New Electrical Equipment & Systems Products

Step-Up DC/DC Converter suits battery back-up applications.

Housed in SOT-23 package, LTC3459 consists of 10 V synchronous boost DC/DC converter with onboard output disconnect and inrush current limiting. It operates from input voltage of 1.5-5.5 V, and, at 5 V input voltage, generates 8 V @ 30 mA. Features include constant off-time architecture, short circuit protection, and Burst ModeÃ-® operation, which uses only 10 Ã-µA of quiescent current....

Embedded Processor is available in 3 versions.

NiosÃ-® II family consists of three 32-bit RISC embedded soft-core processors that deliver more than 200 DMIPS: one for maximum system performance, one optimized for minimum logic usage, and one in-between. All cores are 100 percent code compatible and include software development suite with compiler, IDE, JTAG debugger, MicroC/OS-II RTOS, and TCP/IP stack. Developers can also add up to 256...

Controller and Power Module suit Ethernet-powered appliances.

Model TPS2375 IC controller manages discovery, classification, and delivery of dc power to powered device, while providing power management control and protection. It withstands transients to 100 V and features 15 kV system-level ESD capability. Power-over-Ethernet plug-in power module PTB48540 helps detect, classify, and deliver up to 10 W of dc power. Requiring external Power-over-Ethernet...

Distribution Blocks are rated 120 V, 20 A.

Available in water-tight or weather-proof models, GFCI Distribution Blocks are molded from Hypalon rubber. Water-Tight sealed GFCI in-line block is submersible in up to 3 ft of standing water and has permanently sealed cover. Internal GFCI can be reset from top of block without removing cover. Weather-Proof GFCI block features 55 A max input, 20 A output, and 120 V per receptacle. Each receptacle...

Choosing the Optimal IDC & Medical PPE Supplier

This white paper provides an in-depth overview into infectious disease control (IDC) medical PPE including development, key benefits, applications and product offerings.

PCB Key Switches handle up to 100 mA.

Tested to more than 3 million operations without failure, RACON Series has operating life of 1 million actuations at full load. Surface-mount and through-hole versions contain no lead, cadmium, or mercury and are compatible with lead-free soldering processes. RACON 8 devices measure 8.4 mmÃ-² x 5 mm high and have operating force of 2.5 N with switching travel of 0.6 mm. RACON 12 switches...

OPGW Cable enables optical communications.

Providing electrical grounding protection, 6841 Optical Ground Wire (OPGW) functions as drop-in communications cable replacement for overhead ground or static wire. Designs use stainless steel or aluminum tubes along with aluminum-clad steel and aluminum-alloy wires to provide electrical grounding protection, mechanical strength, and optical fiber protection. They are available with TeraLight...

Fixed Cord PDUs facilitate cable management and airflow.

HP Fixed Cord Extension Bars and Fixed Cord PDUs (power distribution units) aid in managing cable clutter in back of rack and improve airflow throughout the enclosure. Made for 1U fixed rail servers, output cords are fixed to PDU extension bar to reduce chances of accidental disconnection. Each output cord is 13 in. long, and there are 7 output cords per extension bar. Fixed cord PDU kits provide...

UTP Cables extend video and data transmission.

BrillianceÃ-® VideoTwist(TM) Unshielded Twisted Pair (UTP) Cables deliver video and data in plenum and riser versions over distances of 1,300 ft and beyond depending on transmission equipment. VideoTwist Nanoskew(TM) 7987P and 7987R are suited for video-only transmissions, while other models suit component video, data, and KVM applications. With bonded-pair construction, VideoTwist 7988 and...

Miniature Slide Switches suit variety of PCB applications.

Miniature SPDT EG1260 series features 2 optional SMT mounting configurations and 3 slide actuator sizes. Designed with electrical life of 10,000 cycles, products are rated at 0.3 A @ 4 Vdc. Designed with chamfered locating pins, dimensions are 0.106 x .264 x 0.055 in. Actuation force is rated at 150 g Ã-

DC-AC Inverter offers closed-loop current control.

Class W6m Inverter provides open lamp detection, input voltage range of 8-18 Vdc, and low profile of 6 mm for LCDs backlit by CCFL. Designed around custom on-board IC, unit's closed loop current control provides regulated output that maintains consistent lamp brightness, unaffected by variations in input voltage. Inverter includes on-board dimming and is suited for battery-powered and portable...
