Rittal Corporation
Springfield, OH 45504
Nov 19, 2007 Housing sensitive networking equipment in plant floor environments, enclosures can be individually configured to suit specific requirements with range of accessories. They are available in carbon steel wallmount and freestanding designs to promote manufacturing environment networking efficiency and security monitoring capabilities. Available products include RiLAN junction boxes and RiLAN bus enclosures, each of which is offered in various versions.

Dotworkz Systems, Inc.
San Diego, CA 92110
Nov 19, 2007 Model D2-XC is equipped with Ring of Fire(TM) heating system, which provides constant warm airflow and built-in defrosting. Compatible with most analog and PTZ surveillance cameras, enclosure offers on-board mounting space that accommodates routers, cell networks, hard drives, UPS, WiMAX, and Mesh hardware. Rapid Link(TM) allows integration into 900, 5.8, and 2.4 GHz wireless networks worldwide with range of up to 20 miles.

InduSoft
Hilton Head Island, SC 29928
Nov 12, 2007 RealTime Performance Management enables manufacturing and process plants to gather real-time data from PLCs, PCs, DCSes, and historians, as well as ERP programs, MES, and WRP software. It also enables definition of KPIs, which can be displayed and analyzed in real-time or in historic reports. System employs PC server that runs on InduSoft Web Studio-based application and allows access to performance data/analyses via plant intranet, wireless mobile device, or over Internet.

Durham Manufacturing Company, The
Durham, CT 06422-2108
Nov 06, 2007 Workbenches are manufactured with ¼ in. steel plate top welded to 3 in. C channel frame mounted on 3 x 3 x 3/16 in. angle iron legs. They include 12 ga, 29½ in. deep shelf positioned 10 in. above floor for storage space as well as stability. Offered in 3 models, units are 36 in. deep by 34 in. high in widths of 48, 60, and 72 in. and are also available with optional drawer that attaches to underside of work surface.

Aries Electronics, Inc.
Bristol, PA 19007-6810
Nov 01, 2007 Constructed of black UL 94V-0 glass filled 4/6 Nylon, Series 680 programmable headers and covers are available with either plain (solid) or top-slot press-on covers. They feature 3/4 hard brass alloy pins, as well as tin pin plating, and offer 50-150 m minimum matte tin per ASTM B545-97 over 50 m nickel plating per SAE-AMS-QQ-N-290. With current rating of 1 A, units have operating temperature of 221°F. Products can be mounted in PCB hole size of 0.032 ± 0.002 in. in dia.

IAC Industries
Brea, CA 92821 2926
Oct 25, 2007 Dimension 4 workstations are available with optional Power Distribution System, which lets user swap duplex outlet modules on-the-fly to provide access to one of 3 separate 20 A circuits. Up to 6 separate duplex receptacle module locations are provided on single Dimension 4 upright. Users exchange numbered duplex receptacles to access separate power circuits. Modular workstations can be assembled as standalone unit or strung together to form any type of cellular work area required.

Superior Manufacturing Group
Chicago, IL 60638
Oct 24, 2007 Sorb Stance(TM) features raised footing system on underside of mat that provides cushioning comfort and aeration. Available in 3 x 5 ft stock size, Eco Stance(TM) light-weight, single work station mat features molded bubble pattern on surface. Both accommodate 30 in. wide sorbent pad and include recessed top surface, molded pins on surface to grip pad, and molded beveled borders. They are designed for environments where pooling liquids create safety hazards.

Pro-Line
Haverhill, MA 01835
Oct 24, 2007 Adjustable over 12 in. vertical range from 30-42 in., Heavy Duty Ergo-Line (ELH) series lets operators of all sizes and physical characteristics change work surface height at will. Standard actuation is via manual hand crank that can be mounted on front of left or right leg, but optional electric hydraulic pushbutton actuation is available. Work surface choices include plastic laminate, ESD, or solid maple, and optional work surface tilting feature is available.

Emerson Process Management, Rosemount Div.
Chanhassen, MN 55317
Oct 23, 2007 Rosemount 702 wireless discrete transmitter allows access to data on plant performance and safety and is fully compatible with existing smart wireless networks. Applications include level and environmental spill prevention, personnel safety, and plant equipment status. It is an extension of PlantWeb® digital plant architecture and supports variety of non-powered switch types, with single- or dual-channel capacity, and is hazardous area-approved.

Advantech Automation Corp.
Cincinnati, OH 45240
Oct 18, 2007 Featuring 4 status LEDs, IPC-630 supports PICMG 1.0/1.3 backplanes of up to 15 slots and ATX motherboards. This 4U rack-mount chassis offers front access to removable fans, including filters made of washable nylon material. Behind lockable front door, unit provides access to I/O port connectors and disk drives. Shock-mounted, removable disk drive carrier provides three 5.25 in. and one 3.5 in. drive bays as well as one 3.5 in. internal drive bay.

Aitech Defense Systems Inc.
Chatsworth, CA 91311
Oct 18, 2007 Lightweight E192 2-slot 3U cPCI enclosure incorporates modular and removable power supply and houses standard ANSI/IEEE 30.1-2002 conduction-cooled cPCI and PMC modules. Baseplate allows dissipation of over 50 W at 160°F while maintaining 25.2°F difference at card edge. It also features 28 Vdc power input per MIL-STD-704 with EMI/EMC-compliant power input filter and backplane I/O transition module to support front panels designed for circular MIL-C-38999 or other connectors.

Continental Access
Amityville, NY 11701
Oct 17, 2007 With ability to support all access control functions for 1 or 2 doors, Super-Two distributed processor-based controller operates as standalone unit when server communications are interrupted. It features 8 supervised inputs (expandable to 56) and 5 Form C rated 3 A at 24 Vdc/Vac standard outputs (expandable to 53). Controller accepts standard Wiegand output devices as well as all card/reader technologies including proximity, smartcard, biometric, magnetic stripe, and barcode.

ALECO
Muscle Shoals, AL 35661
Oct 10, 2007 Suited for building entryways in foodservice and processing facilities, JetStream(TM) Air Curtain provides invisible barrier of air that protects entrances from contaminants, stops wind, and reduces infiltration of outside air into heated/air conditioned areas. Energy saving product offers precise, continual, and uniform air distribution with adjustable air velocity through directional plenum.

Supermicro Computer, Inc.
San Jose, CA 95131
Oct 04, 2007 Powered by C2SBX, SuperWorkstation 5035B-T features 465 W power supply for operation at less than 43 dB. Designed for optimal graphics and memory performance in uni-processor platform, C2SBX supports 2 PCI-Express x16 and 2 PCI-X 133/100 expansion slots, DDR3 1,333 MHz memory, and connectivity for digital media. Its 1.5 V DDR3 memory modules provides data transfers up to 1.6 Gbps, and I/O bandwidth is rated to 5 Gbps. Other features include 2 IEEE 1394 headers and HD 7.1 audio.

SourceLabs Inc.
Seattle, WA 98104
Oct 02, 2007 Continuous Support System (CS2) lets users proactively monitor and diagnose system faults, crashes, defects, and other key events in mission-critical systems as well as across large, distributed environments. Use of diagnostic probes and intelligent algorithms running against repository of 10+ million data points delivers complete knowledge base available about individual open source projects as well as interoperability issues between open source technologies.

Flexible Panels International
Sarasota, FL 34243
Oct 02, 2007 While offering appearance of ordinary tambour, Savio flexible panels utilize unitized construction capable of carrying any type of surface material - woodprint, metallic, vinyl, fabric - without lines, seams, or cracks. Panels come in straight-topped or slanting design and can be used as freestanding partitions or linked together to define spaces of any size. Each panel can flow into arches/curves, and any number of panels can be linked together without screws or other assembly parts.

Acme Portable Machines, Inc.
Azusa, CA 91702
Sep 28, 2007 Based on 2.13 GHz Intel Core 2 Duo E6400 processor backed by 2 GB RAM, Model AFS-370 is capable of capturing evidence from off-site SCSI, IDE, and SATA drives. Gigabyte Ethernet, USB 2.0, and Firewire are incorporated to speed communications, while 17 in. LCD displays status and results. Using 3 independently operating write-blocked Tableau bridges to inspect 3 subject drives at once, workstation outputs data and images to triple 500 GB hot-swappable SATA drives.

ALECO
Muscle Shoals, AL 35661
Sep 26, 2007 JetStream(TM) Air Curtain provides invisible barrier of air that protects entrances from contaminants, stops wind, and reduces infiltration of outside air into heated or air-conditioned areas. Requiring 8½ in. clearance, device is available in widths from 36-60 in. and features corrosion-resistant cabinet with baked enamel beige or SS finish. Units are UL approved with pre-wired 5 ft 110 V grounded plug and installation bracket.

Flexible Montisa
Plainwell, MI 49080
Sep 24, 2007 Available as fixed or mobile unit, Heavy Duty Adjustable Bench features 12 gauge legs and 14 gauge stringers. Top options include 2¼ in. maple, 1¼ in. stainless steel 16 gauge Cap-top, and solid 3/8 in. steel. Available with optional 5 in. casters, bench is suited for industrial applications, maintenance departments, diagnostic centers, and prototype specialists.

New Pig Corporation
Tipton, PA 16684 0304
Sep 19, 2007 Available in yellow or brown, Lightpole Base Cover camouflages lightpole bases in parking lots, industrial and commercial facilities, indoors or out. UV-resistant polyethylene cover does not rust, fade, or corrode, and is not affected by cart bumps and minor vehicle impact. Offered as cap and base set or as individual cap, it consists of domed top and set of panels to cover rounded bottom.
