New Electrical Equipment & Systems Products

Terminal interfaces standard valve terminals to Fieldbus systems.

CPX system is based upon configurable modules, where different electrical functions and pneumatic interface can be assembled to meet requirement. It is constructed in sandwiched functional layers consisting of interlinking base block, electronics intermediate module, and connection top block. Electronics modules are either analog or digital. System supports DeviceNet, Profibus-DP, Interbus,...

DC/DC Converters offer 4 to 1 input voltage ranges.

Series UHE 25-30 W converters include Model Q12 with input range of 9-36 V, and Model Q48 with input range of 18-75 V. They come in 1.6 x 2 x 0.4 in. encapsulated plastic package, and feature 1500 Vdc isolation, efficiencies as high as 90% and I/O protection. Output voltages and currents include 3.3 V @ 7.5 A, 5 V @ 5 A, 12 V @ 2.5 A, and 15 V @ 2 A. Units are UL/EN/IEC60950 certified and suited...

Battery provides front access.

Liberty Series 1000Ã-® FAM 12-100 valve regulated lead-acid battery has front terminal to simplify installation and reduce maintenance. Battery, with 100 A-hr rating, uses low-calcium lead alloy, which extends battery life through low grid corrosion and low gassing. Features include flame retardant polypropylene jar and cover that meet UL94 VO and flame arresting one-way low-pressure release...

Valve Regulated Lead-Acid Battery suits cellular applications.

Liberty Series 2000 SuperMAXÃ-® Battery System offers 295-2,000 A-hr capacity. Positive grids improve plate performance an average of 4.6% at 8 hr rate to 1.75 vpc cutoff. Able to maintain cell compression without mechanical devices, plates are oriented horizontally. Maximizer(TM) internal catalyst reduces float current and limits oxygen and hydrogen loss. Rack base incorporates solid steel...

Selecting the Right Materials for Your Metal Stamping Project

Learn about metals and their characteristics to help you choose the right option for your unique application.

Battery has 2000 A-hr capacity.

LibertyÃ-® Series 2000 SuperMAX(TM) HD-2000 valve regulated lead-acid battery features horizontal plate orientation and movable positive post seal. System has rack frames, removable shelves, and solid base plate. Two Maximizer(TM) catalysts aid in recombination process, reduce float current, and maintain cell capacity. Low gravity model SuperMAX HDL-1700 is for low float applications at 2.2O...

DC/DC Converters deliver up to 60 A output current.

Single-output ALQ Series converters, with quarter-brick configuration, measure 0.38 in. high and offer open-frame construction suited to Distributed Power Architecture (DPA) applications. Operating from input voltage range of 36-75 V, ALQ models are available with 3.3, 2.5, 1.8, and 1.2 V output voltages. Devices feature clean monotonic output startup characteristic and -40 to +185Ã-

Pressure Switches suit OEM applications.

Series MDA Miniature Adjustable Pressure Switches protect against false actuation from shock and vibration. SPST normally open type units can be used in single or differential pressure applications and are compatible with air or liquids. Each has current rating of 40 mA resistive for life in excess of 20 million cycles, and operating temperature of 40-150Ã-

Control Relays feature Category 4 safety rating.

Safe 2.2 Series features 22.5 mm housing, LED visual indicators for state of operation, power indication for both channels, opposite polarity between channels, and 2 normally open safety contacts. Relays are suited for applications where safety mats, safety edges, or E-stop controls are utilized.

KVM Switch allows audio and peripheral sharing.

Model FS-102ATL 2-port switch offers dual functionality for PC control and peripheral sharing via USB link. Mini-tower console saves space by controlling 2 desktop or notebook PCs, Sun, or Mac machines through one keyboard, monitor, and mouse. It permits connected PC machines to transfer files via TCP/IP and directly share audio speakers and other USB peripheral devices. Simultaneous system...

Cradle/Straightner/Feeder offers hands-free loading.

Model CSF handles coil weights from 10,000-60,000 lb and up to 120,000 psi yield material. It accommodates material thicknesses of .040-.750 in. Main unit consists of 1 set of feed rolls, 7 straightening rolls, and 1 set of input threading rolls. Multi-pitch gear train directly drives upper and lower feed rolls throughout feeding process. Solid steel 2-roll coil rest supports and pays off...
