MG America
Fairfield, NJ 07004
Oct 06, 2008 Operated with PC-based control, GTL30 case packer incorporates servo-motors for main machine movements. It features operator touchscreen interface, balcony design for ease of cleaning and maintenance, and requires no change of parts for different case sizes. Pre-arranged for integration to supervisory control systems, unit delivers case erection from loading to machine discharge.

R.A. Jones & Co. Inc.
Covington, KY 41017
Sep 29, 2008 Available in right and left hand configurations, Meridian IM Cartoners feature 9 or 12 in. centers with speeds of 53 and 45 cpm, respectively. Carton sizes range from 4-8 in. x ½-6 in. x 4.5-12 in. with 9 in. center machine, and 4-11 in. x ½-6 in. x 4.5-12 in. with 12 in. center model. Standard features include Allen Bradley ControlLogix controls and Kinetix drives, color touch-screen HMI, servo-driven flap closers, Nordson Pro-Blue 7 hot melt glue system, and straight-in bucket conveyor.

Orwak USA LLC
Shelton, CT 06484
Aug 20, 2008 Featuring twin chamber design, Orwak 5040 employs dual-phase PET bottle compaction involving perforating needles. Compaction ratio for PET bottles is up to 10:1, and one bale of PET contains 350-500 bottles. Machine also makes stackable compact bales of aluminum cans, without any tying needed to keep bales together. One bale of 35 cl cans contains ~650 cans, and compaction ratio is 6:1. Compactor produces 400 x 400 mm bales, adjustable from 350-550 mm in height, that weigh 10-14 kg.

Specialty Equipment
Houston, TX 77055
Jul 07, 2008 Designed for 5-500 gal containers, sub-surface filling machine allows the filling lance to penetrate within 3 in. of bottom of 81 in. tall IBC. It also has retractable bellows for drawing away toxic fumes. Including NTEP approved digital weight meter, 10,000 lb capacity scale base with 4 load cells, and microprocessor controller, filler uses 2 hydraulic cylinders to raise/lower the boom and lance carriage from drum height to IBC height to within 1 in. clearance above container.

Flexicon Corporation
Bethlehem, PA 18020 8006
Jun 24, 2008 Equipped with Spout-Lock® clamp ring and Power-Cincher® flow control valve, Model BFC-F-X eliminates dust during untying, discharging, retying, collapse, and removal of bags while allowing thorough washdown. Flow-Flexer® raises and lowers opposite bottom sides of bag into steep V shape, and Tele-Tube® telescoping tube maintains downward tension on bag as it empties. Cantilevered I-beam with electric hoist and trolley allows raising and positioning of bulk bags without forklift.

Thiele Technologies, Inc.
Minneapolis, MN 55418
May 07, 2008 Available in single-spout OmniStar or dual-spout UltraStar system, Star Series bag filling system combines all filling operations for poly and paper bags including bag setup, filling, weighing, and sealing into single system. It precisely controls bag position through independent, servodriven upper and lower drive systems, and servo speed controls are accessed and adjusted via 12 in. PanelView(TM) HMI screen. Unit has maintenance reminder alert system and fault history log.

Douglas Machine
Alexandria, MN 56308 3399
Apr 30, 2008 Featuring walk-in frame construction for maximum accessibility, Continuous Motion Axiom® DL Case/Tray Packers gently load products onto case or tray blank at speeds to 55 cases/trays per minute. Electronic motion controls ensure repeatable changeovers, while Slipstream(TM) pinless metering eliminates traditional metering pins. Smartrak® Steady Stream Infeed prevents product bridging and removes gaps that compromise pack pattern accuracy and continuous product flow.

Schneider Packaging Equipment Co., Inc.
Brewerton, NY 13029 0890
Apr 22, 2008 Able to accumulate, erect, pack, and seal, VCP-20 is suited for lower rate applications up to 20 cases/min. It uses servo-controlled motion for smooth handling and can be designed to pack cases from 7-24 in. long and 4-18 in. wide. As conveyed product reaches bottom load case packer, servo mechanism pushes product from conveyor to construct pack pattern that is loaded into waiting case. Simultaneously, packer selects and erects cases and then folds and seals flaps.

3M Company / Packaging Systems Division
St. Paul, MN 55144
Mar 11, 2008 Suited for operations currently taping boxes by hand, 3M-Matic(TM) a70 features 4-belt drive for optimal traction and consistent sealing of uniformly sized RSCs. Unit includes 3M(TM) AccuGlide(TM) Taping Head 2+ for low-impact application of tape from 36-48 mm wide. Machine handles carton sizes from 6-21.5 in. wide, 4.75-21.5 in. high, and up to 65 lb.

Key Technology Corp.
Mukilteo, WA 98275
Feb 15, 2008 Featuring semi-automatic, push-button operation, AV Sealer heat-seals various bag sizes with or without vacuum and has optional gas flush cycle. Adjustable user programs set vacuum pressure, gas flush, heat sealing temperature, and seal time. Able to be switched over to handle different products and bag sizes in seconds without tools, changeparts, or mechanical adjustments, PLC-controlled unit has open design, weighs 73 lb, and is constructed of stainless steel and anodized aluminum.

Novatec EAP
Montauban   France
Dec 10, 2007 With working area up to 330 x 330 mm, Tabletop VacuNest is suited for printing, dispensing, and placement machines. It provides secure, cushioned support that removes risk of damage due to point force pressures. Each VacuNest module consists of pliable, anti-static chamber containing foam former surrounded by polymer granules. Within 30 sec, chamber can be profiled to shape of work piece assembly or enclosure. Under vacuum, profile can be retained indefinitely.

A-B-C Packaging Machine Corp.
Tarpon Springs, FL 34689 4137
Dec 06, 2007 Built with independent sealing modules for tape and hot melt adhesive application, Model 436 top case sealer can handle up to 50 cases/minute. Measuring 10 ft long, it features stainless steel frame, welded/bolted construction, and roller compression wheels. Pacer belt infeed accepts cases spaced or back to back and times them at correct intervals into sealer, while cast aluminum flap folders gently close outer flaps to form square cases.

Douglas Machine
Alexandria, MN 56308 3399
Dec 03, 2007 Operating at rates to 25 cases/trays per minute, Invex® can handle range of products due to integrated servo controls that promote smooth, quiet operation while minimizing maintenance time and jams. Controls also promote recipe-driven changeover and startup efficiency. Operator/technician can pinpoint root cause of problems through HMI, while OMAC Packaging Guidelines standards-based connectivity and IEC conforming software structure make this machine PackML- and PackTags-ready.

Cermex Inc.
Norcross, GA 30071
Nov 30, 2007 Measuring 8 ½ x 6 ½ ft with optional labeling system, Model SW can erect, load, and seal cases. Unit features stainless steel frame, ergonomic corrugated magazine with 34 in. infeed level, and collating systems adapted to nature, shape, and rigidity of product. Depending on products, side-loading machine can process up to 18 cases/min. AB Compact Logix and PV 1000+ colored touch screen are standard and can interface with plant management systems.

Standard-Knapp, Inc.
Portland, CT 06480
Nov 21, 2007 Designed to handle range of tablock case types, Slitter/Sealer features continuous motion design suitable for food and beverage industries. Pitch adjustment employs servo motors and variable drive controls to ensure precise timing and eliminate operator error, while infeed design provides positive product timing. Able to achieve speeds of more than 100 cases/min, machine features stainless steel rust-proof frame and ergonomically designed touch screen control panel.

3M Adhesives & Tapes Div.
St. Paul, MN 55144 1000
Nov 20, 2007 Featuring 4 belts for positive traction and pneumatic station to keep cases centered, 3M-Matic(TM) Random Case Sealer r70 automatically adjusts to width (6-21.5 in.) and height (4.75-21.5 in.) of carton. It seals up to 15 different case sizes per minute and is equipped with 3M(TM) AccuGlide(TM) Taping Head 2+, which provides low-impact sealing that protects cases. Machine is designed for use with full range of 36-48 mm Scotch® Box Sealing Tapes.

3M Industrial Tape & Specialties Div.
St. Paul, MN 55144 1000
Nov 01, 2007 Compatible with full range of 36-48 mm Scotch® box sealing tapes for top and bottom sealing of RSCs, 3M-Matic(TM) Adjustable Case Sealer a20 can seal up to 30 uniformly-sized RSCs per minute. Case sealer features adjustable bottom belt drive and dual masts for taping head stability. It handles carton sizes from 6-21.5 in. wide and 4.75-21.5 in. high, and up to 65 lb. Unit features 3M(TM) AccuGlide Taping Head 2+ that provides low-impact sealing to protect cases.

Standard-Knapp, Inc.
Portland, CT 06480
Sep 14, 2007 Designed for packing carbonated, non-carbonated, and hot filled PET bottles into corrugated trays or plastic shells, Model 396 Positron(TM) Case Packer is equipped with Overhead Flight Grouper that provides accurate, positive product control. Continuous motion ensures gentle product handling, while PLC-controlled variable frequency drives automatically adjust to changing line speeds. Powered by two 1 hp motors, unit features stainless steel frame, shafts, and hardware.

Automation R & D
Darlington, SC 29540
Sep 07, 2007 Constructed with rigid steel frame, SS-10 utilizes computer control and employs 10 hp, 3-phase motor. System features automatic cycle along with interlocking door, indicator lights, as well as pushbutton controls for Up, Down, and key lock E-Stop functions. Use of 6 in. hydraulic cylinder, with 56,500 lb platen force, applies 2,000 psi to load in order to create 700-1,000 lb, 60 x 30 in. bales with adjustable heights to 48 in.

Douglas Machine
Alexandria, MN 56308 3399
Aug 13, 2007 Using electronic motion controls, Axiom® BCL case/tray packers operate at speeds up to 80 cases/trays per minute. Walk-in frame design allows operators to effectively complete changeovers and preventive maintenance, and full-length polycarbonate guard doors facilitate troubleshooting. Electronic handwheel provides slow motion hand cycling of machine when troubleshooting or when fine tuning, and tool-free changeovers can be completed in minutes.
