Electrical Equipment & Systems

Power Supply/Temperature Controller is rack mountable.
Controls and Controllers

Power Supply/Temperature Controller is rack mountable.

SHPS8KW closed loop power supply and digital temperature controller powers all types of heaters including PGG or PBN Button Substrate Heaters. When used with Neocera heater assembly, it provides stability of better than ±1°C. Unit features 8 kW output power, Watlow Series 145 temperature limit with LED output status indicators, Type-K thermocouple, and SCR protection via 3 rear panel...

Read More »
AC motors can replace PMDC motors.
Motors

AC motors can replace PMDC motors.

MicroMAX(TM) line of low horsepower ac inverter duty motors are direct replacement for permanent magnet dc (PMDC) systems. Available in l/4 to 3 hp, C face motors have same mounting configuration as PMDC counterparts, including foot print, flange dimensions, shaft length, and diameter. They can be equipped with PWM scalar drive.

Read More »
Housed Low Liquid Level Switch uses magnetic reed switch.
Switches

Housed Low Liquid Level Switch uses magnetic reed switch.

Designed to actuate devices when liquid supply fails or recedes to predetermined levels, switch can be wired to flash warning light, sound howler, shut off machine, or signal computer. Level switches operate at pressures up to 125 PSI and temperatures of 170°F. Buna N seals are used throughout, large liquid passages are provided, and float chamber has 2 end plates of aluminum alloy, which...

Read More »
Modular Jack fits on printed circuit board.
Connectors

Modular Jack fits on printed circuit board.

CAT5 modular RJ45 jack can be used in high-speed networking and communication applications such as Ethernet, LANs, hubs, and routers. Jack is made of gray PBT thermoplastic, has standard contacts that are gold flash or plated with 50Â-µ gold, and is fully shielded to reduce EMI/RFI. Slim profile allows for positioning flexibility on PC board. Total height of the connector is 0.650 in.

Read More »
Non-Isolating Transmitters are powered by 4-20 mA loop.
Transmitters

Non-Isolating Transmitters are powered by 4-20 mA loop.

LPN-Series includes potentiometer, RTD transmitter, and in-head RTD transmitter. Potentiometer has LED indication of loop current, reverse polarity protection and DIN rail mount enclosure. Model LPN-R takes input from Pt 100 RTD linearizes temperature, and sends 40-200mV output test signal. In-Head 3-wire RTD transmitter fits RTD connection heads. It is available in standard or special...

Read More »
Explosion-Proof Control Enclosures are ATEX-certified.
Enclosures

Explosion-Proof Control Enclosures are ATEX-certified.

XCEX Series is used in installation of electrical and electronic components for control, measurement, or monitoring applications in hazardous environments. Enclosures feature copper-free aluminum construction, which is corrosion resistant with tumblast finish. Wall thicknesses are uniform to aid in installation of control devices, windows, and conduit openings. Integral, cast-on mounting lugs are...

Read More »
Headers and Sockets are available in various heights.
Electrical Connectors

Headers and Sockets are available in various heights.

PTT Series press fit 2mm pitch headers and PTF Series sockets provide board-to-board spacing of 8,36mm when mated. Elevated version of PTF socket provides mated height of 11,15mm. Dual row interconnects are available in any number of positions per row up to 50. ESQT Series interconnects meet all PC 104+ specifications by providing 4 rows x 30 positions; 9,35mm socket height; and both...

Read More »
DC/DC Converter features dual outputs of 3.3 and 5 volts.
Power Supplies

DC/DC Converter features dual outputs of 3.3 and 5 volts.

VSX60 60W converter includes power trading facility that enables full 60W to be provided from either output. Unit is available in 2 versions with input voltage ranges of 18-36V or 36-75V. Input-to-output isolation is specified as 1500 VDC. VSX60 features input filtering, remote on/off with positive or negative logic, and non-latching protection against undervoltage, overvoltage, short-circuit,...

Read More »
Integrated Circuit predicts fan failure.
Circuits

Integrated Circuit predicts fan failure.

TC670 detects critical fan speed of 2-wire and 3-wire fans and provides thermal failure protection in temperature-sensitive equipment. It predicts fan failure by sensing fan revolutions and asserting logic-low alert signal whenever fan speed falls below user programmable trip point. Single resistor divider is adequate for setting RPM alarm level, eliminating need for software. Unit also features...

Read More »
