHz.

January 31, 2014

Offering measurement speed of 900 readings/sec, U8480 Series USB Thermocouple Power Sensors feature power linearity of less than 0.8%. Real-time measurement uncertainty feature cuts overall test time by eliminating need for manual measurement uncertainty calculations. By correcting mismatch errors caused by inserted components between device-under-test and power sensor, S-parameter and gamma correction functions further optimize measurement accuracy. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Communication Systems & Equipment, Electronic Components & Devices

Waveguide Power Sensor provides E-band power measurements.

January 29, 2014

Designed with WR-12 flange connector, E8486A Waveguide Power Sensor makes precise power measurements in E-band spectrum of 60–90 GHz. Unit comes with 80 dB dynamic range option, allowing sensor to measure from -60 to +20 dBm instead of standard -30 to +20 dBm range. To facilitate calibration, sensor incorporates 50 MHz calibration port, eliminating uncertainties due to temperature changes and variance in making measurements with different meter and sensor combinations. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Power Monitors measure 3 phases of current and voltage.

January 8, 2014

Powered from external supply for measurement accuracy, APN Series computes 14 values necessary to track power usage in RS485 Modbus RTU format, which is compatible with many PLCs. Digital units can be configured to accept standard 5 A current transformer inputs or sensors producing 333 mVac proportional to AC current of circuit, or they can use factory matched Rogowski coil inputs. Primary circuit voltage is connected directly to monitor for 600 Vac or lower. Read More

Test & Measuring Instruments, Software, Sensors, Monitors & Transducers

Branch Circuit Monitoring System optimizes data centers.

November 27, 2013

Combining hardware, software, and services, BCM Solution can be retrofitted into existing panels or pre-integrated into select panels and shipped as complete solution. Hardware includes modular collector strips, removable split-core current transducers, and in-panel aggregator. With secure, cloud-based monitoring and analytics offering, operator can analyze and trend collected data to identify potential problems, locate stranded power, or identify owners of circuits requiring increased capacity. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Communication Systems & Equipment, Green & Clean

Handheld Solar Power Meter facilitates in-field measurements.

November 27, 2013

Facilitating process of taking measurements while in field, M140 Mini Solar Power Meter has 1,999 W/m² range, and 0.1 W/m² resolution, and typical accuracy within ±10 W/m² or ±5% (whichever is greater in sunlight). This 5.3 x 1.9 x 0.2 in. meter, powered by 2 AAA batteries, can relay readings in W/m² or BTU/(ft².h) via its integrated 3 ¾-digit display. Functions include Data Hold, Max/Ave/Min Hold, and Zero Adjustment. Auto power off and disable function are also standard. Read More
