Transformer delivers 0.5 W continuous power.
Model 4283-1400 Miniature High Voltage Output Transformer provides typical operating frequency of 25 kHz and offers up to 800 Vdc output. Surface-mount, application specific DC-DC unit is .495 x .495 x .36 in. With external drive circuitry and internal diodes, minimum efficiency for DC input to DC output is 60%. Transformer can be custom-configured to meet variety of military, medical, and...
Read More »I/O Connector System is suited for server industry.
LaneLink(TM) connectors support InfiniBand(TM) 4X and 12X link technology. Cable-to-board I/O system is optimized for differential signaling at 2.5 Gbps per pair. Its pcb receptacle provides isolation of cable loads from SMT solder tails. Cable wire terminates directly to plug contacts, while wire guide and strain relief captures individual wires and attaches to ground contacts. Pinch-to-release...
Read More »
Edge Connectors support PCI Express(TM) technology.
Edge card connector line includes series of four edge connectors, each with specific bandwidth capabilities. Connectors are suitable for use in computing and data communications applications including PCs, servers, and workstations.
Read More »
Interconnects support notebook, server storage markets.
Serial ATA Interconnects feature differential pair signaling technology and can support 1.5 Gbps. Combined signal and power interface, with built-in hot-plug capability, is suitable for blind-mate applications. Units support 1.8, 2.5, and 3.5 in. form factors with both cabled and direct docking systems.
Read More »
Guide To Swageless Fittings
Electroline specializes in innovative, easy-to-install swageless fittings. The following guide will highlight everything you need to know about swageless fittings.
Read More »
Inverters offer interchangeable operator panels.
MICROMASTER universal drives are available in 4 performance classes: MM410, fractional to 1 hp, 1-phase 120 and 220 V contactor drives; MM420, fractional to 15 hp, 1- and 3-phase, 230 and 460 V basic inverter drives; MM430 variable torque rated inverters; and MM440 units with sensorless vector capability and optional closed loop vector control. All units offer accessible terminals,...
Read More »
Automotive Relay has ultra-miniature package.
Measuring 11.8 x 8.8 x 10.3 mm, surface-mount electromechanical relay offers efficient magnetic circuit structure. Model FTR-P6 consumes 800 mW and has 25 A (14 Vdc) contact rating at locked motor load for 100 K. Capable of handling max inrush current of 35 A, relay has max acoustic noise level of 60 dB/5 cm. Unit's structure withstands vibration and lead-free reflow soldering processes. Its...
Read More »
Stepper Motors provide 5-phase motion control.
Series PCE High Torque Motors are CE-rated and come in 3 lengths from 33 to 98 mm and standard 17, 23 and 34 NEMA sizes. Units offer dielectric strength of 3,000 V and produce nearly 900 oz-in. holding torque. They feature cast iron exterior and are sealed for protection against dust and moisture. High-resolution performance includes 500 Full Steps per Revolution (.72Ã-
Read More »
AC Gearmotors operate at noise thresholds of 29 dB.
V Series AC gearmotors incorporate strengthened shafts that mate to long life (10,000 hours) GV gearheads. Noise-reduction techniques include accurate assembly to micron level. Motors provide output power levels of 6 to 60 W, depending on motor frame size, and include induction, reversible, and electromagnetic brake motors. They can be supplied as 1-phase 110/115 Vac or 220/230 Vac as well as...
Read More »
Power Rocker Switches are available in 3 sizes.
Available in 13 x 19 mm, 14 x 28.5 mm, and 25 x 28.5 mm sizes, switches fit into industry standard panel cutouts. They offer various termination methods, illumination, single/double pole capability, and markings. Dust resistant switches are rated for 16 A at 125 Vac (1/3 HP) and handle capacitive loads of up to 50 A for 3 msec. Actuation force ranges between 150 and 1,250 g (model dependent), and...
Read More »
Switches replace existing instrument and control switches.
Type W Switch is available with maintained, momentary, slip, or lateral contacts. Continuous rating is 20 A at 600 V and interrupt ratings include 5-50 A at 120-600 Vac or 8 A at 125 Vdc. Type W2 rotary-roller-action switch is available with up to 6 rollers. Spring-actuated design provides momentary, maintained, or combination contacting with up to 3 key interlocks. Continuous rating is 20 A at...
Read More »
Locon Sensors Withstand Extreme Temperatures
Locon Sensor Systems offer robust sensor solutions for even the most severe environmental conditions. Their line of high-temp inductive sensors and their cylindrical photoelectric series can operate in temperatures up to 250 degrees Celsius. See our video to learn more.
Read More »
