Actuators

Linear Ceramic Actuators feature vacuum compatible design.

With no lubricants, millisecond responsiveness, and non-magnetic design, Ceramic Piezo Motors and Nanopositioning Actuators replace classical actuator and motion control components in precision motion control applications. For travel ranges less than 1 mm, PiezoMove® flexure actuators are recommended. PILine® ultrasonic stepping actuators provide speeds to 800 mm/sec, while...

Read More »
Machining

Quadrant EPP Broadens Torlon® PAI Product Lineup

More Sizes and More Shapes of Torlon® PAI Machining Stock Now Available from Quadrant (Reading, PA, March 11, 2008) - Engineers and designers will have more options for new or upgraded part designs with Quadrant's expanded range of Torlon® PAI shapes. Torlon is an ideal material for applications where extreme strength, stiffness, stability and wear-resistance are required. It is far...

Read More »
Linear Stepper Motor features 1 micron resolution.
Motors

Linear Stepper Motor features 1 micron resolution.

Capable of 5 lb continuous force, 5 lb Linear Stepper travels at 80 ips, can operate in any axis, and features 1 G acceleration. Two-phase, single-axis motor is capable of precise position, velocity, and acceleration control when integrated with microstepping drive and indexer; resolutions are .010 in. for full step and .00004 in. for one microstep. While suited for open loop positioning...

Read More »
Servo Motor provides 100 W continuous mechanical power.
Motors

Servo Motor provides 100 W continuous mechanical power.

Operating at 2,000 rpm, NEMA 34 Model QCI-A34L-1 requires only 4.5 A, which means single cable can be used for both motor and encoder signals. Motor delivers 185 oz-in. continuous torque and 260 oz-in. peak torque. Ability to handle inertial mismatches of 100:1 makes motor suited for driving large flywheel loads without additional gearing.

Read More »
Calibrators

Server minimizes multi-projector display alignment time.

Camera-based solution, Sol(TM) Server 1.2, automatically corrects geometric distortion, intensity, and color variation that result from using multiple overlapping projectors. It works with flat, n-gons, cylindrical, or spherical displays and features robotic pan-tilt option that, when attached, provides support for multiple camera vantage points. Along with soft-edge and localized blending...

Read More »
Custom Fiber Air Shafts for Custom Converting Machinery
Shafts

Custom Fiber Air Shafts for Custom Converting Machinery

Where can an OEM of custom converting machinery go for lightweight air shafts that meet the challenges of handling extra-long, extra-heavy rolls? That's exactly the situation that led Premier Paper Converting Machinery to tap the custom carbon fiber winding capabilities of NimCor, Inc., a nationally known producer of both conventional and carbon fiber air shafts. Premier Paper Converting...

Read More »
Marathon Mounted Bearing Units
Bearings

Marathon Mounted Bearing Units

'SEALED FOR CERTAIN': OFFER DUAL-SEALING PROTECTION AGAINST CONTAMINANTS Marathon® mounted bearing units integrate a patented stainless steel dual-sealing system designed to protect against contaminants, resist corrosion, and extend service life. These bearing units are among the growing family of MRC® solutions engineered to withstand typically harsh conditions in the food processing and...

Read More »
Motors

DC Motor includes integrated Hall sensor.

Providing starting torque of 50 Nm, Series 319 features IP55 watertight rating and aluminum gear box. Using Hall sensor, motor is capable of detecting speed, position, and rotation, and issues data by means of independent digital outputs. Sensor provides 3 output channels and accurate position measuring due to 12 pulses/rev of motor.

Read More »
Motors

Brush Motor delivers 400 W of power from compact package.

Suited for hand-held and battery-powered devices and machines, TGB2013 utilizes ironless-core motor technology, measures 2.0 in. dia x 3.87 in. long, and weighs 34 oz. It delivers 400 W (0.5 hp) of continuous shaft power with max efficiency of 86%. At 18 V, motor runs at 13,400 rpm, producing 40 oz-in. of torque while drawing 26 A. Linearity between torque and current allows peak torque of 240...

Read More »
Linear Actuators come in 115 and 230 Vac models.
Actuators

Linear Actuators come in 115 and 230 Vac models.

With 100-600 mm stroke length, Jaeger® SJ Series electromechanical linear actuators provide repetitive-motion solutions for ac-powered applications in wide range of motion-driven equipment/devices. UL approved units feature motors offering thermal protection up to 120Â-º, integrated limit switches, Acme screw, and metal gearbox. They are available in 3 standard types with capability to...

Read More »
Triad's JSU Series of Power Supplies Provide Robust, Low Cost Solutions
Sponsored

Triad's JSU Series of Power Supplies Provide Robust, Low Cost Solutions

Triad Magnetics is an established leader in power supply innovation, offering product lines that span a wide range of diverse industries and applications. Adding to their long list of successful product launches, Triad announces the release of the new cutting-edge JSU Series of power supplies. To learn about all of its advantages and advanced features, see our video.

Read More »
