Machining Centers

Machining Centers

Robotic Finishing System accommodates oversized parts.

Able to minimize machining and finishing time for products such as wind blades, aerospace components, and boat hulls, RAPA G3 is designed with double workstation and works over 164 x 49 x 20 ft standard area. Double modular rack and pinion drive system create any X-axis length required, while anthropomorphic KUKA robot can access any wind blade surface point. Featuring 7+1+1 servo-controlled...

Read More »
Multitasking Turn/Mill System has two 24-tool ATC magazines.
Machining Centers

Multitasking Turn/Mill System has two 24-tool ATC magazines.

Occupying 102 ftÂ-² footprint, Super NTMX offers full 5-axis milling capability via Fanuc 31iA5 Control for manufacturing complex contoured components. Front location of ATC Magazines facilitates setup, and inserts can be changed without stopping machine. Machining center employs left and right spindle with speeds up to 5,000 rpm at 15/10 hp. Distance between spindles is 38.58 in., with max...

Read More »
Multi-Axis Manufacturing System handles 1-ton workpieces.
Machining Centers

Multi-Axis Manufacturing System handles 1-ton workpieces.

Comprised of 6-axis robot, pallet storage magazine, and one or two model C 50 U 5-axis machining centers, RS 4 flexible manufacturing system (FMS) can automatically handle loads up to 1,000 kg - including workpiece, fixture, and pallet. It also has integral, +30/-115 degree swiveling trunnion supporting rotary table. Capable of single-digit micron accuracy, FMS employs up to 18,000 rpm spindle...

Read More »
Vertical Machining Centers combine speed and precision.
Machining Centers

Vertical Machining Centers combine speed and precision.

Powered by 15-30 hp spindle motors, metal-cutting DNM series is available in 3 sizes - each as standard or high-speed (DNM HS) versions - and holds 5.40 roundness and Ra 0.12 roughness under adverse conditions. Metal removal rates range from 26.4 in.Â-³/min when face milling SM45C carbon steel to 42.2 in.³ for GC25 gray casting and 109 in.³ for AL6061 aluminum....

Read More »
The Next Wave of Intelligent Design Automation
Sponsored

The Next Wave of Intelligent Design Automation

In the amount of time it takes to set up a meeting to discuss just one design, engineers can now explore designs exponentially. Generative design has catalyzed a paradigm shift in product development. This shift not only drastically decreases the time it takes to design a product. It also opens the door to design options that might never have been imagined by engineers on their own.

Read More »
Hurco Announces Higher Performance at No Extra Cost
Machining Centers

Hurco Announces Higher Performance at No Extra Cost

Hurco has launched a major upgrade of its best-selling, compact-footprint VM range of vertical machining centres. The improvements include adding around 50 mm to the Y and Z axes and providing a 10,000 rpm spindle as standard. Designated VM10, VM20 and VM30, the new models also have a faster, electronic, 20-station swing-arm toolchanger to minimise non-cutting time and further improve...

Read More »
Toyoda's Flexible Pallet Automation Achieves Highest Spindle Utilization
Machining Centers

Toyoda's Flexible Pallet Automation Achieves Highest Spindle Utilization

Arlington Heights, IL - Toyoda Machinery offers modular and expandable automation with its Flexible Pallet Automation (FPA) systems. Toyoda's FPA systems dramatically enhance the production capabilities of horizontal machining centers by automating tasks like machine loading and unloading. The system is easily upgradeable and can be customized to suit any production environment. A single system...

Read More »
CNC Machining/Finishing System offers 5-axis flexibility.
Machining Centers

CNC Machining/Finishing System offers 5-axis flexibility.

With unlimited X-axis range, 40 m/min traverse speed, automatic tool change, and 5 servo-controlled axes, Agile Gantry handles oversized parts as well as parts with complex geometries. CNC machine-tool platform, which uses modular rail system, supports various applications and processes. Gantry cross rail provides 5.5 m Y-axis travel and 2.5 m or more of Z-axis reach. Servo-controlled contouring...

Read More »
CNC Milling/Turning Center produces medical devices.
Machining Centers

CNC Milling/Turning Center produces medical devices.

Designed for continuous production of multiple and different parts from bar stock, 5-axis Model MC 726 MT features 60-position tool magazine and rotating/swiveling trunnion positioning device. Drilling, milling, and turning operations are performed on both vertical and horizontal spindles, all programmed on CNC. Machine provides vertical spindle speeds up to 12,000 rpm, horizontal spindle speeds...

Read More »
HMCs offer productivity-enhancing support package.
Machining Centers

HMCs offer productivity-enhancing support package.

Models HP4000/HP5100 are available with Super-Capacity package, which consists of either of 2 multi-pallet APCs: semi-circular system with 7-pallet capacity or double-tiered linear system with setup station and 12, 24, and 36 pallets. In both, pallets are 15.75 x 15.75 in. and support loads to 880 lb. Addition of tooling magazine with capacities of 116/170/262 tools and hinge, scraper, or drum...

Read More »
5-Axis Waterjet Cutting Head has height/crash sensor option.
Machining Centers

5-Axis Waterjet Cutting Head has height/crash sensor option.

Designed for cutting bevels and weld preps in material, Psy-Winder 5-axis abrasive waterjet cutting head features fixed mechanical tool tip, capacity of 12-24 in. vertical travel on Z axis, and cutting angle from 0° vertical to 90° horizontal. User can install up to 9 cutting heads on one cross beam with single X-Classic controller. Speeds can be up to 2,000 in./min depending on...

Read More »
Triad's JSU Series of Power Supplies Provide Robust, Low Cost Solutions
Sponsored

Triad's JSU Series of Power Supplies Provide Robust, Low Cost Solutions

Triad Magnetics is an established leader in power supply innovation, offering product lines that span a wide range of diverse industries and applications. Adding to their long list of successful product launches, Triad announces the release of the new cutting-edge JSU Series of power supplies. To learn about all of its advantages and advanced features, see our video.

Read More »
