Machinery & Machining Tools

Angle Head Systems feature onboard braking system.
Machining Heads

Angle Head Systems feature onboard braking system.

Available in Flex 5 and Flex 5 Plus models, Angle Head Systems come with saw blade flange with flush-mount ER25 nut and collet system. Providing 0 to 90 degrees sawing swivel range and 0 to 100 degrees routing swivel range, units use movement of C-axis for changing output angle. Offering rotation speed of 15,000 RPM and 1 to 1 gear ratio, angle heads offer 15 sec tool change output connections...

Read More »
BC40 Presto Black Finishing System produces satin black finishing.
Finishing Equipment

BC40 Presto Black Finishing System produces satin black finishing.

Combining tank system, heaters, plumbing connections and tank lids, BC40 Presto Black Finishing System features seven individual tanks made of high density polypropylene and polyethylene with 16 x 24 x 24 in. deep dimensions. Offering uniform .000030 in. thickness, unit’s black finishing protects against corrosion and resists up to 1200 hours humidity without peeling. System comes in 3 x 15 ft...

Read More »
Dual Feedback Voice Coil Positioning Stage
Positioners

Dual Feedback Voice Coil Positioning Stage

The VCS20-020-CR-01-MC-F3K voice coil positioning stage has dual feedback capability. It can operate either under closed loop position control with force monitoring or closed loop force control with position monitoring. It uses H2W voice coil motor NCC20-18-020-1A to generate a continuous/peak force of 2.0 lbs [8.9 N]/6.0 lbs [26.7 N] with a total stroke length of 2.0 in [50.8 mm]. The 1-micron...

Read More »
Plastic Technologies Announces New Technology for Smaller Quantity, Injection-Molded Pet Preforms to Support Validation, Market Tests
Molding Machinery

Plastic Technologies Announces New Technology for Smaller Quantity, Injection-Molded Pet Preforms to Support Validation, Market Tests

Holland, Ohio (April 18, 2017) - Brand owners interested in conducting package validation testing (performance, filling line, shipping, etc.) and small test market distribution before committing to a wider launch now have access to a cost-effective alternative. Additionally, converters needing development and production support also can tap into a new resource. Plastic Technologies, Inc. (PTI), a...

Read More »
Pneumatic Saw & Clamp System Cuts Steel Plate Wihout Heat Affect Zone
Hand (Tool) Clamps

Pneumatic Saw & Clamp System Cuts Steel Plate Wihout Heat Affect Zone

A pneumatic saw and clamp system that eliminates torch cutting and lets users produce clean accurate cuts on thick steel plate fast with no heat affect zone (HAZ) is available from ESCO Tool of Holliston, Massachusetts. ESCO’s APS-438 Air-Powered Saw and Quick-Clamp sets up fast using a 2”W steel track and has two wedge-style clamps that attach to steel plate up to 15’W by 3.5” thick and...

Read More »
Hydraulic Chucks can be clamped to drills directly without reduction sleeve.
Chucks and Collets

Hydraulic Chucks can be clamped to drills directly without reduction sleeve.

Suitable for finishing processes with drills, reamers, ball mills, end mills, diamond reamers and grinding tools, Slim Hydraulic Chucks feature 14 mm diameter chuck nose and 40 mm gauge length. Designed for HSK-E 25, HSK-E 32 and HSK-E 40 machine spindles, units can be clamped directly to cutting tools with shank diameter of 3 or 4 mm. Each tool is balanced to deliver speeds up to 60,000 rpm and...

Read More »
Cleanroom Table with Automatic Height Adjustment
Tables

Cleanroom Table with Automatic Height Adjustment

Fullerton, CA – Terra Universal's ErgoHeight™ Auto-Adjusting Cleanroom Work Station is designed to easily and quickly adjust to comfortable heights for sitting or standing. Motorized lifters, encased within the table's legs, lift or lower the table surface based on control panel input. Surface height ranges from 28" to 43" to accommodate personnel of different statures, as well as...

Read More »
MIXO Modular Inserts are resistant to mechanical stresses.
Inserts

MIXO Modular Inserts are resistant to mechanical stresses.

Available with types of connections ranging from small signal connectors with low amp and voltage, up to 200 amp connectors, MIXO Modular Inserts are mounted side by side and locked into metallic frame. Each insert is designed to fit and lock into frame sizes ranging from 1 module to 12 modules. Housing signal, power, data and pneumatics contacts for conduction with up to 8 bars pressure...

Read More »
Mazak Brings Big-part Multi-Tasking Prowess and Advanced CNC to WMTS
Turning Machinery

Mazak Brings Big-part Multi-Tasking Prowess and Advanced CNC to WMTS

FLORENCE, Ky., April 12, 2017 – At WMTS 2017, Mazak Canada will demonstrate how the QTN 450M turning center with Multi-Tasking DONE IN ONE® capabilities boosts productivity and reduces cycle times for large-diameter, shaft-type part manufacturing in industries such as oil and gas. The company will also run simulations of its MAZATROL SmoothX CNC, the industry’s fastest most progressive...

Read More »
How SpinSelect Can Save You Time and Money
Sponsored

How SpinSelect Can Save You Time and Money

Thanks to the unique SpinSelect™ Multi-Pocket selectable quick change tool holder, it's time to rethink the range, complexity and volume of parts that your lathe can produce. Our Spin-Select™ tool was created to increase productivity and consistency by decreasing downtime associated with lathe cutting tool and insert setups or changeovers. This product is a game-changer for the industry and we're pleased to show you why.

Read More »
