Vishay Intertechnology, Inc.
Malvern, PA 19355 2143
Sep 01, 2009 Supplied in 4 x 4 mm DFN package with 0.65 mm pitch and 1 mm profile, precision thin film SMT resistor networks and dividers offer ratio tolerances to ±0.05% and stable film and performance characteristics of 500 ppm at +70°C for 2,000 hr. Respective TCR tracking is ±3 ppm and ±5 ppm, and power rating is 50 mW at +70°C per resistor. While DFN resistor networks offer resistance from 100 W to 100 kW per element, dividers feature resistance from 1-100 kW with ratios from 2:1 to 100:1.

AVX Corp.
Myrtle Beach, SC 29578
Aug 31, 2009 Including 15 and 33 pF capacitance devices with 5.6 V rating in 0201 case size, miniature Transguard 0201 bi-directional transient voltage suppressor offers designers ability to clamp transients and filter EMI in one compact device. It features sub 1 nsec response time to ESD strike, has leakage current of less than 5 µA at rated voltage, and is able to withstand 1,000 strikes at 8 kV of contact.

Altera Corporation
San Jose, CA 95134
Aug 19, 2009 Offering complete system of pre-verified components and supporting hardware reference designs, Arria® II GX FPGA Development Kit provides hardware and software resources needed to evaluate and adopt Arria II GX 40 nm FPGAs. Entire PCIe Gen1 end-point design package features PCI-SIG-compliant Arria II GX FPGA-based development board with embedded PCIe Gen1 hard IP core. Users also get one-year license for Quartus® II Design Software and access to MegaCore® IP library.

Altera Corporation
San Jose, CA 95134
Aug 18, 2009 Targeting power- and board space-sensitive applications, Altera® Cyclone® III LS FPGAs are rated at less than 0.25 W of static power for 200 K logic elements. Information-assurance design suite offers anti-tamper, design-security, and design-separation capabilities. To protect highly sensitive information, anti-tamper features include JTAG port protection, tamper monitoring, and cyclical redundancy check. FPGAs also have AES 256-bit encryption key for design security.

Altera Corporation
San Jose, CA 95134
Aug 18, 2009 Featuring up to 48 transceivers (11.3 Gbps) and 530K logic elements, Stratix® IV GT EP4S40G5 and EP4S100G5 support range of 40G/100G technologies. Single-chip solutions' transceivers can interface directly to CFP optical module and meet emerging IEEE 802.3ba standard for 100G MACs. Supporting various protocols and standards, FPGAs offer density and bandwidth that help incorporate traffic management, packet processing, and custom functionality into one device.

Lattice Semiconductor Corp.
Hillsboro, OR 97124
Aug 18, 2009 Available in 0.8 mm pitch, 14 x 14 mm, 256-pin Chip-Array BGA package with up to 211 user I/O, Mach XO640, XO1200, and XO2280 enable implementation of board space-constrained designs. Units include embedded memory, built-in PLLs, multi-voltage I/O, remote field upgrade technology, and low-power sleep mode. PLDs are suited for general purpose I/O expansion, control, bus bridging, and power-up management functions in wide range of low-density applications.

Xilinx, Inc.
San Jose, CA 95124 3400
Aug 18, 2009 Virtex®-5Q FPGAs leverage ASMBL(TM) architecture and underlying programmable technologies to optimize speed, capacity, and power consumption. Cryptographic capabilities are included along with inherent re-programmability and SCC technology, while ruggedized packaging across board provides redundant protection against tin-whiskering and support for military assembly processes. Defense-grade devices include 4 domain-specific FPGA families.

Xilinx, Inc.
San Jose, CA 95124 3400
Aug 18, 2009 Designed to help shorten development cycles, Xilinx Base Targeted Design Platform Kits combine v11.2 release of ISE® Design Suite, IP, and pre-verified reference designs targeting Virtex-6 or Spartan-6 FPGAs. Reference designs outline best practices for integrating custom elements into base design and implementing features such as DDR2 and DDR3 memory interfaces, high-speed serial I/O, and on-chip clocking resources. Board schematics and layout files further streamline design process.

Curtiss-Wright Controls Embedded Computing
Leesburg, VA K2V1A6
Aug 13, 2009 Suited for signal and image processing applications including radar, sonar, and signal intelligence, Model VPX3-450 combines Xilinx Virtex-5 FPGA node, 1 GHz dual-core Freescale 8640D processor node, and on-board PCI Express switch. Device includes sensors for monitoring board temperatures and FPGA power consumption, multi-board synchronous clock, and support for ChipScope Pro and JTAG processor debug interfaces. With compact 3U form factor, VPX3-450 is suited for UAVs and land vehicles.

Curtiss-Wright Controls Embedded Computing
Leesburg, VA 20175
Aug 12, 2009 Model XMC-FPGA05F FPGA XMC/PMC module incorporates Xilinx® Virtex®-5 FPGA with 4 front panel, single or multimode fiber-optic transceivers supporting speeds including 2.0, 2.125, 2.5, and 3.125 Gbps. Data flow is handled by IP core for protocols such as Aurora(TM) or Serial FPDP. Unit includes 4 banks of 128 MB DDR2 SDRAM memory, with bandwidth near 1 Gpbs; DMA controllers; and onboard Flash. Air- or conduction-cooled versions are available.

Xilinx, Inc.
San Jose, CA 95124 3400
Jul 08, 2009 Xilinx Base Targeted Design Platform combines v11.2 release of ISE® Design Suite, expanded IP portfolio, and pre-verified reference designs targeting Virtex-6 or Spartan-6 FPGAs within fully integrated evaluation kits. By utilizing key system functions that have been pre-validated to work together in base platform, designers can expedite development time. Reference designs guide designers on best practices for integrating custom elements into base design and implementing advanced features.

Aeroflex / Metelics, Inc.
Sunnyvale, CA 94085
Jun 12, 2009 Offered in asymmetrical and symmetrical SP2T topologies, MSW2000 switches incorporate high voltage PIN diodes and passive devices within ceramic substrate. They function in 2 frequency bands; 20-700 and 400-4000 MHz, and are available in compact surface mount packages measuring 8 x 5 x 2.5 mm. Capable of operating at +5, +28, and +50 Vdc power, units are suited for use in high power switch applications up to 4 GHz, and applications requiring high volume, solder re-flow manufacturing.

Digital Monitoring Products
Springfield, MO 65803
Jun 02, 2009 DMP SCS-1R receivers are available with SCS-150 Main Processor Card, which contains firmware for system operation, provides all time-keeping functions, and controls line cards, keypad, and printer. Featuring 5,000-event memory, card supports panel programming via receiver line cards using auxiliary port as well as receiver system setup programming via SCS-1R keyboard/display and Remote Link(TM) via auxiliary port. Also, receiver software is updatable using SD card.

IRC, Advanced Film Div.
Corpus Christi, TX 78411
May 28, 2009 Suiting spaced-constrained applications, DIV23 Series voltage divider in SOT23 package measures 0.1125 x 0.051 in. with board-mounted profile of 0.0305 in. It incorporates self-passivating TaNFilm® on silicon technology which does not dissolve when exposed to moisture and voltage. Operating in temperatures from -55 to +125°C, unit has rated operating voltage of 100 V and element power rating of 100 mW at 70°C with package power rating of 1.0 W at 70°C.

PRIME ELECTRONICS
GANDHINAGAR 382024  India
May 22, 2009 Measuring 145 x 250 x 250 mm, 600 W Model EL 601 features voltage range of 2-60 Vdc and current range of 0-120 A. Multi-turn pot enables user to set load, while DPM meter provides continuous display of load voltage and current or power on front panel. With built-in over load, over voltage, and over temperature protection, as well as reserve input, portable electronic load is suited for testing switching power supplies, SMPS units, DC power plants, DC-DC converters, and solar charges.

AdvancedIO Systems, Inc.
British Columbia V6C 2T5  Canada
May 20, 2009 Offering all tools needed to embed applications directly into 10 GbE interfaces, expressXG(TM) accelerates ability to tackle system communication problems. It provides framework of FPGA firmware and host software that abstracts details of Ethernet protocols and interfaces to reduce development effort and schedule for designers to implement their own custom algorithms. Also, removal of hardware dependencies enables future code portability.

DuPont
Research Triangle Park, NC 27709-4425
May 20, 2009 DuPont(TM) PV5300 Series and DuPont(TM) PV5200 Series can protect solar cells. DuPont(TM) PV5300 Series sheets can be used for new module designs like building-integrated photovoltaic tiles for installation on building roofs. Based on polyvinyl butyral polymer technology, DuPont(TM) PV5200 Series sheets suit needs of thin-film solar power generation.

BI Technologies Corp.
Fullerton, CA 92835-1051
May 15, 2009 Housed in surface mount SON packages, SFN Series comes in custom, isolated, bussed, and voltage divider circuit configurations. Units are offered in 6-pad, 2 mm² outline with 0.65 mm pad pitch as well as 8-pad, 4 mm² outline with 0.8 mm pad pitch. Available with 2, 4, or 7 resistors, standard networks feature nominal resistance ranges from 10 W to 100 KW with absolute tolerance to ±0.25% and ratio tolerance to ±0.05%.

Advanced Analogic Technologies Inc.
Sunnyvale, CA 94085
Apr 28, 2009 Driving up to 8 backlight LEDs at up to 30 mA each, AAT2862 utilizes 1 MHz trimode charge pump that automatically switches between 1, 1.5, and 2x modes to maximize operating efficiency. It includes 4 LDOs as well as 8 LED outputs programmable from 500 µA up to 30 mA, 2 outputs which can be set up to 60 mA each. Operating from 2.7-5.5 V input voltage, unit includes automatic fade-in/out backlight control and allows current to be set to any of 32 levels via I²C interface.

Fairchild Semiconductor
San Jose, CA 95134
Apr 28, 2009 Suited for designers of telecom, server, set-top box, and other consumer applications, synchronous RD278 features FAN21SV06, single supply, highly integrated 6 A buck solution that can be configured to work as either master or slave. Buck solution combines controller, driver, and optimized power MOSFETs in compact 5 x 6 mm MLP package and has wide operating range of 6.5-24 V. Regulator can be enabled separately, allowing for power-sequencing in point of load (POL) applications.
