Switchmode Power Supplies fit automation applications.

Compact connectPower CP-SNT 55W requires 2 1/4 in. of TS 35 DIN-rail. Models are available in four versions: 24 to 28 Vdc at 2.3 A; 5 Vdc at 3 A; 12 to 15 Vdc at 3.0 A; and 48 Vdc at 1.04 A. All have adjustable outputs, metal housings, inputs of 85 to 265 Vac or 120 to 300 Vdc, overcurrent shutdown with automatic restart, thermal shutdown, and approvals including UL 508 listing, CE, and CSA. The...

Relays provide power and logic control.

SZR-MY relays are available in 2 configurations: DPDT with 5 A load and 4PDT with 3 A load. SZR-LY relays come in same configurations, but break 10 A loads. Optional LED indicator shows when coil is energized, and optional internal surge protection diode protects from back electromotive force. Units are available with either or both options.

Power Supply provides 90% efficiency rating.

Switch mode wipos Series provides 20 A, 24 V with single-phase, 100 to 130 Vac input. Unit features power factor correction according to EN 61000-3-2, temperature-prompted power limitation, adjustable output voltage of 23 to 27 V, and selectable output current balancing during parallel operation. Ramp up time is

Power Controller is PCI hot-plug compliant.

MIC2590 dual-slot controller supports system voltages required by PCI, including 3.3 V auxiliary voltage specified by PCI Standard v2.2. It supports +12, -12, 3.3, 5.0 V primary supplies, and 3.3 V auxiliary supplies with overcurrent protection. IC offers adjustable overcurrent timeout, circuit-breaker fault protection, and undervoltage lockout. Integrated 8-bit ADC monitors voltage and current...

A Complete Guide to Aerospace Metal Fabrication eBook

Check out this eBook to learn all about aerospace metal fabrication - materials, processes, and applications.

Linear Bushings work in one-armed robots.

STAR Torque-Resistant Linear Bushings are suitable for applications requiring shaft guideway to transmit both linear motion and torque while remaining torsionally stiff, such as one-armed swivel grippers or robots. Bushings can be installed without parallel second shaft normally required in standard applications to resist cocking loads. They are available in rotationally symmetrical sleeved or...

Liquid Level Switch suits overfill protection applications.

Mini-Squing vibrating liquid level switch offers tuning fork technology, 3/4 in. mounting, and heartbeat LED. Instrument includes protection against reverse polarity and short circuit connection. Mini-Squing has continuous operating temperature of 300 deg F and handles pressures to 1450 psi. Its variable operating frequency avoids false switching. Direct load switching model suits supplies rated...

USB Receptacle saves space on printed circuit boards.

Upright, right-angle, A-type USB connector reduces footprint by 25% compared to previous products. Connector allows high-speed data transfer between computers and peripherals such as printers, scanners, and video equipment. It has kinked grounding pins for PC retention, and indentations at inlet for mating retention. Height is 0.545 in. Insulator material is black or white, PBT thermoplastic and...

AC/DC Power Supplies provide output of 5 to 22 watts.

OFM Series ultraminiature, modular, switching power supplies accept universal input from 85 to 265 Vac and 47 to 440 Hz. Single outputs of 5 to 24 Vdc are provided by the 18 models. Units include power-good LED and output adjustment potentiometer, and will operate over ambient temperature of 0 to 48 deg C without forced cooling or output power derating. All models contain over voltage and short...

Coaxial Connector will not vibrate loose.

Series 1.0/2.3 coaxial connector interface delivers RF performance in switching equipment operating at frequencies up to 4 GHz. Its push-pull coupling mechanism allows installation and de-coupling, and will not accidentally disconnect. These 50 ohm connectors have working voltage ratings of 250 Vrms and dielectric withstanding voltage rating of 750 Vrms. Straight and right angle connectors have...

Signal Relay meets international standards.

Miniature FTR-B3 through-hole, flat relay measures 10.6 x 7.2 x 5.2 mm, enabling increased packaging density in compact equipment. Heat-resistant material withstands infrared reflow and vapor-phase soldering methods. Relay has minimum insulation distance of 1.6 mm between coil and contacts, 1.5 kV coil-contact withstand voltage, and 2.5 kV coil-contact withstand surge voltage. Relay meets...
