New Machinery & Machining Tools Products

Die Holder fits stacked tooling sets.

Available for any size or brand of rotary bender with stacked tooling for 2 to 3 sets of tools, Model TFB wiper device is easily adjusted to properly fit different radius bend dies. Each wiper die can be adjusted to locate wiper with correct amount of angle in relation to tube or rake. Wiper die support helps prevent tube wrinkling and prolongs life of dies. Automatic lubrication to each wiper is...

Mold Inserts include multi-purpose post.

Master Unit Die (MUD) Enhanced Series Mold Inserts have guide ejection system design, maximizing available insert core and cavity surface area. Guidepost retains and guides ejection system, and provides support without additional support pillars. Inserts are available in popular 08/09 insert thicknesses. They come with 4 leader pins, bushings, and return pins. Parting line plates are...

Primer-Free Threaded Inserts resist galvanic corrosion.

Stainless steel Heli-Coil inserts, manufactured to military and metric aerospace standards, eliminate need for applying zinc chromate primer. Resin-bonded, fluoropolymer coating creates barrier between insert and parent material. Coating also provides additional lubricity, easing installation in anodized and chemically treated holes and allowing for consistent prevailing torque with screw-lock...

Inserts press into plastic without melting.

Series 50 through-hole and Series 51 headed, through-hole press-in brass inserts can be cold pressed into plastic without heat or ultrasonic equipment. Inserts have helical knurl that optimizes plastic migration, providing good pull-out and torque resistance. Inserts can be installed with arbor press or fully automated machine into ABS and polycarbonate plastics. Applications include securing...

Construction Materials for the Future

In this eBook, we highlight some key advantages of Cross-Laminated Timber (CLT) and show why every builder needs to consider adopting this remarkable construction advancement. We'll also introduce you to the latest innovation in CLT, GRIPBlock™, an exciting new technology that will change the way you look at CLT forever.

Tubing Cutter cuts stainless steel.

RIDGID(R) Model 15-SI with E1525 cutter wheel provides clean, accurate cutting of stainless steel tubing. Large knob gives user more control over feedscrew torque, and allows for faster feedscrew advancement. Cutter uses 6 individual bearings that help decrease drag around tubing. Bearings create smooth, fluid cut, reducing number of rotations needed to cut tubing. It cuts tubing from 3/16 to 1...

Laser Processing Systems weld and cut metallic materials.

JK802 and JK1002 Nd:YAG laser systems utilize super modulation technology, which momentarily doubles laser's output intensity up to 2,000 watts. They include fiber system with built-in process detection and intuitive, self-protecting diagnostics. Flashlamps, which are designed for more than 1,000 hours of operation, are modular and can be changed on production floor. Systems are available with...

Linear Slides can be air ported from multiple sides.

Nickel-phosphorus coated, high-strength aluminum-alloy Series FST and FSF enable maximizing payload and moment capacity by mounting bearing rail on moving member and integrating floating coupling with piston shafts. FST twin-piston design lifts loads to 580 N. FSF flat, single-piston design suits minimized space requirements. Bore sizes range from 6 to 25 mm with various adjustable strokes from...

Fiber Winder has alphanumeric display and interface.

Machine transfers fiber to target spool or holder for making erbium doped fiber amplifiers or for re-spooling fiber, wire, tubing or similar materials at speeds to 120 fpm with programmable tension. It measures 35 x 18 x 12 in., weighs 65 lb, and handles spools up to 5 in. high and 12 in. dia. Pinch roller with one-way clutch simplifies process of changing target holders. Interface is used for...

Grinding Wheels are continually sharpened.

CIMFORM(R) MSB has abrasives that micro-fracture during use, creating new grinding surface, and thus constantly sharpening themselves. They are suitable for centerless, center-type, micro-centric, surface, surface/creepfeed, internal, tool manufacturing, and tool cutter applications. MILSPEX(R) educational software tool familiarizes user with grinding technology and processes. DATA PRIME(TM)...

Miter Saw cuts structural steel.

CNC controlled LC-1250 cold saw can process up to 50 in. deep sections when positioned to cut at 90 deg, and sections as deep as 34.8 in. can be cut at 45-deg miter in either direction. Option allows saw to miter up to 60 deg in one direction and 45 deg in opposite direction. Miter angle and blade rate of feed are separate axis and are directed as required by CNC program. Rack and pinion system...
